. 1995 May;68(5):1727–1739. doi: 10.1016/S0006-3495(95)80350-4

Restatement of order parameters in biomembranes: calculation of C-C bond order parameters from C-D quadrupolar splittings.

J P Douliez 1, A Léonard 1, E J Dufourc 1
PMCID: PMC1282076  PMID: 7612816

Abstract

An expression for the C-C bond order parameter, SCC, of membrane hydrocarbon chains has been derived from the observed C-D bond order parameters. It allows calculation of the probability of each of the C-C bond rotamers and, consequently, the number of gauche defects per chain as well as their projected average length onto the bilayer normal, thus affording the calculation of accurate hydrophobic bilayer thicknesses. The effect of temperature has been studied on dilauroyl-, dimyristoyl-, and dipalmitoylphosphatidylcholine (DLPC, DMPC, DPPC) membranes, as has the effect of cholesterol on DMPC. The salient results are as follows: 1) an odd-even effect is observed for the SCC versus carbon position, k, whose amplitude increases with temperature; 2) calculation of SCC, from nonequivalent deuterons on the sn-2 chain of lipids, SCC2, leads to negative values, indicating the tendency for the C1-C2 bond to be oriented parallel to the bilayer surface; this bond becomes more parallel to the surface as the temperature increases or when cholesterol is added; 3) calculation on the sn-2 chain length can be performed from C1 to Cn, where n is the number of carbon atoms in the chain, and leads to 10.4, 12.2, and 13.8 A for DLPC, DMPC, and DPPC close to the transition temperature, TC, of each of the systems and to 9.4, 10.9, and 12.6 for T-TC = 30-40 degrees C, respectively; 4) separation of intra- and intermolecular motions allows quantitation of the number of gauche defects per chain, which is equal to 1.9, 2.7, and 3.5 for DLPC, DMPC, and DPPC near TC and to 2.7, 3.5, and 4.4 at T-TC = 30-40 degrees C, respectively. Finally, the validity of our model is discussed and compared with previously published models.

Full text

PDF
1727

Selected References

These references are in PubMed. This may not be the complete list of references from this article.

