Systematic Part Transfer by Extending a Modular Toolkit to Diverse Bacteria

Abstract

It is impractical to develop a new parts collection for every potential host organism. It is well-established that gene expression parts, like genes, are qualitatively transferable, but there is little quantitative information defining transferability. Here, we systematically quantified the behavior of a parts set across multiple hosts. To do this, we developed a broad host range (BHR) plasmid system compatible with the large, modular CIDAR parts collection for E. coli, which we named openCIDAR. This enabled testing of a library of DNA constructs across the Pseudomonadota—Escherichia coli, Pseudomonas putida, Cupriavidus necator, and Komagataeibacter nataicola. Part performance was evaluated with a standardized characterization procedure that quantified expression in terms of molecules of equivalent fluorescein (MEFL), an objective unit of measure. The results showed that the CIDAR parts enable graded gene expression across all organisms—meaning that the same parts can be used to program E. coli, P. putida, C. necator, and K. nataicola. Most parts had a similar expression trend across hosts, although each organism had a different average gene expression level. The variability is enough that to achieve the same MEFL in a different organism, a lookup table is required to translate a design from one host to another. To identify truly divergent parts, we applied linear regression to a combinatorial set of promoters and ribosome binding sites, finding that the promoter J23100 behaves very differently in K. nataicola than in the other hosts. Thus, it is now possible to evaluate any CIDAR compatible part in three other hosts of interest, and the diversity of these hosts implies that the collection will also be compatible with many other Proteobacteria (Pseudomonadota). Furthermore, this work defines an approach to generalize modular synthetic biology parts sets beyond a single host, implying that only a few parts sets may be needed to span the tree of life. This will accelerate current efforts to engineer diverse species for environmental, biotechnological, and health applications.

Introduction

Bacteria with powerful metabolic capabilities that are well-adapted to challenging environments promise solutions for a variety of current manufacturing and environmental problems.¹ Tools for genetic manipulation of these organisms are required to study their phenotypes and design them to achieve set objectives. To this end, synthetic biology and metabolic engineering are currently engaged in efforts termed “onboarding” that seek to optimize and accelerate successful genetic transformation and genome engineering across the tree of life. Though new toolkits are continually published for organisms across the bacterial domain,²⁻¹⁰ these toolkits often focus on a single species or a narrow range of related bacteria with attractive catabolic, anabolic, and tolerance phenotypes. However, this approach will struggle to keep pace as the breadth and scale of engineerable microbes increases. Ideally, designers should be able to reprogram organisms as quickly as they are described. Therefore, it is not practical to develop new tools for each organism. Instead, methods for transferring genetic parts between hosts are needed.

Part transfer is common in nature. Genomics has confirmed horizontal gene transfer (HGT) between organisms, which can confer a competitive advantage to the new host.¹¹ Mobile bacterial genetic elements, including plasmids and transposons,¹² also commonly have broad host ranges (BHR). To replicate within the host or to provide an evolutionary advantage, these elements carry genes for cis-regulatory proteins, antibiotic resistance, biosynthetic gene clusters, or a variety of other functions. The genes are expressed, implying that either leaky transcription or the original gene expression parts are able to transcribe the foreign genes. These elements have been repurposed into vectors since the beginning of genetic engineering, and continue to form the foundation for new broad host range expression strategies.^13,14 It is clear from these examples that functional part transfer should be possible, but how broad, quantifiable, and predictable genetic part transfer can be has not yet been established.

Paired promoters and ribosome binding sites (RBS) are elemental genetic parts in gene expression control. Synthetic biology has widely adopted the Anderson promoter library, a series of synthetic constitutive promoters designed as variants of a consensus E. coli promoter, and synthetic RBSs from the Weiss group and the BIOFAB Foundry to achieve graded constitutive gene expression in E. coli.^5,15 Recently, these parts were incorporated into a modular cloning standard, CIDAR, that permits combinatorial assembly. This standard has been recently expanded to include over 100 unique parts, making it the largest of the E. coli part kits available on Addgene. Many of these parts have been used in a range of bacteria outside of E. coli,^4,16 yet their function has not been systematically characterized between diverse species. Often, the plasmid backbone, part context, or flow cytometry method varies between these experiments. Therefore, it is difficult to compare expression across these instances because the same DNA and quantification methods have not been used.

The phylum Pseudomonadota contains several species of interest that could be new hosts for synthetic biology, yet the available parts are limited. These species span the major classes within the phylum. Pseudomonas putida, like E. coli, is a gammaproteobacterium commonly found in soil that can degrade organic solvents, thrive in harsh chemical environments, and is genetically tractable with a few emerging parts sets.¹⁷ The betaproteobacterium Cupriavidus necator is well-known for its flexible metabolism and high accumulation of polyhydroxybutyrates, yet there are few genetic tools available.¹⁸ The alphaproteobacterium Komagataeibacter nataicola, along with related cellulose-producing acetic acid bacteria, is used in the fermentation of kombucha tea as well as the industrial production of bacterial nanocellulose.¹⁹ Some engineering tools have been established in all of these organisms, but not at the scale and depth of the CIDAR parts for E. coli.

