Abstract Abstract
Background
Loach is one of the major cypriniform fishes in freshwater habitats of Japan; 35 taxa/clades have, until now, been recognised. Parallel to genetic studies, morphological examinations are needed for further development of loach study, eventually ichthyology and fish biology. Digital archiving, concerning taxonomy, ecology, ethology etc., is one of the progressive challenges for the open science of biology. This paper aimed to online publish photo images, 3D models and CT scanned data of all the known clades of loaches inhabiting Japan (103 individuals in total with several type specimens), contributing to ichthyology and public interest of biodiversity/biology.
New information
Photo images, 3D models and CT scanned data of all the known 35 taxa/clades of loaches inhabiting in Japan were online published at http://ffish.asia/loachesOfJapan and http://ffish.asia/loachesOfJapan3D.
Keywords: 3D model, Anatomy, Bone, CT scan, Digital archiving, Fish specimen, Freshwater fishes of Japan, GBIF, Holotype, Loach, Morphology, Open science, Paratype, Skeleton, Undescribed species
Introduction
Loach is one of the major cypriniform fishes in freshwater habitats of Japan, being recognised with 23 described species/subspecies and 12 undescribed/undecided clades (Nakajima and Uchiyama 2017) (http://ffish.asia/loachesOfJapan). As well as molecular genetic research (Kitagawa et al. 2001a, Kitagawa et al. 2001b, Kitagawa et al. 2003b, Kitagawa et al. 2003a, Kitagawa et al. 2005, Suzawa 2006, Morishima et al. 2008, Saitoh et al. 2010, Kano et al. 2011, Shimizu et al. 2011, Kano et al. 2012, Nakajima 2012, Nakajima 2016, Nakajima and Suzawa 2016, Nakajima and Uchiyama 2017), morphological examinations are needed for further development of loach study. Digital archiving of fish specimens is one of the progressive challenges in ichthyology for open science (Kanagawa Prefectural Museum of Natural History and National Museum of Nature and Science 1998, Berquist et al. 2012, Kano et al. 2013, Kano et al. 2016). This paper aimed to online publish photo images, 3D models and CT scanned data for all the known taxa/clades of loaches inhabiting Japan (http://ffish.asia/loachesOfJapan3D) for the advances of loach study and ichthyology and furthermore as a challenge of open science for public interests of biology.
General description
Purpose
This research aims to
1) list all the known taxa/clades of loaches inhabiting Japan with photo images (http://ffish.asia/loachesOfJapan) and
2) digitalise the specimens of each taxa/clades by 3D models and CT scanning (http://ffish.asia/loachesOfJapan3D).
Additional information
The dataset was also registered on GBIF (http://ipt.pensoft.net/resource?r=jp_loaches_3dct_models)
Sampling methods
Study extent
Photo images and specimens of loaches of Japan were taken in the field and borrowed from museums (see "Collection data").
Sampling description
The specimens were generally captured by a hand-net in the field. All the specimens were fixed in 10% formalin and preserved in 70% ethanol.
Step description
Photo images were taken in the field by capturing individuals (Fig. 1) (Kano and Nakajima 2014) and/or by snorkelling (Fig. 2). The formalin-fixed specimens were also photographed in the laboratory (Fig. 3) followed by CT scanning (Aloka Latheta LCT-200, Hitachi, Ltd.). 3D surface (Fig. 4; CT value: -400 to -40) and skeletal (Fig. 5; CT value: 5 to 200) models were extracted from the CT data. The CT data (Figs 6, 7) in raw file format were also stored and available on the web.
Figure 1.
A photo image of an individual of Parabotia curtus in a makeshift aquarium at a wild habitat.
Figure 2.
A photo image of Cobitis sakahoko in the wild, under cloudy water by volcanic ash of Mt. Kirishima.
Figure 3.
An old specimen of Misgurnus anguillicaudatus (Jindai-dojyô) (MPMQ-JJ1), an uncertain local clade that is already extinct.
