Short abstract
Objective
Evidence from cell and mouse models and human tissues suggests that cyclin dependent kinase 1 (CDK1) is involved in lung cancer (LC) tumorigenesis. However, the different types of expression patterns and prognostic results of CDK1 need further analysis.
Methods
In the current study, we assessed CDK1 expression and LC patient outcomes using data from the Oncomine, GEPIA, and Kaplan–Meier Plotter databases. Additionally, mutations in the CDK1 gene were analyzed by using the cBioPortal database. The expression of CDK1 was verified by real-time quantitative PCR using the Human Protein Atlas database and human tissues.
Results
Expression of CDK1 was higher in lung adenocarcinoma and squamous cell lung carcinoma tissues than in normal lung samples. Moreover, CDK1 expression was linked to disease progression. Survival analysis indicated that upregulation of CDK1 was related to poor overall survival, low first progression, and post-progression survival in patients with LC.
Conclusions
Our results indicate that CDK1 is a potential clinical target and prognostic biomarker for patients with LC.
Keywords: CDK1, expression, lung carcinoma, prognosis, survival, biomarker
Introduction
Lung cancer (LC) is a frequently occurring malignancy and it accounts for a large proportion of cancer-related mortality worldwide.1–3 It is categorized into small and non-small-cell subtypes in accordance with histology. The non-small-cell subtypes include large cell carcinomas, lung squamous cell carcinoma (LUSC), and lung adenocarcinoma (LUAD), which make up nearly 85% of all LC.4 Despite considerable advancements in diagnosis and treatment, 5-year overall survival (OS) of LC patients remains below 15%.5,6 Hence, prognostic markers and potential drug targets should be identified to enhance prognosis and individualized treatments.
Cyclin dependent kinases (CDKs) are serine/threonine kinases that regulate the cell cycle in cooperation with certain regulatory cyclins. CDK1 is the only essential CDK,7,8 promoting the G2/M and G1/S transitions, as well as G1 progression.9 Unrestricted cell proliferation, an indicator of malignancy, is normally driven by alterations in CDK1 activity. Upregulation of CDK1 protein is closely related to the prognosis of several malignant tumors.10 However, our understanding of the specific roles and potential mechanisms of CDK1 in lung cancer is limited. It has been reported that dysregulation of CDK1 expression, which correlates with clinicopathological characteristics, is partially observed in humans but much remains to be discovered about the expression patterns and prognostic values of CDK1. In this study, we analyzed expression level and mutations of CDK1 in patients with LC to determine potential gene and protein functions. We also aimed to assess the prognostic value of CDK1 in LC by analyzing information in published papers and in public gene expression databases.
Materials and methods
Ethical approval
The study was approved by the institutional review board (IRB) of Ningbo University (permit number: NO.89). This study was conducted according to the ethical guidelines of the Declaration of Helsinki. All datasets were retrieved from the published literature, so informed consent was not obtained.
Oncomine analysis
Oncomine (www.oncomine.org) is a public database of gene expression data in a variety of tumors. In this study, we used the Oncomine database to analyze the expression level of CDK1 in lung cancer. The mRNA expression of CDK1 in cancer specimens was compared with that in normal controls, using Student’s t-test to determine significant differences. A P-value of 0.01 was used as the cut-off.
GEPIA database
GEPIA (http://gepia.cancer-pku.cn/) is an online database that incorporates gene expression data from The Cancer Genome Atlas (TCGA) and the Genotype Tissue Expression (GTEx) project, comprising 9,736 tumor samples and 8,587 normal controls. The GEPIA database allows users to explore gene expression as a function of cancer type or pathological stage. Additional functions include similar gene detection, correlation analysis, patient survival analysis, and dimensionality reduction analyses.11 Using GEPIA, we analyzed the expression of CDK1 in LC by tumor stage. The method for differential gene expression analysis was one-way ANOVA, using pathological stage as a variable for calculating differential expression. Then, we plotted log2 (TPM + 1) transformed expression data, where TPM is transcripts per million. GEPIA automatically generates violin plots of expression data based on patient pathological stage when we input CDK1 gene.
RNA extraction and quantitative real-time PCR
To verify the mRNA expression of CDK1, we collected eight pairs of LC tissues (LUAD and LUSC) and adjacent non-tumor tissues from the Department of Radiation Oncology, Ningbo Medical Center Lihuili Eastern Hospital from 1 January to 1 June 2019. Written informed consent was obtained from all participating patients. Approximately 20 mg of tissue was obtained from each sample for RNA extraction using Trizol reagent (Invitrogen, Carlsbad, CA, USA) according to the manufacturer’s protocols. All PCR reactions were performed using an ABI Prism 5700 Sequence Detection System (PerkinElmer Applied Biosystems, Foster City, CA, USA). The primers and probes used for quantitative real-time PCR were as follows: CDK1 forward primer: CCTAGCATCCCATGTCAAAAACTTGG; CDK1 reverse primer: TGATTCAGTGCCATTTTGCCAGA; and CDK1 probe: TGCTCTCGAAAATGTTAATCTATGATCCAGCCAAACGA.
