. 1985 May;119(2):236–243.

Morphologic studies of bladder tumors treated with hematoporphyrin derivative photochemotherapy.

J E Klaunig, S H Selman, J R Shulok, P J Schafer, S L Britton, P J Goldblatt
PMCID: PMC1887898  PMID: 3158208

Abstract

The morphologic changes that occurred in transplanted rat bladder tumors after treatment with hematoporphyrin derivative (HPD) and/or phototherapy were investigated. Transitional cell bladder tumors were initiated subcutaneously in male F344 rats by injection of AY27 cells. When tumors reached 1 cm in diameter, the rats received either HPD (10 mg/kg body weight) photochemotherapy, HPD only, phototherapy only, or no treatment. Tumors were sampled immediately (0 time), 1/2, 1, 2, 4, and 24 hours after phototreatment for light and electron microscopy. Tumors receiving HPD-photochemotherapy displayed progressive injury to both tumor cells and endothelial cells. Early changes (0-2 hours) included focal tumor and endothelial cell vacuolation and swelling as well as sloughing of tumor cells into papillary spaces. Tumor cells and endothelial cells displayed vacuolization and damage to cell mitochondria immediately after phototreatment. Intercellular spaces also increased in size. Lethally injured cells were apparent in papillary spaces. At 4 hours after phototherapy, tumor cells and endothelial cells exhibited extensive cell damage, including mitochondrial destruction, endoplasmic reticulum swelling, polyribosome disaggregation, and plasma membrane blebbing. By 24 hours after phototherapy, the majority of cells within the tumor were necrotic. Untreated tumors and those treated with phototherapy-only did not exhibit these changes. Tumors that received HPD only exhibited focal areas of cell swelling and focal mitochondrial vacuolization in both tumor and endothelial cells. These changes, unlike the HPD-light-treated group did not progress and were reversible.

Full text

PDF
236

Images in this article

240Figure 2
on p.240
241Figure 3
on p.241
238Figure 1
on p.238

Selected References

These references are in PubMed. This may not be the complete list of references from this article.

