Enhanced specificity and efficiency of the CRISPR/Cas9 system with optimized sgRNA parameters in Drosophila

Summary

The CRISPR/Cas9 system has recently emerged as a powerful tool for functional genomic studies in Drosophila melanogaster. However, sgRNA parameters affecting the specificity and efficiency of the system in flies are still not clear. Here, we found that off-target effects did not occur in regions of genomic DNA with three or more nucleotide mismatches to sgRNAs. Importantly, we document for the first time a strong positive correlation between mutagenesis efficiency and sgRNA GC content of the six protospacer adjacent motif-proximal nucleotides (PAMPNs). Furthermore, by injecting well-designed sgRNA plasmids at the optimal concentration we determined, we could efficiently generate mutations in four genes in one step. Finally, we generated null alleles of HP1a using optimized parameters through homology-directed repair, and achieved an overall mutagenesis rate significantly higher than previously reported. Our work presents the most comprehensive optimization of sgRNA and promises to vastly simplify CRISPR/Cas9 experiments in Drosophila.

Introduction

The past few years have witnessed a remarkable development of sequence-specific DNA endonuclease technologies in model organisms for precise genome editing, which holds the promise to greatly improve our understanding of developmental biology and diseases (Rong and Golic, 2000; Bibikova et al., 2002; Gong and Golic, 2003; Gao et al., 2008; Huang et al., 2009; Liu et al., 2012; Bassett et al., 2013; Chang et al., 2013; Cong et al., 2013; Friedland et al., 2013; Gaj et al., 2013; Gratz et al., 2013; Jiang et al., 2013; Kondo and Ueda, 2013; Mali et al., 2013; Ren et al., 2013; Wang et al., 2013; Yu et al., 2013). Considering cost, design and efficiency, the CRISPR/Cas9 system has a number of advantages over Zinc-finger or TALE protein fused nucleases (Mali et al., 2013). In this system, the Streptococcus pyogenes Cas9 contains two nuclease active sites, and the chimeric sgRNA consists of a crRNA and a tracrRNA module (Jinek et al., 2012). The tracrRNA module is required for Cas9 nuclease activity, and the crRNA module guides the Cas9 protein to cleave double-stranded genomic DNA with sequence specificity provided by base-pairing between the 20 nucleotide (nt) targeting sequence and the targeted DNA (Figure 1A). The three-nucleotide (NGG for S. pyogenes Cas9 system) Protospacer Adjacent Motif (PAM) in the genomic DNA is not included in the sgRNA sequence, but is required for sgRNA targeting. Despite the wide utility of the powerful CRISPR/Cas9 system, its specificity and efficiency are two common concerns in the user community.

Figure 1. The criteria for off-target effects in the DGSC system.

(A) Schematic showing the Cas9/sgRNA system. Cas9 is shown as the red background. The sgRNA is shown in green. The 3-nucleotide PAM sequence (NGG or NAG) in the DNA is shown in blue. The PAM-distal and – proximal ends are labeled by the green arrows. (B) Mutagenesis efficiency of sgRNAs with mismatches (red) to a target of the white locus. Results are from three independent experiments, and error bar shows standard error of the mean. (C) Mutagenesis efficiency of sgRNAs with mismatches (red) to targets of different loci. (D) Off-target mutagenesis efficiency of 10 sgRNAs (numbered 1 to 10), compared with the on-target efficiency. The potential off-targets have three nucleotide mismatches (red) to the sgRNAs. PAMs are indicated in bold text. (E-F) Mutagenesis efficiency of sgRNAs with 20 nt targeting sequences, those with 18 nt, and those with 18 nt sequences and one-base mismatches (red). (G-H) Mutagenesis efficiency of sgRNAs with targeting sequences ranging from 17 to 22 nt. The regular 20 nt sgRNAs are shown in blue. Each row in (A-B) and (E-H) represents an sgRNA sequence, and its mutagenesis rate. Each row in (C-D) represents a site of the fly genome, and the mutagenesis rate at that site. See also Figure S1.

Studies in mammalian cells showed that the number, position, and distribution of nucleotide mismatches between the sgRNAs and the genomic DNA are major parameters affecting off-target effects and mutagenesis efficiency. These studies either introduced sgRNAs with mismatches to transgenes or endogenous loci, evaluated the binding patterns of nuclease-deficient Cas9, or directly tested mutagenesis rates at potential off-targets (Fu et al., 2013; Hsu et al., 2013; Mali et al., 2013; Pattanayak et al., 2013; Kuscu et al., 2014; Wu et al., 2014). To reduce off-target effects, a general design principle of avoiding sgRNAs with three or fewer nt mismatches to potential off-targets has been suggested (Hsu et al., 2013; Mali et al., 2013), but off-target mutation had been detected at genomic DNA regions with up to five mismatches to the sgRNA (Fu et al., 2013). Of the 20 nt targeting sequence of sgRNAs, mismatches in the “seed region”, the 5 to 12 nt closest to the PAM, have the largest impact on mutagenesis efficiency. Mismatches in the PAM-distal nucleotides generally have less effect on disrupting the sgRNA-target DNA hybrid than those in the PAM-proximal nucleotides (PAMPNs) (Jinek et al., 2012; Cong et al., 2013; Fu et al., 2013; Mali et al., 2013; Pattanayak et al., 2013; Wu et al., 2014). It has been shown that the expression levels of Cas9 and sgRNA together affect mutagenesis efficiency and off-target effects (Bassett et al., 2013; Fu et al., 2013; Hsu et al., 2013; Pattanayak et al., 2013). However, most cell line studies did not evaluate Cas9 and sgRNA levels independently, and an in vivo study showed that sgRNA parameters are the major factors affecting specificity and efficiency within a certain Cas9 expression range (Wang et al., 2013). In addition, truncated sgRNAs with 18 nt targeting sequences have been shown to reduce off-target effects while retaining similar efficiency (Fu et al., 2014).

We and others have recently developed the CRISPR/Cas9 system in Drosophila (Bassett et al., 2013; Gratz et al., 2013; Kondo and Ueda, 2013; Ren et al., 2013; Yu et al., 2013; Gratz et al., 2014; Port et al., 2014; Xue et al., 2014; Yu et al., 2014). However, there have been no systematic studies evaluating the efficiency and specificity in this system. Based on specificity studies in mammalian cells that reported off-target effects at genomic regions with five mismatches (Fu et al., 2013; Kuscu et al., 2014; Wu et al., 2014), 70% of the potentially usable sgRNAs could have off-target effects if five mismatches were tolerated in Drosophila (Ren et al., 2013), which greatly decreases the flexibility of the CRISPR/Cas9 system.

