Predicting IDH mutation status in grade-II gliomas using amide proton transfer-weighted (APTw) MRI

Abstract

Purpose

To assess the APTw-MRI features of isocitrate dehydrogenase (IDH)-wildtype and IDH-mutant grade-II gliomas and to test the hypothesis that the APTw signal is a surrogate imaging marker for identifying IDH mutation status preoperatively.

Methods

27 patients with pathologically confirmed low-grade glioma, who were previously scanned at 3T, were retrospectively analyzed. The Mann-Whitney test was used to evaluate relationships between APTw intensities for IDH-mutant and IDH-wildtype groups, and the receiver-operator-characteristic analysis was used to assess the diagnostic performance of APTw.

Results

Based on histopathology and molecular analysis, seven cases were diagnosed as IDH-wildtype grade-II gliomas, and 20 cases as IDH-mutant grade-II gliomas. The maximum and minimum APTw values, based on multiple regions of interest, as well as the whole-tumor histogram-based mean and 50^th percentile APTw values, were significantly higher in the IDH-wildtype gliomas than in the IDH-mutant groups. This corresponded to the areas under the receiver-operator-characteristic curves of 0.89, 0.76, 0.75, and 0.75, respectively, for the prediction of the IDH mutation status.

Conclusions

IDH-wildtype lesions were typically associated with relatively high APTw signal intensities, compared with IDH-mutant lesions. The APTw signal could be a valuable imaging biomarker by which to identify IDH1 mutation status in grade-II gliomas.

INTRODUCTION

Gliomas are the most common primary brain tumors, and more than 23,770 new cases are diagnosed in the USA each year (1). The recent breakthrough in the understanding of isocitrate dehydrogenase (IDH) mutations in glioma has resulted in a prompt reappraisal of the molecular oncogenesis of this group of diseases (2–5). Notably, for the first time, the most recent 2016 WHO classification of central nervous system (CNS) tumors uses molecular parameters, in addition to histology, to define tumor entities, thus formulating a basis for how CNS tumor diagnoses should be structured in the molecular era (6). The IDH enzyme catalyzes the oxidative decarboxylation of isocitrate to α-ketoglutarate (α-KG), needed for producing NADH and NADPH during cellular respiration. Mutations in IDH genes, which occur in the majority of WHO grade-II and -III gliomas and secondary glioblastomas, have been postulated to indicate a favorable clinical prognosis (2–5). Since IDH-gene-encoded enzymes are closely involved in the energy-producing Krebs cycle as catalytic isozymes, mutations in IDH genes may cause widespread disturbances of cellular metabolism, including alteration of amino acid concentrations and enzymatic activity (7, 8), and raise global DNA hypermethylation and global downregulation of protein expression as well (9, 10). Therefore, IDH-directed therapy, including IDH inhibitors and DNA methyltransferase inhibitors, have been developed and may impart a cumulative clinical benefit for the targeted patients (11).

As popularly applied in clinical practice, IDH mutation screening is generally performed with an immunohistochemical (IHC) assay on surgical samples using antibodies which detect IDH1-R132H. More than 85% of all genetic alterations in IDH1 in gliomas are heterozygous missense mutations of arginine to histidine (R132H); thus, this immunohistochemical approach will detect the majority of cases (12). For IHC-negative or IHC-equivocal cases, DNA sequencing is recommended as a complementary test (13). However, it is not uncommon that lab tests lead to false-negative results when inadequate neoplastic cells from a biopsy procedure are mixed in with the normal cell background. Thus, sufficient tumor tissue should be obtained from surgery, while balancing the benefits of removing tumor versus the potential risks for damaging normal tissue in patients with low-grade gliomas. It is these aspects of IDH-wildtype and IDH1-mutant gliomas that provide the impetus for the pre-operative determination of IDH mutational status, with methods such as MRI, which, potentially, can rapidly and noninvasively provide a comprehensive assessment. Such imaging methods could at minimum be used to better guide the biopsies needed for ICH assessment.

