Partial Mastectomy and M. Latissimus Dorsi Reconstruction for Radiation-induced Fibrosis After Breast-conserving Cancer Therapy

Abstract

Background

Patients with severe complaints of radiation-induced fibrosis after breast-conserving therapy and not responding to conservative therapy, were treated by partial mastectomy and m. latissimus dorsi reconstruction.

Method

To determine the feasibility and outcome of this approach, a retrospective study of nine patients was carried out.

Results

After a mean follow-up of 46 months, eight of the nine patients experienced improvement of their complaints and shape of the breast. In only one case did the procedure fail, as evidenced by continuation of all complaints.

Conclusions

Partial mastectomy and m. latissimus dorsi reconstruction is the ultimate option in the treatment of radiation fibrosis. The procedure is safe with satisfying results.

Introduction

Cancer patients who undergo radiotherapy (RT) remain at lifelong risk of serious radiation-induced injury to normal tissue. This injury varies from fibrosis and radionecrosis to radiation-induced malignancies in the long term. In breast cancer about half of the patients are treated with breast-conserving therapy (BCT), and this number seems to be increasing. A consequence of BCT is that postoperatively the remaining breast is irradiated, and a boost is given at the lumpectomy site [1]. These patients have a potential risk of radiation-related complications.

The complications are radiation dose and fractionation related, with a critical cut-off point of 50 Gy [2]. Other individual characteristics, such as diabetes and vascular disorders can contribute to the complication rate. In most cases the acute reaction will stay within acceptable limits and will return to normal within a few weeks. When the unfavorable effects persist for longer than 6 months, spontaneous improvement cannot be expected.

The layer of endothelium supplying the irradiated area starts to proliferate, resulting in a proliferative endarteritis. Most often noted in the capillaries, the endarteritis continues and interferes with the normal process of supplying blood to irradiated areas.

Significant problems arise during this clinical period as a consequence of chronic deterioration of the microvasculature and hypoperfusion, resulting in a mild radiation-induced fibrosis (RIF) in the boost area. With increasing tissue fibrosis and parenchymal degeneration, the compromised tissue has a lower resistance to stress factors. The ischemic tissue may survive without adequate blood supply for a long time, but a traumatic or infectious incident can trigger a series of events that may ultimately lead to extensive tissue death.

The reported incidence of RIF is 5–15%, probably underestimating its true incidence [3, 4]. Studies report that about 45% of patients experience breast pain associated with RIF, ranging from frequent to constant pain in the irradiated area [5].

In published series it has been suggested that RIF stabilizes 2 years after RT to the breast [6]. Clinically, RIF is characterized by skin retraction, atrophy, and toughness to palpation, with consequent functional limitations, as well as by decreased tissue compliance. There will be a limited number of women with a progressive RIF over years; however, the exact number is unknown

Depending on the patient’s complaints, conservative treatment can be administered; this can include systemic or topical medication (corticosteroids, anti-inflammatory agents, zinc, antioxidants), physiotherapy, or hyperbaric oxygen therapy. However, the results have been disappointing, and reports in the literature provide no evidence of benefit.

In some cases the RIF will become worse with persisting severe complaints, such as pain, deformity of the breast, discoloration, and repeated infections of the overlying skin.

When conservative treatment has failed and complaints remain, excision of the area with fibrosis or even mastectomy might be the ultimate treatment option. Excisional procedures often have numerous complications, however, because the surrounding tissue does not heal due to radiotherapy-induced ischemia. When attempting to graft to or rotate a flap to this area, surgeons must connect to tissue that is ischemic and hypoxic. The proper approach to overcoming this problem is to remove an extensive amount of breast tissue beyond the boost area, which results in a partial mastectomy (PM). Oncoplastic techniques can be used to close the defect, either with tissue displacement or tissue replacement.

The m. latissimus dorsi (LD) reconstruction is a widely used and safe reconstruction after partial or total mastectomy [7, 8]. In irradiated areas it has also been proven to be safe [9]. The present study describes patients with serious complaints of RIF who were treated by a PM with LD reconstruction.