Figure 4.
A 3D model of the surface of Misgurnus anguillicaudatus (Clade B1) (JNC342).
Figure 5.
A 3D skeletal model of a paratype of Cobitis striata fuchigamii (MPM-Fi1501).
Figure 6.
CT scanned data of Barbatula oreas (JNC256).
Figure 7.
A movie for CT scanned data of Cobitis minamorii yodoensis (OMNH-P45848), changing the camera angle and CT value.
Geographic coverage
Description
Inland water habitats of Japan.
Coordinates
23 and 46 Latitude; 150 and 123 Longitude.
Taxonomic coverage
Description
This paper includes all the known 35 loach taxa/clades (103 specimens) in Japan, of which 12 clades have still been undescribed or are uncertain.
Type specimens: The dataset includes nine type specimens as below.
Holotype: MPM-Fi1507 (Cobitis minamorii tokaiensis).
Paratypes: MPM-Fi1501 (Cobitis striata fuchigamii); MPM-Fi1502 (Cobitis striata hakataensis); MPM-Fi1503 (Cobitis kaibarai); MPM-Fi1504 (Cobitis magnostriata); MPM-Fi1505 (Cobitis minamorii minamorii); MPM-Fi1506 (Cobitis minamorii oumiensis); MPM-Fi1508 (Cobitis minamorii tokaiensis); MPM-Fi1509 (Cobitis minamorii saninensis).
Undescribed/uncertain clades: Below, we interpret the 12 undescribed/uncertain clades.
Twenty taxa of genus Cobitis have been hitherto known in Japan (Ikeda 1936, Okada and Ikeda 1939, Mizuno 1970, Kitagawa et al. 2003a, Kitagawa et al. 2003b, Suzawa 2006, Nakajima 2012, Nakajima et al. 2012, Nakajima 2016, Nakajima and Suzawa 2016, Nakajima and Uchiyama 2017), although five taxa are still undescribed/undecided without scientific names: One from Cobitis matsubarae species complex and the other four from Cobitis biwae species complex. Cobitis sp. "yamato" complex Type A (sensu Kitagawa et al. 2003a; one of Cobitis matsubarae species complex), distributed exclusively in Nagato District (western Honshu, Yamaguchi Prefecture), has peculiar genetic traits (Kitagawa et al. 2003a) and which should be treated as a single clade (Nakajima and Uchiyama 2017). It has a similar morphology to Cobitis matsubarae, whilst Nakajima and Uchiyama (2017) indicated that the genetic traits were close to Cobitis magnostriata and Cobitis takenoi. Amongst the four types of Cobitis biwae species complex, it is unknown which of these corresponds to the scientific name "Cobitis biwae" (Kitagawa et al. 2003b, Nakajima and Uchiyama 2017). Cobitis sp. BIWAE type A, also referred as "Western group (tetraploid form)" (Kitagawa et al. 2003b), is distributed amongst western Honshu, northern Shikoku, Awaji Island and eastern Kyushu. Cobitis sp. BIWAE type B, also referred to as "Western group (diploid form)" (Kitagawa et al. 2003b), is distributed in western Honshu and Oki-dougo Island. Cobitis sp. BIWAE type C, also referred to as "Eastern group" (Kitagawa et al. 2003b), is distributed between eastern Honshu and Sado Island. Cobitis sp. BIWAE type D, also referred to as "Kochi group" (Kitagawa et al. 2003b), inhabits the rivers flowing to Tosa Bay, southern Shikoku.
