. 1989 Jun;413:75–89. doi: 10.1113/jphysiol.1989.sp017642

Characterization of proton currents in neurones of the snail, Lymnaea stagnalis.

L Byerly 1, Y Suen 1
PMCID: PMC1189089  PMID: 2557442

Abstract

1. Internal perfusion voltage-clamp and inside-out patch-clamp techniques were used to study the voltage-dependent H+ currents in snail neurone cell bodies. 2. In whole cells the voltage-activated outward H+ current was measured 60 ms after stepping to +40 mV with an internal pH (pHi) of 5.9 and no internal K+([K+]i = 0), and the delayed K+ current was measured 60 ms after stepping to +40 mV with pHi = 7.3 and [K+]i = 74 mM. The mean H+ and K+ current densities were 14.6 +/- 7.8 and 38.2 +/- 14.0 nA/nF, respectively, giving a mean ratio of the H+ to K+ current of 0.4 +/- 0.2. There is not a strong correlation between the densities of the two kinds of outward currents found in different cells. 3. Inside-out patch studies reveal that the H+ and K+ currents are distributed quite differently in the membrane. While 85% of all patches had K+ current, only five out of thirty-eight patches studied had H+ currents. In those five patches the H+ currents measured at +30 mV ranged from 10.7 to 21.0 pA, and the ratio of the H+ and K+ currents at +30 mV was 0.83 +/- 0.38. The mean H+ and K+ currents for all thirty-eight patches were 1.9 +/- 4.9 and 10.5 +/- 7.9 pA, respectively. 4. The current distribution patterns demonstrate that the H+ current does not flow through the delayed K+ current channels even though the two currents have similar voltage dependence and time course. 5. The relative ability of various extracellular divalent cations to block the H+ current was found to be Cu2+ approximately equal to Zn2+ greater than Ni2+ greater than Cd2+ greater than Co2+ greater than Mn2+ greater than Mg2+ = Ca2+ = Ba2+. Since 100 microM-Zn2+ blocks the H+ current more than it blocks the Ca2+ current, it can be used to reduce the contamination of Ca2+ current measurements by the H+ current. 6. The magnitude of the H+ current has a stronger temperature sensitivity than does the magnitude of the delayed K+ current. The Q10 of the H+ current magnitude is 2.1 +/- 0.4, while the Q10 of the K+ current magnitude is 1.4 +/- 0.04. This suggests a higher activation energy may be involved in the conduction of the H+ current than for K+ current. 7. The smooth time course of the H+ current measured in patches indicates that the size of the unitary H+ current is very small.(ABSTRACT TRUNCATED AT 400 WORDS)

Full text

PDF
75

Selected References

These references are in PubMed. This may not be the complete list of references from this article.