Here, we redesign the CIDAR backbones to include a broad host range replicon, BBR1, to enable CIDAR parts expression across Pseudomonadota. These backbones, termed openCIDAR, are compatible with all CIDAR parts currently on Addgene. We then characterize standard genetic parts in the lab strain Pseudomonas putida KT2440, the lab strain Cupriavidus necator H16, and a newly isolated strain of Komagataeibacter nataicola called DS12. This spans the major groups of the Pseudomonadota as well as strains in various stages of domestication. We then assess the function of CIDAR promoters and RBSs in the same genetic context in each of these hosts, using molecules of equivalent fluorescein (MEFL), an emerging standard unit for flow cytometry,^20,21 to quantitatively compare performance. We find that the same DNA functions relatively the same across the hosts, showing that just as genes can be relatively easily exchanged across organisms, so can transcriptional and translational elements. We also show that linear models can identify parts that behave less predictably, specifically J23100 in K. nataicola, enabling rapid identification of the appropriate parts to use in engineering a new host. Thus, a large, well-characterized parts set with graded gene expression is now accessible for any organism compatible with the pBBR1 plasmid, which includes species across Pseudomonadota (Figure 1A).

Figure 1.

Enabling parts expression across hosts. (A) Known pBBR1 compatible bacteria, presented in a reconstructed phylogenetic tree. All major clades of Pseudomonadota are represented in this group. Hosts used in this study are highlighted. (B) Diagram of the native architecture of pBBR1, as isolated from Bordatella bronchiseptica. Modern derivatives do not include the Mob transcription unit, but are otherwise similar.

Results

Genetic Design Strategy

We wanted to design our system to be compatible with accessible commonly used parts. Therefore, we sought an assembly standard that had many well-characterized physical constructs readily available to researchers. We found that the Modular Cloning toolkit on Addgene that conforms to the CIDAR⁵ standard from the Densmore lab, when combined with the extension kit²² available from the Murray lab, is comprehensive, characterized, accessible, and convenient to clone. Altogether, the CIDAR standard currently contains 15 constitutive promoters, 15 inducible promoters, 5 monocistronic RBSs, 14 bicistronic RBSs, 18 fluorescent protein coding sequences, 59 other coding sequences, and 11 terminators. Other possibilities like the iGEM collection, the DOE JGI Inventory of Composable Elements, or SynBioHub, met most, but not all, of our initial requirements. Therefore, everything we built in this effort is compatible with the CIDAR standard.

We next designed an expression vector based on a broad host range (BHR) plasmid. BHR plasmids are independent of host genomics and simple in terms of cloning. We considered this superior to integrative vectors, which are stable, yet they tend integrate randomly or require preinsertion of a landing pad, creating context effects and increasing host engineering effort. There are several BHR plasmids that function in Pseudomonadota (Table 1). Of these, the pBBR1 plasmid is small, has a broad range, relatively high stability, and is maintained at a medium copy number. Specifically, BBR1 and derivatives have been shown to replicate in all major divisions of Pseudomonadota, and as of this writing, at least 33 species (Figure 1A).²³⁻³⁷ In pBBR1, the Rep protein is required for replication, and in all known cases expression is controlled by DNA elements (i.e., promoter and RBS) native to the pBBR1 plasmid (Figure 1B). Thus, a backbone with a replicon based on BBR1 and compatible with the CIDAR Modular Cloning standard could extend well-known synthetic biology parts across a wide range of bacterial hosts (Figure 1A). To test this, we selected four hosts (highlighted, Figure 1A) representing the major classes of Pseudomonadota.

Table 1. Broad Host Range Plasmids Vary in Size, Range, and Copy Number.

replication system	size (bp)	range	incompatibility group	copy number in E. coli	notes
RK2	2226	broad	Inc.P	2
pBBR1	1524	broad	pBBR1	5
pRO1600/ColE1	1973	gammaproteobacteria	colE1-like	32	reported not to replicate in K. rhaeticus(24)
RSF1010	3678	broad	Inc.Q	5
pWV01	2178	very broad (includes Gram+)	pWV01	not measured	reported to be unstable38

Creating OpenCIDAR—A Broad Host Range Parts Collection

First, we built destination vectors that combine the CIDAR standard with the pBBR1 origin of replication. To be compatible, a synonymous mutation was introduced to the rep protein to remove a BbsI site. The resulting vectors are listed in Table S1. The CIDAR assembly standard is hierarchical—parts in Level 0 vectors are assembled into Level 1 transcription units, which can be further assembled into Level 2 devices or circuits. For the Level 1 destination vectors (pBBR1_DVK, Figure S1), we retained the CIDAR⁵ kanamycin marker for selection because the target species in this study are sensitive to kanamycin (Figure S4).^16,39 However, we replaced the Level 2 ampicillin marker with chloramphenicol (pBBR1_DVC, Figure S2) and spectinomycin (pBBR1_DVS, Figure S3) because K. nataicola was found to be only moderately sensitive to ampicillin (Figure S4). The name of each destination vector was followed by a suffix indicating the CIDAR assembly scars flanking the cloning site (e.g., _AE or _EF).