The efficiency of mutation through the Non-Homologous End Joining (NHEJ) pathway after CRISPR/Cas9 induced Double-Strand Breaks (DSBs) is high, especially with flies carrying transgenic Cas9, such as the Drosophila germline specific Cas9 (DGSC) system we developed (Ren et al., 2013). However, with different sgRNAs targeting the same gene, the efficiency can vary ~10-fold by our estimation (our unpublished data). On the other hand, CRISPR/Cas9-mediated Homology-Directed Repair (HDR) usually has an efficiency of less than 5.0% and rarely reaches 10%, for homozygous viable genes (Baena-Lopez et al., 2013; Gratz et al., 2014; Xue et al., 2014; Yu et al., 2014). The HDR recovery rates through CRISPR/Cas9 systems for recessive lethal alleles have not been reported in Drosophila, but they are very likely to be even lower when generating loss-of-function alleles, due to the cellular lethality of homozygous mutations.

Therefore, a systematic investigation of parameters affecting the specificity and efficiency of the CRISPR/Cas9 system in flies is highly desired. In this study, we first systematically evaluated the parameters that affect the specificity and efficiency of the CRISPR/Cas9 system in Drosophila. We demonstrate that off-target effects do not occur in regions of genomic DNA with three or more nucleotide mismatches to the 104 sgRNAs (20 nt) that we evaluated, and that the mutagenesis efficiencies of sgRNAs with a targeting sequence from 17 to 20 nt are similar, while reducing the length of sgRNA to 18 nt can further limit off-target effects. In addition, we optimize parameters for micro-injection of sgRNA in Drosophila embryos, based on our assays for efficiency and fertile G0 rate. Furthermore, we report for the first time a strong, positive correlation between mutagenesis efficiency and sgRNA GC content of the six protospacer adjacent motif-proximal nucleotides (PAMPNs). With these optimized parameters, we then demonstrate the potential for high efficiency sgRNA target selection by generating mutations in up to four genes in one injection. Furthermore, we successfully carried out CRISPR/Cas9-mediated homology-directed repair to generate a null allele of HP1a, a homozygous lethal gene, with a high mutagenesis rate (12%).

Results

New criteria for off-target effects

We employed two strategies to better understand the off-target effects of CRISPR-mediated mutagenesis in Drosophila: First, we made artificial off-targets by altering sgRNAs to contain a variety of mismatches to their targets. Second, we examined sgRNAs with natural potential off-targets. For the first strategy, we generated a series of derived sgRNAs targeting white (w) with up to five mismatched nucleotides to an intended target, and evaluated the mutagenesis efficiency of these sgRNAs in the DGSC system. The original intact sgRNA efficiently triggered mutagenesis, while those with one or two mismatches in the most PAM-distal region significantly reduced the efficiency. sgRNAs with three or more mismatches, even most distal to PAMs, could not generate heritable mutations (>3,000 F1 screened) (Figure 1B). Next, we examined an sgRNA with three separated mismatches and another one with three consecutive mismatches but closer to the PAM, and we again observed no mutants (Figure 1B).

To test whether this phenomenon is common in Drosophila, we picked another six highly efficient sgRNAs (average mutagenesis efficiency > 80%) targeting the coding region of the yellow (y), w, vermilion (v), and ebony (e) genes, and designed corresponding sgRNAs with either two or three mismatches in the PAM-distal nucleotides. These four recessive genes have visible phenotypes when homozygous for the null alleles (Figure S1A), thus allowing us to assess germline mutation rate by crossing the G0 injected flies to the corresponding null mutants. We tested the heritable mutagenesis rate of these mismatched sgRNAs, together with the original intact sgRNAs. Consistent with the above results, we observed that four out of six sgRNAs with two mismatches generated heritable mutations at a much lower rate; the other two had mutation rates of zero. No mutants were recovered using sgRNAs with three mismatches (Figure 1C). To test if the positions of the mismatches affect efficiency, we picked two sgRNAs each with two mismatches and introduced a third mutation (transition and transversion) at each of the other 18 nucleotides. We found that these 72 sgRNAs we tested were unable to generate heritable mutants (Table 1 and Table S1). These results suggest that three mismatches between sgRNAs and targets are not well tolerated in generating DSBs in Drosophila.

Table 1.

The heritable mutation rates of 72 derived sgRNAs with three mismatches to the original sgRNAs. See also Table S1.

