. 1978 Oct;283:605–619. doi: 10.1113/jphysiol.1978.sp012522

Histological analysis of cat muscle spindles following direct observation of the effects of stimulating dynamic and static motor axons.

R W Banks, D Barker, P Bessou, B Pagès, M J Stacey
PMCID: PMC1282798  PMID: 152810

Abstract

1. Eleven cat tenuissimus spindles have been analysed mainly by cutting serial, transverse, 1 micrometer thick sections following direct observation of the effects of dynamic motor (gamma or beta) stimulation. 2. Histological results from these spindles were also used to interpret the effects of static fusimotor stimulation of other spindles. 3. Dynamic motor stimulation usually produced contractions seen as convergent movements of sarcomeres in single bag fibres, identified as bag1 fibres for reasons given in the text. 4. In one spindle a single dynamic axon produced a translational movement in one pole of a bag1 fibre and a convergent movement in each pole of a bag2 fibre, together with movements in other unidentified (presumably chain) fibres. Subsequent analysis showed that besides innervating both bag fibres the axon also supplied two chain fibres. 5. Contrary to expectation, motor endings on the bag1 fibres seldom occurred at the sites of convergent movement. Only two cases of coincidence occurred among sixteen foci and twenty-one motor endings; otherwise focus and nearest ending were separated by distances of 0.85--2.5 mm. 6. Most of the convergent movements of sarcomeres observed in bag1 fibres occurred in a region of the pole that is ultrastructurally distinct from the region where most of the motor endings were located. The possible relevance of this to the production of contractions in the bag1 fibre is discussed. 7. Convergent movement foci in bag2 fibres produced by the stimulation of static axons occurred largely within the same regions of the pole as the motor endings were located, though, whereas foci were observed in both intra- and extracapsular regions, most of the endings were intracapsular.

Full text

PDF
605

Selected References

These references are in PubMed. This may not be the complete list of references from this article.

