Potato Wound-Healing Tissues: A Rich Source of Natural Antioxidant Molecules with Potential for Food Preservation

Abstract

The need for safe, effective preservatives is a prominent issue in the food and drug industries, reflecting demand for natural alternatives to synthetic chemicals viewed as harmful to consumers and the environment. Thus, this study determined the identities and scavenging capacities of antioxidant metabolites produced as a response to potato tuber wounding, using activity-guided fractionation of polar extracts from a Yukon Gold cultivar that had previously exhibited exceptionally high radical-scavenging activity. Activity-guided fractionation using the ABTS^•+ radical scavenging assay and LC-MS with TOF-MS for compositional analysis of the most potent antioxidant fractions yielded identification of nine constituents: coumaroylputrescine; feruloylquinic acid; isoferuloylputrescine; ferulic acid; 22,25-dimethoxy-3-[[2,3,4-tri-O-methyl-6-O-(2,3,4,6-tetra-O-methyl-β-D-glucopyranosyl)-β-D-glucopyranosyl]oxy]-(3β)-lanost-9(11)-en-24-one; 4-(2Z)-2-decen-1-yl-5-[1-(4-hydroxyphenyl)decyl]-1,2-benzenediol; 8-[(2E)-3,7-dimethyl-2,6-octadien-1-yl]-5-hydroxy-2,8-dimethyl-6-(3-methyl-2-buten-1-yl)-2H-1-benzopyran-4,7(3H,8H)-dione; 3-[(2-O-β-D-glucopyranosyl-β-D-glucopyranosyl)oxy]-20-[(6-O-β-D-xylopyranosyl-β-D-glucopyranosyl)oxy]-dammar-24-en-19-al; (3β)-28-oxo-28-(phenylmethoxy)oleanan-3-yl 2-O-β-D-galactopyranosyl-3-O-(phenylmethyl)-, butyl ester β-D-glucopyranosiduronic acid. A positive correlation was observed between the scavenging activities and the polarities of the active fractions. The antioxidant capacities of the fractions were also characterised by monitoring the activity throughout a 45-minute assay period.

1. Introduction

The development of safe, effective preservatives poses a significant challenge in the food and drug industries. The demand for sustainable, natural alternatives to synthetic preservatives, many of which are reported to have a negative impact on the environment as well as potentially carcinogenic effects on consumers, has been growing rapidly over the past decade (Nychas & Tassou, 1999). Plant-based antioxidants have potential applications as natural preservatives, but their sources and potencies remain to be optimised. In particular, the potato (Solanum tuberosum) has been found to be a rich source of antioxidants with high capacities for free radical scavenging (Madiwale, Reddivari, Holm, & Vanamala, 2011). In previous studies, the extracts from potato peels have also been reported to inhibit oxidative processes in food products (Kanatt, Chander, Radhakrishna, & Sharma, 2005).

As the world’s fourth largest crop after wheat, rice, and corn, the potato also ranks third in global consumption, demonstrating its importance as a staple in the human diet as well as a mainstay of the global economy (Al-Weshay & Rao, 2012; Madiwale, et al., 2011; Thompson, et al., 2009). Wounding and mechanical damage of the potato tuber together with suboptimal healing conditions result in desiccation and allow for bacterial or fungal infection. These problems render as many as 40–50% of harvested potatoes unsuitable for human consumption and generate substantial waste by-products (Schieber & Saldana, 2008). However, under proper conditions potatoes form a layer called the wound periderm to guard against pathogen invasion and dehydration, progressing through different stages of healing at successive time points: three days after wounding, the suberised closing layer is fully formed; by the seventh, development of the wound periderm is initiated (Dastmalchi, et al., 2014; Neubauer, Lulai, Thompson, Suttle, & Bolton, 2012). Moreover, in conjunction with periderm formation, wounded potato tissues generate reactive oxygen species (ROS) such as superoxide, peroxide, and hydroxyl radicals, containing infection by triggering cell death and thus damaging the tuber tissue (Reyes, Villarrel, & Cisneros-Zevallos, 2007).