The situation about "Misgurnus anguillicaudatus" is rather complicated. Six taxa/clades of Misgurnus anguillicaudatus species complex has been hitherto known in Japan, namely "A", "B1", "B2", "Jindai", "IR" and "OK". Misgurnus sp. (Clade A) is a native loach clade of Japan, although the distribution is limited to northern parts such as Hokkaido and eastern Honshu (Morishima et al. 2008, Nakajima and Uchiyama 2017). Misgurnus anguillicaudatus (Clade B1) is another clade native to Japan and is widely distributed amongst Hokkaido (likely domestically introduced from Honshu), Honshu, Shikoku, Kyushu and several isolated islands (Morishima et al. 2008, Kano et al. 2011). Misgurnus anguillicaudatus (Clade B2) is a non-native clade introduced from mainland China and is also widely distributed amongst Honshu, Kyushu and Sado Island (Morishima et al. 2008, Kano et al. 2011). Misgurnus anguillicaudatus (Jindai), so-called "Jindai-dojyô" in Japanese, meaning "God's vicarious loach" or "loach in God's era", is an unusual local population that is already extinct. The loach had been distributed exclusively in Shindo Zone (Iga City, Mie Prefecture) having been visibly discriminated from the sympatric M. anguillicaudatus (Clade B1) by its size: the body size of the loach sometimes reached more than 30 cm (Takeda 1978). The ecology of the loach also seemed to be different from M. anguillicaudatus (Clade B1) as the trials of artificial breeding of the loach were extremely difficult and in vain, while the breeding of M. anguillicaudatus (Clade B1) was much easier (Takeda 1978). No genetic information on the loach was unfortunately available at present as the few old specimens were all formalin-fixed. Misgurnus sp. IR is distributed amongst several islands of Amami Islands and Iriomote Island, the southern part of Japan, with peculiar genetic/morphological traits (Shimizu et al. 2011, Kano et al. 2012, Nakajima and Uchiyama 2017). Misgurnus sp. OK has been found from Okinawa and Yonaguni Islands in Japan (Shimizu et al. 2011, Nakajima and Uchiyama 2017). The native distribution ranges of Misgurnus sp. IR and Misgurnus sp. OK are unknown.
Two Lefua species have still been left undescribed. Lefua sp. 1 is distributed amongst a narrow range of western Honshu, eastern Shikoku, Awaji Island and Shodo Island (Nakajima and Uchiyama 2017). Lefua sp. 2 is distributed in a limited area of Tokai region of Honshu, which is genetically discriminated from allopatric Lefua sp. 1 although the morphology of the two is rather similar (Nakajima and Uchiyama 2017).
Non-native to Japan:
Misgurnus anguillicaudatus (Clade B2): Definite native range of M. anguillicaudatus (Clade B2) is still unclear, but it potentially inhabits China (Chen 1981, Morishima et al. 2008), Korean Peninsula (Choi et al. 1990), northern Vietnam (Yen 1985) and Taiwan (Lin 2017).
Misgurnus dabryanus: Native to China (Chen 1981), Korean Peninsula (Choi et al. 1990) and Taiwan (Lin 2017).
Lefua costata: Native to northern China (Shedko et al. 2008, Miyazaki et al. 2011) and Korean Peninsula (Choi et al. 1990, Mihara et al. 2005, Shedko et al. 2008).
IUCN rank and extinction: Japanese loaches are generally faced with extinction and a part of them are listed in the IUCN Red List. Two loaches have been unconfirmed for the last 20 years indicating extinction.
CR: Parabotia curtus
LC: "Misgurnus anguillicaudatus" that potentially includes Misgurnus sp. (Clade A), M. anguillicaudatus (Clade B1), M. anguillicaudatus (Clade B2), M. anguillicaudatus (Jindai), Misgurnus sp. IR and Misgurnus sp. OK.
Assumed to be extinct: Cobitis minamorii yodoensis; Misgurnus anguillicaudatus (Jindai).