CCLE analysis
The mRNA level of CDK1 in various cancers was determined in the Cancer Cell Line Encyclopedia (CCLE) database (https://portals.broadinstitute.org/ccle/home), which brings together sequencing data, chromosomal copy number, and gene expression from 947 human cancer cell lines.
Human Protein Atlas
The Human Protein Atlas (https://www.proteinatlas.org) contains immunohistochemical expression data for nearly 20 common types of tumors, and each tumor includes 12 individual tumor subtypes.12 The database allows researchers to identify the expression patterns of certain proteins in tumors of a given type. In this study, we directly compared the expression level of CDK1 between tumor and normal tissues by immunohistochemistry.
Kaplan–Meier Plotter
The Kaplan–Meier (K-M) Plotter database was used to assess the prognostic relevance of CDK1 levels (www.kmplot.com).13 This database includes gene expression and outcome data for 2,436 LC patients. The patients with LC were separated into two groups according to the median expression of CDK1 gene (high or low expression). The two patient cohorts were compared by K-M survival plots, and hazard ratios with 95% confidence intervals (CIs) and log rank P-values were calculated.
Functional and pathway enrichment analyses
Gene Ontology (GO) analysis identifies genes that are significantly overrepresented from three aspects: cellular component, molecular function, and biological process.14 The Kyoto Encyclopedia of Genes and Genomes (KEGG) database is used to understand the high-level functions and utilities of a biological system.15 The STRING database (https://string-db.org/) is used not only to construct a protein–protein interaction (PPI) network but also to provide a comprehensive functional approach by which to determine the biological meaning of genes. In this study, we performed GO function and KEGG pathway enrichment analyses of CDK1 using the STRING database with a threshold of P < 0.05.
TCGA data and cBioPortal
TCGA compiles pathological and sequencing data from 30 different cancers.16 Relevant data on lung adenocarcinoma and squamous cell carcinoma were included for further analyses of CDK1 using cBioPortal (https://www.cbioportal.org). Genomic profiles included mutations and putative copy-number alterations calculated using cBioPortal.
Statistical analysis
Data from the online databases were processed using the databases described above. Results derived from samples were analyzed by using SPSS version 19.0 (IBM Corp., Armonk, NY, USA). Continuous variables between two groups were compared using Student’s t-test. Differences with P < 0.05 were considered significant.
Results
Expression of CDK1 gene in LC
The Oncomine database was used to compare the expression of CDK1 in LC and normal samples. The results showed that CDK1 was overexpressed in various cancers, and its expression was significantly increased (P < 0.05) in LC patients in 11 datasets (Figure 1a). We further queried the Oncomine database to analyze CDK1 expression in several lung cancer studies. All results indicated that transcription levels of CDK1 in lung adenocarcinoma and squamous cell lung carcinoma were higher (P < 0.05) than those in normal lung tissues (Figure 1b).
Association between CDK1 expression and clinicopathological findings in LC patients
The expression level of CDK1 between LC and normal lung tissues was compared by using the GEPIA database. The results indicated that expression of CDK1 in LUAD and LUSC tissues was significantly higher (P < 0.05) than that in normal lung tissues (Figure 2a, b). We also analyzed expression of CDK1 with tumor stage for lung adenocarcinoma and squamous cell lung carcinoma; expression of CDK1 was positively and highly associated (P < 0.05) with advanced cancer stages (Figure 2c). After examining the mRNA expression pattern of CDK1 in LC, we explored the protein expression pattern of CDK1 in LC by using the Human Protein Atlas. As shown in Figure 3a, CDK1 protein was not expressed in normal lung tissues, whereas high expression of CDK1 was observed in LC tissues. In addition, the results of CCLE analysis agreed with that of Oncomine, and suggested that CDK1 was notably upregulated (P < 0.05) in lung cancer cell lines (Figure 3b). To verify the mRNA expression level of CDK1, 8 pairs of LC tissues and adjacent non-tumor tissues were collected. The mRNA expression level of CDK1 in LUSC and LUAD was significantly higher (P < 0.05) than that in normal tissues (Fig. S1). Taken together, our results showed that transcriptional and proteomic expression of CDK1 was upregulated in patients with LC.