It has been proposed that tubers produce antioxidant compounds to scavenge for ROS in response to such stress (Reyes, et al., 2007), displaying antioxidant activity (AOA) levels comparable to high-antioxidant herbs such as ginkgo and ginger (Kähkönen, et al., 1999). The reported phytochemicals are of significant nutritional and pharmacological interest: they can interfere with oxidative processes by disrupting chain-breaking reactions and scavenging for free radicals; and they are associated with antibacterial, antiallergic, and anticarcinogenic properties (Friedman, 1997; Madiwale, et al., 2011; Madiwale, Reddivari, Holm, & Vanamala, 2012; Thompson, et al., 2009). Moreover, the periderm from potato tubers represents a major industrial by-product that offers a potentially rich source of natural antioxidants. To realistically assess their efficacy as preservatives, the antioxidants must be isolated and identified so that their activities in different food systems can be determined. Published reports of free radical scavenging activities typically utilise assays that are subject to shortcomings such as limited pH range, polarity, steric hindrance, and spectral interference (Magalhaes, Segundo, Reis, & Lima, 2008). Therefore, we sought a versatile assay that could overcome these limitations. The resulting antioxidant activities then formed the basis for activity-guided fractionation and identification of the most potent extracts from the wound-healing potato tuber periderm tissues.

The 2,2'-azinobis(3-ethylbenzothiazoline-6-sulfonic acid) ammonium salt (ABTS) decolorisation assay measures the ability of antioxidants to scavenge free radicals in potato wound periderm by means of a single electron transfer reaction. Its advantages stem from the solubility of ABTS^•+ in both hydrophilic and lipophilic systems and its ability to monitor AOA over a wide pH range as well as over time. The ABTS assay also offers improvements compared with the traditional 2,2-diphenyl-1-picrylhidrazyl (DPPH) assay reported previously (Reyes & Cisneros-Zevallos, 2003; Reyes, et al., 2007), which can suffer from steric hindrance or spectral interference from other phytochemicals (Re, et al., 1999).

A reverse-phase high-performance liquid chromatography (RP-HPLC) strategy using a non-linear gradient system was then employed for separation of phytochemical constituents present in the antioxidant-rich fractions of the wound tissue extract. Finally, liquid chromatography-mass spectrometry (LC-MS) and time-of-flight mass spectrometry (TOF-MS) made it possible to identify the chemical constituents present in the most active fractions. Using the techniques outlined above, this study aimed to isolate and identify the most important antioxidants produced during the wounding response of potato tubers by determining the AOA in Day-7 Yukon Gold polar extracts and the metabolites responsible for scavenging activity. This study builds upon the findings of Dastmalchi, et al. (2014), who found polar wound periderm extracts of the Yukon Gold cultivar at Day 7 to have the highest activity among four tubers with distinct russeting patterns, reflecting the strong antioxidant ability of a number of secondary metabolites (polyphenolic amines, flavonoid glycosides, and phenolic acids) involved in potato tissue wound healing.

Specifically, we subjected the polar fractions of the Day-7 Yukon Gold extract obtained through RP-HPLC to the ABTS assay, in order to evaluate scavenging activity over a time period of 45 minutes, permitting detection of slow- as well as fast-acting antioxidants. To isolate the constituents present in the fractions obtained by HPLC, we used reverse-phase liquid chromatography-mass spectrometry (LC-MS), since the extract being fractionated is polar and its constituents are non-volatile. Hence, through the structural elucidation of highly active fractions and the characterisation of their bioactivities, we hoped to identify promising new sources of natural preservatives with dietary value. We also obtained new information about the phytochemical constituents produced during the potato tuber wound-healing process, uncovering several compounds that had not been identified previously in their native or wound periderms (Dastmalchi, et al., 2014; Dastmalchi, et al., 2015; Narvaez-Cuenca, Vincken, Zheng, & Gruppen, 2012; Yang & Bernards, 2007).

2. Materials and Methods

2.1. Chemicals and reagents

HPLC-MS grade acetonitrile, water, methanol (J. T. Baker, Phillipsburg, NJ), and formic acid (Sigma-Aldrich, St. Louis, MO) were used in HPLC, LC-MS, and TOF-MS analyses. 2,2'-Azinobis(3-ethylbenzothiazoline-6-sulfonic acid ammonium salt) (ABTS), 6-hydroxy-2,5,7,8-tetramethylchromane-2-carboxylic acid (TCI, Tokyo, Japan) and potassium peroxosulfate (Sigma-Aldrich, St. Louis, MO) were used for the antioxidant assay.

2.2 Plant material

Potato tuber cultivars of the Yukon Gold variety, 2011 crop year, were provided by Joe Nuñez, University of California Cooperative Extension (Davis, CA).