Taxa included
| Rank | Scientific Name | Common Name |
|---|---|---|
| kingdom | Animalia | Animals |
| phylum | Chordata | Chordates |
| subphylum | Craniata | Vertebrates and hagfishes |
| class | Osteichthyes | Bony fishes and tetrapods |
| subclass | Actinopterygii | Ray-finned fishes |
| order | Cypriniformes | Carps, loaches, minnows and relatives |
| family | Botiidae | Botiid loach |
| species | Parabotia curtus | "Ayumodoki" |
| family | Cobitidae | True loaches |
| species | Cobitis kaibarai | "Ariake-suji-shima-dojyô" |
| species | Cobitis magnostriata | "Oogata-suji-shima-dojyô" |
| species | Cobitis matsubarae | "Yamato-shima-dojyô" |
| species | Cobitis sp. "yamato" complex Type A | "Yamato-shima-dojyô" (Type A) |
| subspecies | Cobitis minamorii minamorii | "San'yô-kogata-suji-shima-dojyô" |
| subspecies | Cobitis minamorii oumiensis | "Biwa-kogata-suji-shima-dojyô" |
| subspecies | Cobitis minamorii saninensis | "San'in-kogata-suji-shima-dojyô" |
| subspecies | Cobitis minamorii tokaiensis | "Tôkai-kogata-suji-shima-dojyô" |
| subspecies | Cobitis minamorii yodoensis | "Yodo-kogata-suji-shima-dojyô" |
| species | Cobitis sakahoko | "Oyodo-shima-dojyô" |
| species | Cobitis shikokuensis | "Hina-ishi-dojyô" |
| species | Cobitis sp. BIWAE type A | "Oo-shima-dojyô" |
| species | Cobitis sp. BIWAE type B | "Nishi-shima-dojyô" |
| species | Cobitis sp. BIWAE type C | "Higashi-shima-dojyô" |
| species | Cobitis sp. BIWAE type D | "Tosa-shima-dojyô" |
| subspecies | Cobitis striata fuchigamii | "Onga-suji-shima-dojyô" |
| subspecies | Cobitis striata hakataensis | "Hakata-suji-shima-dojyô" |
| subspecies | Cobitis striata striata | "Chûgata-suji-shima-dojyô" |
| species | Cobitis takatsuensis | "Ishi-dojyô" |
| species | Cobitis takenoi | "Tango-suji-shima-dojyô" |
| species | Misgurnus sp. (Clade A) | "Kita-dojyô" |
| species | Misgurnus anguillicaudatus (Clade B1) | "Dojyô" (Japan clade) |
| species | Misgurnus anguillicaudatus (Clade B2) | "Dojyô" (China clade) |
| species | Misgurnus anguillicaudatus (Jindai) | "Jindai-dojyô" |
| species | Misgurnus sp. IR | "Shinobi-dojyô" |
| species | Misgurnus sp. OK | "Hyoumon-dojyô" |
| species | Misgurnus dabryanus | "Kara-dojyô" |
| species | Niwaella delicata | "Ajime-dojyô" |
| family | Nemacheilidae | Stone loaches |
| species | Barbatula oreas | "Fuku-dojyô" |
| species | Lefua costata | "Hime-dojyô" |
| species | Lefua echigonia | "Hotoke-dojyô" |
| species | Lefua nikkonis | "Ezo-hotoke-dojyô" |
| species | Lefua sp. 1 | "Nagare-hotoke-dojyô" |
| species | Lefua sp. 2 | "Tôkai-nagare-hotoke-dojyô" |
Temporal coverage
Data range: 1954-6-06 – 2017-12-15.
Notes
Several specimens have no temporal information.
Collection data
Collection name
JNC/JNCP (J. Nakajima's personal collection); KPM (Kanagawa Prefectural Museum of Natural History); LBM (Lake Biwa Museum); MPM/MPMQ (Mie Prefectural Museum); OMNH (Osaka Museum of Natural History); QUYK (Y. Kano's personal collection); TKPM (Tokushima Prefectural Museum).
Specimen preservation method
Fixed in formalin and preserved in 70% ethanol.
Usage rights
Use license
Other
IP rights notes
Creative Commons Attribution Non Commercial (CC-BY-NC) 4.0 License
Data resources
Data package title
Photo images, 3D models and CT scanned data of loaches (Botiidae, Cobitidae and Nemacheilidae) of Japan
Number of data sets
3
Data set 1.