  1. Banks R. W., Barker D., Bessou P., Pagès B., Stacey M. J. Serial-section analysis of cat muscle spindles following observation of the effects of stimulating dynamic fusimotor axons [proceedings]. J Physiol. 1976 Dec;263(1):180P–181P. [PubMed] [Google Scholar]
  2. Banks R. W., Barker D., Harker D. W., Stacey M. J. Proceedings Correlation between ultrastructure and histochemistry of mammalian intrafusal muscle fibres. J Physiol. 1975 Nov;252(2):16P–17P. [PMC free article] [PubMed] [Google Scholar]
  3. Banks R. W., Harker D. W., Stacey M. J. A study of mammalian intrafusal muscle fibres using a combined histochemical and ultrastructural technique. J Anat. 1977 Jul;123(Pt 3):783–796. [PMC free article] [PubMed] [Google Scholar]
  4. Barker D., Banks R. W., Harker D. W., Milburn A., Stacey M. J. Studies of the histochemistry, ultrastructure, motor innervation, and regeneration of mammalian intrafusal muscle fibres. Prog Brain Res. 1976;44:67–88. doi: 10.1016/s0079-6123(08)60724-4. [DOI] [PubMed] [Google Scholar]
  5. Barker D., Bessou P., Jankowska E., Pagès B., Stacey M. J. Identification of intrafusal muscle fibres activated by single fusimotor axons and injected with fluorescent dye in cat tenuissimus spindles. J Physiol. 1978 Feb;275:149–165. doi: 10.1113/jphysiol.1978.sp012182. [DOI] [PMC free article] [PubMed] [Google Scholar]
  6. Barker D., Emonet-Dénand F., Harker D. W., Jami L., Laporte Y. Distribution of fusimotor axons to intrafusal muscle fibres in cat tenuissimus spindles as determined by the glycogen-depletion method. J Physiol. 1976 Sep;261(1):49–69. doi: 10.1113/jphysiol.1976.sp011548. [DOI] [PMC free article] [PubMed] [Google Scholar]
  7. Barker D., Emonet-Dénand F., Harker D. W., Jami L., Laporte Y. Types of intra- and extrafusal muscle fibre innervated by dynamic skeleto-fusimotor axons in cat peroneus brevis and tenuissimus muscles, as determined by the glycogen-depletion method. J Physiol. 1977 Apr;266(3):713–726. doi: 10.1113/jphysiol.1977.sp011789. [DOI] [PMC free article] [PubMed] [Google Scholar]
  8. Bessou P., Emonet-Dénand F., Laporte Y. Motor fibres innervating extrafusal and intrafusal muscle fibres in the cat. J Physiol. 1965 Oct;180(3):649–672. doi: 10.1113/jphysiol.1965.sp007722. [DOI] [PMC free article] [PubMed] [Google Scholar]
  9. Bessou P., Pagès B. Intracellular potentials from intrafusal muscle fibers evoked by stimulation of static and dynamic fusimotor axons in the cat. J Physiol. 1972 Dec;227(3):709–727. doi: 10.1113/jphysiol.1972.sp010055. [DOI] [PMC free article] [PubMed] [Google Scholar]
  10. Bessou P., Pagés B. Cinematographic analysis of contractile events produced in intrafusal muscle fibres by stimulation of static and dynamic fusimotor axons. J Physiol. 1975 Nov;252(2):397–427. doi: 10.1113/jphysiol.1975.sp011150. [DOI] [PMC free article] [PubMed] [Google Scholar]
  11. Boyd I. A., Gladden M. H., McWilliam P. N., Ward J. Control of dynamic and static nuclear bag fibres and nuclear chain fibres by gamma and beta axons in isolated cat muscle spindels. J Physiol. 1977 Feb;265(1):133–162. doi: 10.1113/jphysiol.1977.sp011709. [DOI] [PMC free article] [PubMed] [Google Scholar]
  12. Boyd I. A., Gladden M. H., McWilliam P. N., Ward J. Static and dynamic fusimotor action in isolated cat muscle spindles with intact nerve and blood supply. J Physiol. 1973 Apr;230(1):29P–30P. [PubMed] [Google Scholar]
  13. Boyd I. A. The response of fast and slow nuclear bag fibres and nuclear chain fibres in isolated cat muscle spindles to fusimotor stimulation, and the effect of intrafusal contraction on the sensory endings. Q J Exp Physiol Cogn Med Sci. 1976 Jul;61(3):203–254. doi: 10.1113/expphysiol.1976.sp002354. [DOI] [PubMed] [Google Scholar]
  14. Boyd I. A., Ward J. Motor control of nuclear bag and nuclear chain intrafusal fibres in isolated living muscle spindles from the cat. J Physiol. 1975 Jan;244(1):83–112. doi: 10.1113/jphysiol.1975.sp010785. [DOI] [PMC free article] [PubMed] [Google Scholar]
  15. Emonet-Dénand F., Laporte Y., Matthews P. B., Petit J. On the subdivision of static and dynamic fusimotor actions on the primary ending of the cat muscle spindle. J Physiol. 1977 Jul;268(3):827–861. doi: 10.1113/jphysiol.1977.sp011884. [DOI] [PMC free article] [PubMed] [Google Scholar]
  16. HUXLEY A. F., PEACHEY L. D. The maximum length for contraction in vertebrate straiated muscle. J Physiol. 1961 Apr;156:150–165. doi: 10.1113/jphysiol.1961.sp006665. [DOI] [PMC free article] [PubMed] [Google Scholar]
  17. Harker D. W., Jami L., Laporte Y., Petit J. Fast-conducting skeletofusimotor axons supplying intrafusal chain fibers in the cat peroneus tertius muscle. J Neurophysiol. 1977 Jul;40(4):791–799. doi: 10.1152/jn.1977.40.4.791. [DOI] [PubMed] [Google Scholar]
  18. Hess A. Vertebrate slow muscle fibers. Physiol Rev. 1970 Jan;50(1):40–62. doi: 10.1152/physrev.1970.50.1.40. [DOI] [PubMed] [Google Scholar]
  19. KOKETSU K., NISHI S. An analysis of junctional potentials of intrafusal muscle fibres in frogs. J Physiol. 1957 Nov 14;139(1):15–26. doi: 10.1113/jphysiol.1957.sp005871. [DOI] [PMC free article] [PubMed] [Google Scholar]