2.3 Sample preparation

Procedures for this work followed the methods described by Dastmalchi et al. (2014, 2015). Briefly, Yukon Gold potato tubers were peeled and sectioned longitudinally under sterile conditions using a mandolin slicer to obtain disks ∼5 mm in thickness. Disks were placed on wet cellulose filter paper and left for 7 days at 25 °C on wire netting supports within closed plastic boxes in a dark enclosure. Humidity was maintained by adding water to the bottom of the boxes. The newly formed brown surface layer of easily detached wound tissue was collected using a flat spatula. Harvested wound tissues were frozen immediately in liquid nitrogen and stored at −80 °C for further processing.

The wound tissues were extracted using a modification of the protocol employed by Choi, et al. (Choi, et al., 2004). A 10-mg portion of the freeze-dried material was extracted with 2 mL of 60% (v/v) methanol-water by ultrasonication (Branson Ultrasonics, Danbury, CT) for 1 min, followed by addition of 2 mL chloroform and sonication again for 1 min. Each extract was then incubated at room temperature in a shaker for 10 min, followed by tabletop centrifugation (Beckman Coulter, Fullerton, CA) at 3000 rpm to produce three separate phases: soluble polar, soluble nonpolar, and an interphase of suspended particulates. The upper soluble polar extracts were removed carefully with a glass Pasteur pipette and dried under a flow of nitrogen gas.

2.4 Fractionation of the extracts

LC separation was performed using a 150 × 4.6 mm, 3.0 µm AscentisR C18 column (Supelco, Bellefonte, PA) operated by an Agilent 1200 Series HPLC liquid chromatograph equipped with a G1311A quaternary pump, G1322A degasser, G1316A temperature controller, and G1315B diode array detector coupled to a G1364C analytical fractionator (Agilent, Santa Clara, CA). Each analysis was performed by injecting a 30-µL sample into the column and eluting with a flow rate of 0.4 mL/min. The mobile phase was composed of 0.1% aqueous formic acid (A) and 0.1% formic acid in acetonitrile (B). The following program of nonlinear gradient elution was used: 2% B (0–5 min), 10% B (5–8 min), 15% B (8–25 min), 100% B (25–38 min), and 2% B (38–50 min). Fractions were collected in time-based mode at 30-s intervals between 14 and 41 min during a 50-min chromatographic run that was repeated twenty times to accumulate enough sample for concentration and analysis by LC-MS and TOF-MS.

2.5 ABTS^•+ scavenging

Antioxidant assessment of the polar extracts was conducted using the ABTS assay, following the method employed by Dastmalchi et al. (2014, 2015). The ABTS radical cation was produced by reacting a 140 mM potassium persulfate (K₂S₂O₈) oxidising agent with 7 mM ABTS in the dark at ambient temperature for approximately 12 to 16 hours. Once sufficient ABTS was converted into ABTS,^•+ resulting in decolorisation of the cation, its absorbance was adjusted to 0.70 (±0.02) at 734 nm by dilution with ethanol. A series of 2-µL samples from each of the 30 periderm fractions was placed in individual wells of a 96-well microplate, with each fraction designated by a column of 8 replicates.

The same amounts of ferulic acid and 60% methanol were added to columns designated as positive and negative controls, respectively; 198 µL of ABTS^•+ were added to each well. Absorbance was recorded immediately after mixing using a Spectra_max microplate reader (Molecular Devices, Sunnyvale, CA) set at 734 nm, and at subsequent 5-min intervals for 45 min. The percent inhibition values for each sample were then calculated using the equation:

$$\left[\frac{({\mathit{\text{Absorbance}}}_{\mathit{\text{control}}}-{\mathit{\text{Absorbance}}}_{\mathit{\text{sample}}})}{({\mathit{\text{Absorbance}}}_{\mathit{\text{control}}})}\right]\times 100$$ (1)

Inhibition values for 8 concentrations from 0.2 to 2.0 mM of 6-hydroxy-2,5,7,8 tetramethylchromane-2-carboxylic acid (Trolox) were measured as a reference standard. The area underneath the curve (AUC) of the plot of percent inhibition versus reaction time was then calculated for each fraction. Calculating and comparing the AUC values assesses the levels of scavenging more accurately than the Trolox Equivalent Antioxidant Capacity (TEAC) value, which reflects only the capacity of the antioxidant to inhibit ABTS at a defined time point relative to Trolox. Moreover, the AUC usefully takes into account the rates of reaction of the various antioxidants with ABTS, thus reflecting total activity of both slow and fast-acting compounds.