In recent years, researchers have evaluated the feasibility of applying several MRI techniques to determine IDH status in patients with gliomas (14–18), including gadolinium-enhanced T₁-weighted (Gd-T₁w) images (19), diffusion (20–22), perfusion (23), sodium MRI (24), and machine-learning algorithms (25, 26). Notably, since lab studies have proven that the oncometabolite 2-hydroxyglutarate (2-HG) holds a 100-fold increase in IDH-mutant cells compared to IDH-wildtype type cells (27), recent studies have also shown that significantly higher 2-HG detected by single-voxel MRS can identify patients with IDH-1 mutant gliomas, with high sensitivity (28–30). However, the MRS detection of 2-HG in IDH-mutant gliomas requires a large tumor volume (31), and is time-consuming, which limits the application of MRS. In addition, partial volume effects between different tumor regions may obscure the presence of 2-HG in smaller regions.

Amide proton transfer-weighted (APTw) MRI, a specific type of chemical exchange-dependent saturation transfer (CEST) imaging (32, 33), is an upcoming molecular imaging technique that can generate image contrast based on the endogenous cellular mobile proteins in tissue (34, 35). Since APT imaging was first reported in 2003 (34, 35), it has been studied as an imaging biomarker in a variety of cancers (36–41) and non-oncologic diseases (42–45). For glial neoplasms, in particular, consistent APTw MRI results have been produced across various labs, showing promise for the grading of gliomas (distinct hyperintensity in grades-III and -IV gliomas vs. iso-intensity to minimal hyperintensity in grade-II gliomas) (46–48), which demonstrate increasing protein concentrations with grade, as revealed by proteomics (49, 50) and in vivo MR spectroscopy (51). In this study, we assessed the APTw MRI features for IDH-wildtype and IDH-mutant grade-II gliomas before surgery, with the hypothesis that APTw signal intensity metrics could aid in the preoperative identification of the IDH genotype in grade-II gliomas.

METHODS

Patients

This retrospective study was approved by the local institutional review board, and informed consent was waived. Enrollment criteria were as follows: ≥18 years old; APTw and routine MRI scanning occurred within 7 days preoperatively; histopathologically confirmed as a WHO grade-II astrocytoma, oligoastrocytoma, or oligodendroglioma (according to their medical records; originally based on the 2007 WHO criteria); IDH1 mutation status and 1p/19q co-deletion status available from operative sample; and received no radiotherapy or chemotherapy before imaging. Exclusion criteria included: inferior image quality due to various reasons.

MRI Data Acquisition

MRI scanning was performed on a 3T clinical MRI scanner (Achieva; Philips Medical Systems, Best, The Netherlands). APT image data were obtained using a fat-suppressed, single-shot, fast spin-echo pulse sequence, using the following parameters: radiofrequency saturation power = 2 µT; duration = 800 ms (four block pulses; 200 ms each; inter-pulse delay, 10 ms); repetition time = 3 sec; echo time = 11 ms; matrix = 140×70 (reconstructed to be 400 × 400); sensitivity-encoding factor = 2; turbo-spin-echo factor, 37; field of view = 240×240 mm²; and slice thickness = 6 mm. A single-slice, combined APTw imaging and Z-spectrum acquisition protocol [31 offsets = 0, ±0.25, ±0.5, ±0.75, ±1, ±1.5, ±2, ±2.5, ±3 (2), ±3.25 (4), ±3.5 (8), ±3.75 (4), ±4 (2), ±4.5, ±5, ±6 ppm; the values in parentheses were the number of acquisitions, which was 1, if not specified] was applied to the maximum cross-sectional tumor area (as determined by standard MRI images). More acquisitions were obtained at and around ±3.5 ppm to obtain a sufficient signal-to-noise ratio for APTw images; more offsets were used near 0 ppm to increase the fitting accuracy of B₀ maps; and more offsets were used close to ±3.5 ppm to increase the interpolation accuracy of APTw data for B₀ correction (36). A saturated image at 15.6 ppm (or 2 kHz at 3 Tesla) was also acquired to calculate magnetization transfer ratio (MTR) values for conventional semisolid magnetization transfer (MT) imaging. The scanning time for this combined scan was about three minutes. Several standard MRI sequences were acquired for reference, including T₂-weighted (T₂w), T₁w, and Gd-T₁w. The Gd-T₁w imaging (0.2 mL/kg body weight; Magnevist; Bayer Schering, Guangzhou, China) was the last sequence acquired.