Data set name
loachesOfJapan
Data format
html; jpg
Number of columns
6
Character set
UTF-8
Download URL
Description
All the 35 known clades of loaches inhabiting Japan are listed with photo images. Below, the main 6 columns are listed;
Data set 1.
| Column label | Column description |
|---|---|
| Scientific name | Formal scientific name or tentative name |
| Taxon | Taxonomical hierarchy (order/family/genus) |
| Species image | Photo images of the species |
| N | Number of specimen/occurence data |
| Specimens/data distribution | Showing rough localities of the occurence on a map |
| Other information | Other information such as Japanese name |
Data set 2.
Data set name
loachesOfJapan3D
Data format
html; Wavefront object format (.obj); CT dicom file (.dcm)
Number of columns
12
Character set
UTF-8
Download URL
Description
Surface/skeletal 3D models and CT scanned data are available for all the clades (103 individuals). To render the CT dicom files as a visual 3D volume, several free software are available. Below, the main 12 columns are listed;
Data set 2.
| Column label | Column description |
|---|---|
| Specimen/Data ID | ID for the specimen/occurence |
| Images | Downloadable images/files of photos, 3D models and CT scanned data |
| Species | Scientific name (or tentative name) of the specimen |
| Taxon | Taxonomical hierarchy (order/family/genus) |
| N | Number of the individual(s) |
| DNA information | DNA sequence data if available |
| Location | Description of the locality |
| Specimens/data distribution | Showing rough localities of the occurence on a map |
| Sample year/month/day | Temporal infomation of the sampling |
| Japanese name | Japanese name |
| English name | English name or roman phonetics for Japanese |
| Comment | Other infomation such as sex, holotype, paratype etc. |
Data set 3.
Data set name
Photo images, 3D models and CT scanned data of loaches (Botiidae, Cobitidae and Nemacheilidae) of Japan
Data format
Darwin Core Archive
Number of columns
10
Download URL
Description
GBIF registered occurrence data for the specimens. Below, the main 10 columns are listed;
Data set 3.
| Column label | Column description |
|---|---|
| occurrenceID | Occurrence ID and URL |
| basisOfRecord | The specific nature of the data record |
| eventDate | The date-time or interval during which the specimen collected |
| scientificName | Scientific name (or tentative name) of the specimen |
| decimalLatitude | Rough value of decimal latitude |
| decimalLongitude | Rough value of decimal longtitude |
| verbatimLocality | Description of the locality |
| typeStatus | Noted if the specimen is holotype or paratype |
| sex | Discrimination of male or female, while some are unknown |
| vernacularName | Japanese name |
Acknowledgements
We deeply appreciate Dr. Akihisa Iwata for help in taking photographs of Parabotia curtus. We are grateful to Mr. Mike Skinner for English proofreading. We also thank The Kyoto University Museum, Kanagawa Prefectural Museum of Natural History, Osaka Museum of Natural History and Tokushima Prefectural Museum for renting/loaning the specimens. This paper also includes partial results of studies funded by JSPS KAKENHI Grant Number 18HP8029 and Ministry of Agriculture, Forestry and Fisheries of Japan (Research Project for Biodiversity Assessment and Conservation for Sustainable Agriculture).
Funding Statement
This work was supported by JSPS KAKENHI Grant Number 18HP8029 and Ministry of Agriculture, Forestry and Fisheries of Japan (Research Project for Biodiversity Assessment and Conservation for Sustainable Agriculture).
Author contributions
Yuichi Kano (manuscript writing, photographs and database/data management), Jun Nakajima (manuscript writing, photographs, identification and specimens provision), Taksehi Yamasaki (CT scanning), Jyun-ichi Kitamura (specimens provision) and Ryoichi Tabata (specimens provision).