The AUCs were determined using two different numerical methods. They were first calculated with SigmaPlot (Fig. 1, middle). The integration function of this program employs the trapezoidal rule (Whitaker & Robinson, 1967), which computes the integral over n subintervals of time using a linear piecewise interpolation between the data values obtained over each run. It uses the following equation:

$$\underset{a}{\overset{b}{\int }}f(x)\mathit{\text{dx}}\approx \sum _{i=1}^{n-1}[y(x_{i+1}-x_i)+\frac{1}{2}(y_{i+1}-y_i)(x_{i+1}-x_i)]$$ (2)

These values were then crosschecked with Simpson’s rule (Abramowitz & Stegun, 1972), an alternative method of estimating definite integrals that approximates the function using quadratic instead of linear interpolation (Fig. 1, bottom) using the following equation:

$$\underset{a}{\overset{b}{\int }}f(x)\mathit{\text{dx}}\approx \frac{\Delta \mathrm{x}}{3}[f(x_0)+4f(x_1)+2f(x_2)+\dots +2f(x_{n-2})+4f(x_{n-1})+f(x_n)]$$ (3)

Fig. 1.

2.6 LC-MS

Liquid chromatography was performed using a Shimadzu Ultra Fast Liquid Chromatograph equipped with two LC-20 AD pumps, an SIL-20 AC autosampler, and a CTO-20 AC column oven. Separation was carried out utilizing a 150 × 4.6 mm Supelco AscentisR C18 column. The mobile phase was composed of solvents A, 0.1% aqueous formic acid and B, 0.1% formic acid in acetonitrile with a program of nonlinear elution: 2% B (0–5 min), 2–10% B (5–8 min), 10–15% B (8–13 min), 15% B (13–25 min), 15–30% B (25–28 min), 30–40% B (28–50 min), and 40–100% B (50–60 min). The analysis was performed by injecting 10 µL of each sample twice at a flow rate of 0.4 mL/min at 35 °C.

The LC system was coupled to an Applied Biosystems 4000Q Linear Ion Trap Quadrupole Trap (Q-Trap) mass spectrometer (Foster City, CA) in order to identify the chemical compounds present in each fraction through their MS² fragmentations, using an unfractionated Yukon Day-7 extract as a reference standard. Spectra and full scan data were acquired in both positive and negative modes using electrospray ionisation (ESI), optimised to 66 V and −140 V, respectively, and with a source temperature of 300 °C. Data collected over an m/z range of 100–1300 were processed with Analyst 1.4.1 software; potato metabolites such as chlorogenic acid and rutin, which have been reported previously in potatoes (Dastmalchi, et al., 2014), were used to optimise the declustering potential.

2.7 TOF-MS

The fractions were infused at a rate of 0.01 mL/min using a Harvard 11 Plus Syringe pump (Harvard Apparatus, Holliston, MA) into a Waters LCT XE TOF mass spectrometer (Micromass, Manchester, UK) in positive electrospray mode over the range of m/z 100–1300. The software used for data analysis was MassLynx Version 4.1. The capillary voltage was maintained at 4000 V and the nitrogen gas flow was 300 L/h for both desolvation and nebulisation. The desolvation and source temperatures were 150 °C and 80 °C, respectively. The reference standard used for dynamic range enhancement was a solution of 200 pg/mL leucine/encephalin in 1:1 v/v acetonitrile-water containing 0.1% formic acid. The reference was collected every five scans and data were collected using a scan time of 0.2 s.

2.8 Metabolite identification

Based on the m/z values of the molecular and fragment ions obtained from the TOF-MS experiments, elemental composition analysis was carried out using MassLynx V4.1 software. This procedure generated possible molecular formulas within the given margin of error. Using SciFinder Scholar, we considered all possible compounds with these formulas that had been isolated and identified previously in the Solanaceae plant family; their published molecular ions and fragmentation data were examined to find the molecular structure that best matched our experimental data.

2.9 Statistical analysis

The antioxidant results were presented as mean value ± standard error. Analysis of variance was carried out using Tukey pairwise analysis procedures (Jackson, 2014). Correlations between data sets were calculated using Pearson’s correlation values (Crawley, 2005). SigmaPlot version 13 was used for calculation of the areas under the curve.