sgRNA name	sgRNA sequencea	Heritable mutation rate, % (n)b
yellow-sgRNA-1:TATTCGTCACTGTTCCCCGC
1-18TA	ATATCGTCACTGTTCCCCGC	0% (0/823)
1-17TA	ATTACGTCACTGTTCCCCGC	0% (0/913)
1-16CG	ATTTGGTCACTGTTCCCCGC	0% (0/559)
1-15GC	ATTTCCTCACTGTTCCCCGC	0% (0/472)
1-14TA	ATTTCGACACTGTTCCCCGC	0% (0/584)
1-13CG	ATTTCGTGACTGTTCCCCGC	0% (0/563)
1-12AT	ATTTCGTCTCTGTTCCCCGC	0% (0/510)
1-11CG	ATTTCGTCAGTGTTCCCCGC	0% (0/665)
1-10TA	ATTTCGTCACAGTTCCCCGC	0% (0/583)
1-9GC	ATTTCGTCACTCTTCCCCGC	0% (0/654)
1-8TA	ATTTCGTCACTGATCCCCGC	0% (0/751)
1-7TA	ATTTCGTCACTGTACCCCGC	0% (0/457)
1-6CG	ATTTCGTCACTGTTGCCCGC	0% (0/835)
1-5CG	ATTTCGTCACTGTTCGCCGC	0% (0/719)
1-4CG	ATTTCGTCACTGTTCCGCGC	0% (0/521)
1-3CG	ATTTCGTCACTGTTCCCGGC	0% (0/489)
1-2GC	ATTTCGTCACTGTTCCCCCC	0% (0/507)
1-1CG	ATTTCGTCACTGTTCCCCGG	0% (0/755)
1-18TC	ATCTCGTCACTGTTCCCCGC	0% (0/710)
1-17TC	ATTCCGTCACTGTTCCCCGC	0% (0/547)
1-16CT	ATTTTGTCACTGTTCCCCGC	0% (0/557)
1-15GA	ATTTCATCACTGTTCCCCGC	0% (0/693)
1-14TC	ATTTCGCCACTGTTCCCCGC	0% (0/876)
1-13CT	ATTTCGTTACTGTTCCCCGC	0% (0/584)
1-12AG	ATTTCGTCGCTGTTCCCCGC	0% (0/620)
1-11CT	ATTTCGTCATTGTTCCCCGC	0% (0/726)
1-10TC	ATTTCGTCACCGTTCCCCGC	0% (0/482)
1-9GA	ATTTCGTCACTATTCCCCGC	0% (0/799)
1-8TC	ATTTCGTCACTGCTCCCCGC	0% (0/682)
1-7TC	ATTTCGTCACTGTCCCCCGC	0% (0/791)
1-6CT	ATTTCGTCACTGTTTCCCGC	0% (0/734)
1-5CT	ATTTCGTCACTGTTCTCCGC	0% (0/832)
1-4CT	ATTTCGTCACTGTTCCTCGC	0% (0/817)
1-3CT	ATTTCGTCACTGTTCCCTGC	0% (0/779)
1-2GA	ATTTCGTCACTGTTCCCCAC	0% (0/581)
1-1CT	ATTTCGTCACTGTTCCCCGT	0% (0/662)
yellow-sgRNA-2:GCGATATAGTTGGAGCCAGC
2-18GC	CGCATATAGTTGGAGCCAGC	0% (0/663)
2-17AT	CGGTTATAGTTGGAGCCAGC	0% (0/594)
2-16TA	CGGAAATAGTTGGAGCCAGC	0% (0/692)
2-15AT	CGGATTTAGTTGGAGCCAGC	0% (0/684)
2-14TA	CGGATAAAGTTGGAGCCAGC	0% (0/634)
2-13AT	CGGATATTGTTGGAGCCAGC	0% (0/479)
2-12GC	CGGATATACTTGGAGCCAGC	0% (0/683)
2-11TA	CGGATATAGATGGAGCCAGC	0% (0/621)
2-10TA	CGGATATAGTAGGAGCCAGC	0% (0/465)
2-9GC	CGGATATAGTTCGAGCCAGC	0% (0/464)
2-8GC	CGGATATAGTTGCAGCCAGC	0% (0/594)
2-7AT	CGGATATAGTTGGTGCCAGC	0% (0/820)
2-6GC	CGGATATAGTTGGACCCAGC	0% (0/649)
2-5CG	CGGATATAGTTGGAGGCAGC	0% (0/788)
2-4CG	CGGATATAGTTGGAGCGAGC	0% (0/580)
2-3AT	CGGATATAGTTGGAGCCTGC	0% (0/489)
2-2GC	CGGATATAGTTGGAGCCACC	0% (0/801)
2-1CG	CGGATATAGTTGGAGCCAGG	0% (0/523)
2-18GA	CGAATATAGTTGGAGCCAGC	0% (0/829)
2-17AG	CGGGTATAGTTGGAGCCAGC	0% (0/660)
2-16TC	CGGACATAGTTGGAGCCAGC	0% (0/855)
2-15AG	CGGATGTAGTTGGAGCCAGC	0% (0/773)
2-14TC	CGGATACAGTTGGAGCCAGC	0% (0/839)
2-13AG	CGGATATGGTTGGAGCCAGC	0% (0/605)
2-12GA	CGGATATAATTGGAGCCAGC	0% (0/509)
2-11TC	CGGATATAGCTGGAGCCAGC	0% (0/809)
2-10TC	CGGATATAGTCGGAGCCAGC	0% (0/558)
2-9GA	CGGATATAGTTAGAGCCAGC	0% (0/578)
2-8GA	CGGATATAGTTGAAGCCAGC	0% (0/582)
2-7AG	CGGATATAGTTGGGGCCAGC	0% (0/715)
2-6GA	CGGATATAGTTGGAACCAGC	0% (0/846)
2-5CT	CGGATATAGTTGGAGTCAGC	0% (0/543)
2-4CT	CGGATATAGTTGGAGCTAGC	0% (0/528)
2-3AG	CGGATATAGTTGGAGCCGGC	0% (0/607)
2-2GA	CGGATATAGTTGGAGCCAAC	0% (0/602)
2-1CT	CGGATATAGTTGGAGCCAGT	0% (0/638)

^aThe mismatched nucleotides to the original sgRNA were bolded.

^bThe heritable mutation rate was calculated as the number of mutant F1s divided by the number of all F1s observed.

To further test this observation, we employed our second strategy for examining off-targets. We picked 10 high-efficiency sgRNAs that each have a potential off-target site with three mismatches in the Drosophila genome. Previous reports (Hsu et al., 2013; Jiang et al., 2013; Mali et al., 2013; Pattanayak et al., 2013) and our results (Table S2) showed that certain sgRNAs targeting genomic sequences with NAG PAMs could generate low-level mutations, which indicated that off-target sites with NAG PAMs should not be excluded. Therefore, when sequencing the potential off-target genomic sites of F1 mutant flies generated by these 10 sgRNAs, we included sites with NAG PAMs in addition to those with NGG PAMs (Figure 1D). We did not observe off-target mutations in the fly genome for any of these 10 sgRNAs (Figure 1D). Furthermore, we evaluated the mutation rates at potential off-target sites with two mismatches and one insertion/deletion to 13 sgRNAs (Lin et al., 2014), and again observed no off-target effects (Figure S1B).

Taken together, the 81 sgRNAs (5 from Figure 1B, 6 from Figure 1C, and 70 from Table 1) we tested that have three or more mismatches, consecutive or separate, do not generate mutants, even though the seven sgRNAs they are derived from are very efficient (Figures 1B and 1C). In addition, the 23 high-efficiency sgRNAs do not have off-target effects at genomic regions with three mismatches (Figures 1D and S1B). Therefore, when designing sgRNAs in Drosophila, one can significantly reduce or avoid off-target effects by avoiding DNA sequences with homologous genomic regions of two or fewer mismatches. Using this criterion, about 86.9% (6,575,357/7,566,724) sgRNAs targeting the fly genome have low or no off-target effects.

sgRNAs with targeting sequences of 18 nt are superior to those of 20 nt

A previous report shows that removing the two nucleotides most distal to the PAM from the sgRNA does not interfere with efficiency significantly (Fu et al., 2014), but mutagenesis efficiency at genomic sites with two contiguous mismatches in these nucleotides is compromised in our assays (Figures 1B and 1C). Thus, although the two PAM-distal nucleotides are the least important for an sgRNA in Drosophila, they seem to be important enough to have an impact on mutagenesis rates. We wondered whether this discrepancy reflected a difference of the CRISPR/Cas9 system activities between in mammalian cell lines and in Drosophila, or it showed a difference between having mismatched base-pairs and having no pairings for the sgRNA and DNA. To directly test the effects of removing the two most PAM-distal nucleotides, two sgRNAs with 18 nt targeting w and y were constructed and examined. Indeed, we found that the mutagenesis efficiency of the 18 nt sgRNAs is comparable to that of the 20 nt ones (Figures 1E and 1F). In addition, one mismatch, but not three, abolished the ability of 18 nt sgRNAs to generate heritable mutations, unless the single mismatch was in the most PAM-distal pair (Figures 1E and 1F).

We further constructed a series of sgRNAs with targeting sequences ranging from 17 to 22 nt, and the results showed that the mutagenesis efficiency of sgRNAs with targeting sequences from 17 to 20 nt were at a similar level. Surprisingly, sgRNAs with 21 and 22 nt targeting sequences were far less effective than 20 nt ones (Figures 1G and 1H). In sum, the sgRNAs of 18 nt targets not only maintained a similar mutagenesis efficiency compared with those of 20 nt, but also further limited off-target effects in Drosophila.

