. 1983 Feb;39(2):623–629. doi: 10.1128/iai.39.2.623-629.1983

Serological, chemical, and structural analyses of the Escherichia coli cross-reactive capsular polysaccharides K13, K20, and K23.

W F Vann, T Soderstrom, W Egan, F P Tsui, R Schneerson, I Orskov, F Orskov
PMCID: PMC347997  PMID: 6187684

Abstract

The Escherichia coli K13, K20, and K23 capsular polysaccharide antigens are serologically related. All of these polysaccharides contain ribose and 2-keto-3-deoxyoctonate in equimolar quantities. The K13 and K20 polysaccharides are partially O-acetylated. A comparison of these polysaccharides after O-deacetylation, by nuclear magnetic resonance and permethylation analysis, showed that these polysaccharides contained the disaccharide repeat unit leads to)-beta-ribofuranosyl-(1 leads to 7)-beta-2-keto-3-deoxyoctonate. They differed in the presence and location of an acetyl moiety. The K13 polysaccharide was O-acetylated at C-4 of the 2-keto-3-deoxyoctonate. The K20 antigen was O-acetylated at C-5 of the ribose moiety. The K23 polymer was nonacetylated. The cross-reactivity of these antigens was demonstrated by tandem-crossed immunoelectrophoresis. Antibodies to K23 could be completely absorbed from OK K23 serum by K13, K20, and K23 antigenic extracts. The K13 and K20 antibodies could be completely absorbed from their respective antisera only by homologous antigenic extracts. Monoclonal antibodies were prepared against a protein conjugate of the K13 polysaccharide. Analyses of the reactions of these antibodies with the three polysaccharides suggest that the K13 polysaccharide has at least three antigenic sites, one of which is common to the K13, K20, and K23 polysaccharides.

Full text

PDF
623

Selected References

These references are in PubMed. This may not be the complete list of references from this article.

