Xenodiagnosis using Ixodes scapularis larvae in humans is safe and well tolerated. There is no evidence of persistence of infection after antibiotic therapy in the majority of individuals.
Keywords: xenodiagnosis, Ixodes scapularis, Lyme disease, Borrelia burgdorferi, human
Abstract
Background. Animal studies suggest that Borrelia burgdorferi, the agent of Lyme disease, may persist after antibiotic therapy and can be detected by various means including xenodiagnosis using the natural tick vector (Ixodes scapularis). No convincing evidence exists for the persistence of viable spirochetes after recommended courses of antibiotic therapy in humans. We determined the safety of using I. scapularis larvae for the xenodiagnosis of B. burgdorferi infection in humans.
Methods. Laboratory-reared larval I. scapularis ticks were placed on 36 subjects and allowed to feed to repletion. Ticks were tested for B. burgdorferi by polymerase chain reaction (PCR), culture, and/or isothermal amplification followed by PCR and electrospray ionization mass spectroscopy. In addition, attempts were made to infect immunodeficient mice by tick bite or inoculation of tick contents. Xenodiagnosis was repeated in 7 individuals.
Results. Xenodiagnosis was well tolerated with no severe adverse events. The most common adverse event was mild itching at the tick attachment site. Xenodiagnosis was negative in 16 patients with posttreatment Lyme disease syndrome (PTLDS) and/or high C6 antibody levels and in 5 patients after completing antibiotic therapy for erythema migrans. Xenodiagnosis was positive for B. burgdorferi DNA in a patient with erythema migrans early during therapy and in a patient with PTLDS. There is insufficient evidence, however, to conclude that viable spirochetes were present in either patient.
Conclusions. Xenodiagnosis using Ixodes scapularis larvae was safe and well tolerated. Further studies are needed to determine the sensitivity of xenodiagnosis in patients with Lyme disease and the significance of a positive result.
Clinical Trials Registration NCT01143558.
(See the Editorial Commentary by Bockenstedt and Radolf on pages 946–8.)
Lyme disease, caused by Borrelia burgdorferi and transmitted by Ixodes ticks, is the most common tick-borne illness in the United States and Europe [1]. Borrelia burgdorferi enters the skin at the site of the tick bite, typically resulting in the erythema migrans (EM) skin lesion. From the inoculation site, the organism can disseminate and affect the heart, joints, and central nervous system. Antibiotic therapy resolves clinical symptoms in most cases [2].
A minority of patients will have persistent or relapsing nonobjective symptoms (eg, fatigue, musculoskeletal pain, and cognitive complaints, called posttreatment Lyme disease syndrome, [PTLDS]) after receiving a recommended course of antibiotic therapy. The pathogenesis of PTLDS remains an area of great controversy [3]. Evidence of ongoing infection has not been found using polymerase chain reaction (PCR) or culture [4, 5]. Current antibody-based assays cannot determine successful eradication of the organism. Randomized placebo-controlled trials have not shown significant, sustained benefit of retreatment with antibiotic therapy in patients with PTLDS [4–6].
Recent animal data suggest that eradication of B. burgdorferi by antibiotics may be incomplete. Studies in dogs, mice, and monkeys have shown that B. burgdorferi DNA can be detected in tissues for up to 9 months after antibiotic therapy [7–12]. Xenodiagnosis, the use of a vector to detect the presence of an organism, has been used to detect B. burgdorferi in animal studies [13–15]. Ixodes ticks fed on antibiotic-treated mice and monkeys were able to acquire B. burgdorferi, as demonstrated by PCR of the tick and, in some mice studies, transmission to immunodeficient mice during the next blood meal [9–12]. However, some of the animal studies have had methodological concerns [16–18], including infection by needle inoculation instead of tick transmission, use of high-dose inocula of cultured spirochetes, and inability to replicate the antibiotic pharmacokinetics and exposure expected in humans; and, by their very nature, have limited generalizability to human disease.
Here, we present the results of the first study of the use of I. scapularis larvae for xenodiagnosis of B. burgdorferi infection in humans.
METHODS
Study Protocol
Written informed consent was obtained from all participants. The study was approved by the institutional review board at each center and was conducted in accordance with Good Clinical Practice guidelines and under an investigational device exemption approved by the Food and Drug Administration. An independent medical monitor reviewed interim data for safety.
Participants were enrolled at 3 sites in Massachusetts, Connecticut, and Maryland. All patients were 18 years of age or older. Healthy volunteers resided in endemic areas (Maryland and Massachusetts), had no history of Lyme disease, and were seronegative by C6 antibody enzyme-linked immunosorbent assay (Immunetics, Inc). The patient with EM on treatment (potential positive control) had EM diagnosed by a study physician and started antibiotic therapy concomitantly with tick placement. Patients in the posttreatment EM group had EM diagnosed by a physician and had completed recommended antibiotic therapy [2] between 1 and 4 months before enrollment. Subjects enrolled in the high C6 antibody group had Lyme disease [19], received recommended therapy [2], and had a C6 antibody index >3 for at least 6 months after completion of therapy. Subjects with PTLDS had Lyme disease [19], had received a minimum of 1 course of recommended therapy [2], and had persistent nonspecific symptoms that began coincident with the onset of Lyme disease, which were severe enough to cause a reduction in activities. Subjects in the high C6 antibody and PTLDS groups could not have received antibiotics within 3 months of enrollment.