Determination of the optimal injection concentration

The individual effects of Cas9 and sgRNA expression levels have not been fully evaluated in Drosophila. To examine whether Cas9 level affects sgRNA-triggered mutagenesis, we tested the mutagenesis efficiency of heterozygous Cas9 transgenic flies, which should express Cas9 at half of the typical homozygous level. We found that heterozygous Cas9 flies had similar heritable mutation rates as homozygous flies, when injected with either high- or low-efficiency sgRNAs targeting the white gene (Table S3). Thus, Cas9 level does not play a critical role in determining the mutagenesis efficiency within the wide range tested in the DGSC system.

We then asked whether there was an optimal amount of sgRNA for mutagenesis. Because equal volumes (1 nL) of sgRNA vectors are introduced into fly embryos with each injection, we can identify an optimal sgRNA concentration by assessing the mutagenesis efficiency and the fertile G0 rate. Specifically, we examined two sgRNAs targeting the white gene, w1 and w2, which represented high and low efficiencies of mutagenesis, respectively, over a concentration range of 0–250 ng/μL. To our surprise, we found that concentrations between 75 and 150 ng/μL generated the highest mutation rate for both sgRNAs (Figure 2A). When the fertile G0 rate, which decreased with increased sgRNA concentration (Figure 2B), is taken into account, concentrations from 50 to 100 ng/μL generated the highest mutation rate for both sgRNAs (Figure 2C). Concentrations were tested using an additional sgRNA that targets e, and the same optimal concentrations between 50 and 100 ng/μL were observed (Figures S2A-S2C). Taken together, our data suggest that the optimal injection concentration of the sgRNA construct is approximately 75 ng/μL.

Figure 2. Parameters affecting sgRNA mutagenesis efficiency.

(A) Heritable mutation rate of sgRNA w1 (n = 3) and w2 (n = 3). (B) Fertile G0 rate of w1 (n = 3) and w2 (n = 3). Fertile G0 rate is calculated as the number of fertile G0 flies divided by total embryos injected. (C) Relative mutagenesis efficiency of w1 and w2. To calculate relative mutagenesis efficiency, heritable mutation rate is multiplied by fertile G0 rate and divided by the highest value. (A-C) The X-axis shows injection concentration of sgRNA vector at 0, 10, 25, 50, 75, 100, 150, 200, and 250 ng/μL. Results are from three independent experiments each for w1 and w2. Error bar shows SEM. (D) Plot figure showing the correlation between mutagenesis efficiency and sgRNA GC content, when different numbers of PAM-proximal nucleotides are considered. (E) Scatter plot demonstrating the correlation between sgRNA heritable mutation rate and 6 PAMPN GC content. Data points for the sgRNA targets in white (w, n = 27), vermilion (v, n = 4), ebony (e, n = 4), and yellow (y, n = 4) are shown. Pearson’s correlation coefficient (r) = 0.675. (F) A three-dimensional column graph that shows the comparison of correlation coefficient when different consecutive regions of the sgRNAs are considered. Each column represents the Pearson’s r between mutagenesis efficiency and GC content of a specific region of the sgRNAs. The 20-nt targeting sequence of the sgRNA is numbered with the nucleotide closest to PAM as 1 and the one farthest to PAM as 20. The x-axis shows the position of the nucleotide at the PAM-distal end of the region, the y-axis shows the position of the nucleotide position at the PAM-proximal end, and the z-axis show the value of r. Positive values are shown in brick red and negative values in sky blue. The correlation coefficient is at the highest between mutagenesis efficiency and the GC content of the six nucleotides closest to the PAM. See also Figure S2.

Mutation rate is highly associated with the sequence of the six PAMPNs

Different sgRNAs produce different mutagenesis rates, possibly due to the epigenetic state of the target genomic locus or features of the targeting sequence of the sgRNA. Methylation of DNA does not affect Cas9 activity and, even though higher levels of Cas9 bind in euchromatic regions, Cas9 can target heterochromatin regions of the Drosophila chromosome (Hsu et al., 2013; Kuscu et al., 2014; Yu et al., 2013). Therefore, we focused our analysis on the targeting sequence of the sgRNAs.

Previously, when using the DGSC system to generate w mutants in Drosophila (Ren et al., 2013), we observed a correlation between mutagenesis efficiency and GC content of the most proximal nucleotides to the PAM sequence of the sgRNAs we designed. To further confirm this phenomenon, we designed a series of sgRNAs targeting the coding regions of y, w, v, and e (Table 2). We evaluated the efficiency of these sgRNAs in generating mutants in the F1 generation and, to determine the optimal number of PAMPNs to consider, we analyzed the correlation coefficient between mutagenesis efficiency and GC content of PAMPNs of different lengths (Figures 2D and 2F). The correlation was highest (0.675) for the GC content of a 6-nt PAMPN motif (Figures 2D-2F). In contrast, we did not observe such strong correlations between mutagenesis efficiency and the GC content of the 12 nt seed region (0.540) or the complete 20 nt targeting sequence (0.236) (Figures 2D and 2F; Figures S2D-S2U). sgRNAs with three or fewer GCs in the six nucleotides closest to the PAM rarely reach a 60% heritable mutation rate, but sgRNAs with at least 4 GCs in that region nearly always have a heritable mutation rate over 60% (Figure 2E). These observations suggest that effective sgRNAs can be selected according to the GC content of the six PAMPNs.

Table 2.

Correlation between sgRNA mutation rate and GC content

gene name (CG#)	sgRNA target sequence	6nt GC content (%)		heritable mutation rate (%)a
white (CG2759)	GCACCATGGCTTGGAAAATC	17	low	11.8%
	CACCTATGCCTGGCACAATA	17		42.4%
	CCGTTAGGGAGCCGATAAAG	17		44.5%
	TTCGGGCAGGCCAAAAACTA	17		50.4%
	GGCACAATATGGACATCTTT	17		52.1%
	CAGCAGGATGACCTCTTTAT	17		60.4%
	CTGCAACGAGCGACACATAC	33		23.4%
	TTCTTGAGCAAATGTTTCCT	33		36.0%
	GCACAATATGGACATCTTTG	33		43.7%
	TTCGCAGAGCTGCATTAACC	33		53.5%
	TCGCAGAGCTGCATTAACCA	33		58.8%
	CGCCGGAGGACTCCGGTTCA	50		18.1%
	TAGTTGGCCGCTCCCTGAAC	50		32.3%
	CTGCGGCGATCGAAAGGCAA	50	high	57.1%
	GCTGCATTAACCAGGGCTTC	67		64.1%
	CCCAGTCCGCCGGAGGACTC	67		72.3%
	TTTTGGCCTGCCCGAAGCCC	67		73.5%
	CCAAAAACTACGGCACGCTC	67		78.6%
	CAATATGGACATCTTTGGGG	67		81.6%
	CAGGAGCTATTAATTCGCGG	83		61.8%
	GCTCCGGCCACCCAGTCCGC	83		63.6%
	TTATCGGCTCCCTAACGGCC	83		71.4%
	CCTCCGGCGGACTGGGTGGC	83		80.2%
	CATTAACCAGGGCTTCGGGC	83		82.8%
	CCGGCCACCCAGTCCGCCGG	100		33.2%
	AGCGACACATACCGGCGCCC	100		80.1%
	TTGAAACTCAGTTTGCGGCG	100		96.0%
vermilion (CG2155)	CAGAAACGATCACGATGATT	17	low	9.0%
	TTCGGCGGTGCCATTAACCA	33		59.7%
	AACAGATGCTCATCGTGCAC	67	high	98.1%
	TCTGTTCATCATCACGCACC	83		95.8%
ebony (CG3331)	GCTGCTGCTCCTCGAAGATG	33	low	25.1%
	CCACAATTGTCGATCGTCAA	50		39.4%
	TGTGGTGAATGCGGTTCGCC	67	high	62.5%
	GAACCGGGCAGCCCGCCTCC	83		100%
yellow (CG3757)	GTGCACTGTTCCAGGACAAA	33	low	10.9%
	TTGGGCTGCTTACAAACTTC	33		29.8%
	GCGATATAGTTGGAGCCAGC	83	high	97.1%
	TATTCGTCACTGTTCCCCGC	100		76.1%

