. 1980 Jun;303:441–474. doi: 10.1113/jphysiol.1980.sp013298

Characterization of the electrogenic sodium pump in cardiac Purkinje fibres

D A Eisner 1,*, W J Lederer 1,†
PMCID: PMC1282904  PMID: 7431244

Abstract

1. The Na pump is examined in sheep cardiac Purkinje fibres using a two micro-electrode voltage clamp technique.

2. After reducing the external K concentration, [K]o, to zero for 2 min or more, subsequent addition of an `activator cation' (known to activate the Na pump in other preparations) produces a transient increase of outward current. This outward current transient is abolished by 10-5 M-strophanthidin (cf. Gadsby & Cranefield, 1979a).

3. It is concluded that this transient increase of outward current is a result of a transient stimulation of the sodium pump by the raised [Na]i following exposure to 0-Ko. Although this current transient may reflect the activity of an electrogenic Na pump, it is difficult to use K as the activator cation to establish this point. This is due to the extracellular K depletion that occurs during Na pump reactivation and the subsequent change that this K depletion produces in the current—voltage relationship of the Purkinje fibre.

4. Rbo or Cso have been used instead of Ko to reactivate the Na pump when examining the transient increase of outward current. On adding either of these cations after exposing a preparation to a solution without such `activator cations', the outward current transient is relatively voltage independent over a wide range of potentials (-90 to +10 mV). It is concluded that, following the addition of Rbo or Cso, the transient increase of outward current is a direct measure of the transient increase of the electrogenic Na pump current.

5. Increasing [Rb]o or [Cs]o over the range of 0-40 mM increases the rate of decay of the electrogenic Na pump current transient. Using a simple model (cf. Rang & Ritchie, 1968), it is shown that the decay rate constant of the electrogenic Na pump current transient is a good measure of the degree of activation of the external site of the Na pump. At a given concentration of activator cation, Rbo produces a greater activation of the Na pump than does Cso. The K0.5 for Rbo is 6.3 mM and for Cso is 14.2 mM. Lio activates the Na pump more weakly than Rbo and Cso.

6. The coupling ratio of the Na pump is shown to be independent of Rbo or Cso over the range 2-40 mM. Furthermore, consistent with the results of Gadsby & Cranefield (1979a), the coupling ratio is independent of Nai over the range considered.

7. The Q10 for the electrogenic Na pump current transient varies between 1.6 and 2.3 over the range of temperature 26-46 °C.

8. A maximum Na pump current of about 0.78 μA cm-2 is obtained. Assuming a coupling ratio of 3Na/2K, the rate of Na ion transport into the cell is estimated to be about 23 p-mole cm-2 sec-1. Assuming a Na pump turnover of 150 sec-1, we estimate that there are about 1000 Na pump sites per μm2 of cell surface.

9. We conclude that the electrogenic Na pump current transient provides a good measure of the activity of the Na pump when Rb or Cs are used as `activator cations'. This measure can be used in the intact preparation to investigate the relationship between Na pump rate and other cellular events such as the regulation of tension (Eisner & Lederer, 1980).

Full text

PDF
441

Selected References

These references are in PubMed. This may not be the complete list of references from this article.