Study Design
Subjects had 25–30 pathogen-free I. scapularis larval ticks (Supplementary Appendix) placed over a 7-cm2 area under a modified retention dressing (Le Flap, Monarch Labs, Irvine, California; Figure 1).When possible, an area where disease was observed (EM site, close to an affected joint) was selected. Ticks were collected 3–7 days after placement. Two 2-mm skin punch biopsies were performed at the exact sites of tick feeding. If <14 engorged ticks were recovered, individuals could repeat the procedure if they still met entry criteria. A repeat procedure was also offered to individuals with a positive xenodiagnostic result.
Figure 1.
Dressing used for xenodiagnosis. The left panel depicts the LeFlap dressing with unfed ticks placed on the forearm of a subject. The right panel shows the attached feeding ticks.
Participants completed a diary card for the first month, and assessments were done at 7 days, 1 month, and 3 months after tick removal. Adverse events were graded according to the Division of AIDS Table for Grading Adult and Pediatric Adverse Experiences [20].
Testing of Xenodiagnostic Ticks
Two protocols were used for processing of xenodiagnostic ticks. Ticks were tested individually unless noted. In protocol 1, live replete ticks were kept in a humidified chamber. Approximately 3 weeks after molting, nymphal ticks were fed on C3H/HeN severe combined immunodeficiency (SCID) mice. Replete ticks were analyzed for infection by PCR and culture [21, 22] (Supplementary Appendix). SCID mice were monitored for infection by culture and PCR of ear punch biopsies at 2 weeks after tick feeding, and at 4 weeks by culture and PCR of skin, ankle joint, heart, and bladder tissues.
A modified protocol (protocol 2) was used after the 23rd xenodiagnostic procedure. Recovered ticks were kept in a humidified chamber for 11–14 days. Ticks were crushed and tested by PCR and injection of the lysate subcutaneously into an SCID mouse and/or by isothermal amplification followed by PCR and electrospray ionization mass spectroscopy (IA/PCR/ESI-MS) [23–27] (Supplementary Appendix). Skin biopsies were tested by culture and culture PCR. Direct IA/PCR/ESI-MS testing was performed in the skin biopsy of 6 subjects.
Xenodiagnosis was considered positive when any of the techniques demonstrated B. burgdorferi or its DNA in a xenodiagnostic tick(s) or in tissue from the SCID mice injected with tick lysate or fed upon by nymphal ticks.
Culture, PCR, and SCID mouse infection were performed at Tufts Medical Center. The investigators were not blinded to participant group status. Testing by IA/PCR/ESI-MS was performed at Ibis Biosciences without knowledge of participant group status.
RESULTS
Subject Characteristics
A total of 36 subjects were enrolled in the study (21 men and 15 women, with a median age of 55 years). Participants who underwent xenodiagnosis included 10 patients with high C6 antibody levels, 10 patients with PTLDS, 5 patients with EM after completion of antibiotic therapy, 1 patient with EM on therapy, and 10 healthy volunteers (Table 1). All patients acquired the infection in the eastern United States. Seven patients underwent >1 xenodiagnostic procedure. These included 5 individuals in the high C6 group, 1 individual in the PTLDS group, and the individual with EM (7 months after completion of antibiotic therapy).
Table 1.
Participant Demographic Data
| ID | Group | US State Where Patient Acquired Infectiona | Lyme Disease Presentation | Time From Suspected Infection to Therapy, d | Time From Diagnosis to Therapy, d | Time From Diagnosis to Procedure, d | No. of Treatments, IV/Oral | C6 Index | IgG WB | IgM WB | Symptoms Present in the Month Before Enrollmentb |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A-01 | EM | MA | EM | 0 | 0 | 0 | 0/1 | 0.5 | 0/10 | 1/3 | D |
| B-01 | EM PTx | CT | EM | 13 | 0 | 71 | 0/1 | 4.9 | 1/10 | 1/3 | |
| B-02 | EM PTx | WV | MEM | 11 | 0 | 96 | 0/1 | 4.41 | 2/10 | 2/3 | D |
| B-03 | EM PTx | WV | MEM | 15 | 0 | 126 | 0/1 | 3.89 | 3/10 | 3/3 | D |
| B-04 | EM PTx | MD | EM | 38 | 1 | 115 | 0/2 | 5.14 | 3/10 | 3/3 | |
| B-05 | EM PTx | MA | EM | 14 | 0 | 138 | 0/1 | 1.94 | 7/10 | 1/3 | B, D |
| C-02 | High C6 | VA | EM | 1 | 0 | 3941 | 0/7 | 5.43 | 2/10 | 1/3 | B, D |
| C-03 | High C6 | MD | Arthritis | 717 | 0 | 1081 | 0/1 | 9.57 | 6/10 | 0/3 | C |
| C-04 | High C6 | MD | MEM, FP | 24 | 0 | 1802 | 0/1 | 5.74 | 4/10 | 1/3 | B, D, I, N |
| C-05 | High C6 | MD | FP, meningitis | 47 | 0 | 714 | 1/1 | 4.63 | 3/10 | 3/3 | F, G |
| C-06 | High C6 | VA | EM, arthritis | 988 | 8 | 894 | 1/2 | 8.72 | 9/10 | 1/3 | B, D, G, K, L, N |
| C-07 | High C6 | MD | Arthritis | 16 | 16 | 1473 | 0/2 | 9.42 | 10/10 | 1/3 | A, B, D, M, N |