^aThe heritable mutation rate was calculated as the number of mutant F1s divided by the number of all F1s observed. Six PAMPNs are in bold text.

Of the ~7.6 million sgRNAs targeting the fly genome, about 2.4 million have greater than 50% GC contents at the 6-nt PAMPN and thus are more likely to have high efficiencies. 892,854 of these target the CDS of 13,612 protein coding genes, which covers 97.5% of all protein coding genes (Table S4). If the criterion of having fewer than 3-nt mismatched potential off-targets is included, about 2.1 million sgRNAs qualify, and these cover 97.2% of all protein coding genes (Table S4).

Generating multiple gene mutations in one step

To understand how protein complexes work in vivo and how redundant genes work co-operatively, the simultaneous mutation of multiple genes using the Cas9/sgRNA system has been recently developed in mice (Wang et al., 2013). However, because only a few pole cells are present in each Drosophila embryo, it is a significant challenge to recover defined mutants in multiple genes in one step. We wondered whether our optimization of injection concentration and sgRNA target selection would overcome such limitations.

We injected Cas9 transgenic fly embryos with four sgRNA plasmids targeting y, w, v, and e at a combined DNA concentration of 300 ng/μL (75 ng/μL each). Two groups of sgRNAs were selected based on six PAMPN GC content to represent low and high efficiency sgRNAs for the six PAMPN (Table S5). Since these mutations have visible recessive phenotypes, we crossed adult G0 flies to existing strains with multiple mutations and evaluated mutation rates by the visible markers in F1 (Figure 3A). However, vermilion-eye and white-eye phenotypes are not visible at the same time, since w is epistatic to v.

Figure 3. Triple and quadruple mutations in Drosophila with one shot.

(A) Representative images of control flies, triple mutant F1s, and quadruple mutant F1s. The genotypes are listed on the top. (B) Triple and quadruple mutagenesis rates shown in a bar graph. Each row represents an sgRNA combination and the corresponding mutagenesis rate. Low GC content sgRNAs have less than 3 GCs in the 6 PAM-proximal nucleotides (PAMPNs), while high GC content ones have 5 or 6. See also Table S5.

Therefore, for each injection, we divided adult G0 flies into two groups, and crossed them either to existing y w e or y v e triple mutants. For the six PAMPN low-GC content group, the triple mutagenesis rates reached 0.2% and 3.0%, for y w e and y v e combinations, respectively. For those with high GC content, the rates were 4.5% and 13.6% for the two different combinations (Figure 3B). We then crossed successful y w e triple mutant male F1s to existing v females. We could therefore estimate quadruple rates by assessing v mutation rates in y w e mutants, because mutant v allele could only originate from CRISPR/Cas9 introduced mutations in G0. Thus, we estimated the y w v e quadruple rate was 0% for the group of sgRNAs with low PAMPN GC content, and 1.6% for the group with high GC content (Figure 3B).

To visualize quadruple mutagenesis events directly, we chose sgRNAs that targeted y, scute (sc), v, and e, as the sc homozygous mutation has a visible phenotype that can be observed simultaneously with y v e. We injected Cas9 fly embryos with four sgRNAs vectors of high six PAMPN GC content at 75 ng/μL each, and crossed G0 flies to existing y sc v e mutants. We observed a quadruple mutagenesis rate of 7.4% (Figure 3B), which is comparable to the theoretical rate of 5.8% estimated by multiplying single-gene mutation rates. These results demonstrate that the simultaneous mutation of multiple genes is achievable in Drosophila with sgRNAs of high PAMPN GC content under the optimized condition.

Generating an HP1a null allele through homology-directed repair

As the DGSC system was efficient in generating insertion or deletion mutants through the NHEJ pathway, we next evaluated the efficiency of mutagenesis by homology-directed repair (HDR). We chose HP1a for this test because known HP1a loss-of-function alleles are homozygous lethal before pupal stage (James and Elgin, 1986; Eissenberg et al., 1992), allowing for evaluation of the HDR efficiency of developmentally essential genes. To replace the entire coding sequence of a gene through HDR, we usually use two sgRNAs and a plasmid DNA donor with a selective marker in combination with the DGSC system (Figure 4A). Two sgRNA plasmids with high six PAMPN GC content (Figure S3B) and a DNA donor template with 4XP3 promoter-driven mCherry flanked by homologous arms to HP1a (Figure 4A) were co-injected. Successful HDR mutants with mCherry eyes were counted in the F1 generation (Fig. 4B) and confirmed by PCR (Figure 4C). We found the HDR efficiency occurred at a rate of 12% (98/822 F1s), with a fertile G0 rate of 11.6% (10/86 G0s) and a founder (G0s that produced any mutant F1s) rate of 50% (Table 3). We selected six successful HP1a^HDR-mCherry mutant F1s (four from different G0s and two from the same G0) with mCherry expression in the eyes and confirmed all six lines had the same break points by sequencing (Figure S3A). We also tested for off-target effects in 24 F1s that had mCherry expression in the eyes. Since we tried to avoid off-target cuts when designing the sgRNAs, we applied two sgRNAs without close matches (i.e. with potential off-targets of at least four mismatches) in the fly genome. Thus, the two most likely off-targets had four mismatches to the sgRNAs (Figure S3B). We sequenced these sites and detected no off-target mutations in any of the 24 mutant F1s.

Figure 4. Mutating HP1a through HDR using optimal sgRNAs.

(A) Diagrams showing the repair donor plasmid and the mutation after HDR. The coding sequence of the HP1a locus is illustrated by the white boxes, and the 5’ and 3’ UTRs by the shaded boxes. The HP1a donor HP1a-4XP3-mCherry contains a 4XP3-mCherry sequence (red box) to replace most of the coding sequence of HP1a. The two homologous arms (HA-L and HA-R; blue) of the donor template are 0.97k bp and 1.2k bp, respectively. The Cas9/sgRNA cutting sites are denoted by the scissors. Successful replacement can be detected by mCherry expression in the fly eyes, or by PCR to detect the left and the right homologous arms. (B) Images of w¹¹¹⁸ control and successful HP1a^HDR-mCherry heterozygous mutant flies under bright-field (top) or epifluorescent light sources to show mCherry expression in the eyes (bottom). (C) Agarose gel electrophoresis with PCR band sizes confirming the successful HP1a HDR mutation. See also Figure S3.