Next, we characterized the copy number of the new vectors in each host organism, to confirm the mutated pBBR1 was still functional. The Level 1 (single transcription unit) destination vector pBBR1_DVK_AE was transformed into all host strains, and plasmid copy number during exponential growth phase was determined by ddPCR. Copy number was defined as the ratio of absolute concentration of BBR1 rep protein amplicons to a single-copy target in each host genome (Table S3). The copy numbers for E. coli and P. putida were similar, with approximately 10–11 copies per cell for each species (Figure 2C and D). The average copy number was lower for C. necator and K. nataicola, at about 7 (Figure 2E) and 3 (Figure 2F) copies per cell, respectively.

Figure 2.

OpenCIDAR design and function. (A) Design of the new destination vectors containing KanR, the pBBR1 origin and rep gene, and a CIDAR cloning site where transcription units may be assembled. Although this is over 100 parts, only the parts in this study are shown. (B) Molecules of Equivalent Fluorescein (MEFL) expression values for the combinations of parts included in the original CIDAR paper. These were interpolated from CIDAR Figure S1. Expression from the original vector series in E. coli matches closely to the expression reported in this study. (C) Violin plots of the expression values in MEFL for E. coli populations expressing each construct, along with the average copy number assessed by ddPCR. The violin plots for three replicates are overlaid, showing little variation between replicates. (D) The same plots in as in C for the same constructs expressed in P. putida. (E) The same plots in as in C for the same constructs expressed in C. necator. (F) The same plots in as in C for the same constructs expressed in K. nataicola.

Analysis of a Combinatorial Expression Library Demonstrates Wide Portability of Commonly Used Parts

To test gene expression across the hosts with the openCIDAR vectors, we selected commonly used parts that have been well characterized in E. coli (Figure 2A). For promoters, synthetic Anderson series promoters were chosen. In E. coli the expected qualitative relative strengths are, from highest to lowest, J23100, J23106, and J23103.⁵ For RBSs, several different types were chosen, including bicistronic and ribozyme-insulated designs. The standard RBSs had qualitative relative strengths ordered B0034m, B0032m, and B0033m. The bicistronic and insulated RBSs BCD2, RiboJ+BCD2, and RiboJ+UTR1 were expected to be high expression, but with unknown relative magnitude.

To assess expression strength in E. coli and the other three hosts, we built a library of fluorescent reporter strains under the control each combination of the three promoters and six RBSs. Although this set is small, we developed a liquid handling protocol for assembly that could be scaled to the size of the CIDAR parts set (Methods). We then transformed this set of 18 expression units into each host, quantified fluorescence intensity using flow cytometry, calibrated fluorescence intensity to an external standard (molecules of equivalent fluorescein, or MEFL), and subtracted cell autofluorescence. The expression strengths for a portion of this combinatorial library have previously been measured in E. coli in the original CIDAR vectors (Figure 2B, values extrapolated from the CIDAR MoClo Supporting Information⁵). When compared to the openCIDAR expression values for E. coli (Figure 2C), we found that the relative expression strengths for combinations of parts characterized in CIDAR and openCIDAR vectors were consistent. In general, we found that expression strengths were qualitatively similar across the other hosts P. putida KT2440 (Figure 2D), C. necator H16 (Figure 2E), and K. nataicola DS12 (Figure 2F). This was true despite the copy number variation across hosts. However, the violin plots revealed low-expressing subpopulations with fluorescence intensity close to the empty vector control in P. putida, while this phenomenon was not observed in E. coli.

To better assess part performance across hosts, we first plotted all expression values on the same chart, which is possible because all values are expressed in terms of MEFL (Figure 3A). Unexpectedly, global expression values for all constructs were more than twice as high in C. necator (difference = 0.48 – log₁₀, p < 0.01) and about twice as high in P. putida (difference = 0.35 – log₁₀, p < 0.01) compared to E. coli. Then, Pearson correlation coefficients were calculated for the constructs across hosts (Figure 3B). Expression values for the same constructs in the closely related species E. coli and P. putida were well-correlated (Pearson coefficient R = 0.84). Expression levels were also well-correlated between C. necator and E. coli (R = 0.83), and between C. necator and P. putida (R = 0.87). In contrast, expression levels were poorly correlated between K. nataicola and E. coli (R = 0.33), P. putida (R = 0.00017), and C. necator (R = 0.22). This demonstrates that although a range of expression values are possible in K. nataicola, the same combinations of promoters and RBS cannot be used to achieve similar expression levels. This necessitates an MEFL lookup table (LUT), which can be used to transfer a genetic design from one organism to another (Figure 4). With a LUT, equivalent parts in a new organism can be matched to known part sets, or part sets which achieve a desired expression level can be selected. This is made possible by the MEFL standard expression unit.

Figure 3.

