The Journal of Physiology logoLink to The Journal of Physiology
. 1971 Jun;215(2):353–380. doi: 10.1113/jphysiol.1971.sp009474

The time course of minimal excitatory post-synaptic potentials evoked in spinal motoneurones by group la afferent fibres

J J B Jack, S Miller, R Porter, S J Redman
PMCID: PMC1331888  PMID: 5145723

Abstract

1. Group Ia EPSPs were recorded from lumbosacral motoneurones in anaesthetized cats after almost complete section of the relevant dorsal roots. The EPSPs were usually of small amplitude (median value of 230 μV) and an averaging device was used to improve the definition of their time course.

2. From a total of over 500 averaged EPSPs a smaller number (342) were subjected to analysis. The other EPSPs were rejected either because they showed signs of multiple origin in the rising phase of their time course (see Methods) or because the resting membrane potential of the cell was less than 50 mV. All the selected EPSPs had their rise time (from the 10 to the 90% level) and half-width measured, and a semilogarithmic plot of their decay time course was made.

3. 252 of the EPSPs showed an exponential decline in their later time course and the slope of this line was used to give an estimate of the membrane time constant. The range of the time constant for different motoneurones was 2·3-12·9 msec, with a mean value of 5·8 msec.

4. In ten cells an EPSP was recorded which was judged to be generated exclusively by synaptic knobs located on the soma. On this assumption measurements of the normalized rise time, half-width and break point time were used to estimate α, ρ∞ and L by the method suggested in Jack & Redman (1971b).

The estimated value of α ranged from 18 to 65. A positive correlation was found between α and τm, indicating that for these EPSPs the duration of current injection was independent of the membrane time constant. The peak time of the wave form of current injection was between 0·1 and 0·25 msec.

The estimates of ρ∞ were not thought to be very accurate. A lower limit of 4 was assumed and the highest measured value was 12, but in three cells the time course of the EPSP could not be fitted even with a very high value of ρ∞. Some possible explanations for this discrepancy are mentioned in the Discussion.

The electrotonic length of the dendrites (L) was usually greater than 1·0 λ and ranged between 0·75 and 1·5 λ. Evidence for an open-circuit termination of the dendrites was found in some cells.

5. The normalized values of the rise time and half-width were used to make an electrotonic distance allocation to the 246 EPSPs which were judged to be non-somatic. The method of allocation was not precise because individual values of ρ∞ and L were not available for these motoneurones. Instead, a maximum possible range was assumed: for ρ∞, 4-25; for L, 0·75-1·5. The range of α was also assumed, from 12 to 100. With these values the motoneurone model (Jack & Redman, 1971b) was used to set limits within which the normalized rise time and half-width of all EPSPs, generated by current at a single point, should lie. Twenty of the 246 EPSPs lay outside these boundary lines and hence they did not receive a distance allocation. The remaining 226 were assigned values between 0·2 and 1·6 λ (in 0·2 λ steps); the majority of the allocations (183) were to the proximal electrotonic part of the dendrites (0·2, 0·4 or 0·6 λ).

The relationship of these distance allocations to the histological results of Conradi (1969) is discussed.

6. It is concluded that there is no good evidence against the view that the main time course of minimal Ia EPSPs can be explained by their generation by a brief pulse of synaptic current and subsequent passive spread.

Full text

PDF
353

Selected References

These references are in PubMed. This may not be the complete list of references from this article.