  1. Axelsen N. H., Bock E., Kroll J. Comparison of antigens: the reaction of 'identity'. Scand J Immunol Suppl. 1973;1:91–94. doi: 10.1111/j.1365-3083.1973.tb03785.x. [DOI] [PubMed] [Google Scholar]
  2. Axelsen N. H. Intermediate gel in crossed and in fused rocket immunoelectrophoresis. Scand J Immunol Suppl. 1973;1:71–77. doi: 10.1111/j.1365-3083.1973.tb03782.x. [DOI] [PubMed] [Google Scholar]
  3. Bettelheim K. A., Taylor J. A study of Escherichia coli isolated from chronic urinary infection. J Med Microbiol. 1969 Aug;2(3):225–236. doi: 10.1099/00222615-2-3-225. [DOI] [PubMed] [Google Scholar]
  4. Bhattacharjee A. K., Jennings H. J., Kenny C. P. Structural elucidation of the 3-deoxy-D-manno-octulosonic acid containing meningococcal 29-e capsular polysaccharide antigen using carbon-13 nuclear magnetic resonance. Biochemistry. 1978 Feb 21;17(4):645–651. doi: 10.1021/bi00597a013. [DOI] [PubMed] [Google Scholar]
  5. Engvall E., Perlmann P. Enzyme-linked immunosorbent assay, Elisa. 3. Quantitation of specific antibodies by enzyme-labeled anti-immunoglobulin in antigen-coated tubes. J Immunol. 1972 Jul;109(1):129–135. [PubMed] [Google Scholar]
  6. Gotschlich E. C., Rey M., Etienne J., Sanborn W. R., Triau R., Cvjetanović B. The immunological responses observed in field studies in Africa with group A meningococcal vaccines. Prog Immunobiol Stand. 1971;5:485–491. [PubMed] [Google Scholar]
  7. Kaijser B., Hanson L. A., Jodal U., Lidin-Janson G., Robbins J. B. Frequency of E. coli K antigens in urinary-tract infections in children. Lancet. 1977 Mar 26;1(8013):663–666. doi: 10.1016/s0140-6736(77)92111-0. [DOI] [PubMed] [Google Scholar]
  8. Kroll J. Tandem-crossed immunoelectrophoresis. Scand J Immunol Suppl. 1973;1:57–59. [PubMed] [Google Scholar]
  9. Köhler G., Milstein C. Continuous cultures of fused cells secreting antibody of predefined specificity. Nature. 1975 Aug 7;256(5517):495–497. doi: 10.1038/256495a0. [DOI] [PubMed] [Google Scholar]
  10. Larsen J. C., Orskov F., Orskov I., Schmidt M. A., Jann B., Jann K. Crossed immunoelectrophoresis and chemical structural analysis used for characterization of two varieties of Escherichia coli K2 polysaccharide antigen. Med Microbiol Immunol. 1980;168(3):191–200. doi: 10.1007/BF02122853. [DOI] [PubMed] [Google Scholar]
  11. Orskov F., Orskov I., Evans D. J., Jr, Sack R. B., Sack D. A., Wadström T. Special Escherichia coli serotypes among enterotoxigenic strains from diarrhoea in adults and children. Med Microbiol Immunol. 1976 Jun 1;162(2):73–80. doi: 10.1007/BF02121318. [DOI] [PubMed] [Google Scholar]
  12. Orskov I., Orskov F., Birch-Andersen A. Comparison of Escherichia coli fimbrial antigen F7 with type 1 fimbriae. Infect Immun. 1980 Feb;27(2):657–666. doi: 10.1128/iai.27.2.657-666.1980. [DOI] [PMC free article] [PubMed] [Google Scholar]
  13. Orskov I., Orskov F., Jann B., Jann K. Serology, chemistry, and genetics of O and K antigens of Escherichia coli. Bacteriol Rev. 1977 Sep;41(3):667–710. doi: 10.1128/br.41.3.667-710.1977. [DOI] [PMC free article] [PubMed] [Google Scholar]
  14. Schneerson R., Barrera O., Sutton A., Robbins J. B. Preparation, characterization, and immunogenicity of Haemophilus influenzae type b polysaccharide-protein conjugates. J Exp Med. 1980 Aug 1;152(2):361–376. doi: 10.1084/jem.152.2.361. [DOI] [PMC free article] [PubMed] [Google Scholar]
  15. Spencer A. G., Mulcahy D., Shooter R. A., O'Grady F. W., Bettleheim K. A., Taylor J. Escherichia coli serotypes in urinary-tract infection in a medical ward. Lancet. 1968 Oct 19;2(7573):839–842. doi: 10.1016/s0140-6736(68)90998-7. [DOI] [PubMed] [Google Scholar]
  16. Stein K. E., Bona C., Lieberman R., Chien C. C., Paul W. E. Regulation of the anti-inulin antibody response by a nonallotype-linked gene. J Exp Med. 1980 May 1;151(5):1088–1102. doi: 10.1084/jem.151.5.1088. [DOI] [PMC free article] [PubMed] [Google Scholar]
  17. Vann W. F., Jann K. Structure and serological specificity of the K13-antigenic polysaccharide (K13 antigen) of urinary tract-infective Escherichia coli. Infect Immun. 1979 Jul;25(1):85–92. doi: 10.1128/iai.25.1.85-92.1979. [DOI] [PMC free article] [PubMed] [Google Scholar]
  18. WARAVDEKAR V. S., SASLAW L. D. A sensitive colorimetric method for the estimation of 2-deoxy sugars with the use of the malonaldehyde-thiobarbituric acid reaction. J Biol Chem. 1959 Aug;234(8):1945–1950. [PubMed] [Google Scholar]
  19. Weeke B. A manual of quantitative immunoelectrophoresis. Methods and applications. 1. General remarks on principles, equipment, reagents and procedures. Scand J Immunol Suppl. 1973;1:15–35. doi: 10.1111/j.1365-3083.1973.tb03776.x. [DOI] [PubMed] [Google Scholar]
  20. Weeke B. Crossed immunoelectrophoresis. Scand J Immunol Suppl. 1973;1:47–56. doi: 10.1111/j.1365-3083.1973.tb03778.x. [DOI] [PubMed] [Google Scholar]
