. 1991 Dec 1;88(23):10855–10859. doi: 10.1073/pnas.88.23.10855

Formation of cage-like particles by poly(amino acid)-based block copolymers in aqueous solution.

A Cudd 1, M Bhogal 1, J O'Mullane 1, P Goddard 1
PMCID: PMC53030  PMID: 11607245

Abstract

When dissolved in N,N-dimethylformamide and then dialyzed against phosphate-buffered saline, A-B-A block copolymers composed of poly [N5-(2-hydroxyethyl)-L-glutamine]-block-poly(gamma-benzyl-L-glutamate)- block-poly [N5-(2-hydroxyethyl)-L-glutamine] form particles. The particles are cage-like structures with average diameters of 300 nm (average polydispersity, 0.3-0.5). They are stable in aqueous solution at 4 degrees C for up to 3 weeks, at which time flocculation becomes apparent. Negative staining and freeze-fracture electron microscopy suggest that cage-like particles are formed by selective association of segregated micelle populations. A model of particle formation is presented in which B blocks form micelles in dimethylformamide. On dialysis against an aqueous solution, the extended A blocks then associate intermolecularly to form rod-shaped micelles, which connect the B block micelles. The result is a meshed cage-like particle. The implications of these observations on the aggregation behavior of polymeric surfactants in dilute solution are discussed.

Full text

PDF
10855

Images in this article

Selected References

These references are in PubMed. This may not be the complete list of references from this article.

  1. Chan K. M., Tse P. Y. Late subcapital fracture of the neck of the femur--a rare complication of Ender nailing. J Trauma. 1986 Feb;26(2):196–198. doi: 10.1097/00005373-198602000-00019. [DOI] [PubMed] [Google Scholar]
  2. DEBYE P., ANACKER E. W. Micelle shape from dissymmetry measurements. J Phys Colloid Chem. 1951 May;55(5):644–655. doi: 10.1021/j150488a003. [DOI] [PubMed] [Google Scholar]
  3. Fuller W. D., Verlander M. S., Goodman M. A procedure for the facile synthesis of amino-acid N-carboxyanhydrides. Biopolymers. 1976 Sep;15(9):1869–1871. doi: 10.1002/bip.1976.360150922. [DOI] [PubMed] [Google Scholar]
  4. Lasic D. D. The mechanism of vesicle formation. Biochem J. 1988 Nov 15;256(1):1–11. doi: 10.1042/bj2560001. [DOI] [PMC free article] [PubMed] [Google Scholar]
  5. Ollivon M., Eidelman O., Blumenthal R., Walter A. Micelle-vesicle transition of egg phosphatidylcholine and octyl glucoside. Biochemistry. 1988 Mar 8;27(5):1695–1703. doi: 10.1021/bi00405a047. [DOI] [PubMed] [Google Scholar]