Comparing and correlating part function across hosts. (A) Rank order comparison of MEFL for each construct in each host. This shows a rough global correlation for expression in all species. Divergent values are largely found only in K. nataicola. (B) Species–species correlations. The species is in the diagonal, with the MEFL values in each species plotted in the top right boxes and the correlation coefficients in the bottom left boxes.

Figure 4.

MEFL lookup table (LUT) for openCIDAR. By matching MEFL across organisms, researchers may design genetic constructs that achieve the same expression values across different organisms.

Truly interchangeable parts should have negligible interactions with other elements. To investigate interactions, linear regression models of GFP expression by promoter, RBS, and the interactions between the two (all other construct elements were constant) were fit for each organism. The coefficients of each term (log₁₀ transformed) were compared as a proxy for understanding the relative effect size of each term. The individual effect sizes of the intercept (baseline fluorescence), promoters, and RBSs were usually the dominant factors, indicating independent contributions to the total MEFL. For K. nataicola, however, the interaction between promoter J23100 and several RBSs had coefficients equivalent or larger than the promoter coefficients themselves. We conclude that promoter J23100 is not “well-behaved” in K. nataicola, that is it does not function the same across hosts, even though it still produces functional transcription units. This is a notable finding as promoter J23100 is a very commonly used strong promoter, and is likely to be one of the first choices for synthetic biologists working in novel Pseudomonadota. This interaction would be difficult to detect without a combinatorial approach and quantitative analysis. The behavior of this single promoter appears to be the cause of the lack of correlation between K. nataicola and the other organisms in Figure 3B, especially considering the improved correlation between K. nataicola and all other species (R ≈ 0.8) when only the J23103 and J23106 data are included (Figure S5).

Discussion

As new organisms are identified as chassis of interest for synthetic biology, appropriate tools and part sets for controlling gene expression need to be identified. Here, we demonstrate a method for rapidly identifying appropriate expression parts for multiple organisms from a single parts set. This obviates the need to develop new part sets by genome mining or other methods. This should enable researchers to more rapidly onboard new organisms.

Previous studies have explored the range of fluorescent protein expression achievable in nonconventional prokaryotes by varying promoters with a consistent RBS, or RBS with a consistent promoter.^2,4,7,28 Few, if any, studies have explored fully combinatorial sets of both promoters and RBSs across several hosts from diverse lineages. This, coupled with the standard MEFL measurement, enabled analyses not previously possible, with several interesting outcomes.

First, we noted that expression of the same DNA across different hosts resulted in MEFL values that were generally well-correlated. However, P. putida, C. necator, and K. nataicola all had a higher average expression strength than E. coli which did not correlate with copy number. This suggests that other host factors besides plasmid copy number may be contributing to expression. Furthermore, these results show that at least in some bacteria, it may be more difficult to achieve low expression rather than high expression.

Second, we observed that the promoters are largely functional across hosts. This is not unique to bacteria—this has been observed in yeast⁴⁰ and animals.⁴¹ Yet, the yeast study clearly showed an evolutionary distance trend where sufficiently distant promoters were no longer functional (promoters from Yarrowia lipolytica and Schizosaccharomyces pombe were not functional in Saccharomyces cerevisiae). In contrast, we observed a breakdown in expression patterns but not a nonfunctional barrier, even for distantly related bacteria. The lack of a nonfunctional barrier could be due to the efficiency and simplicity of prokaryotic gene expression, the parts being synthetic rather than host derived, greater conservation of prokaryotic gene expression machinery, or some other mechanism. Differences in expression levels are possibly due to differences in transcription factor binding affinity, ribosome binding affinity, and global protein expression control within the cell.

To enable similar function of genetic designs across hosts, we propose designs should be transferred using a lookup table that matches equivalent expression parts across hosts. This would account for the variability of the same DNA across hosts. Rebuilding a design for a new host is particularly facile in the openCIDAR system compared to other systems due to the modular cloning framework and availability of a large parts set, although the characterization strategy could be used to translate between different part collections as well, since the comparison is made with MEFL, not arbitrary units. Furthermore, by using combinatorial experiments and linear regression, it was possible to identify the divergent behavior of the J23100 promoter in K. nataicola. This demonstrates that it is possible to debug parts and derive design rules in each organism, in addition to the lookup table, that can inform future designs.

While the parts function across the major classes of Pseudomonadota, it is important to note that several factors such as transposons, host restriction systems, and growth rate could limit the application of this parts set in a potential new host. We know this is at least true of Vibrio natriegens (communication with Tanya Tschirhart), as pBBR1 is particularly unstable even though functional.²⁸ However, the lookup table approach would still be useful to translate E. coli designs to a V. natriegens expression system, as long as all parts are measured in MEFL. Others are developing approaches to overcome host limitations like tools that evade restriction-modification systems.⁴² Even though openCIDAR may not work in all Pseudomonadota due to these factors, the collection should at least work well in all species that can stably maintain pBBR1.