| C-08 | High C6 | MD | Arthritis | 10 | 1 | 186 | 0/1 | 5.32 | 7/10 | 0/3 | |
| C-09 | High C6 | MD | MEM | 12 | 0 | 2098 | 0/3 | 3.406 | 5/10 | 1/3 | B, C, D, F, I, K, L, M, N |
| C-01 | High C6 | MA or NJ | NB, arthritis | 2679 | 0 | 2073 | 1/3 | 5 | 7/10 | 1/3 | B, D, M, N |
| C-10 | High C6 | MA | EM | 0 | 0 | 5416 | 0/3 | 5 | 10/10 | 0/3 | |
| D-01 | PTLDS | CT | EM | 15 | 0 | 6249 | 1/1 | 2.31 | 2/10 | 2/3 | A, B, C, D, E, F, G, H, I, J, K, L, M, N |
| D-02 | PTLDS | MD | Arthritis | 23 | 0 | 411 | 0/1 | 11.04 | 10/10 | 2/3 | B, D, F, G, H, I, K, L, M, N |
| D-04 | PTLDS | VA | FP | 228 | 0 | 1721 | 0/4 | 4.31 | 10/10 | 1/3 | B, D, F, M, N |
| D-03 | PTLDS | MA | EM | 33 | 33 | 2748 | 0/1 | 5 | 7/10 | 2/3 | B, D, M, N |
| D-05 | PTLDS | MA | EM | 30 | 0 | 256 | 0/1 | 5.39 | 1/10 | 1/3 | D, M, N |
| D-06 | PTLDS | MA | EM | 4 | 0 | 1050 | 0/1 | 0.53 | 1/10 | 1/3 | D, M, N |
| D-07 | PTLDS | MA | Arthritis | 329 | 0 | 322 | 1/2 | 3.31 | 9/10 | 1/3 | B |
| D-08 | PTLDS | MA | EM, arthritis | 17 | 10 | 3068 | 0/2 | 5 | 6/10 | 1/3 | B, D, F, M, N |
| D-09 | PTLDS | PA | EM, arthritis | 119 | 56 | 438 | 1/1 | 0.97 | 2/10 | 1/3 | B, D, F, G, I, K, L, M, N |
| D-10 | PTLDS | MA | PN | 180 | 0 | 2247 | 0/2 | 5 | 10/10 | 1/3 | B, D, G, I, K |
Abbreviations: C6 index, IgG and IgM Western blot results at study entry; EM, erythema migrans; EM PTx, after completing antibiotic therapy for erythema migrans; FP, facial palsy; IgG, immunoglobulin G; IgM, immunoglobulin M; IV, intravenous; MEM, multiple erythema migrans; NB, neuroborreliosis; PN, peripheral neuropathy; PTLDS, posttreatment Lyme disease syndrome; WB, Western blot.
a CT, Connecticut; MA, Massachusetts; MD, Maryland; NJ, New Jersey; PA, Pennsylvania; VA, Virginia; WV, West Virginia.
b A, decreased appetite; B, arthralgia; C, cough; D, fatigue; E, fevers; F, headaches; G, stiff neck; H, abdominal pain; I, myalgia; J, nausea; K, tingling; L, numbness; M, difficulty concentrating; N, memory problems.
Patients in the high C6 group enrolled a median of 4.5 years after their original diagnosis and received a median of 2.5 courses of antibiotics. The most common presenting manifestation in high C6 patients was Lyme arthritis (Table 1).
Patients in the PTLDS group enrolled a median of 3.8 years after their original diagnosis and received a median of 2 courses of antibiotics. Three of 10 individuals had received intravenous antibiotic therapy. The most common initial presenting manifestation of Lyme disease in PTLDS patients was EM (Table 1). The most common symptoms at enrollment were fatigue, difficulty concentrating, memory complaints, and arthralgias. Eight of the 10 patients still had elevated C6 antibody titers and/or a positive Lyme disease immunoglobulin G (IgG) Western blot (Table 1).
Tick Placement Procedure
As no previous protocol for xenodiagnosis with I. scapularis larvae in humans existed, we developed a retention dressing using the Le Flap dressing, modified for use with ticks. Subjects enrolled early in the trial had fewer ticks feed successfully due to entrapment of the ticks in the adhesive. After the addition of a foam ring to create a barrier between ticks and adhesive, we were able to get between 30% and 50% of ticks to feed successfully. Figure 1 shows the dressing used and images before and after xenodiagnosis. Larval ticks required 4–5 days to feed to repletion, (mean, 4.6 days [range, 3–7 days]).
Adverse Events
Xenodiagnosis was well tolerated (Table 2). All subjects successfully completed the tick placement and there were no withdrawals during the study. The most common adverse event was mild itching at the site, which was seen in 58% of subjects, with a median duration of 3 days. Repeat of the xenodiagnosis procedure was similarly well tolerated, with mild itching at the site being the most common complaint. There were no serious adverse events associated with the procedure.
Table 2.
Adverse Events
| Adverse Event | No. of Episodes |
|---|---|
| Itching at the xenodiagnosis site | 27 episodes in 21 subjects |
| Itching related to the dressing | 6 episodes in 6 subjects |
| Itching to skin punch biopsy site | 4 episodes in 3 subjects |
| Erythema at the skin punch biopsy site | 2 episodes in 2 subjects |
| Upper respiratory infection | 10 episodes in 8 subjects |
| Headache | 8 episodes in 7 subjects |
| Mild nausea without apparent cause | 3 episodes in 3 subjects |
Adverse events that occurred in >1 subject are shown.
Other adverse events included 10 episodes of mild upper respiratory symptoms, which occurred in 8 individuals. Eight episodes of headaches occurred in 7 subjects. Two episodes were graded as moderate and 1 as severe, and occurred 1–3 months after the procedure. All 7 individuals had a prior history of recurrent headaches.