3. Results and Discussion

3.1 Evaluation of ABTS^•+ scavenging activity

The validity and accuracy of the ABTS assay for accurate evaluations of AOA in potato wound periderm were demonstrated using a positive control, ferulic acid in ethanol. The average of TEACs measured over all time points was 1.32 mM Trolox/100 g (Table 1), confirming previously published results (El-Sayed & Rabaliski, 2013). Among the 30 fractions that were collected, fractions 1–12 demonstrated significant percentage inhibition values at the end of the assay period (Fig. 1), whereas fractions 13–30 showed no antioxidant activity. Therefore the former fractions were examined further to elucidate their constituent phytochemical substances using LC-MS and MS-TOF analysis.

Table 1.

Linear regression parameters and Trolox equivalent antioxidant capacity (TEAC) values for ferulic acid

Ferulic Acid (Positive Control)
time (min)	trendline equation	regression coefficient	TEAC (mmol Trolox/100 g)1
0	y = 15.878x + 11.881	r2 = 0.9969	1.075
5	y = 19.496x + 9.883	r2 = 0.9848	1.178
10	y = 20.863x + 9.4455	r2 = 0.9954	1.232
15	y = 21.514x + 10.602	r2 = 0.9979	1.307
20	y = 19.441x + 9.9925	r2 = 0.9984	1.199
25	y = 23.006x + 11.496	r2 = 0.9986	1.397
30	y = 23.563x + 11.48	r2 = 0.9988	1.423
35	y = 23.843x + 12.025	r2 = 0.9978	1.456
40	y = 24.012x + 12.375	r2 = 0.9978	1.478
45	y = 24.097x + 12.928	r2 = 0.9976	1.504

¹Values are compared in the text with the report of El-Sayed and Rabaliski, 2013.

Since an RP-HPLC separation technique was employed, more polar compounds eluted first, producing well-resolved chromatograms (Supplementary Figure 1). Therefore one can deduce that the active fractions, 1–12, are the more polar ones and that there is a direct correlation between levels of scavenging activity and polarity. A similar trend was observed in previously studied plant systems for which the greatest antioxidant capacity was found in compounds with highest polarity; now we can extend this correlation to the wound periderm of potato (Bhandari & Rastogi, 1983; Calliet, Lorenzo, Cote, Sylvain, & Lacroix, 2013; Re, et al., 1999).

By comparing the respective percentage inhibitions at the end of the 45-minute assay period as well as their cumulative antioxidant capacities (Fig. 1, top), we identified F4-F8 as the most active fractions. The trend in final percent inhibitions (Fig. 1, top) was confirmed by the AUC values calculated using two different numerical methods (Fig. 1, middle and bottom). Whereas the differences between the AUCs calculated by the two methods are negligible, as shown by a 99.9% correlation between the two sets of numbers, the values calculated with Simpson’s Rule are expected to have a lower percentage error because this method uses a closer approximation to the function curve.

Ultimately, the percentage inhibition at 45 minutes and the AUC values over time were in excellent agreement: F4-F8 possessed both the highest AUC and average final percentage inhibition; likewise, the AUCs for the remaining fractions were directly proportional to their respective inhibition values. By using the AUC approach as well as comparing percent inhibitions, we were able to accurately characterise scavenging activity for both those antioxidants with lag phases (slow-acting) and those without delays (fast-acting). Likewise, the percentage-inhibition vs time plots were able to provide additional information about the kinetics of the antioxidant constituents in each fraction (Fig. 1). Fractions F1–F4 demonstrated a largely linear time dependence of activities, which suggests the presence of slow-acting antioxidants (Figure 2). Conversely, the graphs for F5–F12, which generally show an initial rapid increase followed by a slower rise during the 20- to 45-minute assay period, imply that they likely contain predominantly fast-acting antioxidants (Fig. 1). Pearson correlation analyses (Crawley, 2005) of the data showed >95% correlation of the AUC values with either the 0-minute percentage inhibitions or the activities at 45 min, indicating that the fractions contained both slow- and fast-acting antioxidants. This ability to categorise the rate of antioxidant action by monitoring the scavenging capacity during extended time periods offers further indication of the usefulness of protocols such as the ABTS^•+ scavenging assay.

Fig. 2.

Among the most active fractions, we chose five of the most potent ones for further compositional analysis. The order of activity among these fractions based on the AUC values was F5 > F6 > F8 > F7 and F4.