In conclusion, we have defined a system that enables transfer of accessible, well-characterized parts to new chassis. By screening a modest library, we achieved constitutive expression over 3 orders of magnitude in each species studied. Coupled with recent advances in scalable and high-throughput electroporation devices,⁴³ our approach can make automated, high-throughput, modular DNA assembly in many nonconventional prokaryotes an achievable and practical workflow. This is because only one part set is required for a large group of related bacteria—hinting that only a few parts sets may need to be developed to enable gene expression control across the tree of life.

Material and Methods

Phylogenetic Placement of pBBR1-Compatible Bacteria

A literature search was conducted to identify bacterial species reported to be transformable with the pBBR1 plasmid and derivatives. These species are reported in Table S2. Representative genomes for each species were accessed from the NCBI RefSeq database, and a species tree showing phylogenetic relationships was constructed from genomic protein sequences using the OrthoFinder tool.^44,45 The resulting tree was visualized using IcyTree.⁴⁶ The E. coli and Pseudomonadota clades (Figure 1C) were visualized using the Interactive Tree of Life (iTOL).⁴⁷

Strains and Media

All cloning was performed in NEB 5-alpha Competent Escherichia coli (New England BioLabs C2987U). The Pseudomonas putida KT2440 strain was purchased from ATCC (#47054). The Cupriavidus necator H16 strain was purchased from ATCC (#17699). The Komagataeibacter nataicola DS12 strain was isolated from a kombucha tea culture (Urban Farm, Portland ME) by Elizabeth van Zyl of the Coburn lab and provided as a gift. Routine culture of E. coli for cloning purposes was performed in Miller’s LB Broth (Fisher BP1426–2) in 14 mL Falcon tubes (VWR 60819-761) at 37 °C on a rotating drum. Routine culture of P. putida and C. necator was performed in Miller’s LB Broth using 50 mL conical tubes in an orbital incubator shaker at 30 °C, 220 rpm. Routine culture of K. nataicola was performed in Hestrin-Schramm media⁴⁸ (5 g/L Bacto Peptone (BD 211677), 5 g/L Difco Yeast Extract (BD 210929), 1.15 g/L citric acid (Sigma-Aldrich C0759), 2.7 g/L sodium phosphate dibasic anhydrous (Sigma-Aldrich S5136), 20 g/L glucose (Sigma-Aldrich G7021)) using 125 mL shake flasks in an orbital incubator shaker at 30 °C, 220 rpm. Solid media plates were prepared using the previously described media supplemented with 20g/L (E. coli, P. putida, C. necator) or 15 g/L (K. nataicola) agar (Sunrise Science Products 1910–1KG). For antibiotic selection and plasmid maintenance, kanamycin (Alfa Aesar J61272) was added at 50 μg/mL (E. coli, P. putida), 100 μg/mL (K. nataicola) and 200 μg/mL (C. necator). For identification of background colonies in cloning, X-Gal was supplemented to the selection media (Thermo Scientific R0941).

The CIDAR MoClo Parts Kit was a gift from Douglas Densmore (Addgene kit #1000000059). CIDAR MoClo Extension, Volume I was a gift from Richard Murray (Addgene kit #1000000161). pSEVA331Bb was a gift from Tom Ellis (Addgene plasmid #78269; http://n2t.net/addgene:78269; RRID:Addgene_78269).

Cloning of New Destination Vector Series

To construct the Level 1 series, the BBR1 origin of replication was amplified from pSEVA331Bb (Addgene #78269). A silent mutation was introduced in the Rep protein to remove a BbsI restriction site (G186A). The kanamycin resistance cassette was amplified from pAN861. The CIDAR MoClo cloning sites were amplified from DVK_AE, DVK_EF, DVK_FG, and DVK_GH. The fragments containing the origin of replication, kanamycin resistance gene and cloning site, along with appropriate flanking sequences, were combined by Gibson Assembly (NEB E2621S) to form pBBR1_DVK_AE (Figure S1), pBBR1_DVK_EF, pBBR1_DVK_FG, and pBBR1_DVK_GH. To construct the Level 2 series, the fragment containing the BBR1 origin of replication was combined with a chloramphenicol resistance cassette from pY122 or a spectinomycin resistance cassette from pICH41308 and the cloning site from DVA_AF, DVA_AG, and DVA_AH to form pBBR1_DVC_AF (Figure S2), pBBR1_DVC_AG, pBBR1_DVC_AH, pBBR1_DVS_AF (Figure S3), pBBR1_DVS_AG, and pBBR1_DVS_AH. Correct assembly was confirmed by Sanger sequencing. All new destination vectors constructed for this study are summarized in Table S1.