Testing of Xenodiagnostic Ticks
A total of 162 engorged or partially engorged ticks was recovered from the initial 23 subjects and processed using protocol 1, which included molting and feeding of nymphs on SCID mice. Of these 162 ticks, 80 ticks molted to nymphs, and 77 nymphs were placed on SCID mice. Only 37 nymphs were recovered after feeding on SCID mice (Table 3). Four participants had no fed or partially fed ticks recovered, and 7 participants had no xenodiagnostic ticks tested due to loss during molting or feeding on the SCID mice.
Table 3.
Results of Xenodiagnostic Testing
| Group | ID | Protocol | No. of Fed Ticks Tested by PCR/Culture | No. of Positive Ticks | No. of Fed and Partially Fed Larvae Tested by IA/PCR/ESI-MS | No. of IA/PCR/ESI-MS Positive Results |
|---|---|---|---|---|---|---|
| EM | A-01 | 2 | 6 | 0 | 4 | 2 |
| EM PTxa | A-01R | 2 | ND | ND | 10 | 0 |
| EM PTx | B-01 | 1 | 0 | N/A | N/A | N/A |
| EM PTx | B-02 | 1 | 1 | 0 | N/A | N/A |
| EM PTx | B-03 | 1 | 2 | 0 | N/A | N/A |
| EM PTx | B-04 | 1 | 8 | 0 | N/A | N/A |
| EM PTx | B-05 | 2 | 11 | 0 | 11 | 0 |
| High C6 | C-01 | 1 | 0 | N/A | N/A | N/A |
| High C6 | C-02 | 1 | 1 | 0 | N/A | N/A |
| High C6 | C-02R | 2 | ND | ND | 21 | 0 |
| High C6 | C-03 | 1 | 1 | 0 | N/A | N/A |
| High C6 | C-03R | 2 | ND | ND | 9 | 0 |
| High C6 | C-04 | 1 | 5 | 0 | N/A | N/A |
| High C6 | C-04R | 2 | ND | ND | 24 | 0 |
| High C6 | C-05 | 1 | 1 | 0 | N/A | N/A |
| High C6 | C-06 | 1 | 0 | N/A | N/A | N/A |
| High C6 | C-06R | 2 | ND | ND | 23 | 0 |
| High C6 | C-07 | 1 | 0 | N/A | N/A | N/A |
| High C6 | C-07R | 2 | ND | ND | 20 | 0 |
| High C6 | C-08 | 2 | 8 | 0 | ND | ND |
| High C6 | C-09 | 2 | 19 | 0 | ND | ND |
| High C6 | C-10 | 2 | 9 | 0 | ND | ND |
| PTLDS | D-01 | 1 | 0 | N/A | N/A | N/A |
| PTLDS | D-02 | 1 | 5 | 1 | N/A | N/A |
| PTLDS | D-02R | 2 | 1 | 0 | 1 | 1 |
| PTLDS | D-03 | 1 | 0 | N/A | N/A | N/A |
| PTLDS | D-04 | 1 | 7 | 0 | N/A | N/A |
| PTLDS | D-05 | 2 | 22 | 0 | ND | ND |
| PTLDS | D-06 | 2 | 24 | 0 | ND | ND |
| PTLDS | D-07 | 2 | 15 | 0 | ND | ND |
| PTLDS | D-08 | 2 | 7 | 0 | 5 | 0 |
| PTLDS | D-09 | 2 | ND | ND | 24 | 0 |
| PTLDS | D-10 | 2 | 5 | 0 | 5 | 0 |
| HV | E-01 | 1 | 0 | N/A | N/A | N/A |
| HV | E-02 | 1 | 1 | 0 | N/A | N/A |
| HV | E-03 | 1 | 0 | N/A | N/A | N/A |
| HV | E-04 | 1 | 3 | 0 | N/A | N/A |
| HV | E-05 | 1 | 0 | N/A | N/A | N/A |
| HV | E-06 | 1 | 0 | N/A | N/A | N/A |
| HV | E-07 | 1 | 2 | 0 | N/A | N/A |
| HV | E-08 | 1 | 0 | N/A | N/A | N/A |
| HV | E-09 | 2 | 8 | 0 | 10 | 0 |
| HV | E-10 | 2 | 11 | 0 | 11 | 0 |
Abbreviations: EM, erythema migrans; EM PTx, after completing antibiotic therapy for erythema migrans; High C6, subjects with persistently elevated C6 antibody serum levels; HV, healthy volunteers; IA/PCR/ESI-MS, isothermal amplification followed by polymerase chain reaction and electrospray ionization mass spectroscopy; N/A, not applicable; ND, not done; PCR, polymerase chain reaction; PTLDS, posttreatment Lyme disease syndrome; R, repeat xenodiagnostic procedure.
a Procedure was repeated 7 months after completing antibiotic therapy and the patient was asymptomatic. Nymphal ticks were tested by PCR and culture in protocol 1; larval ticks were tested in protocol 2. Direct testing of ticks by IA/PCR/ESI-MS was performed only under protocol 2. Individual ticks were evaluated by only 1 of the 2 methods.
Due to the loss of ticks during the molting and feeding on the SCID mice, the protocol for processing recovered ticks was changed. For protocol 2, all ticks were tested after a 10- to 14-day incubation to allow replication of any acquired B. burgdorferi. Ticks were tested by (1) culture, PCR, injection of lysates into SCID mice with subsequent culture and PCR and/or (2) IA/PCR/ESI-MS. From 13 subjects, 146 ticks were tested by PCR and culture; and from 14 individuals, 178 ticks were tested directly by IA/PCR/ESI-MS. For 7 individuals, ticks were tested by both PCR and culture and IA/PCR/ESI-MS (Table 3).