3.2 Metabolite identification

The most active fractions, F4–F8, were further analysed by mass spectrometry using LC-MS Q-Trap and MS-TOF instruments; the chemical constituents present therein were then identified from spectra illustrated in Supplementary Figure 2 and are summarized in Table 2. The full scan data from the LC-MS Q-Trap analysis were compared with the ionic spectra from MS-TOF runs, in order to confirm the consistency of the two datasets. The active fraction F4 contained coumaroylputrescine (Table 2, compound 1), a compound with reported superoxide anion radical-scavenging activity (Narvaez-Cuenca, et al., 2012) that is thought to be an important part of the plant’s non-enzymatic defence mechanism (Velikoca, Edreva, Tsonev, & Jones, 2007). Ferulic acid (FA) was found in both F4 and F5 (Table 2, compound 2); this second compound has been reported previously for effective scavenging of superoxide anion radical and thus approved in several countries as a safe food additive to inhibit lipid peroxidation (Chung & Champagne, 2011). Moreover, Compound 2 has also demonstrated significant levels of antifilarial activity against adult worms of S. cervi in comparison to those of antifilarial drugs in current use (Saini, Gayen, Nayak, & Deepak, 2012). A third isolated component with m/z 525.2873 did not appear in prior published reports for this plant family.

Table 2.

Chemical Constituents Present in Antioxidant-Rich Polar Fractions of Wound-Healing Potato Periderms

Compound No.	Fraction	Observed Mass (formula, error)	MS/MS fragment ions (positive mode) (m/z	Compound (molecular weight)	Formula	References
1	4	235.1471 (C13H19N2O9 −10.2ppm)	235, 118	Coumaroylputrescine (234.1368)		(Narvaez-Cuenca, Vincken, & Gruppen, 2012)
2	4, 5	217.0465 (C10H10O4Na −5.5ppm)	173,155, 127	Ferulic acid (194.0579)		(Ieri et al., 2011)
3	5	369.1133 (C17H21O9 −14.4ppm)	305, 261, 217	Feruloylquinic acid (368.1107)		(Wu, Meyer, Whitaker, Litt, & Kennelly, 2013)
4	6	925.6329 (C51H89O14 7.7ppm)	791, 613	22,25-dimethoxy-3-[[2,3,4-tri-O- methyl-6-O-(2,3,4,6-tetra-O- methyl-β-D-glucopyranosyl)-β-D- glucopyranosyl]oxy]-, (3β)- lanost-9(11)-en-24-one(924.6174)		(Bhandari & Rastogi 1983)
5	6	481.3687 (C32H49O3 −4.9ppm)	437,419,217	4-(2Z)-2-decen-1-yl-5-[1-(4- hydroxyphenyl)decyl]-1,2- benzenediol (480.3603)		(Yang, Sun, Yang, Hu, Luo, Wang, et al., 2013)
6	7	265.1534 (C14H21N2O3, 0.4ppm)	162, 149, 134,117	Isoferuloylputrescine (264.1474)		(Dastmalchi et al. 2014)
7	7	413.2687 (C26H37O4 −0.5ppm)	297, 279, 239, 219, 171, 133	8-[(2E)-3,7-dimethyl-2,6- octadien-1-yl]-5-hydroxy-2,8- dimethyl-6-(3-methyl-2-buten-1- yl)-2H-1-benzopyran-4,7(3H,8H)- dione(412.2614)		(An, Hu, Cheng, & Chen, 2001)
8	7	1077.5980 (C53H89O22Na 12.4ppm)	913, 861, 413	3-[(2-O-β-D-glucopyranosyl-β-D- glucopyranosyl)oxy]-20-[(6-O-β- D-xylopyranosyl-β-D- glucopyranosyl)oxy]-dammar-24- en-19-al(1032.6174)		(Yoshikawa, M., Arihara, S., Matsuura, K., & Miyaset, T. 1992)
9	8	1033.6256 (C60H89O14 11.1ppm)	1017, 753, 634, 387, 349	(3β)-28-oxo-28-(phenylmethoxy) oleanan-3-yl 2-O-β-D-galactopyranosyl-3-O-(phenylmethyl)-, butyl ester β-D-glucopyranosiduronic acid (1032.6174)		An, Hu, Cheng, & Chen, 2001)
Incompletely Identified Compounds
	Fraction		Exact Mass	Fragment ions	Class of Compound
1	4		525.2873	481, 349, 305,261
2	5		349.1836	313, 185, 195	Ferulic acid derivative