Automated Cloning Pipeline

The CIDAR MoClo Parts Kit (#1000000059) and CIDAR MoClo Extension, Volume I (#1000000161) were purchased from Addgene. Plasmid DNA was purified from E. coli host strains using the QIAprep Spin Miniprep kit (Qiagen 27106). Plasmid DNA was quantitated using a NanoDrop spectrophotometer and diluted to 20 fmol/μL in nuclease-free water (VWR 02-0201-0500). An appropriate volume of reaction Mastermix was prepared with the following composition: 20% v/v BsaI (New England BioLabs R3733S) or BbsI (Thermo Scientific ER1012), 8% v/v T4 DNA ligase HC (Promega M1794), 20% v/v T4 DNA ligase buffer (Promega), 52% v/v nuclease-free water. This Mastermix was transferred to a Labcyte Echo 384 LDV plate (001-13070), along with an appropriate volume of each DNA part. For a five part assembly, 200 nL of each part (4 fmol) was transferred to an Eppendorf twin.tec 96-well PCR plate (951020427), along with 1 μL of Mastermix using a Labcyte Echo 525 acoustic liquid handler. The transfers were programmed using the Echo Plate Reformat software. After completion of transfer, the PCR plate was sealed with PCR film (VWR 60941-078) and the following reaction was carried out on a thermocycler: 37 °C for 90 s then 16 °C for three minutes cycled 25 times, followed by five minutes and 50 °C and 10 min at 80 °C. The plate was then transferred to an Eppendorf epMotion 5075t liquid handler, where the following operations were performed: 10 μL NEB 5-alpha Competent E. coli (C2987U) cells added to each well, shaken at 500 rpm for 15 s, incubated for 15 min in a block prefrozen at −20 °C, heat shocked at 42 °C for 30 s, moved back to cold block for 5 min, 100 μL SOC added, incubated at 37 °C for one hour. Subsequently, 10 μL of transformation mixture was transferred to unused wells of the original Echo 384 well plate, and that plate was transferred to the Echo 525 acoustic liquid handler. Transformed cells were transferred to prewarmed (37 °C) antibiotic selection media plates (OmniTray, Thermo Scientific 264728) in a pseudo-96 well pattern, with one 25 nL droplet per spot and 18 spots per pseudowell. Plates were incubated overnight at 37 °C and white colonies were picked. Positive colonies were confirmed for correct assembly by enzymatic digestion (with BbsI for level 1 assemblies) followed by gel electrophoresis band size analysis (Invitrogen G401001).

Transformation of Komagataeibacter nataicola

The method for transformation of K. nataicola was adapted from Florea et al.²⁴ A source plate of K. nataicola was streaked out on HS media, incubated for 3–4 days at 30 °C and then stored at RT for up to a month. A whole colony was picked from this plate and inoculated into a preculture of 10 mL HS media with 0.2% v/v cellulase (Sigma-Aldrich C2730) in a 125 mL flask. When grown on solid media, K. nataicola forms hard, connected networks, making the difference between a “whole colony” and a “small chunk” somewhat subjective. The preculture was incubated with shaking at 30 °C, 220 rpm for 2–3 days until quite cloudy (OD₆₀₀ ∼ 1–2). From this preculture, two 50 mL cultures (in 250 mL flasks) were inoculated at OD = 0.005 and 0.010. These flasks were incubated with shaking at 30 °C, 220 rpm overnight. The next day, the flask in the range of OD = 0.4–0.7 at the time of transformation was used. Prior to transformation, a swinging-bucket centrifuge was prechilled to 4 °C for at least 30 min, until the centrifuge cups were cold to the touch. Solutions of 1 mM HEPES (diluted from Fisher BP299) and 15% glycerol (Fisher BP229) were stored at 4 °C and transferred to ice buckets as the centrifuge was chilled. Cells were decanted into a 50 mL conical tube and transferred to ice for 10 min. From this step forward, all procedures were performed on ice. Cells were pelleted at 3000g for 5 min, and the supernatant was decanted and discarded. The pellet was washed twice in 10 mL HEPES with the following method: gently resuspend the pellet by tapping, resuspend in 1 mL using a P1000 (breaking up any clumps), resuspend in the remaining 9 mL using a 10 mL serological pipet, then pellet at 3000g for 5 min. During this these washes, 1 mm electroporation cuvettes (Molecular BioProducts 5510) were stored on ice and labeled, along with 0.2 mL PCR tubes (USA Scientific 1402-4700) for each transformation. Plasmid DNA (up to 200 ng, maximum volume 4 μL) was transferred to PCR tubes. The final washed pellet was resuspended in 1 mL ice-cold 15% glycerol, and 100 μL competent cell suspension was added to the DNA in the PCR tubes. Any remaining competent cells were aliquoted into PCR strips and stored at −80 °C for later use. The tubes were gently tapped to mix and briefly centrifuged to collect in the tube bottom, and then incubated on ice for 10 min. Each mixture was then transferred to the corresponding electroporation cuvette, which was dried and electroporated at 2.5 kV, 400 Ohm resistance, 25 μF capacitance. Recovery media (1 mL HS with 0.2% cellulase) was immediately added to the cuvette. Following all transformations, cells in recovery media were transferred to 14 mL round-bottom Falcon tubes and incubated with shaking at 30 °C, 220 rpm overnight. Transformation efficiency varied from construct to construct. Typically, 100 μL of recovered cells were spread on a 10 cm dish containing selection media and incubated at 30 °C for 3–4 days. If this procedure did not yield colonies, the transformation was repeated and the entire volume of transformed cells was centrifuged and resuspended in 200 μL HS with the appropriate antibiotic, then plated on selective media. Colonies were picked into 10 mL HS with 0.2% cellulase and the appropriate antibiotic, grown at 30 °C, 220 rpm until cloudy (typically 1–2 days but up to 4 for slow-growing strains), and preserved as glycerol stocks (500 μL cell culture plus 500 μL 50% glycerol for final glycerol concentration of 25%).