Table 3.

A comparison of CRISPR/Cas9 mediated HDR rates in Drosophila from recent literature

	Recessive viable allele	Recessive lethal allele	HDR Efficiency
			% (no.) founders	% (no.) HDR progeny
Yu, Zhongsheng et al., (Biology Open, 2014)	CG4221	-	10.8% (3/28)	4.3% (10/230)
	CG5961	-	8.3% (1/12)	3.8% (2/52)
Gratz, Scott J. et al., (Genetics, 2014)	DSH3PX1 (CG6757)	-	18.0% (9/50)	7.8% (599/7657)
		-	11.1% (2/18)	1.6% (48/3016)
		-	0% (0/28)	0% (0/5665)
		-	3.2% (1/31)	0.04% (2/4573)
		-	12.5% (2/16)	2.0% (45/2277)
Port, Fillip et al., (PNAS, 2014)	wntless (CG6210)	-	67% (4/6)	28% (13/46)
	ebony	-	60% (3/5)	11% (8/76)
Our method	piwi (CG6122)	-	53.8% (7/13)	32.8% (446/1361)
	-	HP1a (CG8409)	50% (5/10)	12% (98/822)

Discussion

Previous work, including ours, has demonstrated the feasibility of CRISPR/Cas9-mediated gene editing in Drosophila (Baena-Lopez et al., 2013; Bassett et al., 2013; Gratz et al., 2013; Hsu et al., 2013; Kondo and Ueda, 2013; Ren et al., 2013; Yu et al., 2013; Gratz et al., 2014; Port et al., 2014; Xue et al., 2014; Yu et al., 2014). The off-target effect (i.e., specificity) and efficiency of the CRISPR/Cas9 system has been recently investigated in mammalian cells (Fu et al., 2013; Hsu et al., 2013; Mali et al., 2013; Pattanayak et al., 2013; Cho et al., 2014; Fu et al., 2014; Kuscu et al., 2014; Lin et al., 2014; Wu et al., 2014). In this work, we investigated the parameters to achieve high specificity and efficiency in Drosophila, which consequently enabled us to mutate up to four genes in one step and carry out homology-directed repair (HDR) with higher efficiency than previously reported.

Off-target effects (i.e., specificity) of the CRISPR/Cas9 system

In our tests, the mutagenesis efficiency dramatically reduces to zero for the 81 sgRNAs with three or more mismatches, even at the most distal end to the PAM, when 20-nt sgRNAs are used. Since mismatches closer to the PAM are more likely to disrupt the sgRNA-DNA hybrid (Jinek et al., 2012; Cong et al., 2013; Mali et al., 2013), genomic regions with three or more mismatches to sgRNAs have reduced or no off-target effects in Drosophila. This conclusion is further supported by the observation that sgRNAs targeting the y, w, v, and e genes do not induce off-target mutations in genomic DNA carrying three mismatches (Figure 1D and Figure S1B), and is in line with recent studies in mammalian cells (Hsu et al., 2013; Mali et al., 2013; Wang et al., 2014). In addition, although sgRNAs targeting DNA with NAG PAMs do not generate mutants efficiently, potential off-target effects with NAG PAMs cannot be completely excluded.

Consistent with a previous report (Fu et al., 2014), the sgRNAs with targeting sequences of 18 nt are as effective as those with 20 nt in Drosophila. This result is seemingly contradictory with our result with the mismatched sgRNAs. However, these results support a model where mismatches between the sgRNA and the DNA target prevent Cas9 nuclease activities but extensive matches, although fewer, allow DSBs by Cas9 (Wu et al., 2014). The finding that sgRNAs with targeting sequences shorter than 20 nt are as effective but more specific in Drosophila further facilitates the design of specific sgRNAs. However, it is important to note that removing one nucleotide from the targeting sequence of an sgRNA increases the possibility of off-targets in the genome four fold, theoretically. Since 18-nt-target sgRNAs nearly abolish off-target effects in regions with only a single base mismatch, decreasing sgRNA length further may not be necessary. Nevertheless, the observation that 17- to 20-nt-target sgRNAs have similar mutagenesis efficiencies in Drosophila demands further investigation of even shorter target lengths in vivo. It is surprising to find that 21- to 22-nt-target sgRNAs have a dramatic decrease in efficiency compared with those of 20 nt. Possibly, the extra 1-2 nucleotides have to be trimmed away in Drosophila just like in mammalian cell lines (Ran et al., 2013), and thus the additional processing makes 21- and 22-nt-target sgRNAs less effective than 20-nt ones. Alternatively, the extra base pairs might interfere with the Cas9 enzymatic activity or the dissociation of Cas9 from genomic DNA.

The results of our study suggest the pool of specific sgRNA targets in the Drosophila genome is significantly larger than previously thought (Ren et al., 2013), which makes it possible to target specific locations to make fine alterations in the fly genome instead of simply knocking out genes. These results also show that the phenotypic analysis of mutant alleles generated by the Cas9/sgRNA system is more reliable than we previously assumed (Ren et al., 2013).

Mutagenesis efficiency of the CRISPR/Cas9 system

Our in vivo data show that the protein level of Cas9 is not critical in determining mutagenesis efficiency within the bounds of the DGSC system. We then examined a wide range of injected sgRNA concentrations, with the expectation that the mutagenesis rate would positively correlate with the sgRNA concentration. To our surprise, we found that the mutagenesis efficiency peaks at an injection concentration of 75 to 150 ng/μL. The exact reason why increasing sgRNA concentration beyond 150 ng/μL decreases mutagenesis rates is not clear. However, the fact that the fertile G0 rate decreases with increased sgRNA concentration supports an idea that excessive off-target DNA DSBs may lead to cell death and thus loss of mutant germline cells. Alternatively, large amounts of sgRNA or plasmid DNA might be toxic to the cells.

Considering these observed effects of sgRNA concentration on both mutagenesis efficiency and specificity, an injection concentration of approximately 75 ng/μL is ideal when using the DGSC system to generate heritable mutant flies. Since most DNA miniprep kits routinely yield a final concentration of greater than 100 ng/μL, sgRNA vectors from minipreps can be easily applied in the DGSC system without further concentration. These results also suggest that higher levels of sgRNA do not necessarily mean higher efficiency, when applying CRISPR/Cas9 systems.