  1. Burke R. E. Composite nature of the monosynaptic excitatory postsynaptic potential. J Neurophysiol. 1967 Sep;30(5):1114–1137. doi: 10.1152/jn.1967.30.5.1114. [DOI] [PubMed] [Google Scholar]
  2. Burke R. E. Group Ia synaptic input to fast and slow twitch motor units of cat triceps surae. J Physiol. 1968 Jun;196(3):605–630. doi: 10.1113/jphysiol.1968.sp008526. [DOI] [PMC free article] [PubMed] [Google Scholar]
  3. CURTIS D. R., ECCLES J. C. The time courses of excitatory and inhibitory synaptic actions. J Physiol. 1959 Mar 12;145(3):529–546. doi: 10.1113/jphysiol.1959.sp006159. [DOI] [PMC free article] [PubMed] [Google Scholar]
  4. ECCLES J. C. Membrane time constants of cat motoneurons and time courses of synptic action. Exp Neurol. 1961 Jul;4:1–22. doi: 10.1016/0014-4886(61)90074-7. [DOI] [PubMed] [Google Scholar]
  5. Eisenberg R. S., Engel E. The spatial variation of membrane potential near a small source of current in a spherical cell. J Gen Physiol. 1970 Jun;55(6):736–757. doi: 10.1085/jgp.55.6.736. [DOI] [PMC free article] [PubMed] [Google Scholar]
  6. Illis L. The relative densities of monosynaptic pathways to the cell bodies and dendrites of the cat ventral horn. J Neurol Sci. 1967 Mar-Apr;4(2):259–270. doi: 10.1016/0022-510x(67)90104-9. [DOI] [PubMed] [Google Scholar]
  7. Ito M., Oshima T. Electrical behaviour of the motoneurone membrane during intracellularly applied current steps. J Physiol. 1965 Oct;180(3):607–635. doi: 10.1113/jphysiol.1965.sp007720. [DOI] [PMC free article] [PubMed] [Google Scholar]
  8. Jack J. J., Redman S. J. An electrical description of the motoneurone, and its application to the analysis of synaptic potentials. J Physiol. 1971 Jun;215(2):321–352. doi: 10.1113/jphysiol.1971.sp009473. [DOI] [PMC free article] [PubMed] [Google Scholar]
  9. Jack J. J., Redman S. J. The propagation of transient potentials in some linear cable structures. J Physiol. 1971 Jun;215(2):283–320. doi: 10.1113/jphysiol.1971.sp009472. [DOI] [PMC free article] [PubMed] [Google Scholar]
  10. KUNO M. QUANTAL COMPONENTS OF EXCITATORY SYNAPTIC POTENTIALS IN SPINAL MOTONEURONES. J Physiol. 1964 Dec;175:81–99. doi: 10.1113/jphysiol.1964.sp007504. [DOI] [PMC free article] [PubMed] [Google Scholar]
  11. Kuno M., Miyahara J. T. Analysis of synaptic efficacy in spinal motoneurones from 'quantum' aspects. J Physiol. 1969 Apr;201(2):479–493. doi: 10.1113/jphysiol.1969.sp008768. [DOI] [PMC free article] [PubMed] [Google Scholar]
  12. Mendell L. M., Henneman E. Terminals of single Ia fibers: distribution within a pool of 300 homonymous motor neurons. Science. 1968 Apr 5;160(3823):96–98. doi: 10.1126/science.160.3823.96. [DOI] [PubMed] [Google Scholar]
  13. Nelson P. G., Lux H. D. Some electrical measurements of motoneuron parameters. Biophys J. 1970 Jan;10(1):55–73. doi: 10.1016/S0006-3495(70)86285-3. [DOI] [PMC free article] [PubMed] [Google Scholar]
  14. Porter R., Hore J. Time course of minimal corticomotoneuronal excitatory postsynaptic potentials in lumbar motoneurons of the monkey. J Neurophysiol. 1969 May;32(3):443–451. doi: 10.1152/jn.1969.32.3.443. [DOI] [PubMed] [Google Scholar]
  15. RALL W. Branching dendritic trees and motoneuron membrane resistivity. Exp Neurol. 1959 Nov;1:491–527. doi: 10.1016/0014-4886(59)90046-9. [DOI] [PubMed] [Google Scholar]
  16. Rall W., Burke R. E., Smith T. G., Nelson P. G., Frank K. Dendritic location of synapses and possible mechanisms for the monosynaptic EPSP in motoneurons. J Neurophysiol. 1967 Sep;30(5):1169–1193. doi: 10.1152/jn.1967.30.5.1169. [DOI] [PubMed] [Google Scholar]
  17. Rall W. Distinguishing theoretical synaptic potentials computed for different soma-dendritic distributions of synaptic input. J Neurophysiol. 1967 Sep;30(5):1138–1168. doi: 10.1152/jn.1967.30.5.1138. [DOI] [PubMed] [Google Scholar]
  18. Sterling P., Kuypers H. G. Anatomical organization of the brachial spinal cord of the cat. I. The distribution of dorsal root fibers. Brain Res. 1967 Feb;4(1):1–15. doi: 10.1016/0006-8993(67)90144-8. [DOI] [PubMed] [Google Scholar]
  19. Sterling P., Kuypers H. G. Anatomical organization of the brachial spinal cord of the cat. II. The motoneuron plexus. Brain Res. 1967 Feb;4(1):16–32. doi: 10.1016/0006-8993(67)90145-x. [DOI] [PubMed] [Google Scholar]