Ticks from healthy volunteers tested by protocol 1 and 2 were negative (Tables 3 and 4). Twenty-three subjects with Lyme disease had at least 1 tick tested by protocol 1 and/or 2 (Table 3). From these 23 participants, 19 tested negative. There were indeterminate results in 2 patients, attributed to laboratory contamination. All tissues from SCID mice that had been fed upon by nymphs (protocol 1) or were injected with lysate from recovered ticks (protocol 2) tested negative by PCR and culture (Table 4).
Table 4.
Results of Severe Combined Immunodeficiency Mice Testing
| Group | ID | Protocol | No. of Nymphal Ticks Applied to Mice | No. of Fed and Partially Fed Larvae Used in the Lysate | SCID Organ Culture and PCR Result |
|---|---|---|---|---|---|
| EM | A-01 | 2 | N/A | 6 | NEG |
| EM PTx | B-02 | 1 | 1 | N/A | NEG |
| EM PTx | B-03 | 1 | 3 | N/A | NEG |
| EM PTx | B-04 | 1 | 13 | N/A | NEG |
| EM PTx | B-05 | 2 | N/A | 11 | NEG |
| High C6 | C-02 | 1 | 5 | N/A | NEG |
| High C6 | C-03 | 1 | 1 | N/A | NEG |
| High C6 | C-04 | 1 | 10 | N/A | NEG |
| High C6 | C-05 | 1 | 4 | N/A | NEG |
| High C6 | C-06 | 1 | 9 | N/A | NEG |
| High C6 | C-07 | 1 | 8 | N/A | NEG |
| High C6 | C-08 | 2 | N/A | 8 | NEG |
| High C6 | C-09 | 2 | N/A | 19 | NEG |
| High C6 | C-10 | 2 | N/A | 9 | NEG |
| PTLDS | D-02 | 1 | 6 | N/A | NEG |
| PTLDS | D-02R | 2 | N/A | 1 | NEG |
| PTLDS | D-04 | 1 | 10 | N/A | NEG |
| PTLDS | D-05 | 2 | N/A | 22 | NEG |
| PTLDS | D-06 | 2 | N/A | 24 | NEG |
| PTLDS | D-07 | 2 | N/A | 15 | NEG |
| PTLDS | D-08 | 2 | N/A | 7 | NEG |
| PTLDS | D-10 | 2 | N/A | 5 | NEG |
| HV | E-02 | 1 | 1 | N/A | NEG |
| HV | E-04 | 1 | 4 | N/A | NEG |
| HV | E-07 | 1 | 2 | N/A | NEG |
| HV | E-09 | 2 | N/A | 8 | NEG |
| HV | E-10 | 2 | N/A | 11 | NEG |
Abbreviations: EM, erythema migrans; EM PTx, patients after completing antibiotic therapy for erythema migrans; High C6, subjects with persistently elevated C6 antibody serum levels; HV, healthy volunteer; N/A, not applicable; NEG, negative; PCR, polymerase chain reaction; PTLDS, posttreatment Lyme disease syndrome; R, repeat xenodiagnostic procedure; SCID, severe combined immunodeficiency.
Results from subject A-01, EM on therapy, were considered positive by IA/PCR/ESI-MS on 2 separate specimens: 1 from a single tick and 1 from a pool of 3 ticks. The single tick was positive for 6 of 8 primer pairs, with primer pair BCT3519 [25] producing 2 Borrelia amplicons, indicating that this tick contained a mixture of 2 B. burgdorferi genotypes. The tested pooled specimen was positive with 2 of 8 primer pairs and the base-count signatures detected matched the signatures found in the single tick. Six other ticks from this subject tested negative by culture and PCR. The skin biopsy was negative by culture and culture PCR. This participant was completing the fourth day of antibiotic therapy when the ticks were collected and the skin biopsy was performed. This individual repeated the xenodiagnostic procedure 7 months after completing antibiotic therapy, and IA/PCR/ESI-MS testing of 10 recovered ticks was negative (Table 3).
One subject with PTLDS (D-02) was considered positive in 2 separate xenodiagnostic procedures. Ticks recovered from the initial xenodiagnostic procedure were tested using protocol 1. One nymph was found to be positive by PCR of the nymph lysate culture, but direct PCR of the nymph lysate and microscopic evaluation of the culture were negative. Four other nymphs were negative in all testing. All tissues from the SCID mouse on which the nymphs were fed were negative (including the nymph associated with the positive PCR assay). The patient's skin biopsy, performed at the site of the tick feeding, was negative by culture and culture PCR. The original positive ospA PCR of the tick culture was confirmed by PCRs for other B. burgdorferi genes. PCR for flaB, ospC, and a second primer set for ospA were positive, but recA PCR was negative. The DNA extracted from this culture sample was then tested by IA/PCR/ESI-MS, which was positive for 7 of the 8 assay primer pairs. It identified the DNA as from a novel genotype of B. burgdorferi, due to its unique combination of base-count signatures [25]. All strains of B. burgdorferi in use in the Tufts University laboratory were characterized by the IA/PCR/ESI-MS assay and none of the strains matched this genotype, making the possibility of contamination unlikely. Xenodiagnosis was repeated approximately 8 months after the original procedure. Direct testing by IA/PCR/ESI-MS revealed that 1 tick was positive for B. burgdorferi, by detection of 2 of 8 assay primer pairs. The 2 base-count signatures detected were consistent with the previously found genotype. Another tick was tested by PCR and culture and was negative. The patient's 2 repeat skin biopsy samples were negative by culture and culture PCR.