Active fraction F5 was also found to contain feruloylquinic acid (FQA) (Table 2, Compound 3), using high-resolution mass spectrometry (TOF-MS) and by comparison with fragmentation data from prior studies (Wu, Meyer, Whitaker, Litt, & Kennelly, 2013). The presence of a catechol moiety and adjacent phenolic groups can explain the electron-donating ability and consequent free-radical-scavenging activity of this compound (Bendary, Francis, Ali, Sarwat, & El-Hady, 2013). Compound 3 has been reported previously in our metabolomic investigation of polar extracts from wounded potato tissues as an abundant marker for the Norkotah Russet cultivar in both Day-3 and Day-7 extracts (Dastmalchi, et al., 2014). The compound has also been reported to have an inhibitory effect on enzymatic browning caused by polyphenol oxidase (PPOs) in mushroom and potato, proposed in turn to occur by inhibiting the production of o-quinone melanin precursors (Kuijpers, et al., 2014). This compound and its derivatives, which are also found in coffee, have exhibited diverse biological functions in animal models. For instance, they have the ability to suppress postprandial hyperglycaemia, hyperinsulinaemia and hyperlipidaemia through the inhibition of intestinal enzymes in mice (Murase, et al., 2012). A third component present with an m/z 349.1836 failed to match prior reports for this plant family. However, the fragmentation pattern suggests that this compound is a ferulic acid derivative.

In fraction F6 we detected a molecular ion corresponding to the saponin 22,25-dimethoxy-3-[[2,3,4-tri-O-methyl-6-O-(2,3,4,6-tetra-O-methyl-β-D-glucopyranosyl)-β-D-glucopyranosyl]oxy]-lanost-9(11)-en-24-one (Table 2, Compound 4), and its fragment ion corresponding to 26-(acetyloxy)-(24E)-lanosta-7,9(11),24-trien-3-one. This saponin has been isolated previously from the plant Trichosanthes palmate (Bhandari et al., 1983). The fragment aglycone was isolated from Ganoderma lucidum (Munehisa et al., 1986). Another compound present in F6 was the alkylphenol, Sarmentosumol F, designated as 4-(2Z)-2-decen-1-yl-5-[1-(4-hydroxyphenyl)decyl]-1,2-benzenediol (Yang et al., 2013) (Table 2, Compound 5). As mentioned above, the presence of a catechol group and an adjacent phenolic group can explain the free-radical-scavenging ability of the compound and its possible contribution to the antioxidant activity of the extract. Another notable feature of this molecule is the presence of a long-chain hydrocarbon. This compound, isolated for the first time in the plant Piper sarmentosum, has been reported to possess antimicrobial activity against Escherichia coli, Staphylococcus aureus and Candida albicans microbial species. In addition, this compound demonstrated cytotoxicity against human myeloid leukaemia and in two human lung adenocarcinoma cell lines (Yang et al., 2013). All isolated components in fraction 6 were identified.

F7 was found to contain three other compounds of interest: isoferuloylputrescine, Compound 6, 8-[(2E)-3,7-dimethyl-2,6-octadien-1-yl]-5-hydroxy-2,8-dimethyl-6-(3-methyl-2-buten-1-yl)-2H-1-benzopyran-4,7(3H,8H)-dione, Compound 7, and 3-[(2-O-β-D-glucopyranosyl-β-D-glucopyranosyl)oxy]-20-[(6-O-β-D-xylopyranosyl-β-D-glucopyranosyl)oxy]-dammar-24-en-19-al, Compound 8 (Table 2). Compound 6 itself has been reported to offer resistance to Phytophthora infestans infection in potatoes (Yogendra, et al., 2014). Compound 7 was first reported as a benzopryan derivative isolated from Mallotus apelta, a plant widely used to treat chronic hepatitis and showing moderate anti-microbial activity (An, Hu, Cheng, & Chen, 2001). Moreover, its synthetic analogues have been found to exhibit substantial scavenging capacity as well as antiviral activity (Koufaki, et al., 2006). Compound 8, a steroidal saponin known as Gymnemaside V, has been reported in Gymnema sylvestre, which is used in traditional medicine as a diuretic and cough remedy, as well in the treatment of diabetes (Yoshikawa, Arihara, Matsuura, & Miyaset, 1992). This compound belongs to a class of phytochemical substances known as Gypenosides. These compounds have demonstrated bioactivities such as in vitro inhibition of pancreatic lipase which can be relevance in the treatment of hyperlipidaemia (Su, et al., 2016). These compounds are also being investigated for their effectiveness in cancer therapy since they induce p53-independent apoptosis in a lung carcinoma cell line (Liu, et al., 2015). The toxicological attributes of these constituents have not been studied previously; nevertheless, their reported activities suggest valuable potential as preservatives for the manufacture of food and cosmetics. All components of Fraction 7 were identified.