  1. Baker P. F., Blaustein M. P., Keynes R. D., Manil J., Shaw T. I., Steinhardt R. A. The ouabain-sensitive fluxes of sodium and potassium in squid giant axons. J Physiol. 1969 Feb;200(2):459–496. doi: 10.1113/jphysiol.1969.sp008703. [DOI] [PMC free article] [PubMed] [Google Scholar]
  2. Baker P. F., Connelly C. M. Some properties of the external activation site of the sodium pump in crab nerve. J Physiol. 1966 Jul;185(2):270–297. doi: 10.1113/jphysiol.1966.sp007987. [DOI] [PMC free article] [PubMed] [Google Scholar]
  3. Baker P. F., Willis J. S. Potassium ions and the binding of cardiac glycosides to mammalian cells. Nature. 1970 May 9;226(5245):521–523. doi: 10.1038/226521a0. [DOI] [PubMed] [Google Scholar]
  4. Baumgarten C. M., Isenberg G. Depletion and accumulation of potassium in the extracellular clefts of cardiac Purkinje fibers during voltage clamp hyperpolarization and depolarization. Pflugers Arch. 1977 Mar 11;368(1-2):19–31. doi: 10.1007/BF01063450. [DOI] [PubMed] [Google Scholar]
  5. Beaugé L. A., Sjodin R. A. An analysis of the influence of membrane potential and metabolic poisoning with azide on the sodium pump in skeletal muscle. J Physiol. 1976 Dec;263(3):383–403. doi: 10.1113/jphysiol.1976.sp011636. [DOI] [PMC free article] [PubMed] [Google Scholar]
  6. Brinley F. J., Jr, Mullins L. J. Effects of membrane potential on sodium and potassium fluxes in squid axons. Ann N Y Acad Sci. 1974;242(0):406–433. doi: 10.1111/j.1749-6632.1974.tb19106.x. [DOI] [PubMed] [Google Scholar]
  7. Casteels R., Droogmans G., Hendrickx H. Electrogenic sodium pump in smooth muscle cells of the guinea-pig's taenia coli. J Physiol. 1971 Sep;217(2):297–313. doi: 10.1113/jphysiol.1971.sp009572. [DOI] [PMC free article] [PubMed] [Google Scholar]
  8. Cohen I., Daut J., Noble D. An analysis of the actions of low concentrations of ouabain on membrane currents in Purkinje fibres. J Physiol. 1976 Aug;260(1):75–103. doi: 10.1113/jphysiol.1976.sp011505. [DOI] [PMC free article] [PubMed] [Google Scholar]
  9. Cohen I., Daut J., Noble D. The effects of potassium and temperature on the pace-maker current, iK2, in Purkinje fibres. J Physiol. 1976 Aug;260(1):55–74. doi: 10.1113/jphysiol.1976.sp011504. [DOI] [PMC free article] [PubMed] [Google Scholar]
  10. Cotterrell D., Whittam R. The influence of the chloride gradient across red cell membranes on sodium and potassium movements. J Physiol. 1971 May;214(3):509–536. doi: 10.1113/jphysiol.1971.sp009446. [DOI] [PMC free article] [PubMed] [Google Scholar]
  11. DECK K. A., KERN R., TRAUTWEIN W. VOLTAGE CLAMP TECHNIQUE IN MAMMALIAN CARDIAC FIBRES. Pflugers Arch Gesamte Physiol Menschen Tiere. 1964 Jun 9;280:50–62. doi: 10.1007/BF00412615. [DOI] [PubMed] [Google Scholar]
  12. Deitmer J. W., Ellis D. The intracellular sodium activity of cardiac Purkinje fibres during inhibition and re-activation of the Na-K pump. J Physiol. 1978 Nov;284:241–259. doi: 10.1113/jphysiol.1978.sp012539. [DOI] [PMC free article] [PubMed] [Google Scholar]
  13. Dudel J., Peper K., Rüdel R., Trautwein W. The potassium component of membrane current in Purkinje fibers. Pflugers Arch Gesamte Physiol Menschen Tiere. 1967;296(4):308–327. doi: 10.1007/BF00362531. [DOI] [PubMed] [Google Scholar]
  14. Eisner D. A., Lederer W. J. Inotropic and arrhythmogenic effects of potassium-depleted solutions on mammalian cardiac muscle. J Physiol. 1979 Sep;294:255–277. doi: 10.1113/jphysiol.1979.sp012929. [DOI] [PMC free article] [PubMed] [Google Scholar]
  15. Eisner D. A., Lederer W. J. The relationship between sodium pump activity and twitch tension in cardiac Purkinje fibres. J Physiol. 1980 Jun;303:475–494. doi: 10.1113/jphysiol.1980.sp013299. [DOI] [PMC free article] [PubMed] [Google Scholar]