Skin Biopsy Testing
All but 6 participants had skin biopsies performed at the site of tick feeding on completion of the xenodiagnostic procedure. Twenty-nine samples were negative by culture and culture PCR. These included the biopsies from the 2 participants with positive results on the xenodiagnostic testing. Six samples (not including the 2 positive cases) were tested directly by IA/PCR/ESI-MS and were negative.
DISCUSSION
The primary goals of this study were to develop procedures for xenodiagnostic testing of patients with Lyme disease and to determine the safety of tick xenodiagnosis in humans. We demonstrated that up to 30 larval ticks can be safely applied to humans. Adverse events were minimal and limited predominantly to itching at the tick bite sites.
Our initial results show that the majority of the patients with Lyme disease treated with antibiotic therapy are negative by xenodiagnosis. An important caveat is that the number of tested xenodiagnostic ticks per participant in general was small, particularly in the early subjects. The number of engorged ticks tested for each individual is likely to be an important variable. The more engorged ticks tested, the larger the probability of detecting a positive. However, our testing of the ticks included multiple modalities and very sensitive assays targeting B. burgdorferi.
We found the presence of amplifiable B. burgdorferi DNA in xenodiagnostic ticks removed from 2 individuals. One individual had EM, and had just started antibiotic therapy. The aim in evaluating this participant was to include a possible “positive control” for the xenodiagnostic procedure in humans. Although the best positive controls would be individuals with untreated EM, we felt it would be inappropriate to withhold therapy for the few days required for tick feeding, due to the risk of dissemination of the organism and possible morbidity. The second individual was a patient with PTLDS, who had B. burgdorferi DNA detected from 2 different xenodiagnostic procedures, 8 months apart. We were unable to culture the organism or to show transmission to SCID mice.
All of our positive detections were only through DNA amplification techniques. Although this is consistent with the animal studies of xenodiagnosis after antibiotics [9–12], where positivity as assessed by PCR is at very low levels and not associated with identifiable pathology in the animal, it raises the question of whether detection represents the presence of viable organisms. The inability to culture the organism may be due to genetic loss of plasmids by B. burgdorferi [9]. In studies in which B. burgdorferi infection was introduced into mice using cultured spirochetes, xenodiagnosis performed after antibiotic treatment suggested that spirochetes detectable in ticks by PCR but not by culture were viable, because ticks could transmit the infection to SCID mice [10, 11]. Transmission was unsuccessful, however, in other mice studies in which infection was introduced using ticks, which models more closely human acquisition of Lyme disease [9, 28]. If active motility were required for the acquisition of B. burgdorferi by ticks, a positive xenodiagnostic test would imply viability. In the “positive control,” viable spirochetes could have been killed or inhibited by antibiotics in the skin as well as in the blood and interstitial fluid ingested by the tick during its 4-day feeding period [28, 29]. However, an alternative hypothesis is that ticks acquire DNA from dead organisms during their feeding. Borrelia burgdorferi was not found in skin biopsies at the tick feeding sites, but the majority of the samples were tested using culture. IA/PCR/ESI-MS testing of additional skin biopsies might help to clarify whether spirochetal DNA can also be detected directly in skin. A study of patients with Lyme arthritis has showed that B. burgdorferi DNA can persist in the synovial fluid and may not be a marker of viability of the bacteria [30].
Limitations of this study include the relatively small number of patients on which xenodiagnosis was attempted. However, the majority of patients studied were those with residual nonspecific symptoms and persistent seropositivity, which is the group of greatest interest with regard to the question of whether there might be residual infection with B. burgdorferi. Also, because of the nature of patient recruitment, monitoring of compliance with antibiotic therapy for the prior episode of Lyme disease or documentation of the adequacy of blood levels of the antibiotics prescribed was not performed. We cannot exclude the possibility of untreated subclinical reinfections that might have occurred after completion of the last known course of antibiotic treatment; however, it should be noted that reinfected patients would be missed by currently available testing.
This study establishes that xenodiagnosis can safely be used as a tool in patients with Lyme disease and has potential for furthering our knowledge of Borrelia biology in humans. Future studies are necessary to determine the incidence of positive xenodiagnostic results for B. burgdorferi after antibiotic treatment, if these results represent viable organisms or remnants of infection, and whether these results can be related to ongoing symptoms in patients after therapy for Lyme disease.
Supplementary Data
Supplementary materials are available at Clinical Infectious Diseases online (http://cid.oxfordjournals.org/). Supplementary materials consist of data provided by the author that are published to benefit the reader. The posted materials are not copyedited. The contents of all supplementary data are the sole responsibility of the authors. Questions or messages regarding errors should be addressed to the author.
Notes
Acknowledgments. We thank the study participants for their enthusiastic involvement; the Independent Medical Monitor (Fred Gill, MD Clinical Center, National Institutes of Health [NIH]); the staff of the Regulatory Compliance and Human Subjects Protection Branch at the National Institute of Allergy and Infectious Diseases (NIAID; Karen Sweeney, RN; Kelly Cahill, RN; Barry Eagel, MD; Leah Giambarresi, MS; Lisa Hoopengardner, CCRA; and Joy Beeler, MPH); Judith Starling, RPh (NIH Clinical Center Pharmacy); Heidi K. Goethert, ScD (Tufts University); Rachel Fulton, RN; Meghan Gardiner (Mansfield Family Practice); and Robert Kalish, MD (Tufts Medical Center) for their assistance during the study.