The next most active fraction (F8) was found to contain (3β)-28-oxo-28-(phenylmethoxy)oleanan-3-yl 2-O-β-D-galactopyranosyl-3-O-(phenylmethyl)-, butyl ester of β-D-glucopyranosiduronic acid, (Compound 9, Table 2). This compound was first isolated from Panax japonicus, Japanese ginseng. Moreover, as a relatively scarce triperpenoid saponin in nature, its chemical synthesis has also been attempted, due to interest in its anti-fungal and ant-inflammatory properties (Liu, Fan, Li, Li, & Guo, 2010). Similar derivatives have been reported to exhibit substantial DPPH-detected radical scavenging as well as melanogenesis-inhibitory activity (Zhang, et al., 2014). In addition, they have demonstrated anti-diabetic potential, whereby effective inhibition of the formation of advanced glycation end-products could suggest effectiveness against other mechanisms contributing to hyperglycaemia (Matsuda, Wang, Managi, & Yoshikawa, 2003). Ultimately, although lower in scavenging capacity than Compound 3 found in F5, this identified saponin appears to display complementary bioactive functions. All components in Fraction 8 were identified successfully.

Fractions 10 and 11 contained chlorogenic acid, which is a well-established antioxidant (Madiwale, et al., 2011; Nenadis, Wang, Tsimidou, & Zhang, 2004) that is abundant in our wound tissue extracts (Dastmalchi, et al., 2014). Nonetheless the fractions containing chlorogenic acid were not among the most active fractions, possibly because of a potentiation effect for the constituents in the highly active fractions. Chlorogenic acid has been identified previously as a potential biomarker in the Yukon Gold Day-7 polar extract in a study of four potato cultivars with a gradient of russeting character (Dastmalchi, et al., 2014). This compound has been reported to have beneficial properties for human health, including antioxidant, hypoglycaemic, antiviral and hepatoprotective functions demonstrated in vitro, in vivo and in epidemiological studies (Farah & Donangelo, 2006).

4. Conclusions

This study successfully identified the most active polar antioxidant metabolites produced in Yukon Gold potato periderm tissues 7 days after wounding. Moreover, by performing activity-guided fractionation on the wound periderm extract, we established a high degree of correlation between antioxidant capacity and polarity. This trend validates the important contributions of the most polar fractions to the scavenging capacity of the extract (Dastmalchi, et al., 2014; Dastmalchi, et al., 2015; Schieber, et al., 2008).

Many chemical constituents of the most potent antioxidant fractions were provisionally identified using LC-MS/MS and MS-TOF methods; structural elucidation of the two newly reported compounds in active fractions 4 and 5 should be possible with additional NMR measurements on larger samples. A useful follow-up study would involve screening of these fractions against potato pathogens to investigate whether the metabolites can offer protection to the potato tuber on a larger agricultural scale. Future studies could also evaluate interactions, such as synergism, potentiation, and antagonism between the phytochemical constituents, especially those involving the multiple active metabolites present in each of fractions 6, 7. Because compounds such as Sarmentosumol F, 8-[(2E)-3,7-dimethyl-2,6-octadien-1-yl]-5-hydroxy-2,8-dimethyl-6-(3-methyl-2-buten-1-yl)-2H-1-benzopyran demonstrated significant bioactivities in various disease models, they could have potential as templates for drug development. Thus the findings of the current study provide motivation to further investigate the identified metabolites as natural preservatives with possible dietary value (Maqsood, Benjakul, & Shahidi, 2013). Taking such an approach, it is possible to use antioxidant capacity assessment of wounded plant tissues to point the way toward phytochemicals that can be beneficial to the food industry.

Highlights.

• ABTS^•+ scavenging activity was assessed for potato wound periderm extracts.

• Activity monitored vs. time revealed fast- and slow-acting antioxidant fractions.

• The compositions of the most active fractions were analyzed using LC-MS.

• The antioxidant compounds in the most active fractions were identified structurally.