  16. Eisner D. A., Lederer W. J. The role of the sodium pump in the effects of potassium-depleted solutions on mammalian cardiac muscle. J Physiol. 1979 Sep;294:279–301. doi: 10.1113/jphysiol.1979.sp012930. [DOI] [PMC free article] [PubMed] [Google Scholar]
  17. Ellis D. The effects of external cations and ouabain on the intracellular sodium activity of sheep heart Purkinje fibres. J Physiol. 1977 Dec;273(1):211–240. doi: 10.1113/jphysiol.1977.sp012090. [DOI] [PMC free article] [PubMed] [Google Scholar]
  18. Erdmann E., Bolte H. D., Lüderitz B. The (Na + + K + )-ATPase activity of guinea pig heart muscle in potassium deficiency. Arch Biochem Biophys. 1971 Jul;145(1):121–125. doi: 10.1016/0003-9861(71)90017-8. [DOI] [PubMed] [Google Scholar]
  19. Gadsby D. C., Cranefield P. F. Direct measurement of changes in sodium pump current in canine cardiac Purkinje fibers. Proc Natl Acad Sci U S A. 1979 Apr;76(4):1783–1787. doi: 10.1073/pnas.76.4.1783. [DOI] [PMC free article] [PubMed] [Google Scholar]
  20. Gadsby D. C., Cranefield P. F. Electrogenic sodium extrusion in cardiac Purkinje fibers. J Gen Physiol. 1979 Jun;73(6):819–837. doi: 10.1085/jgp.73.6.819. [DOI] [PMC free article] [PubMed] [Google Scholar]
  21. Glitsch H. G. Activation of the electrogenic sodium pump in guinea-pig auricles by internal sodium ions. J Physiol. 1972 Feb;220(3):565–582. doi: 10.1113/jphysiol.1972.sp009723. [DOI] [PMC free article] [PubMed] [Google Scholar]
  22. Glitsch H. G., Grabowski W., Thielen J. Activation of the electrogenic sodium pump in guinea-pig atria by external potassium ions. J Physiol. 1978 Mar;276:515–524. doi: 10.1113/jphysiol.1978.sp012250. [DOI] [PMC free article] [PubMed] [Google Scholar]
  23. HODGKIN A. L., KEYNES R. D. Active transport of cations in giant axons from Sepia and Loligo. J Physiol. 1955 Apr 28;128(1):28–60. doi: 10.1113/jphysiol.1955.sp005290. [DOI] [PMC free article] [PubMed] [Google Scholar]
  24. Hiraoka M., Hecht H. H. Recovery from hypothermia in cardiac Purkinje fibers: considerations for an electrogenic mechanism. Pflugers Arch. 1973 Mar 5;339(1):25–36. doi: 10.1007/BF00586979. [DOI] [PubMed] [Google Scholar]
  25. Isenberg G. Cardiac Purkinje fibres: resting, action, and pacemaker potential under the influence of [Ca2+]i as modified by intracellular injection techniques. Pflugers Arch. 1977 Oct 19;371(1-2):51–59. doi: 10.1007/BF00580772. [DOI] [PubMed] [Google Scholar]
  26. Isenberg G., Trautwein W. The effect of dihydro-ouabain and lithium-ions on the outward current in cardiac Purkinje fibers. Evidence for electrogenicity of active transport. Pflugers Arch. 1974;350(1):41–54. doi: 10.1007/BF00586737. [DOI] [PubMed] [Google Scholar]
  27. Isnberg G. Is potassium conductance of cardiac Purkinje fibres controlled by (Ca2+)? Nature. 1975 Jan 24;253(5489):273–274. doi: 10.1038/253273a0. [DOI] [PubMed] [Google Scholar]
  28. KASSEBAUM D. G. Electrophysiological effects of strophanthin in the heart. J Pharmacol Exp Ther. 1963 Jun;140:329–338. [PubMed] [Google Scholar]
  29. Kononenko N. I., Kostyuk P. G. Further studies of the potential-dependence of the sodium-induced membrane current in snail neurones. J Physiol. 1976 Apr;256(3):601–615. doi: 10.1113/jphysiol.1976.sp011341. [DOI] [PMC free article] [PubMed] [Google Scholar]
  30. Lambert J. D., Kerkut G. A., Walker R. J. The electrogenic sodium pump and membrane potential of identified neurones in Helix aspersa. Comp Biochem Physiol A Comp Physiol. 1974 Mar 1;47(3):897–916. doi: 10.1016/0300-9629(74)90465-4. [DOI] [PubMed] [Google Scholar]
  31. Lederer W. J., Spindler A. J., Eisner D. A. Thick slurry bevelling: a new technique for bevelling extremely fine microelectrodes and micropipettes. Pflugers Arch. 1979 Sep;381(3):287–288. doi: 10.1007/BF00583261. [DOI] [PubMed] [Google Scholar]
  32. Lieberman E. M. Effect of external potassium on the coupled sodium: potassium transport ratio of axons. Pflugers Arch. 1979 Jan 31;378(3):243–249. doi: 10.1007/BF00592742. [DOI] [PubMed] [Google Scholar]