  1. Casal H. L., McElhaney R. N. Quantitative determination of hydrocarbon chain conformational order in bilayers of saturated phosphatidylcholines of various chain lengths by Fourier transform infrared spectroscopy. Biochemistry. 1990 Jun 12;29(23):5423–5427. doi: 10.1021/bi00475a002. [DOI] [PubMed] [Google Scholar]
  2. Davis J. H. Deuterium magnetic resonance study of the gel and liquid crystalline phases of dipalmitoyl phosphatidylcholine. Biophys J. 1979 Sep;27(3):339–358. doi: 10.1016/S0006-3495(79)85222-4. [DOI] [PMC free article] [PubMed] [Google Scholar]
  3. Davis J. H. The description of membrane lipid conformation, order and dynamics by 2H-NMR. Biochim Biophys Acta. 1983 Mar 21;737(1):117–171. doi: 10.1016/0304-4157(83)90015-1. [DOI] [PubMed] [Google Scholar]
  4. Dufourc E. J., Mayer C., Stohrer J., Althoff G., Kothe G. Dynamics of phosphate head groups in biomembranes. Comprehensive analysis using phosphorus-31 nuclear magnetic resonance lineshape and relaxation time measurements. Biophys J. 1992 Jan;61(1):42–57. doi: 10.1016/S0006-3495(92)81814-3. [DOI] [PMC free article] [PubMed] [Google Scholar]
  5. Dufourc E. J., Smith I. C., Dufourcq J. Molecular details of melittin-induced lysis of phospholipid membranes as revealed by deuterium and phosphorus NMR. Biochemistry. 1986 Oct 21;25(21):6448–6455. doi: 10.1021/bi00369a016. [DOI] [PubMed] [Google Scholar]
  6. Dufourc E. J., Smith I. C., Jarrell H. C. A 2H-NMR analysis of dihydrosterculoyl-containing lipids in model membranes: structural effects of a cyclopropane ring. Chem Phys Lipids. 1983 Aug;33(2):153–177. doi: 10.1016/0009-3084(83)90019-1. [DOI] [PubMed] [Google Scholar]
  7. Dufourc E. J., Smith I. C., Jarrell H. C. Amphotericin and model membranes. The effect of amphotericin B on cholesterol-containing systems as viewed by 2H-NMR. Biochim Biophys Acta. 1984 Oct 3;776(2):317–329. doi: 10.1016/0005-2736(84)90221-9. [DOI] [PubMed] [Google Scholar]
  8. Engel A. K., Cowburn D. The origin of multiple quadrupole couplings in the deuterium NMR spectra of the 2 chain of 1,2 dipalmitoyl-sn-glycero-3-phosphorylcholine. FEBS Lett. 1981 Apr 20;126(2):169–171. doi: 10.1016/0014-5793(81)80233-5. [DOI] [PubMed] [Google Scholar]
  9. Hauser H., Pascher I., Pearson R. H., Sundell S. Preferred conformation and molecular packing of phosphatidylethanolamine and phosphatidylcholine. Biochim Biophys Acta. 1981 Jun 16;650(1):21–51. doi: 10.1016/0304-4157(81)90007-1. [DOI] [PubMed] [Google Scholar]
  10. Ipsen J. H., Mouritsen O. G., Bloom M. Relationships between lipid membrane area, hydrophobic thickness, and acyl-chain orientational order. The effects of cholesterol. Biophys J. 1990 Mar;57(3):405–412. doi: 10.1016/S0006-3495(90)82557-1. [DOI] [PMC free article] [PubMed] [Google Scholar]
  11. Léonard A., Dufourc E. J. Interactions of cholesterol with the membrane lipid matrix. A solid state NMR approach. Biochimie. 1991 Oct;73(10):1295–1302. doi: 10.1016/0300-9084(91)90092-f. [DOI] [PubMed] [Google Scholar]
  12. Marcelja S. Chain ordering in liquid crystals. II. Structure of bilayer membranes. Biochim Biophys Acta. 1974 Oct 29;367(2):165–176. doi: 10.1016/0005-2736(74)90040-6. [DOI] [PubMed] [Google Scholar]
  13. Mendelsohn R., Davies M. A., Schuster H. F., Xu Z. C., Bittman R. CD2 rocking modes as quantitative infrared probes of one-, two-, and three-bond conformational disorder in dipalmitoylphosphatidylcholine and dipalmitoylphosphatidylcholine/cholesterol mixtures. Biochemistry. 1991 Sep 3;30(35):8558–8563. doi: 10.1021/bi00099a010. [DOI] [PubMed] [Google Scholar]
  14. Oldfield E., Gilmore R., Glaser M., Gutowsky H. S., Hshung J. C., Kang S. Y., King T. E., Meadows M., Rice D. Deuterium nuclear magnetic resonance investigation of the effects of proteins and polypeptides on hydrocarbon chain order in model membrane systems. Proc Natl Acad Sci U S A. 1978 Oct;75(10):4657–4660. doi: 10.1073/pnas.75.10.4657. [DOI] [PMC free article] [PubMed] [Google Scholar]
  15. Oldfield E., Meadows M., Rice D., Jacobs R. Spectroscopic studies of specifically deuterium labeled membrane systems. Nuclear magnetic resonance investigation of the effects of cholesterol in model systems. Biochemistry. 1978 Jul 11;17(14):2727–2740. doi: 10.1021/bi00607a006. [DOI] [PubMed] [Google Scholar]
  16. Paddy M. R., Dahlquist F. W., Davis J. H., Bloom M. Dynamical and temperature-dependent effects of lipid-protein interactions. Application of deuterium nuclear magnetic resonance and electron paramagnetic resonance spectroscopy to the same reconstitutions of cytochrome c oxidase. Biochemistry. 1981 May 26;20(11):3152–3162. doi: 10.1021/bi00514a026. [DOI] [PubMed] [Google Scholar]
  17. Petersen N. O., Chan S. I. More on the motional state of lipid bilayer membranes: interpretation of order parameters obtained from nuclear magnetic resonance experiments. Biochemistry. 1977 Jun 14;16(12):2657–2667. doi: 10.1021/bi00631a012. [DOI] [PubMed] [Google Scholar]
  18. Schindler H., Seelig J. Deuterium order parameters in relation to thermodynamic properties of a phospholiped bilayer. A statistical mechanical interpretation. Biochemistry. 1975 Jun 3;14(11):2283–2287. doi: 10.1021/bi00682a001. [DOI] [PubMed] [Google Scholar]
  19. Seelig A., Seelig J. The dynamic structure of fatty acyl chains in a phospholipid bilayer measured by deuterium magnetic resonance. Biochemistry. 1974 Nov 5;13(23):4839–4845. doi: 10.1021/bi00720a024. [DOI] [PubMed] [Google Scholar]
  20. Seelig J. Deuterium magnetic resonance: theory and application to lipid membranes. Q Rev Biophys. 1977 Aug;10(3):353–418. doi: 10.1017/s0033583500002948. [DOI] [PubMed] [Google Scholar]
  21. Weisz K., Gröbner G., Mayer C., Stohrer J., Kothe G. Deuteron nuclear magnetic resonance study of the dynamic organization of phospholipid/cholesterol bilayer membranes: molecular properties and viscoelastic behavior. Biochemistry. 1992 Feb 4;31(4):1100–1112. doi: 10.1021/bi00119a019. [DOI] [PubMed] [Google Scholar]

Articles from Biophysical Journal are provided here courtesy of The Biophysical Society