References
- Berquist Rachel M., Gledhill Kristen M., Peterson Matthew W., Doan Allyson H., Baxter Gregory T., Yopak Kara E., Kang Ning, Walker H. J., Hastings Philip A., Frank Lawrence R. The digital fish library: Using MRI to digitize, database, and document the morphological diversity of fish. http://dx.doi.org/10.1371/journal.pone.0034499. PLoS ONE. 2012;7:e34499. doi: 10.1371/journal.pone.0034499. [DOI] [PMC free article] [PubMed] [Google Scholar]
- Chen J. X. 中国花鳅亚科鱼类系统分类的研究 [A study on the classification of the subfamily Cobitinae of China] Transactions of the Chinese Ichtyological Society. 1981;(1):21–32. Chinese.
- Choi Ki-Chul, Jeon Sang-Rin, Kim Ik-Soo, Son Yeong-Mok. 原色韓國淡水魚圖鑑. 1. Hyangmunsa; Seoul: 1990. 278. Korean. [Google Scholar]
- Ikeda H. On the sexual dimorphism and the taxonomical status of some Japanese loaches. Zoological Magazine. 1936;48:983–994. Japanese with English abstract. [Google Scholar]
- History Kanagawa Prefectural Museum of Natural, Science National Museum of Nature and. FishPix. http://fishpix.kahaku.go.jp/fishimage-e/index.html. [2018-02-19T00:00:00+02:00];
- Kano Yuichi, Watanabe Katsutoshi, Nishida Shin, Kakioka Ryo, Wood Chris, Shimatani Yukihiro, Kawaguchi Yôichi. Population genetic structure, diversity and stocking effect of the oriental weatherloach (Misgurnus anguillicaudatus) in an isolated island. http://dx.doi.org/10.1007/s10641-010-9733-7. Environmental Biology of Fishes. 2011;90:211–222. doi: 10.1007/s10641-010-9733-7. [DOI] [Google Scholar]
- Kano Y., Nakajima J., Mizutani H., Nakazato Y,, Nakazato N., Kaji Y., Huang L., Nishida S., Hashiguchi Y. Critical status of the genetically-district, oriental weather loach (Misgurnus anguillicaudatus) population on Iriomote Island, Japan. https://doi.org/10.11369/jji.59.37. Japanese Journal of Ichthyology. 2012;59:37–43. doi: 10.11369/jji.59.37. Japanese with English abstract. [DOI] [Google Scholar]
- Kano Yuichi, Adnan M. Shalahuddin, Grudpan Chaiwut, Grudpan Jarungjit, Magtoon Wichan, Musikasinthorn Prachya, Natori Yoshihiro, Ottomanski Stefan, Praxaysonbath Bounthob, Phongsa Koneouma, Rangsiruji Achariya, Shibukawa Koichi, Shimatani Yukihiro, So Nam, Suvarnaraksha Apinun, Thach Phanara, Thanh P. N., Tran D. D., Utsugi Kenzo, Yamashita Tomomi. An online database on freshwater fish diversity and distribution in Mainland Southeast Asia. http://dx.doi.org/10.1007/s10228-013-0349-8. Ichthyological Research. 2013;60:293–295. doi: 10.1007/s10228-013-0349-8. [DOI] [Google Scholar]
- Kano Y., Nakajima J. Non-killing simple photography techniques of small–middle freshwater fishes in the field. Japanese Journal of Ichthyology. 2014;61:123–125. Japanese. [Google Scholar]
- Kano Yuichi, Musikasinthorn Prachya, Iwata Akihisa, Tun Sein, Yun Lkc, Win Seint Seint, Matsui Shoko, Tabata Ryoichi, Yamasaki Takeshi, Watanabe Katsutoshi. A dataset of fishes in and around Inle Lake, an ancient lake of Myanmar, with DNA barcoding, photo images and CT/3D models. http://dx.doi.org/10.3897/BDJ.4.e10539. Biodiversity Data Journal. 2016;4:e10539. doi: 10.3897/BDJ.4.e10539. [DOI] [PMC free article] [PubMed] [Google Scholar]