APTw and MT Image Processing

The image analysis was performed by the interactive data language (IDL, Version 7; Exelis Visual Information Solutions, Inc., Boulder, CO, USA). To reduce possible motion artifacts during the scanning, the acquired APTw image or Z-spectrum series was registered to the saturated image at 3.5 ppm (52). The acquired APTw image or Z-spectrum series was further corrected for the B₀ inhomogeneity effect on a voxel-by-voxel basis, as described previously (36). The APTw image was constructed with the so-called magnetization transfer-ratio asymmetry at the offsets of ±3.5 ppm (34, 35): MTR_asym(3.5 ppm) = S_sat(−3.5 ppm)/S₀ − S_sat(+3.5 ppm)/S₀, where S_sat and S₀ are the imaging signal intensities with and without selective radiofrequency irradiation, respectively. To account for the contribution of the possible nuclear Overhauser enhancement (NOE) effect of protons in mobile and relatively mobile proteins at −3.5 ppm on MTR_asym(3.5ppm) (53–56), as well as possible asymmetries in the conventional semisolid-based MT effect (57), the calculated MTR_asym(3.5ppm) image is best described as the APTw image (46). In addition, for conventional MT imaging, MTR(2 kHz) = 1 − S_sat(2 kHz)/S₀.

APTw and MT Image Analysis

To perform quantitative APTw and MTR analyses, the acquired conventional MR images from each case were co-registered to the corresponding saturated S_sat image at 3.5 ppm, which was co-registered with the APTw image, as described previously (52). Primarily based on the T₂w image, regions of interest (ROIs) were carefully drawn by radiologists (S.J. and X.W., who have had ten and seven years of experience in brain imaging, respectively), together with MRI physicists. One large ROI covering the whole area of abnormal intensity on the T₂w image was first drawn. Similar to some previous reports (38, 39), five small tumor ROIs were further chosen in the T₂w-hyperintense lesion area. Each ROI encompassed around 100–130 voxels (reconstructed). ROIs excluded the large cyst, hemorrhage, or vessels evident on standard MRI sequences. The contralateral normal-appearing white matter (CNAWM) was also analyzed, and relative APTw values were reported (ROI APTw - CNAWM APTw). For each case, the maximum and minimum APTw values among the five small tumor ROIs, as well as the Z-spectrum data and APTw histogram data corresponding to the ROI with maximum APTw (“tumor core”), were recorded. For the large whole-tumor ROI, the Z-spectrum data, APTw histogram data, and average MTR value were recorded. The histogram data were analyzed for mean, variance, skewness, kurtosis, slope, 10^th percentile, 50^th percentile, 90^th percentile, and peak values, as defined before (58).

Histopathological Evaluation

Operative tissue samples were processed using standard clinical techniques. IDH1-R132H evaluation was performed by IHC and DNA sequencing, as described previously (13, 59). Paraffin-embedded slices of operative specimens were stained with IDH1-R132H-specific antibody (1:50; H09 clone, Dianova; Hamburg, Germany). To amplify exon 4 (codon R132) of the IDH1 gene, we designed the forward primer (5′-ACC AAA TGG CAC CAT ACG A-3′) and reverse primer (5′-GCA AAA TCA CAT TAT TGC CAA C-3′). Fluorescent in situ hybridization testing was applied to assess the 1p/19q codeletion. An experienced pathologist (Y.W.), blinded to the imaging findings, evaluated and re-classified all the cases according to the 2016 WHO classification of central nervous system tumors (6). Tumor grading documented in the clinical pathological reports (originally based on the 2007 WHO criteria and reported by multiple pathologists) was confirmed for all patients enrolled. The molecular pathological reports (IDH, 1p/19q) were taken into account.

