. 1970 May;32(3):344–349. doi: 10.1136/hrt.32.3.344

Mitral valve movement: a study using an ultrasound technique

C F P Wharton 1, L Lopez Bescos 1
PMCID: PMC487331  PMID: 5420079

Abstract

The movement of the anterior leaflet of the mitral valve has been recorded with an ultrasound echo technique. The intrinsic mobility of the valve cusps and the rate of ventricular filling are thought to influence the closure of the valve during diastole. Atrial contraction occurs at the end of ventricular diastole and reopens the valve before the mitral valve returns to the closed position before the onset of ventricular systole.

The relation of the opening snap and third heart sound to the movement of the cusp is shown.

In mitral stenosis ventricular systole occurs when the mitral valve is still far away from the closed position and the rapid movement of the cusp to the closed position may be the cause of the high intensity vibrations of the first heart sound. The EF slope (representing the rate of the closing movement of the cusp in end diastole) is decreased and a good correlation has been found with the degree of stenosis. After mitral valvotomy the EF slope increases significantly.

The validity of these methods in assessing mitral incompetence or relative predominance of stenosis or incompetence in mixed mitral lesions is discussed.

The ultrasound cardiograph is a fairly simple and completely atraumatic technique with proven diagnostic value in mitral valve disease. In addition, because of the new type of information that is given, it has potential as a research tool which is, as yet, largely unexplored.

Full text

PDF
344

Images in this article

Selected References

These references are in PubMed. This may not be the complete list of references from this article.

  1. Winters W. L., Jr, Gimenez J., Soloff L. A. Clinical application of ultrasound in the analysis of prosthetic ball value function. Am J Cardiol. 1967 Jan;19(1):97–107. doi: 10.1016/0002-9149(67)90267-6. [DOI] [PubMed] [Google Scholar]
  2. Winters W. L., Riccetto A., Gimenez J., McDonough M., Soulen R. Reflected ultrasound as a diagnostic instrument in study of mitral valve disease. Br Heart J. 1967 Sep;29(5):788–800. doi: 10.1136/hrt.29.5.788. [DOI] [PMC free article] [PubMed] [Google Scholar]