Transformation of Pseudomonas putida

The method for transformation of P. putida was adapted from the method described by Elmore et al.⁴⁹ A single colony was inoculated into 10 mL of LB in a 50 mL conical tube and incubated with agitation at 30 °C, 220 rpm overnight. The protocol was scaled up as needed by adding more tubes of 10 mL culture. The cell culture was pelleted at 3,200g for 10 min, and washed 3× with 5 mL of 10% v/v glycerol (room temperature). This pellet was resuspended in 200 μL of 10% glycerol per 10 mL starting culture. Aliquots of 50 μL in PCR strips were stored at −80 °C. At the time of transformation, aliquots were thawed at RT for 5 min, and 10 μL of these competent cells were diluted into 40 μL of 10% glycerol in PCR strips. Plasmid DNA was added to these cells (50–150 ng in 1–2 μL). Cells and DNA were mixed by flicking the tubes, which were then briefly spun down and incubated at RT for 5 min. The mixture was transferred to a 1 mm electroporation cuvette and electroporated at 1600 V. The time constant was typically 5–6 ms. SOC recovery media (250 μL) was immediately added to the cuvette following electroporation. The recovering cells were transferred to a 14 mL round-bottom Falcon tube and incubated at 30 °C, 220 rpm for 90 min. Following recovery, 5 μL of transformation mixture was added to a selective media plate and streaked out for single colonies. Plates were incubated overnight at 30 °C and single colonies were picked.

Transformation of Cupriavidus necator

The method for transformation of C. necator was adapted from a method used for P. putida by the lab of Adam Guss (Peabody and Guss, unpublished). A single colony of C. necator H16 was inoculated into 50 mL LB in a 250 mL shake flask for 30–48 h at 30 °C in an orbital shaker set to 220 rpm. All remaining steps were carried out room temperature. The culture was transferred to a 50 mL conical tube and pelleted at 3000g for 15 min. The supernatant was decanted and the cell pellet was gently resuspended in 25 mL 50 mM CaCl_2. The resuspended cells were incubated for 15 min. The cells were again pelleted at 3000g for 10 min, the supernatant was decanted, and the cell pellet was gently resuspended in 25 mL 10% glycerol. This wash step was repeated two more times. The cells were pelleted a final time, the supernatant was decanted, and the cell pellet was resuspended in 500 μL of 10% glycerol. The resulting electrocompetent cells were either used freshly or aliquoted (50 μL) and stored at −80 °C for later use as needed.

For transformation, cells were thawed at room temperature (as needed), and 50 μL of the cell suspension was mixed with approximately 100 ng DNA at room temperature. The cells were incubated with the DNA for 5 min. The mixture was then loaded into a 0.1 mm cuvette and electroporated at 1.6 kV. The cells were then quickly resuspended in 0.5 mL SOC with 20 mM fructose, transferred to a 14 mL round-bottom Falcon tube for 2–3 h for outgrowth at 30 °C with shaking, and plated on a LB with kanamycin at 200 μg/mL.

Flow Cytometry

The method for cell characterization by flow cytometry was adapted from Andrews et al.⁵⁰ For E. coli and P. putida, single colonies were picked into wells of a 96-well V-bottom plate (Thermo Fisher 249662) containing 100 μL LB with the appropriate antibiotic. This plate was incubated overnight with shaking at 1000 rpm, 37 °C for E. coli, 30 °C for P. putida. Cells were then diluted into fresh media (2 μL into 98 μL) in triplicate and grown for 6 h. From this culture, 10 μL was transferred into a plate containing 190 μL diH₂O with 2 mg/mL kanamycin. This plate was incubated at room temperature for 1 h and used directly for flow cytometry.

For C. necator and K. nataicola, single colonies were picked into 5 mL LB or HS (respectively) in a 50 mL conical tube and incubated with shaking at 30 °C, 220 rpm until quite cloudy. Cells were then diluted into 5 mL media in triplicate (5 μL for C. necator, 25 μL K. nataicola) and incubated until slightly cloudy. Cultures which became cloudy an hour or more after the majority of strains became cloudy were noted as containing a growth defect. From these culture, 10 μL was transferred into a plate containing 190 μL diH₂O with 2 mg/mL kanamycin. This plate was incubated at room temperature for 1 h and used directly for flow cytometry.