Importantly, we found the strongest positive correlation between sgRNA mutagenesis efficiency and the GC content of the six PAMPNs. We also observed that sgRNA efficiency of previous reports in Drosophila fit this trend (Bassett et al., 2013; Kondo and Ueda, 2013; Yu et al., 2013), even though they injected in vitro synthesized Cas9 RNA or Cas9 DNA vector, which suggests that this strong correlation can be applied to predict sgRNA efficiency in Drosophila. Previous reports in mammalian cell line studies showed that medium GC-content sgRNAs have higher mutagenesis efficiency compared with those of low or high GC-content, when the whole 20-nt targeting sequence is taken into consideration (Wang et al., 2014). We also do not observe a correlation between efficiency and 20-nt GC content (Figure S2U). However, it would be interesting to know if data from cell line studies show a trend between efficiency and GC content of sgRNAs if the seed region is considered.

Previous reports show that mismatches in the PAMPNs are more likely to disrupt complementation between sgRNA and the intended target than those in the distal nucleotides, and that PAMPNs are important in maintaining the sgRNA:DNA heteroduplex in Cas9 (Jinek et al., 2014; Nishimasu et al., 2014). We therefore hypothesize that PAMPNs with higher CG content have more hydrogen bonds between the sgRNA and DNA, which stabilize the hybrid and increase the Cas9 enzyme efficiency, thus increasing overall heritable mutation rates. sgRNAs with more than 50% GCs in the six PAMPNs generally have higher mutagenesis rates than those with less than 50% GCs. However, within the group of sgRNAs that have more than 50% GCs, there is no further correlation between the actual GC content and mutation rate (Figure 2E). Nonetheless, this strong relationship suggests that the GC content of the six PAMPNs can predict the mutation efficiency of the sgRNA in Drosophila and thus facilitate the design of sgRNAs.

One-step mutation of multiple genes

Generating mutations in multiple genes in one step in flies has been challenging, even with CRISPR/Cas9-based techniques. Microinjection of multiple sgRNA plasmids at the previously described concentration is toxic to the embryo and reduces the number of viable G0s (Ren et al., 2013). The determination of optimal injection parameters and new criteria for selecting an efficient sgRNA target sequence allowed us to generate flies with up to four mutant genes. Under optimized conditions, G0 survival and fertile rates are sufficient to produce triple or quadruple mutants, in sharp contrast to using low GC content sgRNAs. Thus, selecting high PAMPN GC content is critical for mutating multiple genes in one step. This optimization paves the way for genetic studies of protein complexes and redundant pathways in which multiple genes may need to be mutated to manifest any phenotypes.

Efficient homology-directed repair (HDR) to target a homozygous lethal gene

Previously, CRISPR/Cas9-mediated HDR was successfully applied to mutate homozygous viable genes, with the mutagenesis efficiency generally lower than 5% (Baena-Lopez et al., 2013; Gratz et al., 2014; Xue et al., 2014; Yu et al., 2014). The HDR recovery rates with homozygous lethal genes have not been reported, although they are likely to be substantially lower. We targeted HP1a, to examine whether our optimizations enabled the targeting of a homozygous lethal gene. The G0 survival rate when generating the HP1a^HDR-mCherry allele was at 11.6% (10/86 G0s), which was similar to that for the production of a piwi mutant at 16.0% (13/81 G0s) (Ren et al., 2014 and our unpublished data), supporting that HDR only occurred in germ cells, and thus would not affect G0 survival rate. The F1 HDR mutant rate of HP1a (12%) was much lower than that of piwi (32.8%) (Ren et al., 2014 and our unpublished data), indicating that germ cells carrying homozygous HP1a mutations were lethal, thus reduced the efficiency. The achieved high HDR-mediated mutagenesis efficiency shows a substantial improvement over previous methods (Baena-Lopez et al., 2013; Gratz et al., 2014; Xue et al., 2014; Yu et al., 2014), and is comparable with a very recent report using high concentrations of ssDNA oligonucleotide donors (Port et al., 2014) (Table 3). Therefore, the optimized sgRNA parameters we identified in this work will make HDR a lot more feasible in Drosophila, as long as fertile G0 flies can be recovered.

Experimental Procedures

sgRNA vector construct

sgRNAs were designed using the online CRISPR design tool (http://www.flyrnai.org/crispr/) and cloned into the U6b-sgRNA-short vector as previously described (Ren et al., 2013). The oligonucleotides used for cloning are listed in Table S6. sgRNA sequences are also listed in Table 2, Table S1, Table S2, Table S3, Table S5, Table S9, and Figure S3.

Donor vector construct for HDR at the HP1a locus

The HP1a-4XP3-mCherry donor construct was based on the pBluescript plasmid. The left homologous arm of HP1a was amplified from genomic extract with primers HP1a-HA-left-F and HP1a-HA-left-R, and was cloned into the HindIII and AvrII sites. The right homologous arm was amplified with primers HP1a-HA-right-F and HP1a-HA-right-R, and was cloned into the SpeI and SacI sites. The selection marker 4XP3-mCherry was constructed on a different pBluescript vector first. The gene encoding the red fluorescent protein mCherry was amplified with primers mCherry-F and mCherry-R, and was cloned into the XhoI and KpnI sites. The 4XP3 promoter sequence (Horn et al., 2000) was synthesized and cloned into the HindIII and XhoI sites. The SV40 3’UTR sequence was amplified with primers SV40-F and SV40-R, and was cloned into the KpnI and EcoRV sites. The selection marker 4XP3-mCherry was then cut and inserted between the left and right homologous arms of HP1a to finish the HP1a-4XP3-mCherry construct. All PCR fragments were amplified with pfu DNA polymerase (TransGen Biotech, Beijing). The donor construct was confirmed by sequencing (Invitrogen, Beijing). The oligonucleotides used for cloning and PCR confirmation are listed in Table S8.

DNA purification and embryo injection

DNA plasmid solution was thoroughly mixed with 1/10 volume of 3M sodium acetate (pH5.2, AMRESCO) and 5 volumes of absolute ethanol, and stored at -20^oC for 2 hours followed by 21,000 X g centrifugation. The DNA pellet was washed twice in 70% ethanol, twice in 100% ethanol and re-suspended in injection buffer for the appropriate concentration. The Drosophila embryos were injected as previously described (Ren et al., 2013). The injection concentration of sgRNA plasmids was at 75 or 250 ng/μL, except when a range of concentrations (0–250 ng/μL) was tested to determine the optimal injection concentration. The injection concentration of DNA donor for homology-directed repair was 100 ng/μL. The detailed injection concentrations, survival rates, and fertility rates were listed in Table S9.

Fly stocks and mutation screening

All flies were cultured on standard cornmeal food at 25°C, unless otherwise noted. To score for germline mutations, G0 adult flies that developed from injected P{nos-Cas9}attP2 embryos were crossed to y[1] w[67c23], for white and yellow mutations, or to y[1] sc[1] v[1], for vermilion, or to y[1] sc[1] v[1];; Dr[1] e[1]/TM3,Sb[1] for ebony. y[1] sc[1] v[1]; Dr[1] e[1]/TM3, Sb[1] and y[1] w[67c23]; Dr[1] e[1]/TM6B, Tb[1] were used in screening for triple and quadruple mutants. Embryos from y[1] sc[1] v[1];; P{nos-Cas9}attP2 flies crossing to y[1] sc[1] v[1] flies were used for assessment of heterozygous Cas9 mutagenesis efficiency. y[1] sc[1] v[1]; wg[Gla-1] Bc[1]/CyO, Cy[1] was used as the balancer stock for HDR mutants.