  1. Barish M. E., Baud C. A voltage-gated hydrogen ion current in the oocyte membrane of the axolotl, Ambystoma. J Physiol. 1984 Jul;352:243–263. doi: 10.1113/jphysiol.1984.sp015289. [DOI] [PMC free article] [PubMed] [Google Scholar]
  2. Byerly L., Chase P. B., Stimers J. R. Calcium current activation kinetics in neurones of the snail Lymnaea stagnalis. J Physiol. 1984 Mar;348:187–207. doi: 10.1113/jphysiol.1984.sp015105. [DOI] [PMC free article] [PubMed] [Google Scholar]
  3. Byerly L., Hagiwara S. Calcium currents in internally perfused nerve cell bodies of Limnea stagnalis. J Physiol. 1982 Jan;322:503–528. doi: 10.1113/jphysiol.1982.sp014052. [DOI] [PMC free article] [PubMed] [Google Scholar]
  4. Byerly L., Meech R., Moody W., Jr Rapidly activating hydrogen ion currents in perfused neurones of the snail, Lymnaea stagnalis. J Physiol. 1984 Jun;351:199–216. doi: 10.1113/jphysiol.1984.sp015241. [DOI] [PMC free article] [PubMed] [Google Scholar]
  5. Byerly L., Moody W. J. Intracellular calcium ions and calcium currents in perfused neurones of the snail, Lymnaea stagnalis. J Physiol. 1984 Jul;352:637–652. doi: 10.1113/jphysiol.1984.sp015314. [DOI] [PMC free article] [PubMed] [Google Scholar]
  6. Byerly L., Moody W. J. Membrane currents of internally perfused neurones of the snail, Lymnaea stagnalis, at low intracellular pH. J Physiol. 1986 Jul;376:477–491. doi: 10.1113/jphysiol.1986.sp016165. [DOI] [PMC free article] [PubMed] [Google Scholar]
  7. Fenwick E. M., Marty A., Neher E. Sodium and calcium channels in bovine chromaffin cells. J Physiol. 1982 Oct;331:599–635. doi: 10.1113/jphysiol.1982.sp014394. [DOI] [PMC free article] [PubMed] [Google Scholar]
  8. Fukushima Y., Hagiwara S. Currents carried by monovalent cations through calcium channels in mouse neoplastic B lymphocytes. J Physiol. 1985 Jan;358:255–284. doi: 10.1113/jphysiol.1985.sp015550. [DOI] [PMC free article] [PubMed] [Google Scholar]
  9. Hagiwara S., Byerly L. Calcium channel. Annu Rev Neurosci. 1981;4:69–125. doi: 10.1146/annurev.ne.04.030181.000441. [DOI] [PubMed] [Google Scholar]
  10. Hagiwara S., Ohmori H. Studies of calcium channels in rat clonal pituitary cells with patch electrode voltage clamp. J Physiol. 1982 Oct;331:231–252. doi: 10.1113/jphysiol.1982.sp014371. [DOI] [PMC free article] [PubMed] [Google Scholar]
  11. Hamill O. P., Marty A., Neher E., Sakmann B., Sigworth F. J. Improved patch-clamp techniques for high-resolution current recording from cells and cell-free membrane patches. Pflugers Arch. 1981 Aug;391(2):85–100. doi: 10.1007/BF00656997. [DOI] [PubMed] [Google Scholar]
  12. Kostyuk P. G., Krishtal O. A., Shakhovalov Y. A. Separation of sodium and calcium currents in the somatic membrane of mollusc neurones. J Physiol. 1977 Sep;270(3):545–568. doi: 10.1113/jphysiol.1977.sp011968. [DOI] [PMC free article] [PubMed] [Google Scholar]
  13. Lee K. S., Tsien R. W. Reversal of current through calcium channels in dialysed single heart cells. Nature. 1982 Jun 10;297(5866):498–501. doi: 10.1038/297498a0. [DOI] [PubMed] [Google Scholar]
  14. Meech R. W., Thomas R. C. Voltage-dependent intracellular pH in Helix aspersa neurones. J Physiol. 1987 Sep;390:433–452. doi: 10.1113/jphysiol.1987.sp016710. [DOI] [PMC free article] [PubMed] [Google Scholar]
  15. Plant T. D., Standen N. B. Calcium current inactivation in identified neurones of Helix aspersa. J Physiol. 1981 Dec;321:273–285. doi: 10.1113/jphysiol.1981.sp013983. [DOI] [PMC free article] [PubMed] [Google Scholar]
  16. Stevens C. F. Inferences about membrane properties from electrical noise measurements. Biophys J. 1972 Aug;12(8):1028–1047. doi: 10.1016/S0006-3495(72)86141-1. [DOI] [PMC free article] [PubMed] [Google Scholar]
  17. Thomas R. C., Meech R. W. Hydrogen ion currents and intracellular pH in depolarized voltage-clamped snail neurones. Nature. 1982 Oct 28;299(5886):826–828. doi: 10.1038/299826a0. [DOI] [PubMed] [Google Scholar]