  1. Berns M. W., Dahlman A., Johnson F. M., Burns R., Sperling D., Guiltinan M., Siemens A., Walter R., Wright W., Hammer-Wilson M. In vitro cellular effects of hematoporphyrin derivative. Cancer Res. 1982 Jun;42(6):2325–2329. [PubMed] [Google Scholar]
  2. Coppola A., Viggiani E., Salzarulo L., Rasile G. Ultrastructural changes in lymphoma cells treated with hematoporphyrin and light. Am J Pathol. 1980 Apr;99(1):175–192. [PMC free article] [PubMed] [Google Scholar]
  3. Fiel R. J., Datta-Gupta N., Mark E. H., Howard J. C. Induction of DNA damage by porphyrin photosensitizers. Cancer Res. 1981 Sep;41(9 Pt 1):3543–3545. [PubMed] [Google Scholar]
  4. Gibson S. L., Hilf R. Photosensitization of mitochondrial cytochrome c oxidase by hematoporphyrin derivative and related porphyrins in vitro and in vivo. Cancer Res. 1983 Sep;43(9):4191–4197. [PubMed] [Google Scholar]
  5. Girotti A. W. Mechanisms of photosensitization. Photochem Photobiol. 1983 Dec;38(6):745–751. doi: 10.1111/j.1751-1097.1983.tb03610.x. [DOI] [PubMed] [Google Scholar]
  6. Girotti A. W. Photodynamic action of protoporphyrin IX on human erythrocytes: cross-linking of membrane proteins. Biochem Biophys Res Commun. 1976 Oct 18;72(4):1367–1374. doi: 10.1016/s0006-291x(76)80165-9. [DOI] [PubMed] [Google Scholar]
  7. Gomer C. J., Rucker N., Banerjee A., Benedict W. F. Comparison of mutagenicity and induction of sister chromatid exchange in Chinese hamster cells exposed to hematoporphyrin derivative photoradiation, ionizing radiation, or ultraviolet radiation. Cancer Res. 1983 Jun;43(6):2622–2627. [PubMed] [Google Scholar]
  8. Hilf R., Leakey P. B., Sollott S. J., Gibson S. L. Photodynamic inactivation of R3230AC mammary carcinoma in vitro with hematoporphyrin derivative: effects of dose, time, and serum on uptake and phototoxicity. Photochem Photobiol. 1983 Jun;37(6):633–642. doi: 10.1111/j.1751-1097.1983.tb04532.x. [DOI] [PubMed] [Google Scholar]
  9. Hilf R., Smail D. B., Murant R. S., Leakey P. B., Gibson S. L. Hematoporphyrin derivative-induced photosensitivity of mitochondrial succinate dehydrogenase and selected cytosolic enzymes of R3230AC mammary adenocarcinomas of rats. Cancer Res. 1984 Apr;44(4):1483–1488. [PubMed] [Google Scholar]
  10. Kessel D. Effects of photoactivated porphyrins at the cell surface of leukemia L1210 cells. Biochemistry. 1977 Jul 26;16(15):3443–3449. doi: 10.1021/bi00634a023. [DOI] [PMC free article] [PubMed] [Google Scholar]
  11. LIPSON R. L., BALDES E. J., OLSEN A. M. The use of a derivative of hematoporhyrin in tumor detection. J Natl Cancer Inst. 1961 Jan;26:1–11. [PubMed] [Google Scholar]
  12. Moan J., Christensen T., Sommer S. The main photosensitizing components of hematoporphyrin derivative. Cancer Lett. 1982 Feb;15(2):161–166. doi: 10.1016/0304-3835(82)90046-5. [DOI] [PubMed] [Google Scholar]
  13. Moan J., Johannessen J. V., Christensen T., Espevik T., McGhie J. B. Porphyrin-sensitized photoinactivation of human cells in vitro. Am J Pathol. 1982 Nov;109(2):184–192. [PMC free article] [PubMed] [Google Scholar]
  14. Nilsson R., Swanbeck G., Wennersten G. Primary mechanisms of erythrocyte photolysis induced by biological sensitizers and phototoxic drugs. Photochem Photobiol. 1975 Nov;22(5):183–186. doi: 10.1111/j.1751-1097.1975.tb06734.x. [DOI] [PubMed] [Google Scholar]
  15. Salet C., Moreno G. Photodynamic effects of haematoporphyrin on respiration and calcium uptake in isolated mitochondria. Int J Radiat Biol Relat Stud Phys Chem Med. 1981 Feb;39(2):227–230. doi: 10.1080/09553008114550261. [DOI] [PubMed] [Google Scholar]
  16. Salet C., Moreno G., Vinzens F. Photodynamic effects induced by furocoumarins on a membrane system. Comparison with hematoporphyrin. Photochem Photobiol. 1982 Sep;36(3):291–296. doi: 10.1111/j.1751-1097.1982.tb04377.x. [DOI] [PubMed] [Google Scholar]
  17. Selman S. H., Kreimer-Birnbaum M., Klaunig J. E., Goldblatt P. J., Keck R. W., Britton S. L. Blood flow in transplantable bladder tumors treated with hematoporphyrin derivative and light. Cancer Res. 1984 May;44(5):1924–1927. [PubMed] [Google Scholar]
  18. Torinuki W., Miura T., Seiji M. Lipoperoxide formation of lysosome due to hematoporphyrin and ultraviolet light irradiation. Tohoku J Exp Med. 1980 Jan;130(1):87–90. doi: 10.1620/tjem.130.87. [DOI] [PubMed] [Google Scholar]
  19. Torinuki W., Miura T., Seiji M. Lysosome destruction and lipoperoxide formation due to active oxygen generated from haematoporphyrin and UV irradiation. Br J Dermatol. 1980 Jan;102(1):17–27. doi: 10.1111/j.1365-2133.1980.tb05667.x. [DOI] [PubMed] [Google Scholar]

Articles from The American Journal of Pathology are provided here courtesy of American Society for Investigative Pathology