Statistical Analysis

The data were reported as means and standard deviations. After normality testing, the Mann-Whitney U test was used to analyze the statistical differences between quantitative imaging parameters for the two IDH mutation statuses. We further employed receiver operating characteristic curve (ROC) analysis to assess the diagnostic performance of APTw metrics. All statistical analyses were performed using statistical software (SPSS, Version 23; Chicago, IL, USA). Generated P-values were two-tailed, and P < 0.05 was considered statistically significant.

RESULTS

Patient Demographics

Between 2014 and 2016, 31 patients who fulfilled the eligibility criteria according to their medical records were retrospectively analyzed. Patients typically showed some neurological deficit or seizures. 27 patients (15 males, 12 females) were finally recruited for this study, after four patients were excluded (inferior image quality duo to the patient movement, n = 3; or irremovable artifacts caused by a large intratumoral hemorrhage, n = 1). The clinical characteristics of the patient population are summarized in Table 1. Tissue samples were available from all subjects either by stereotactic biopsy (n = 3); gross total resection (n = 21); or subtotal resection (n = 3). IDH mutations were found in 20 cases (74.1%), 15 of which were histopathologically classified as oligodendrogliomas, IDH mutant and 1p/19q codeleted, and five as diffuse astrocytomas, IDH mutant. In the seven patients (25.9%) with IDH-wildtype glioma, all were classified as diffuse astrocytomas, IDH wild-type.

Table 1.

Clinical Characteristics of Patient Population

	IDH wild-type (n = 7)	IDH mutant (n = 20)
Clinical parameters:
Gender (male/female)	4/3	11/9
Ages (y)*	37.1±7.9	40.5±13.7
Seizures (yes/no)	5/2	14/6
KPS score*	82.6±9.7	85.4±8.9
Imaging parameters:
Cerebral lobes involved (<2/≥2)	4/3	15/5
Contrast enhancement (yes/no)	0/7	1/19
Histopathological Diagnosis:
Oligodendroglioma	0	15
Diffuse astrocytoma	7	5

^*Data are mean ± standard deviation.

Comparison between MTR_asym Spectra for IDH-wildtype and IDH-mutant Gliomas

The average MTR_asym spectra for the groups of patients with IDH-wildtype and IDH-mutant gliomas were compared to explore the specific characteristics of the APT effect at an offset of ~3.5 ppm downfield from water (Fig. 1). Both glioma types demonstrated stronger protein-based APT and other CEST effects in the offset range of 1.5–4 ppm, compared to the CNAWM. As reported previously (46), all MTR_asym spectra were negative at the higher frequency (>4.5 ppm) due to the upfield NOE effect and the conventional MT asymmetry. The CEST signal intensities in the offset range of 1.5–4 ppm (including the APT signal at 3.5 ppm downfield from water) were relatively higher in IDH-wildtype than in IDH-mutant gliomas, except for the CEST effect at 2.0 ppm (35, 60), which showed no difference in absolute MTR_asym between the two glioma types, but stood out in intensity relative to the other frequencies in the mutant type itself. Particularly in the IDH-wildtype tumor core, a relatively high APT effect was clearly observed at 3.5 ppm offset from water, at which the amide protons of endogenous mobile proteins and peptides resonate (61). The APTw-MRI metrics are associated with relevant proteomic characteristics that may provide valuable information for the non-invasive discrimination of IDH mutation status.