- Kitagawa Tadao, Yoshioka Motoi, Kashiwagi Masaaki, Okazaki Toshio. Population structure and local differentiation in the delicate loach, Niwaella delicata, as revealed by mitochondrial DNA and morphological analyses. http://dx.doi.org/10.1007/s10228-001-8127-4. Ichthyological Research. 2001;48:127–135. doi: 10.1007/s10228-001-8127-4. [DOI] [Google Scholar]
- Kitagawa Tadao, Watanabe Masakazu, Kobayashi Takanori, Yoshioka Motoi, Kashiwagi Masaaki, Okazaki Toshio. Two genetically divergent groups in the Japanese spined loach, Cobitis takatsuensis, and their phylogenetic relationships among Japanese cobitis inferred from mitochondrial DNA analyses. http://dx.doi.org/10.2108/zsj.18.249. Zoological Science. 2001;18:249–259. doi: 10.2108/zsj.18.249. [DOI] [Google Scholar]
- Kitagawa T, Yoshioka Motoi, Kashiwagi Masaaki, Okazaki Toshio. Genetic structure of a Japanese allotetraploid loach of the genus Cobitis (Osteichthyes, Cobitidae) Folia Biologica. 2003;51 Suppl:93–100. [PubMed] [Google Scholar]
- Kitagawa Tadao, Watanabe Masakazu, Kitagawa Emi, Yoshioka Motoi, Kashiwagi Masaaki, Okazaki Toshio. Phylogeography and the maternal origin of the tetraploid form of the Japanese spined loach, Cobitis biwae, revealed by mitochondrial DNA analysis. http://dx.doi.org/10.1007/s10228-003-0174-6. Ichthyological Research. 2003;50:318–325. doi: 10.1007/s10228-003-0174-6. [DOI] [Google Scholar]
- Kitagawa Tadao, Jeon Sang-Rin, Kitagawa Emi, Yoshioka Motoi, Kashiwagi Masaaki, Okazaki Toshio. Genetic relationships among the Japanese and Korean striated spined loach complex (Cobitidae: Cobitis) and their phylogenetic positions. http://dx.doi.org/10.1007/s10228-004-0261-3. Ichthyological Research. 2005;52:111–122. doi: 10.1007/s10228-004-0261-3. [DOI] [Google Scholar]
- Lin C. 台灣淡水魚蝦生態大圖鑑. 7. Vol. 1. Global Views – Commonwealth Publishing Group; Taipei: 2017. 240. Chinese. [Google Scholar]
- Mihara Motohiro, Sakai Takehiko, Nakao Koushin, Oliveira Martins Leonardo de, Hosoya Kazumi, Miyazaki Jun-Ichi. Phylogeography of Loaches of the Genus Lefua (Balitoridae, Cypriniformes) Inferred from Mitochondrial DNA Sequences. http://dx.doi.org/10.2108/zsj.22.157. Zoological Science. 2005;22(2):157–168. doi: 10.2108/zsj.22.157. [DOI] [PubMed] [Google Scholar]
- Miyazaki Jun-Ichi, Dobashi Manabu, Tamura Toshio, Beppu Saori, Sakai Takehiko, Mihara Motohiro, Hosoya Kazumi. Parallel evolution in eight-barbel loaches of the genus Lefua (Balitoridae, Cypriniformes) revealed by mitochondrial and nuclear DNA phylogenies. http://dx.doi.org/10.1016/j.ympev.2011.05.005. Molecular Phylogenetics and Evolution. 2011;60(3):416–427. doi: 10.1016/j.ympev.2011.05.005. [DOI] [PubMed] [Google Scholar]
- Mizuno N. A new species of cobitid fish from Japan (Cobitis takatsuensis) Memoirs of the Ehime University. Section II, Natural Science (Series B (Biology)) 1970;6:133–143. [Google Scholar]