Disclaimer. The funding sources or Abbott had no roles in data collection, analysis, or interpretation; report writing; or submission. All authors had responsibility for the final decision to submit for publication. Ibis Biosciences/Abbott had no role in the design or interpretation of these studies. Assays described are for research use only.
Financial support. This research was supported by the Intramural Research Program of the NIH, NIAID (A. M., S. P. T., C. W., P. W.), the NIH Bench to Bedside program (A. M., L. T. H.), and the NIAID (grant number R21AI082436 to L. T. H.). This work was also partially supported by the NIH (grant number 2R44AI077156 to M. W. E., C. D. C., H. E. C.) and the Gordon and Llura Gund Foundation (to P. J. K.).
Potential conflicts of interest. M. W. E., C. D. C., and H. E. C. are employees of Ibis Biosciences, an Abbott company, which developed the PCR/ESI-MS and IA/PCR/ESI-MS assays and instrumentation used in these studies. S. R. T. has received consulting fees from Immunetics and is a shareholder of Abbott. All other authors report no potential conflicts.
All authors have submitted the ICMJE Form for Disclosure of Potential Conflicts of Interest. Conflicts that the editors consider relevant to the content of the manuscript have been disclosed.
References
- 1.Centers for Disease Control and Prevention. Lyme disease. Available at: http://www.cdc.gov/lyme/stats/index.html. Accessed 27 June 2013.
- 2.Wormser GP, Dattwyler RJ, Shapiro ED, et al. The clinical assessment, treatment, and prevention of lyme disease, human granulocytic anaplasmosis, and babesiosis: clinical practice guidelines by the Infectious Diseases Society of America. Clin Infect Dis. 2006;43:1089–134. doi: 10.1086/508667. [DOI] [PubMed] [Google Scholar]
- 3.Feder HM, Jr, Johnson BJ, O'Connell S, et al. A critical appraisal of “chronic Lyme disease. N Engl J Med. 2007;357:1422–30. doi: 10.1056/NEJMra072023. [DOI] [PubMed] [Google Scholar]
- 4.Klempner MS, Hu LT, Evans J, et al. Two controlled trials of antibiotic treatment in patients with persistent symptoms and a history of Lyme disease. N Engl J Med. 2001;345:85–92. doi: 10.1056/NEJM200107123450202. [DOI] [PubMed] [Google Scholar]
- 5.Fallon BA, Keilp JG, Corbera KM, et al. A randomized, placebo-controlled trial of repeated IV antibiotic therapy for Lyme encephalopathy. Neurology. 2008;70:992–1003. doi: 10.1212/01.WNL.0000284604.61160.2d. [DOI] [PubMed] [Google Scholar]
- 6.Krupp LB, Hyman LG, Grimson R, et al. Study and treatment of post Lyme disease (STOP-LD): a randomized double masked clinical trial. Neurology. 2003;60:1923–30. doi: 10.1212/01.wnl.0000071227.23769.9e. [DOI] [PubMed] [Google Scholar]
- 7.Straubinger RK. PCR-based quantification of Borrelia burgdorferi organisms in canine tissues over a 500-day postinfection period. J Clin Microbiol. 2000;38:2191–9. doi: 10.1128/jcm.38.6.2191-2199.2000. [DOI] [PMC free article] [PubMed] [Google Scholar]
- 8.Straubinger RK, Straubinger AF, Summers BA, Jacobson RH. Status of Borrelia burgdorferi infection after antibiotic treatment and the effects of corticosteroids: an experimental study. J Infect Dis. 2000;181:1069–81. doi: 10.1086/315340. [DOI] [PubMed] [Google Scholar]
- 9.Bockenstedt LK, Mao J, Hodzic E, Barthold SW, Fish D. Detection of attenuated, noninfectious spirochetes in Borrelia burgdorferi-infected mice after antibiotic treatment. J Infect Dis. 2002;186:1430–7. doi: 10.1086/345284. [DOI] [PubMed] [Google Scholar]
- 10.Hodzic E, Feng S, Holden K, Freet KJ, Barthold SW. Persistence of Borrelia burgdorferi following antibiotic treatment in mice. Antimicrob Agents Chemother. 2008;52:1728–36. doi: 10.1128/AAC.01050-07. [DOI] [PMC free article] [PubMed] [Google Scholar]
- 11.Barthold SW, Hodzic E, Imai DM, Feng S, Yang X, Luft BJ. Ineffectiveness of tigecycline against persistent Borrelia burgdorferi. Antimicrob Agents Chemother. 2010;54:643–51. doi: 10.1128/AAC.00788-09. [DOI] [PMC free article] [PubMed] [Google Scholar]
- 12.Embers ME, Barthold SW, Borda JT, et al. Persistence of Borrelia burgdorferi in rhesus macaques following antibiotic treatment of disseminated infection. PLoS One. 2012;7:e29914. doi: 10.1371/journal.pone.0029914. [DOI] [PMC free article] [PubMed] [Google Scholar]
- 13.Donahue JG, Piesman J, Spielman A. Reservoir competence of white-footed mice for Lyme disease spirochetes. Am J Trop Med Hyg. 1987;36:92–6. doi: 10.4269/ajtmh.1987.36.92. [DOI] [PubMed] [Google Scholar]