The F1 progeny were screened for the first 6 days after eclosion. The heritable mutation rate was calculated as the total number of mutant F1 progeny divided by the number of progeny screened for a given sgRNA target. The correlation coefficient of the sgRNA GC content and mutation rate was calculated by the Pearson method. Mutagenesis events were confirmed by sequencing of F1 adults, and the detection primers are listed in Table S6. The representative images of mutations of relevant genes were obtained using a Leica MZ16 FA microscope with Leica Application Suite (V3.0) software. Successful HP1a^HDR-mCherry mutants were screened by the expression of mCherry in the eyes under a Leica MZ10F fluorescent microscope.

Genomic DNA extraction

Fly genomic DNA was purified via phenol-chloroform extraction. Single flies were homogenized in 400μL of lysis buffer (1X PBS, 0.2% SDS, 200μg/mL proteinase K) and incubated at 50°C for 1 h, followed by extraction in 400μL of phenol-chloroform. The mixture was then centrifuged at 21,000 X g for 20 min at 4°C. The supernatant was transferred to a new tube. An equal volume of isopropanol was added, and the tube was vortexed thoroughly. The mixture was then kept at 20°C for at least 1 h, followed by centrifugation at 21,000 X g for 20 min at 4°C. The supernatant was removed, and the DNA pellet was washed with 500μL of 75% ethanol, followed by centrifugation at 21,000 X g for 5 min at 4°C. Finally, the pellet was dried for 10 min and re-suspended in 30μL of DNase-free water.

Off-target analysis

Potential off-target sites in the Drosophila genome were identified using CRISPR Browser (www.flyrnai.org/crispr), TagScan (www.isrec.isb-sib.ch/tagger), and Flybase Blast (flybase.org/blast). Detailed information about off-target sites are listed in Table S10. The off-target effect was investigated by sequencing (Invitrogen), as previously described (Ren et al., 2013). Briefly, the G0 adults that developed from injected embryos were individually crossed to mutation lines of the corresponding genes, or to a balancer stock, as described in the above section Fly stocks and mutation screening. For off-target analysis on sgRNAs targeting y, w, v, or e, eight independent F1 mutant flies derived from different G0s were collected, and their genomic DNA extracted. For off-target analysis on sgRNAs targeting HP1a, four F1s each from four G0s and eight F1s from one G0 were collected, making a total of 24 flies. Genomic DNA from single flies was used as the template, and primers flanking the potential off-target sites were used to amplify a defined DNA fragment. The PCR products were either directly sequenced by one of the primers, or first cloned into the VALIUM20 vector (Ni et al., 2008) at an Nhel and EcoRI site and then sequenced by specific primers. Off-target effect was identified by alignment of sequenced results to the wild type genomic sequence. Oligonucleotides used for on/off-target analysis are listed in Tables S6, S7, and S8.

Supplementary Material

1

Figure S1. Off-target effects of the Cas9/sgRNA system, related to Figure 1. (A) Representative images of wild type flies and F1 mutants generated by the DGSC system. The visible mutations manifest in the eyes (white, vermilion) and in the body color (ebony, yellow) of both males and females. (B) Mutagenesis efficiency of sgRNAs (numbered 1 to 13) at the on-targets and the potential off-targets with base-pair mismatches (red) and bulge mismatches (cyan) to the sgRNAs. PAMs are indicated in bold text.

Figure S2. Parameters affecting Cas9/sgRNA mutagenesis efficiency, related to Figure 2. (A) Heritable mutation rate of an sgRNA targeting ebony (n = 2). (B) Fertile G0 rate (n = 2). Fertile G0 rate is calculated as the number of fertile G0 flies divided by total embryos injected. (C) Relative mutagenesis efficiency. To calculate relative mutagenesis efficiency, heritable mutation rate is multiplied by fertile G0 rate and divided by the highest value. (A-C) The X-axis shows injection concentration of the sgRNA vector at 0, 10, 25, 50, 75, 100, 150, and 250 ng/μL. Results are from two independent experiments. Error bar shows SEM.

(D-U) Scatter plots demonstrating the relationship between sgRNA heritable mutation rate, and 2-nt (D), 3-nt (E), 4-nt (F), 5-nt (G), 7-nt (H), 8-nt (I), 9-nt (J), 10-nt (K), 11-nt (L), 12-nt (M), 13-nt (N), 14-nt (O), 15-nt (P), 16-nt (Q), 17-nt (R), 18-nt (S), 19-nt (T), and 20-nt (U) PAMPN GC content. In our evaluation, we define GC content greater than 50% as high and heritable mutation rate over 60% as high.

Figure S3. The break points of the HP1a^HDR-mCherry mutants and the potential off-targets, related to Figure 4. (A) The two boxes show parts of the sequencing results that represent the break points on the genomic DNA, with the genomic sequence in cyan and the 4XP3-mCherry sequence in red. Sequencing results with all six HP1a^HDR-mCherry lines indicate identical mutations. (B) Flies from six successful HP1a^HDR-mCherry mutation strains are tested. The two sgRNA on-target sequences and their corresponding potential off-target sites are listed. Genomic regions that have no more than four mismatches to the on-target and a neighboring PAM were sequenced. No mutations were detected at the potential off-targets. Mismatches between the potential off-targets and the targeted region are shown in red. The PAM sequences are in bold type.

2

Table S1. The heritable mutation rates of 72 derived sgRNAs with three mismatches to the original sgRNAs, related to Table 1 and Figure 1C

Table S2. The heritable mutation rates of four sgRNAs that target DNAs with NAG PAMs, related to Figure 1

Table S3. Comparison of mutagenesis rates between heterozygous and homozygous Cas9 transgenic flies, related to Figure 2

Table S4. Numbers of effecient and/or specific sgRNAs in the fly genome, and their coverage rates, related to Figure 1 and Figure 2

Table S5. Efficiency of triple and quadruple mutagenesis, related to Figure 3

Table S6. Sequences of oligonucleotides used for sgRNA constructs and off-target analysis, related to Figure 1 and Experimental Procedures

Table S7. Sequences of oligonucleotides used for off-target analysis at genomic sites with bulge mismatches, related to Figure 1 and Experimental Procedures

Table S8. Sequences of the oligonucleotides for HP1a mutagenesis and off-target analysis, related to Figure 4 and Experimental Procedures

Table S9. Survival and fertility rates of the sgRNAs applied (7 sheets), related to Experimental Procedures

Table S10. Genomic positions of the potential off-targets with three mismatches to the sgRNAs (2 sheets), related to Experimental Procedures