Fig. 1.

a,b: Comparison of the average MTR_asym spectra of whole tumor, tumor core, and CNAWM for IDH-wildtype (a) and IDH-mutant (b) grade-II gliomas. The CEST effects were clearly visible at multiple frequencies in the frequency offset range to 1.5–4ppm. c,d: MTR_asym spectra relative to CNAWM providing the relative APTw intensities. The most significant CEST effect was the APT at 3.5ppm in the IDH-wildtype tumor core.

Comparison between APTw Images for IDH-wildtype and IDH-mutant Gliomas

The APTw features of the IDH-wildtype and IDH-mutant gliomas (WHO grade-II) were further accessed, using several standard MRI (T₂w, T₁w, and Gd-T₁w) sequences. Of seven IDH-wildtype gliomas (WHO grade-II), four lesions were located in the temporal lobe, and the remaining three lesions mainly involved in the frontotemporal lobe. Figure 2 shows one example of standard and APTw MR images for an IDH-wildtype glioma (WHO grade-II). All seven lesions showed no visible enhancement on the post-contrast T₁w images. The APTw images showed mildly increased hyperintensity in T₂w-hyperintense areas (at least some portions), compared to the CNAWM, demonstrating the IDH-wildtype lesions as relatively heterogeneous masses with scattered punctate or pitchy high APTw signals.

Fig. 2.

Conventional and APTw MR images, a mutant IDH1-R132H-stained section, and a whole-tumor histogram of an IDH-wildtype, WHO grade-II diffuse astrocytoma (male; 33y), who underwent partial tumor resection and left a visible surgical cavity and measurable residual tumor. The tumor (red arrows) involved the right frontal lobe and showed heterogeneous hyperintensity on the T₂w image, hypointensity on the T₁w image, and no obvious Gd enhancement. Compared to the CNAWM, the well-defined lesion showed scattered punctate and pitchy hyperintensity on the APTw image (inset, using a small window of −3~3%). The operative sample demonstrated IDH1-negative expression on the IHC-stained slice. The whole-tumor APTw histogram had a mean APTw value of 1.75% and a 50^th percentile APTw value of 1.80%. Yellow arrows were a large cyst. ROIs for quantitative analysis were placed on the T₂w image: red-solid ROIs for five small tumor ROIs; blue-solid ROI for the whole tumor; and green-solid ROI for the CNAWM.

Of 20 patients with IDH-mutant gliomas (WHO grade-II), 11 lesions were located in the frontal lobe, five were located in the temporal lobe, and five had the major lesion located in the frontotemporal lobe. Figure 3 shows one example of the standard and APTw MR images for a patient with an IDH-mutant oligodendroglioma. These IDH-mutant gliomas showed no (n = 19) or slightly central faint (n = 1) enhancement on the post-contrast T₁w images. All lesions showed visually homogeneous iso-intensity to minimal APTw hyperintensity in T₂w-hyperintense areas, compared to the CNAWM.

Fig. 3.

Standard and APTw MR images, a mutant IDH1-R132H-stained section, and a whole-tumor histogram of an IDH1-mutant, WHO grade-II oligodendroglioma (female; 52y). The tumor (red arrows) mainly involved the left frontal lobe, showing homogeneous hyperintensity on the T₂w image, hypointensity on the T₁w image, and no obvious enhancement. Compared to the CNAWM, the ill-defined lesion showed iso-intensity to minimal hyperintensity on the APTw image (inset, using a small window of −3~3%). The operative sample demonstrated diffusely IDH1-positive expression in the tumor cytoplasm on the IHC-stained slice. The whole-tumor APTw histogram had a mean APTw value of 1.37% and a 50^th percentile APTw value of 1.30%. Purple arrows were a large vessel. ROIs for quantitative analysis were placed on the T₂w image: red-dashed ROIs for five small tumor ROIs; blue-dashed ROI for the whole tumor; and green-dashed ROI for the CNAWM.

