Ethyl {4-[(1,5-dimethyl-2,4-dioxo-2,3,4,5-tetra­hydro-1H-1,5-benzo­diazepin-3-yl)meth­yl]-1,2,3-triazol-1-yl}acetate

Abstract

In the title compound, C₁₈H₂₁N₅O₄, the diazepine ring adopts a boat conformation with the triazolylmethyl-bearing C atom as the prow and the C atoms at the ring junction as the stern.

Related literature

For the structure of 1,5-dimethyl-3-propargyl-1,5-benzodiazepine-2,4-dione, see: Dardouri et al. (2010 ▶).

Experimental

Crystal data

• C₁₈H₂₁N₅O₄

• M _r = 371.40

• Monoclinic,

• a = 8.5452 (2) Å

• b = 15.9993 (5) Å

• c = 13.9215 (4) Å

• β = 106.853 (1)°

• V = 1821.56 (9) ų

• Z = 4

• Mo Kα radiation

• μ = 0.10 mm⁻¹

• T = 293 K

• 0.40 × 0.10 × 0.05 mm

Data collection

• Bruker X8 APEXII diffractometer

• 15511 measured reflections

• 4129 independent reflections

• 2909 reflections with I > 2σ(I)

• R _int = 0.037

• Standard reflections: 0

Refinement

• R[F ² > 2σ(F ²)] = 0.045

• wR(F ²) = 0.124

• S = 1.03

• 4129 reflections

• 247 parameters

• H-atom parameters constrained

• Δρ_max = 0.30 e Å⁻³

• Δρ_min = −0.31 e Å⁻³

Data collection: APEX2 (Bruker, 2008 ▶); cell refinement: SAINT (Bruker, 2008 ▶); data reduction: SAINT; program(s) used to solve structure: SHELXS97 (Sheldrick, 2008 ▶); program(s) used to refine structure: SHELXL97 (Sheldrick, 2008 ▶); molecular graphics: X-SEED (Barbour, 2001 ▶); software used to prepare material for publication: publCIF (Westrip, 2010 ▶).

Supplementary Material

Additional supplementary materials: crystallographic information; 3D view; checkCIF report

supplementary crystallographic information

Comment

1,5-Dimethyl-3-propargyl-1,5-benzodiazepine-2,4-dione, whose synthesis was reported recently (Dardouri et al., 2010), possess an acetylenic linkage that can be exploited for the synthesis of other 1,5-benzodiazepine-2,4-dione derivatives. In this study, the compound is reacted with ethyl 2-azidoacetate to yield the title compound (Scheme I, Fig. 1). The ester provides three nitrogen atoms necessary for the formation of the triazolyl ring.

Experimental

To a solution of 3-propargyl-1,5-dimethyl-1,5-benzodiazepine-2,4-dione (0.23 g,1 mmol) in a t-butyl alcohol/water mixture (1:2, 8 ml) was added copper sulfate pentahydrate (0.25 g,1 mmol), sodium ascorbate (0.29 g, 2 mmol) and ethyl 2-azidoacetate (0.64 g, 5 mmol). The mixture was stirred for two hours. Water (20 ml) was added and the organic compound was extracted with ethyl acetate (2 x 20 ml). The extracts were washed with brine and then dried over sodium sulfate. The compound was recrystallized from an n-hexane/ethyl acetate mixture to give colorless crystals.

Refinement

H-atoms were placed in calculated positions (C—H 0.93–0.98 Å) and were included in the refinement in the riding model approximation, with U(H) set to 1.2–1.5U_eq(C).

Figures

Fig. 1.

Anisotropic displacement ellipsoid plot (Barbour, 2001) of C18H21N5O4 at the 50% probability level; hydrogen atoms are drawn as arbitrary radius.

Crystal data

C18H21N5O4	F(000) = 784
Mr = 371.40	Dx = 1.354 Mg m−3
Monoclinic, P21/c	Mo Kα radiation, λ = 0.71073 Å
Hall symbol: -P 2ybc	Cell parameters from 3798 reflections
a = 8.5452 (2) Å	θ = 2.5–26.4°
b = 15.9993 (5) Å	µ = 0.10 mm−1
c = 13.9215 (4) Å	T = 293 K
β = 106.853 (1)°	Prism, colorless
V = 1821.56 (9) Å3	0.40 × 0.10 × 0.05 mm
Z = 4

Data collection

Bruker X8 APEXII diffractometer	2909 reflections with I > 2σ(I)
Radiation source: fine-focus sealed tube	Rint = 0.037
graphite	θmax = 27.5°, θmin = 2.8°
φ and ω scans	h = −10→10
15511 measured reflections	k = −20→20
4129 independent reflections	l = −18→18