Patients and methods

In a retrospective study we describe nine patients with varying complaints after breast-conserving therapy followed by radiotherapy. When all conservative treatment failed, we operated on these patients with a partial mastectomy and reconstruction. The area with RIF was widely excised by a partial mastectomy and an immediate m. latissimus dorsi musculocutaneous flap was used to maintain breast shape and volume. All data were collected retrospectively from the patient files. There was no structured inquiry for pain score, cosmetic outcome, or patient satisfaction.

Technical aspects of the operation

If feasible the operation was carried out in a side position, allowing a simultaneous procedure by surgeon (excision) and plastic surgeon (preparing the LD flap with a skin island). Based on physical examination, mammography, and magnetic resonance imaging (MRI), all fibrotic tissue was removed (partial mastectomy) including the scar, discolored skin, and at least the area of the radiotherapy boost. If the defect was too large for reconstruction with LD, the breast was mobilized and rotated above the pectoral fascia to minimize the defect as it affected the volume of the LD. The muscle was fixed with soluble stitches and a suction drain was left in place. The LD skin island was sutured to the breast skin intracutaneously. All patients were treated with antibiotic prophylaxis.

Results

The patient characteristics are summarized in Table 1. All patients were women whose average age varied between 42 and 63 years, with a mean of 51 years. Radiotherapy (50 Gy) was administered in fractions of 2 Gy, with a boost varying from 0 to 20 Gy. In seven patients the RIF was located in the upper quadrants, five of them in the lateral upper quadrant. The main complaint was pain, sometimes combined with other symptoms like a burning sensation or loss of sensitivity, hyperpigmentation, or teleangiectasia. In two patients the main reason for treatment was dermatitis with recurrent mastitis. The mean time from BCT till PM and LD for RIF was 55 months (4½ years), with a range of 27–89 months.

Table 1.

Partial mastectomy and m. latissimus dorsi reconstruction for radiation-induced fibrosis: patient characteristics

Patients	Age at BCT	Radiation (Gy)a	Quadrant	Interval (months)b	Indication for PM and LDc
1	42	50 + 16	Upper lateral	63	Pain, hyperpigmentation
2	44	50 + 16	Upper central	33	Edema, pain
3	62	50 + 15	Lower lateral	35	Fibrosis, seroma
4	63	50	Lower central	73	Pain, fibrosis
5	57	50 + 20	Upper lateral	68	Pain, hyperpigmentation
6	37	50	Upper lateral	27	Recurrent mastitis, fibrosis
7	53	46 + 20	Upper lateral	89	Dermatitis, fibrosis
8	56	50 + 15	Upper lateral	41	Pain, fibrosis
9	49	50 + 20	Upper lateral	69	Fibrosis, pain

BCT breast-conserving therapy, LD latissimus dorsi flap reconstruction, PM partial mastectomy

^aWhole breast irradiation and boost

^bInterval between BCT and PM

^cThe two main complaints

The mean size of the PM specimen was 465 cm³ (230–750 cm³), and the mean weight was 295 g (60–980 g). Pathology reports of all excised tissue showed pathological changes, confirming the clinical diagnosis of RIF. In no patients breast cancer was found. There were no complications requiring surgical reintervention or leading to prolonged hospital stay. The follow-up after PM and LD was 13–113 months (mean: 46 months). One patient did not report any improvement of her complaints after PM and LD. This patient also suffered from multiple sclerosis and a recent cerebrovascular event, and ultimately a mastectomy was performed. The remaining eight patients were relieved of their most significant complaints. Postoperatively, none of the patients required painkillers, in contrast to the situation before the operation in every case (Table 2). All patients noticed significant improvement in their breast shape and compliance (Fig. 1).

Table 2.