  33. MUELLER P. POTASSIUM AND RUBIDIUM EXCHANGE ACROSS THE SURFACE MEMBRANE OF CARDIAC PURKINJE FIBRES. J Physiol. 1965 Apr;177:453–462. doi: 10.1113/jphysiol.1965.sp007604. [DOI] [PMC free article] [PubMed] [Google Scholar]
  34. Marmor M. F. The independence of electrogenic sodium transport and membrane potential in a molluscan neurone. J Physiol. 1971 Nov;218(3):599–608. doi: 10.1113/jphysiol.1971.sp009635. [DOI] [PMC free article] [PubMed] [Google Scholar]
  35. McAllister R. E., Noble D. The time and voltage dependence of the slow outward current in cardiac Purkinje fibres. J Physiol. 1966 Oct;186(3):632–662. doi: 10.1113/jphysiol.1966.sp008060. [DOI] [PMC free article] [PubMed] [Google Scholar]
  36. McCall D. Cation exchange and glycoside binding in cultured rat heart cells. Am J Physiol. 1979 Jan;236(1):C87–C95. doi: 10.1152/ajpcell.1979.236.1.C87. [DOI] [PubMed] [Google Scholar]
  37. Mobley B. A., Page E. The surface area of sheep cardiac Purkinje fibres. J Physiol. 1972 Feb;220(3):547–563. doi: 10.1113/jphysiol.1972.sp009722. [DOI] [PMC free article] [PubMed] [Google Scholar]
  38. Noma A., Irisawa H. Contribution of an electrogenic sodium pump to the membrane potential in rabbit sinoatrial node cells. Pflugers Arch. 1975 Aug 12;358(4):289–301. doi: 10.1007/BF00580527. [DOI] [PubMed] [Google Scholar]
  39. PAGE E., STORN S. R. CAT HEART MUSCLE IN VITRO. 8. ACTIVE TRANSPORT OF SODIUM IN PAPILLARY MUSCLES. J Gen Physiol. 1965 May;48:957–972. doi: 10.1085/jgp.48.5.957. [DOI] [PMC free article] [PubMed] [Google Scholar]
  40. Rang H. P., Ritchie J. M. On the electrogenic sodium pump in mammalian non-myelinated nerve fibres and its activation by various external cations. J Physiol. 1968 May;196(1):183–221. doi: 10.1113/jphysiol.1968.sp008502. [DOI] [PMC free article] [PubMed] [Google Scholar]
  41. Sachs J. R. Interaction of external K, Na, and cardioactive steroids with the Na-K pump of the human red blood cell. J Gen Physiol. 1974 Feb;63(2):123–143. doi: 10.1085/jgp.63.2.123. [DOI] [PMC free article] [PubMed] [Google Scholar]
  42. Siegelbaum S. A., Tsien R. W., Kass R. S. Role of intracellular calcium in the transient outward current of calf Purkinje fibres. Nature. 1977 Oct 13;269(5629):611–613. doi: 10.1038/269611a0. [DOI] [PubMed] [Google Scholar]
  43. Tamai T., Kagiyama S. Studies of cat heart muscle during recovery after prolonged hypothermia. Hyperpolarization of cell membranes and its dependence on the sodium pump with electrogenic characteristics. Circ Res. 1968 Mar;22(3):423–433. doi: 10.1161/01.res.22.3.423. [DOI] [PubMed] [Google Scholar]
  44. Thomas R. C. Electrogenic sodium pump in nerve and muscle cells. Physiol Rev. 1972 Jul;52(3):563–594. doi: 10.1152/physrev.1972.52.3.563. [DOI] [PubMed] [Google Scholar]
  45. Vassalle M. Electrogenic suppression of automaticity in sheep and dog purkinje fibers. Circ Res. 1970 Sep;27(3):361–377. doi: 10.1161/01.res.27.3.361. [DOI] [PubMed] [Google Scholar]
  46. Whittam R., Ager M. E. Vectorial aspects of adenosine-triphosphatase activity in erythrocyte membranes. Biochem J. 1964 Nov;93(2):337–348. doi: 10.1042/bj0930337. [DOI] [PMC free article] [PubMed] [Google Scholar]
  47. den Hertog A., Ritchie J. M. A comparison of the effect of temperature, metabolic inhibitors and of ouabain on the electrogenic componen of the sodium pump in mammalian non-myelinated nerve fibres. J Physiol. 1969 Oct;204(3):523–538. doi: 10.1113/jphysiol.1969.sp008929. [DOI] [PMC free article] [PubMed] [Google Scholar]
  48. den Hertog A. Some further observations on the electrogenic sodium pump in non-myelinated nerve fibres. J Physiol. 1973 Jun;231(3):493–509. doi: 10.1113/jphysiol.1973.sp010245. [DOI] [PMC free article] [PubMed] [Google Scholar]