Refinement

Refinement on F2	Primary atom site location: structure-invariant direct methods
Least-squares matrix: full	Secondary atom site location: difference Fourier map
R[F2 > 2σ(F2)] = 0.045	Hydrogen site location: inferred from neighbouring sites
wR(F2) = 0.124	H-atom parameters constrained
S = 1.03	w = 1/[σ2(Fo2) + (0.052P)2 + 0.6008P] where P = (Fo2 + 2Fc2)/3
4129 reflections	(Δ/σ)max = 0.001
247 parameters	Δρmax = 0.30 e Å−3
0 restraints	Δρmin = −0.31 e Å−3

Fractional atomic coordinates and isotropic or equivalent isotropic displacement parameters (Ų)

	x	y	z	Uiso*/Ueq
O1	0.56199 (17)	0.18555 (8)	0.67466 (9)	0.0438 (3)
O2	0.81954 (18)	0.21921 (9)	0.49678 (10)	0.0505 (4)
O3	0.41269 (16)	0.12018 (9)	−0.04809 (9)	0.0440 (3)
O4	0.25337 (19)	0.10260 (14)	0.05096 (12)	0.0829 (7)
N1	0.78013 (17)	0.10102 (8)	0.73772 (10)	0.0285 (3)
N2	0.96549 (17)	0.11692 (10)	0.59493 (10)	0.0344 (4)
N3	0.52214 (17)	0.02996 (9)	0.35097 (10)	0.0314 (3)
N4	0.52862 (17)	0.02234 (9)	0.25819 (10)	0.0328 (3)
N5	0.52498 (17)	0.10028 (9)	0.22117 (10)	0.0291 (3)
C1	0.88147 (19)	0.03536 (10)	0.72159 (12)	0.0271 (4)
C2	0.8961 (2)	−0.03761 (11)	0.77820 (13)	0.0347 (4)
H2	0.8390	−0.0426	0.8255	0.042*
C3	0.9939 (2)	−0.10250 (12)	0.76516 (15)	0.0421 (5)
H3	1.0037	−0.1505	0.8042	0.050*
C4	1.0772 (2)	−0.09629 (13)	0.69423 (15)	0.0449 (5)
H4	1.1407	−0.1407	0.6840	0.054*
C5	1.0662 (2)	−0.02442 (13)	0.63862 (13)	0.0395 (5)
H5	1.1237	−0.0205	0.5914	0.047*
C6	0.97042 (19)	0.04275 (11)	0.65161 (12)	0.0300 (4)
C7	0.7764 (2)	0.11896 (12)	0.84068 (13)	0.0385 (4)
H7A	0.7659	0.1781	0.8486	0.058*
H7B	0.8758	0.0996	0.8875	0.058*
H7C	0.6849	0.0909	0.8531	0.058*
C8	0.6620 (2)	0.13566 (10)	0.66069 (12)	0.0301 (4)
C9	0.6685 (2)	0.11352 (10)	0.55590 (11)	0.0263 (3)
H9	0.6798	0.0528	0.5514	0.032*
C10	0.8228 (2)	0.15520 (11)	0.54480 (12)	0.0332 (4)
C11	1.1183 (2)	0.15061 (15)	0.58176 (15)	0.0499 (5)
H11A	1.1209	0.2101	0.5909	0.075*
H11B	1.1237	0.1378	0.5154	0.075*
H11C	1.2100	0.1258	0.6304	0.075*
C12	0.5152 (2)	0.14153 (11)	0.47517 (12)	0.0314 (4)
H12A	0.4195	0.1194	0.4904	0.038*
H12B	0.5083	0.2020	0.4755	0.038*
C13	0.51605 (19)	0.11257 (10)	0.37318 (12)	0.0274 (3)
C14	0.5173 (2)	0.15758 (11)	0.29023 (12)	0.0295 (4)
H14	0.5136	0.2154	0.2830	0.035*
C15	0.5444 (2)	0.11311 (12)	0.12218 (12)	0.0339 (4)
H15A	0.6163	0.0703	0.1096	0.041*
H15B	0.5963	0.1668	0.1207	0.041*
C16	0.3849 (2)	0.11069 (11)	0.03967 (13)	0.0366 (4)
C17	0.2699 (3)	0.11868 (14)	−0.13697 (14)	0.0487 (5)
H17A	0.1960	0.0748	−0.1294	0.058*
H17B	0.3051	0.1058	−0.1956	0.058*
C18	0.1815 (2)	0.19999 (12)	−0.15270 (14)	0.0435 (5)
H18A	0.0900	0.1969	−0.2121	0.065*
H18B	0.2542	0.2436	−0.1603	0.065*
H18C	0.1431	0.2120	−0.0958	0.065*