- 14.Sinsky RJ, Piesman J. Ear punch biopsy method for detection and isolation of Borrelia burgdorferi from rodents. J Clin Microbiol. 1989;27:1723–7. doi: 10.1128/jcm.27.8.1723-1727.1989. [DOI] [PMC free article] [PubMed] [Google Scholar]
- 15.Hua CM, Cheminade Y, Perret JL, Weynants V, Lobet Y, Gern L. Early detection of Borrelia burgdorferi sensu lato infection in Balb/c mice by co-feeding Ixodes ricinus ticks. Int J Med Microbiol. 2003;293:421–6. doi: 10.1078/1438-4221-00285. [DOI] [PubMed] [Google Scholar]
- 16.Wormser GP, Schwartz I. Antibiotic treatment of animals infected with Borrelia burgdorferi. Clin Microbiol Rev. 2009;22:387–95. doi: 10.1128/CMR.00004-09. [DOI] [PMC free article] [PubMed] [Google Scholar]
- 17.Wormser GP, Baker PJ, O'Connell S, Pachner AR, Schwartz I, Shapiro ED. Critical analysis of treatment trials of rhesus macaques infected with Borrelia burgdorferi reveals important flaws in experimental design. Vector Borne Zoonotic Dis. 2012;12:535–8. doi: 10.1089/vbz.2012.1012. [DOI] [PMC free article] [PubMed] [Google Scholar]
- 18.Wormser GP, O'Connell S. Treatment of infection caused by Borrelia burgdorferi sensu lato. Expert Rev Anti Infect Ther. 2011;9:245–60. doi: 10.1586/eri.10.174. [DOI] [PubMed] [Google Scholar]
- 19.Centers for Disease Control and Prevention. 2011 Lyme disease case definition. Available at: http://wwwn.cdc.gov/NNDSS/script/casedef.aspx?CondYrID=752&DatePub=1/1/2011 . Accessed 8 January 2014.
- 20.Division of AIDS, NIAID. National Institutes of Health table for grading adult and pediatric adverse experiences version 1.0—December 2004 (clarification dated August 2009) Available at: http://rsc.tech-res.com/Document/safetyandpharmacovigilance/Table_for_Grading_Severity_of_Adult_Pediatric_Adverse_Events.pdf . Accessed 12 April 2010.
- 21.Wormser GP, Masters E, Nowakowski J, et al. Prospective clinical evaluation of patients from Missouri and New York with erythema migrans-like skin lesions. Clin Infect Dis. 2005;41:958–65. doi: 10.1086/432935. [DOI] [PubMed] [Google Scholar]
- 22.Bunikis J, Tsao J, Luke CJ, Luna MG, Fish D, Barbour AG. Borrelia burgdorferi infection in a natural population of Peromyscus leucopus mice: a longitudinal study in an area where Lyme borreliosis is highly endemic. J Infect Dis. 2004;189:1515–23. doi: 10.1086/382594. [DOI] [PubMed] [Google Scholar]
- 23.Crowder CD, Rounds MA, Phillipson CA, et al. Extraction of total nucleic acids from ticks for the detection of bacterial and viral pathogens. J Med Entomol. 2010;47:89–94. doi: 10.1603/033.047.0112. [DOI] [PMC free article] [PubMed] [Google Scholar]
- 24.Rounds MA, Crowder CD, Matthews HE, et al. Identification of endosymbionts in ticks by broad-range polymerase chain reaction and electrospray ionization mass spectrometry. J Med Entomol. 2012;49:843–50. doi: 10.1603/me12038. [DOI] [PMC free article] [PubMed] [Google Scholar]
- 25.Crowder CD, Matthews HE, Schutzer S, et al. Genotypic variation and mixtures of Lyme Borrelia in Ixodes ticks from North America and Europe. PLoS One. 2010;5:e10650. doi: 10.1371/journal.pone.0010650. [DOI] [PMC free article] [PubMed] [Google Scholar]
- 26.Eshoo MW, Crowder CC, Rebman AW, et al. Direct molecular detection and genotyping of Borrelia burgdorferi from whole blood of patients with early Lyme disease. PLoS One. 2012;7:e36825. doi: 10.1371/journal.pone.0036825. [DOI] [PMC free article] [PubMed] [Google Scholar]
- 27.Eshoo MW, Crowder CD, Li H, et al. Detection and identification of Ehrlichia species in blood by use of PCR and electrospray ionization mass spectrometry. J Clin Microbiol. 2010;48:472–8. doi: 10.1128/JCM.01669-09. [DOI] [PMC free article] [PubMed] [Google Scholar]
- 28.Bockenstedt LK, Gonzalez DG, Haberman AM, Belperron AA. Spirochete antigens persist near cartilage after murine Lyme borreliosis therapy. J Clin Invest. 2012;122:2652–60. doi: 10.1172/JCI58813. [DOI] [PMC free article] [PubMed] [Google Scholar]
- 29.Schwartz I, Wormser GP, Schwartz JJ, et al. Diagnosis of early Lyme disease by polymerase chain reaction amplification and culture of skin biopsies from erythema migrans lesions. J Clin Microbiol. 1992;30:3082–8. doi: 10.1128/jcm.30.12.3082-3088.1992. [DOI] [PMC free article] [PubMed] [Google Scholar]
- 30.Li X, McHugh GA, Damle N, Sikand VK, Glickstein L, Steere AC. Burden and viability of Borrelia burgdorferi in skin and joints of patients with erythema migrans or lyme arthritis. Arthritis Rheum. 2011;63:2238–47. doi: 10.1002/art.30384. [DOI] [PMC free article] [PubMed] [Google Scholar]
Associated Data
This section collects any data citations, data availability statements, or supplementary materials included in this article.
