Abstract
Image Markup Language is an extensible markup language (XML) schema used to describe both image metadata and annotations. It describes both data pertaining to an entire image, and data that are tied to specific regions or features of the image. Developed for a specific domain in Medical Education, this pa-per describes extensions to take advantage of the Dublin Core metadata standard, and of an XML schema for vector graphics representation. We have developed a prototype system of open source tools implementing an authoring system, a client system, and an image annotation database which can be queried though the Web.
Full text
PDF
Selected References
These references are in PubMed. This may not be the complete list of references from this article.
- Brinkley J. F., Bradley S. W., Sundsten J. W., Rosse C. The digital anatomist information system and its use in the generation and delivery of Web-based anatomy atlases. Comput Biomed Res. 1997 Dec;30(6):472–503. doi: 10.1006/cbmr.1997.1461. [DOI] [PubMed] [Google Scholar]
