Abstract
A 14-year-old African American female presented to the emergency department with spontaneous, sudden-onset lip swelling for 1 h. On examination, there was significant water-bag edema of the upper lip extending to the philtrum and premaxilla. Nasopharyngeal laryngoscopy revealed a patent airway without edema. She was initiated on intravenous dexamethasone, famotidine, and diphenhydramine, after which her edema improved but did not resolve. She was subsequently transferred to a local pediatric hospital and upon further testing she was found to have a C1 esterase inhibitor de novo gene mutation. Angioedema causes localized, non-pitting edema of the dermis, subcutaneous and submucosal tissue, and often manifests in the lips, face, mouth, and throat. Signs of laryngeal involvement include change in voice, stridor, dysphagia, and dyspnea. When laryngeal edema is present, it may necessitate definitive airway management and patients should be monitored in the intensive care unit.
Keywords: Angioedema, Hereditary angioedema, Lip swelling, Pediatric otolaryngology
Case presentation
A 14-year-old African American female presented to the emergency department with spontaneous, sudden-onset lip swelling (upper greater than lower lip) for 1 h. On examination, there was significant water-bag edema of the upper lip extending to the philtrum and premaxilla (Fig. 1). The patient and her mother indicated that she did not have any food allergies nor did she have any new or unusual exposures. There was no family history of angioedema. Nasopharyngeal laryngoscopy revealed a patent airway without edema. She was initiated on intravenous dexamethasone, famotidine, and diphenhydramine which improved her edema but did not completely resolve it. She was subsequently transferred to a local pediatric hospital and upon further testing she was found to have a C1 esterase inhibitor de novo gene mutation. She was scheduled to see an allergist as an outpatient for further management.
Fig. 1.
A 14-year-old female with spontaneous lip swelling (upper > lower) extending to the philtrum and premaxilla on frontal (A) and lateral (B) views
Diagnosis
The prevalence of hereditary angioedema is very low, affecting 1/10,000-50,000 people. Hereditary angioedema causes localized, non-pitting edema of the dermis, subcutaneous and submucosal tissue, and often manifests in the lips, face, mouth, and throat. Two main pathways contribute to angioedema—the most immediate pathway (minutes to hours) is mediated by mast cell and basophil degranulation causing urticaria and pruritus, while the more delayed pathway (hours-days) is mediated by kinin. Hereditary angioedema may be considered in the case of angioedema without urticaria, as this rare form involves the latter pathway. Unlike the acquired type, hereditary angioedema is bradykinin-mediated only and is mostly caused by mutations to C1 inhibitor (C1INH), which, through the complement pathway, leads to low C4 levels and eventually uninhibited bradykinin. Hereditary angioedema may be diagnosed by measuring C4 and C1INH levels [1].
Hereditary angioedema typically presents before adulthood as recurrent angioedema attacks without pruritus or urticaria. These episodes usually last 2-5 days without treatment, with no associated triggers and with a possible family history of angioedema. Initial management requires assessing the airway, because edema may rapidly progress. Airway obstruction occurs in up to 15% of cases, accounting for a large portion of morbidity and mortality [2].
Signs of laryngeal involvement include change in voice, stridor, dysphagia, and dyspnea. In these cases, fiberoptic visualization should be emergently performed and may reveal pharyngeal or more ominously, laryngeal edema involving the vocal folds, epiglottis, aryepiglottic folds, or arytenoids. When laryngeal edema is present it may necessitate definitive airway management [3]. If suspecting a need for intubation, laryngoscopy may be performed with endotracheal tube loaded onto it to facilitate fiberoptic intubation. Patients should be monitored in the intensive care unit. Other treatments include C1 inhibitors, bradykinin B2 receptor antagonist, and kallikrein inhibitors to block the bradykinin activity. If these are unavailable, fresh frozen plasma may be used to replace C1 inhibitor [4, 5]. Unlike histamine-mediated angioedema, the hereditary form typically does not respond to antihistamine, corticosteroids, and epinephrine.
Acknowledgements
Not applicable
Authors’ contributions
All authors read and approved the final manuscript.
Funding
None
Availability of data and materials
Not applicable
Declarations
Ethics approval and consent to participate
Not applicable
Consent for publication
Not applicable
Competing interests
The authors declare that they have no competing interests.
Footnotes
Publisher’s Note
Springer Nature remains neutral with regard to jurisdictional claims in published maps and institutional affiliations.
Contributor Information
Helen Lesser, Email: helenles@pcom.edu.
Jason E. Cohn, Email: jcohnmed2729@gmail.com
References
- 1.Kim SJ, Brooks JC, Sheikh J, Kaplan MS, Goldberg BJ. Angioedema deaths in the United States, 1979–2010. Ann Allergy Asthma Immunol. 2014;113(6):630–634. doi: 10.1016/j.anai.2014.09.003. [DOI] [PubMed] [Google Scholar]
- 2.Bork K, Hardt J, Witzke G. Fatal laryngeal attacks and mortality in hereditary angioedema due to C1-INH deficiency. J Allergy Clin Immunol. 2012;130(3):692–697. doi: 10.1016/j.jaci.2012.05.055. [DOI] [PubMed] [Google Scholar]
- 3.Bentsianov BL, Parhiscar A, Azer M, Har-el G. The role of fiberoptic nasopharyngoscopy in the management of the acute airway in angioneurotic edema. Laryngoscope. 2000;110(12):2016–2019. doi: 10.1097/00005537-200012000-00007. [DOI] [PubMed] [Google Scholar]
- 4.Bowen T, Cicardi M, Farkas H, et al. 2010 International consensus algorithm for the diagnosis, therapy and management of hereditary angioedema. Allergy, Asthma Clin Immunol. 2010;6:24. doi: 10.1186/1710-1492-6-24. [DOI] [PMC free article] [PubMed] [Google Scholar]
- 5.Wilkerson RG, Manini A, Scott J. Angioedema in the emergency department: an evidence-based review. Emerg Med Pract. 2012;14(11):1–21. [PubMed] [Google Scholar]
