. 1999 Mar;89(3):374–378. doi: 10.2105/ajph.89.3.374

A deviation bar chart for detecting dengue outbreaks in Puerto Rico.

J G Rigau-Pérez 1, P S Millard 1, D R Walker 1, C C Deseda 1, A Casta-Vélez 1
PMCID: PMC1508601  PMID: 10076488

Abstract

OBJECTIVES: A Centers for Disease Control and Prevention deviation bar chart (Statistical Software for Public Health Surveillance) and laboratory-based surveillance data were evaluated for their utility in detecting dengue outbreaks in Puerto Rico. METHODS: A significant increase in dengue incidence was defined as an excess of suspected cases of more than 2 SDs beyond the mean for all 4-week periods from April through June (the period of lowest seasonal incidence), 1989 through 1993. An outbreak was defined as a cumulative annual rate of reported dengue greater than 3 per 1000 population. RESULTS: Retrospective application of the system to 1994 data showed agreement with previous analyses. In 1995 and 1996, 36.4% and 27.3%, respectively, of municipalities with a significant increase in reports for 2 or more consecutive weeks before the first week of September had an outbreak, compared with 9.0% (in 1995, P = .042) and 6.0% (in 1996, P = .054) of towns without a significant increase. The system showed sensitivity near 40%, specificity near 89%, and accuracy in classifying municipalities near 84%. CONCLUSIONS: This method provides a statistically based, visually striking, specific, and timely signal for dengue control efforts.

Full text

PDF
374

Selected References

These references are in PubMed. This may not be the complete list of references from this article.

  1. Gubler D. J., Casta-Valez A. A program for prevention and control of epidemic dengue and dengue hemorrhagic fever in Puerto Rico and the U.S. Virgin Islands. Bull Pan Am Health Organ. 1991;25(3):237–247. [PubMed] [Google Scholar]
  2. Mayer J. D. Medical geography. An emerging discipline. JAMA. 1984 May 25;251(20):2680–2683. [PubMed] [Google Scholar]
  3. Morens D. M., Rigau-Pérez J. G., López-Correa R. H., Moore C. G., Ruiz-Tibén E. E., Sather G. E., Chiriboga J., Eliason D. A., Casta-Velez A., Woodall J. P. Dengue in Puerto Rico, 1977: public health response to characterize and control an epidemic of multiple serotypes. Am J Trop Med Hyg. 1986 Jan;35(1):197–211. doi: 10.4269/ajtmh.1986.35.197. [DOI] [PubMed] [Google Scholar]
  4. Stroup D. F., Wharton M., Kafadar K., Dean A. G. Evaluation of a method for detecting aberrations in public health surveillance data. Am J Epidemiol. 1993 Feb 1;137(3):373–380. doi: 10.1093/oxfordjournals.aje.a116684. [DOI] [PubMed] [Google Scholar]
  5. Stroup D. F., Williamson G. D., Herndon J. L., Karon J. M. Detection of aberrations in the occurrence of notifiable diseases surveillance data. Stat Med. 1989 Mar;8(3):323–332. doi: 10.1002/sim.4780080312. [DOI] [PubMed] [Google Scholar]
  6. Wharton M., Price W., Hoesly F., Woolard D., White K., Greene C., McNabb S. Evaluation of a method for detecting outbreaks of diseases in six states. Am J Prev Med. 1993 Jan-Feb;9(1):45–49. [PubMed] [Google Scholar]