- Morishima Kagayaki, Nakamura-Shiokawa Yuka, Bando Etsuko, Li Ya-Juan, Boroń Alicja, Rahman Khan Md. Mukhlesur, Arai Katsutoshi. Cryptic clonal lineages and genetic diversity in the loach Misgurnus anguillicaudatus (Teleostei: Cobitidae) inferred from nuclear and mitochondrial DNA analyses. http://dx.doi.org/10.1007/s10709-007-9158-1. Genetica. 2008;132:159–171. doi: 10.1007/s10709-007-9158-1. [DOI] [PubMed] [Google Scholar]
- Nakajima Jun. Taxonomic study of the Cobitis striata complex (Cypriniformes, Cobitidae) in Japan. http://www.mapress.com/j/zt/article/view/14673 Zootaxa. 2012;3586:103–130. [Google Scholar]
- Nakajima J., Suzawa Y., Shimizu T., Saitoh K. Proposal of standard Japanese names for Japanese loaches in the genus Cobitis (Cobitidae) Japanese Journal of Ichthyology. 2012;59:86–95. Japanese. [Google Scholar]
- Nakajima Jun. Cobitis takenoi sp. n. (Cypriniformes, Cobitidae): a new spined loach from Honshu Island, Japan. http://dx.doi.org/10.3897/zookeys.568.7733. ZooKeys. 2016;568:119–128. doi: 10.3897/zookeys.568.7733. [DOI] [PMC free article] [PubMed] [Google Scholar]
- Nakajima J, Suzawa Y. Cobitis sakahoko, a new species of spined loach (Cypriniformes: Cobitidae) from southern Kyushu Island, Japan. https://doi.org/10.1007/s10228-015-0476-5. Ichthyological Research. 2016;63:68–78. doi: 10.1007/s10228-015-0476-5. [DOI] [Google Scholar]
- Nakajima Jun, Uchiyama Ryu. 日本のドジョウ. Yama-kei Publishers; Tokyo: 2017. Japanese with English description for each species/clade. [Google Scholar]
- Okada Y., Ikeda H. A revision of the Japanese striped loaches, referred to the genus Cobitis. Science Report of the Tokyo Bunrika Daigaku. Section B. 1939;4:89–104. [Google Scholar]
- Saitoh Kenji, Chen Wei-Jen, Mayden Richard L. Extensive hybridization and tetrapolyploidy in spined loach fish. http://dx.doi.org/10.1016/j.ympev.2010.04.021. Molecular Phylogenetics and Evolution. 2010;56:1001–1010. doi: 10.1016/j.ympev.2010.04.021. [DOI] [PubMed] [Google Scholar]
- Shedko S. V., Miroshnichenko I. L., Nemkova G. A. On the systematics and phylogeography of eight-barbel loaches of the genus Lefua (Cobitoidea: Nemacheilidae): mtDNA typing of L. pleskei. http://dx.doi.org/10.1134/s1022795408070090. Russian Journal of Genetics. 2008;44(7):817–825. doi: 10.1134/s1022795408070090. [DOI] [PubMed] [Google Scholar]
- Shimizu T, Suzuki T, Takagi M, Oseko N. Morphological and genetic characteristics of misgurnid loach from Okinawa and Iriomote Islands. Bulletin of the Bio-geographical Society of Japan. 2011;66:141–153. Japanese with English abstract. [Google Scholar]
- Suzawa Yuzuru. A new loach, Cobitis shikokuensis (Teleostei: Cobitidae), from Shikoku Island, Japan. http://dx.doi.org/10.1007/s10228-006-0352-4. Ichthyological Research. 2006;53:315–322. doi: 10.1007/s10228-006-0352-4. [DOI] [Google Scholar]
- Takeda K. Jindai-dojyo. Tansuigyo. 1978;(4)::115–118. Japanese.
- Yen Mai Dinh. Species composition and distribution of the freshwater fish fauna of the North of Vietnam. http://dx.doi.org/10.1007/bf00017548. Hydrobiologia. 1985;121(3):281–286. doi: 10.1007/bf00017548. [DOI] [Google Scholar]