Quantitative APTw and MTR Analyses

Figure 4 shows histograms of APTw values obtained from whole tumor, tumor core (corresponding to the ROI with maximum APTw), and CNAWM for IDH-wildtype and IDH-mutant grade-II gliomas. The multi-ROI-based (maximum and minimum) and whole-tumor histogram-based (mean, variance, skewness, kurtosis, slop, 10^th percentile, 50^th percentile, 90^th percentile, and peak) APTw metrics for IDH-wildtype and IDH-mutant gliomas, together with the MTR value, are summarized in Table 2. Differences between APTw values for IDH-wildtype and IDH-mutant gliomas, based on histogram analysis that corresponded to the ROI with maximum APTw, are summarized in Supporting Table S1.

Fig. 4.

a,b: Average histograms of APTw values from the whole tumor, the tumor core, and the CNAWM of IDH-wildtype (a) and IDH-mutant (b) grade-II gliomas. The red lines for tumor cores in (a) and (b) were amplified five-fold. c,d: Comparison of APTw histograms for two IDH mutation types for whole-tumor (c) and tumor core (d).

Table 2.

Differences between APTw and MTR Values for IDH-wildtype and IDH-mutant Gliomas

Parameters	IDH wild-type (n = 7)	IDH mutant (n = 20)	P values
APTw multi-ROI analysis:
Maximum	2.03±0.72	0.99±0.33	<0.001
Minimum	0.99±0.47	0.59±0.32	0.02
Whole-tumor APTw histogram analysis:
Mean	1.39±0.49	0.93±0.44	0.03
Variance	0.61±0.36	0.97±0.73	0.23
Skewness	−0.13±0.28	−0.35±0.83	0.50
Kurtosis	0.57±0.67	1.82±3.32	0.34
Slope	2.27±0.77	2.65±0.91	0.33
10th percentile	0.48±0.54	−0.14±0.76	0.06
50th percentile	1.39±0.46	0.96±0.36	0.02
90th percentile	2.30±0.64	1.98±0.49	0.18
Peak	1.33±0.52	1.02±0.37	0.09
Whole-tumor MTR:
Mean	14.9±2.1	16.3±5.3	0.63

Note: Data are mean ±standard deviation. Significant results are printed in bold.

Based on the multi-ROI analysis, the IDH-wildtype gliomas had higher maximum (2.03 ± 0.72 vs. 0.99 ± 0.33) and minimum (0.99 ± 0.47 vs. 0.59 ± 0.32) APTw values than the IDH-mutant gliomas, both of which were statistically significant (P < 0.001 and P = 0.02, respectively). Based on the histogram-based analysis, the IDH-wildtype gliomas had significantly higher mean (1.39 ± 0.49 vs. 0.93 ± 0.44; P = 0.03) and 50^th percentile (1.39 ± 0.46 vs. 0.96 ± 0.36; P = 0.02) APTw values than the IDH-mutant group. Three other histogram parameters, 10^th percentile, 90^th percentile, and peak values, showed a higher trend in the IDH-wildtype group, compared to the IDH-mutant group (P = 0.06–0.18; insignificantly). For variance, skewness, kurtosis, and slope of APTw values, there were no significant differences between the two glioma groups (P > 0.2). Further, the whole-tumor MTR values showed no significant difference between the IDH-wildtype and IDH-mutant groups (14.9 ± 2.1 vs. 16.3 ± 2.5.3; P = 0.63).

Prediction of IDH Mutation with APTw Metrics

Among 11 APTw metrics, the multi-ROI-based maximum and minimum APTw values, as well as the histogram-based mean and 50^th percentile APTw values, differed significantly between the IDH-wildtype and IDH-mutant groups. Based on ROC curve analyses (Supporting Fig. S1), the multi-ROI-based maximum values showed the highest area under the ROC curve (0.89), and the areas under the ROC curves for the multi-ROI-based minimum, histogram-based mean, and histogram-based 50^th percentile APTw metrics in predicting the IDH mutation status were 0.76, 0.75, and 0.75, respectively (Table 3). IDH mutation status was thus predictable with APTw imaging, non-invasively.