A Beckman Coulter CytoFLEX S flow cytometer was used with the following parameters: GFP channel configured using blue laser (488 nm, 50 mW) with 525/40 nm band-pass filter, gain 90. Gating thresholds FSC 1500 (gain 68) and SSC 1000 (gain 56). SpheroTech Rainbow Calibration particles (URCP-38-2K) and destination vector-only (pBBR1_DVK_AE) control were used for calibration and subsequent analysis. Fluorescent intensities were converted to MEFL using the FlowCal toolkit in a custom Python script.⁵¹

Statistical Analysis

Data visualizations and statistical analysis were performed in R using custom scripts available at https://github.com/emyounglab/openCIDAR/tree/main/flow_cytometry_analysis. The linear models reported in Figure 5 were constructed using the base linear model (lm) function, with promoters, RBS, and promoter*RBS included as the factors in the formula. The linear models were constructed from the subset of MEFL values greater than zero, which were subsequently log₁₀ transformed. A separate linear model was constructed for each species.

Figure 5.

Linear models for part performance across species. (A) General form of the linear models. Expression is the sum of an intercept term plus estimates computed for each promoter, RBS, and the interactions between them. Due to high correlation between variables (i.e., very similar expression between parts), some parameters were not estimated (see Methods). (B) Bar chart of the intercept values, interpreted as background fluorescence, were similar between species. (C) Bar chart of the promoter coefficients. The contribution of each promoter to expression had conserved rank order in each species, however the magnitudes varied. Notably, the expected very low expression of the J23103 promoter in E. coli was not conserved. (D) Bar chart of the RBS coefficients. Rank order of the RBS coefficients is not conserved between species. (E) Bar chart of the interaction terms between promoters and RBSs. Interactions between promoter and RBS terms were very high in K. nataicola relative to other species, especially for those terms including the J23100 promoter.

Differences in global mean expression between species was determined by a Tukey Honest Significant Difference test of a one-way ANOVA using R.

Plasmid Copy Number Determination by ddPCR

Cell cultures were grown to midexponential phase and frozen at −80 °C prior to analysis. Sample preparation was adapted from Jahn et al.⁵² Cell samples were thawed on ice and diluted into 1 mL nuclease-free water at 1:500 or 1:250 dilutions. From this diluted sample, 44 μL were transferred to PCR strips and boiled at 95 °C for 20 min for lysis. BsaI (1 μL) and 10× CutSmart buffer (5 μL) were added to each sample, and the plasmid and genomic DNA was digested at 37 °C for 30 min. Reaction mixtures were prepared by combining the following reagents per wells to BioRad ddPCR plates: 5.5 μL 4× ddPCR SuperMix; 4.4 μL lysed, digested sample; 1.1 μL each probe (5 μM stock) and primer (18 μM stock); and 5.5 μL nuclease-free water. The plate was heat-sealed in foil, vortexed vigorously and centrifuged briefly. Droplets were generated using the BioRad AutoDropletGenerator using the manufacturer’s recommended reagents and consumables. Droplets were read using a QX200 droplet reader with the QuantaSoft software and analyzed using the QX Manager Standard software.

Primers and probes were designed for single-copy genomic targets of each strain as well as the BBR1 rep protein. Genomic targets were labeled with the FAM fluorophore and BBR1 plasmid targets were labeled with the HEX fluorophore for multiplexing. The E. coli cysG, and P. putida ileS primer/probe sets were used as described by Jahn et al.⁵³ Primers and probes for the mutated BBR1 rep protein, C. necator panC target⁶ and the K. nataicola cysG target were designed using NCBI Primer-BLAST. Primer details are included in Table S3.

Glossary

Abbreviations

MEFL

molecules of equivalent fluorescein

ddPCR

droplet digital polymerase chain reaction.

Data Availability Statement

Digital data files related to this study are available from GitHub repository github.com/kevinwkeating/openCIDAR. Data available in this repository includes plasmid sequences, flow cytometry raw data and analysis scripts, and ddPCR analysis exports. Destination vectors and fluorescent reporter cassettes have been deposited with Addgene (Table S1).

Supporting Information Available

The Supporting Information is available free of charge at https://pubs.acs.org/doi/10.1021/acssynbio.3c00104.

• Plasmid maps of the destination vectors pBBR1_DVK_AE, pBBR1_DVC_AF and pBBR1_DVS_AF; antibiotic sensitivity data for the novel isolate Komagataeibacter nataicola DS12; supplementary statistical analysis, a list of all constructs generated through this work with corresponding Addgene numbers; a list of known hosts for the pBBR1 plasmid and derivates; and primer and probe information for ddPCR experiments (PDF)

Author Contributions

KWK designed the research, performed the experiments, and analyzed the data. EMY directed the research. KWK and EMY wrote the manuscript.

This work was supported by the IARPA Finding Engineering-Linked Indicators (FELIX) award HR0011-15-C-0084, a National Science Foundation Harnessing the Data Revolution award 1939860, and Massachusetts Life Sciences Center Building Breakthroughs and Open Capital awards. This document does not contain technology or technical data controlled under either U.S. International Traffic in Arms Regulation or U.S. Export Administration Regulations. KWK is supported by the National Science Foundation Harnessing the Data Revolution award 1939860.

The authors declare no competing financial interest.