Partial mastectomy and m. latissimus dorsi reconstruction for radiation-induced fibrosis: results

Patients	Age at PM and LD (years)	Volume (cm3)	Weight (g)	Follow-up (months)	Results after PM and LD
1	47	?	60	24	Pain, hyperpigmentationa
2	46	540	280	13	Edema,a painb
3	65	360	180	47	Fibrosis, seromaa
4	68	670	?	110	Pain, fibrosisa
5	63	360	300	86	Pain, hyperpigmentationa
6	39	270	160	113	Recurrent mastitis, fibrosisa
7	60	750	980	86	Dermatitis, fibrosisa
8	59	530	290	22	Pain,b fibrosisa
9	55	230	210	25d	Fibrosis,c painc

^a(Almost) no complaints

^bSlight complaints

^cNo change

^dTime to mastectomy

Fig. 1.

Two patients with radiation-induced fibrosis (left) and the result after partial mastectomy and m. latissimus dorsi reconstruction (right)

Discussion

Persisting complaints after breast-conserving surgery followed by radiotherapy represent a frequently reported clinical problem [3, 4]. Usually the complaints resolve without further treatment, but in some instances the adverse reaction of radiotherapy results in an irreversible RIF with associated with pain, erythema, and progressive edema or fibrosis, and complaints can persist for years. It is difficult to measure the degree of RIF with objective criteria. Compliance is the relationship between the force acting upon a tissue and transformation that is caused by that force. One way of measuring the compliance is by palpation [10], but it is subjective, with a great interobserver variability [11]. It is also possible to measure compliance with a more objective noninvasive tissue compliance meter (TCM) [12].

Common therapies consist of eliminating localized and general aggravating factors, and controlling acute and chronic inflammation with antibiotics and steroids. As progress has been made in understanding the pathophysiology of RIF lesions, different treatment strategies have been developed in clinical practice. These consist of anti-oxidants (vitamin-E [13], superoxide dismutase [14]), angiotensin-converting enzyme inhibitor (Captopril [14]), interferon-gamma [15], anti-inflammatory agents (Brufen [16]) and Pentoxifylline (Trental) [17]. However, all the studies of these strategies were performed in patients with acute radiation morbidity and the results, if any, were short-lived [13]. In a small randomized placebo-controlled study a six-month treatment with alpha-tocopherol (vitamin E) and pentoxifylline showed significant regression of RIF [18]; nevertheless, these results could not be confirmed by other investigators [19].

Hyperbaric oxygen therapy (HBOT) seems to be effective in the treatment of late radiation sequelae like pain, edema, erythema, and soft tissue necrosis. The HBOT allows tissue to be hyperoxygenated. By providing inhaled 100% oxygen under pressure, the arterial PO₂ is raised five to ten times above normal, which promotes healing. The hyperoxia stimulates fibroblast proliferation and collagen synthesis, which provide a matrix for angiogenesis at a faster rate, resulting in soft tissue repair. However, no randomized controlled trials are available to prove this theory [20].

When all conservative treatments have failed, it is necessary to excise the lesion extensively. A range of therapeutic options are available from which to choose the most reliable reconstruction technique to close the defect. Muscle and pedicled musculocutaneous flaps are reliable grafts due to their safety, their vascular, trophic and anti-infectious quality, and their excellent capacity of coverage.

A latissimus dorsi flap can be harvested without significant risks or side effects and can be used to fill a defect after resection of the area with RIF. This approach is known for its easy mobilization, high tissue vitality, and good cosmesis. The complication rate is low [7]. In our series we did not have complications while using LD reconstructions.

In one patient the PM and LD failed to solve the complaints based on RIF. In the other patients most of the problems were significantly improved with a mean follow-up of almost 4 years (Table 2).

Conclusions

A small number of patients treated with breast-conserving therapy and subsequent radiotherapy for breast cancer will suffer from radiation-induced fibrosis. Conservative treatment is the treatment of choice, sometimes lacking success at long-term follow-up. When associated problems interfere with the quality of life of patients, surgical removal of all affected tissue can help. A partial mastectomy, reconstructed with m. latissimus dorsi proved to be a safe treatment option with satisfying results. Eight of our nine patients experienced improvement in associated complaints and in the shape of the breast.