Table 3.

Diagnostic Performance of Whole-tumor Histogram-based(Mean, 50^th percentile) and Multi-ROI-based (Maximum, Minimum)APTw Parameters in Predicting IDH Genotypes

Parameters	AUC (95% CI)	Sensitivity (95% CI)	Specificity (95% CI)	PPV (95%CI)	NPV (95%CI)	Cut-off value (%)
Mean	0.75 (0.52–1)	0.57 (0.20–0.94)	1	1	0.87 (0.73–1.01)	1.58
50th percentile	0.75 (0.49–1)	0.71 (0.38–1.05)	0.95 (0.85–1.05)	0.83 (0.54–1.13)	0.91 (0.78–1.03)	1.45
Maximum	0.89 (0.73–1)	0.57 (0.18–0.90)	1	1	0.87 (0.74–0.94)	1.67
Minimum	0.76 (0.51–1)	0.43 (0.10–0.82)	1	1	0.83 (0.72–0.90)	1.12

Note: AUC, area under the ROC curve; 95 %CI, 95 % confidence interval; PPV, positive predictive value; NPV, negative predictive value.

Discussion

Low-grade gliomas yield widely different clinical outcomes. The modernized understanding of the somatic mutations of the IDH 1 and 2 genes in gliomas allows us to better sub-classify this group of entities which have distinguished prognosis, opening up a new era in the treatment of brain tumors. In spite of the frequency of IDH wild-type is relatively rare in the population with WHO grade-II gliomas, around 20% (62), IDH-wildtype gliomas are prone to have poorer prognosis (63). Thus, predicting the IDH mutant status preoperatively, preferably with noninvasive imaging modalities, is becoming a focus of the oncology community. Although promising, most previous studies have been experimental, and results have been mixed thus far, which has hampered consistent clinical application. Therefore, most clinicians agree that more specific imaging modalities are urgently needed to help distinguish IDH-wildtype from IDH-mutant gliomas, especially in ambiguous cases where biopsy could potentially be avoided. CEST imaging provides an important contrast mechanism for molecular MRI (32, 33), and this study is the first to evaluate the ability of CEST-MRI to discriminate IDH-wildtype and IDH-mutant low-grade gliomas preoperatively. Based on the entire MTR_asym spectra (Fig. 1), we found that the CEST signal intensities in the offset range of 1.5–4 ppm (including the protein-based APTw signal at 3.5 ppm downfield from water) were relatively higher in IDH-wildtype than in IDH-mutant grade-II gliomas, except for the CEST effect at 2.0 ppm, which showed no difference between the two glioma types. Interestingly, IDH-mutant gliomas showed an obviously decreased CEST effect at 2.5ppm besides 3.5ppm (APT effect), compared to IDH-wildtype gliomas. The exact mechanism for this needs to be further explored in the future.

In this study, we applied two ROI drawing approaches for APTw value analysis: histogram analysis and multi-ROI-based analysis, and multiple APTw metrics were then obtained. Both APTw analysis methods are able to yield discriminated indexes. Generally, histogram analysis has priority over multi-ROI-based analysis in terms of the operation simplicity, since the latter should be used with caution by excluding large cysts, hemorrhage, or vessels. However, multi-ROI-based analysis is useful for finding tumor hotspots. We found that multi-ROI-based maximum and minimum APTw values, as well as the histogram-based mean and 50^th percentile APTw values, were significantly higher in IDH-wildtype gliomas than in the IDH-mutant gliomas (Table 2), corresponding to areas under the ROC curves of 0.89, 0.76, 0.75, and 0.75, respectively, for the prediction of the IDH mutation status (Table 3). Although the APTw difference between IDH-wildtype and IDH-mutant was very small, it was enough to help making discrimination, showing moderate areas under the ROC curves for these APTw metrics. Therefore, the APTw signal could be a valuable imaging biomarker by which to identify IDH1 mutation status in grade-II gliomas.

According to the CEST theory (64), APTw imaging can generate contrast that, to a large extent, depends on the concentration of endogenous cellular proteins in tissue and the exchange properties of their amide protons with water protons (pH dependent), while other parameters (tissue water content, T₁ of water, saturation efficiency) affect the contrast. However, it is imperative to realize that the effect of an increasing water T₁ on the measured APTw signal is mostly canceled out by the effect of the increasing water content in the tumor (34, 65). Our further results (66) have shown that it may not be necessary to correct for the influence of water T₁ on APT imaging of gliomas, at least at 2 µT, as was used in this study, although this remains an interesting research topic in the field. Based on previous ³¹P NMR spectroscopy studies in experimental brain tumors and in patients with brain tumors (67, 68), the intracellular pH of untreated malignant gliomas was near neutrality, or a little alkaline (with a slight increase of 0.05–0.08 pH unit reported in the literature). Thus, the observed APT effect in tumor is mostly dominated by the increased amide proton concentration related to mobile cellular proteins (such as cytosolic proteins, many endoplasmic reticulum proteins, and secreted proteins) (69), but an extra contribution from the possibly alkaline intracellular pH may exist, as discussed in our early papers (65). Notably, lab research results have shown global downregulation of protein expression in mutant IDH1-driven glioma cells, compared to oncogenic HRAS IDH1-wild type glioma cells (10), which is consistent with our findings that significantly lower APTw signal intensities were observed in IDH-mutant grade-II gliomas. Conventional MT imaging generates unique contrast in MRI that is related to semi-solid macromolecules, such as those in membranes and nuclei (70). Our research did not find any significant difference in MTR between IDH-mutant and IDH-wildtype grade-II gliomas, suggesting a negligible difference in the more solid environment of the cell for these two tumor types. In addition, our results in this study are consistent with a recent study by Xiong et al. (22), who reported that IDH mutations significantly correlated with a lower cell proliferation in grade-II oligodendroglial tumors, thus leading to a lower APTw signal.

There are some limitations or weaknesses in this study. A limitation of our study was the relatively small sample size, especially for the numbers in the IDH-wildtype group due to the inherent IDH mutation distribution ratio in the general population (63). A large-scale study would be required to obtain more conclusive results. Another limitation is that different experimental saturation settings will give different results, and the contrast needs to be standardized. The final potential limitation was the semi-quantitative characteristic of APTw signal intensity. It means that the APTw intensity has multiple contributions including the upfield NOE effect (53–56) and some conventional semisolid MT asymmetry that are mixed in when performing MTR_asym analysis. Fortunately, our recent studies showed that, for the saturation parameters we used, the APT effect (rather than the NOE) would be the major contributor to the APTw image contrast between the tumor and normal brain tissue (or the relative APTw intensity value in the tumor, compared to normal brain tissue, as used in this study) (54, 65, 71). Thus, we believe that our results would be very close to those based on the absolute quantitative APT metrics. Several alternative APTw imaging analysis or acquisition approaches have been proposed to quantify a pure APT effect (72–75). Notably, the extrapolated semisolid magnetization transfer reference model that is being developed by our group (71) should achieve more pure APT quantification, and we will apply this promising imaging analysis method to our future research.

CONCLUSIONS

The present study represents the first analysis of the ability to use APTw MRI to differentiate between IDH-wildtype and IDH-mutant grade-II gliomas. IDH mutation status is associated with distinct APTw signatures, and IDH1-wildtype lesions are typically correlated with relatively high APTw signal intensities, compared with IDH1-mutant lesions. Our early results highlight the potential future of APTw imaging to provide a more precise genotypic diagnostic workup of gliomas. Non-invasive prediction of IDH1 mutation status could provide more valuable supplementary information about the prognosis of grade-II gliomas before surgery.