CDK1 genetic alteration and its neighbor gene network in patients with LC
cBioPortal provides the frequency of alteration of CDK1 mutations in LC. A total of 1097 patients with pulmonary cancer (TCGA, provisional) and lung squamous cell carcinoma (TCGA, provisional) were analyzed. Gene set/pathway was changed in 16 (1%) of the samples under queries. The percentage of genetic alterations was 1.6% based on the two LC datasets (Figure 4a). CDK1 gene alteration was detected in 1.99% of 502 LUSC patients and 1.16% of 516 LUAD patients (Figure 4b). In addition, to better understand the relationship between CDK1 and LC, we analyzed protein–protein interactions. The PPI network was generated by STRING. and showed that SMC2, SMC4, NCAPG, CCNB2, NCAPH, BUB1, CCNB1, PLK1, BUB1B, CKS1B, MAD2L1, CDC20, CKS2, and CCNA2 were associated (P < 0.05) with CDK1 and its functions (Figure 4c).
Functional enrichment analysis of CDK1 in patients with LC
The functions of the CDK1 gene were projected by analyzing GO and KEGG enrichment in the STRING database. GO enrichment analysis indicates how target host genes function in terms of biological mechanism, cellular components, and molecular functions. CDK1 and associated genes were primarily enriched in mitotic chromosome condensation, G2/M transition, mitotic cell cycle checkpoint, organelle organization, regulation of cell cycle, anaphase-promoting complex-dependent catabolic process, mitotic nuclear division, sister chromatid segregation, nuclear division, and cell division (Figure 5a). The molecular functions for these genes were mainly regulated by histone binding, chromatin binding, single-stranded DNA binding, ubiquitin binding, enzyme activator activity, ATP binding, protein kinase binding, cyclin-dependent protein serine/threonine kinase activity, histone kinase activity, and protein serine/threonine kinase activity (Figure 5b). The cellular ingredients that these genes were involved in were cytoskeletal part, cyclin B1-CDK1 complex, microtubule cytoskeleton, nuclear lumen, cytosol, protein-containing complex, spindle, cyclin-dependent protein kinase holoenzyme complex, chromosomal part, and condensed chromosome (Figure 5c). The KEGG pathways for CDK1 and neighboring genes are shown in Table 1. Among these pathways, the cell cycle, the p53 signaling pathway, pathways in small cell lung cancer, viral carcinogenesis, and the FOXO signaling pathway were involved in tumor development and pathogenesis of lung cancer.
Table 1.
Pathway ID | Pathway name | Gene count | False discovery rate | Genes |
---|---|---|---|---|
04110 | Cell cycle | 9 | 4.07E-15 | BUB1, BUB1B, CCNA2, CCNB1, CCNB2, CDC20, CDK1, MAD2L1, PLK1 |
04914 | Progesterone-mediated oocyte maturation | 8 | 4.33E-14 | AURKA, BUB1, CCNA2, CCNB1, CCNB2, CDK1, MAD2L1, PLK1 |
04114 | Oocyte meiosis | 8 | 1.44E-13 | AURKA, BUB1, CCNB1, CCNB2, CDC20, CDK1, MAD2L1, PLK1 |
04218 | Cellular senescence | 4 | 3.08E-05 | CCNA2, CCNB1, CCNB2, CDK1 |
04115 | p53 signaling pathway | 3 | 8.41E-05 | CCNB1, CCNB2, CDK1 |
05166 | HTLV-I infection | 4 | 0.00013 | BUB1B, CCNB2, CDC20, MAD2L1 |
04068 | FoxO signaling pathway | 3 | 0.00039 | CCNB1, CCNB2, PLK1 |
05203 | Viral carcinogenesis | 3 | 0.00092 | CCNA2, CDC20, CDK1 |
05222 | Small cell lung cancer | 2 | 0.0049 | CKS1B, CKS2 |
05169 | Epstein–Barr virus infection | 2 | 0.0185 | CCNA2, CDK1 |
KEGG, Kyoto Encyclopedia of Genes and Genomes; CDK1, cyclin dependent kinase 1.
Correlation between CDK1 expression and survival of LC patients
We used K-M Plotter to analyze the prognostic value of mRNA expression of CDK1 in LC patients. The results demonstrated a correlation for increased expression of CDK1 with poor OS (Figure 6a), first progression (FP) (Figure 6b), and post-progression survival (PPS) (Figure 6c). These results indicated that mRNA expression of CDK1 was significantly associated with prognosis in patients with LC, and CDK1 may be exploited as a useful biomarker for prediction of survival in LC patients.
Discussion
The cell cycle is an evolutionarily conserved process necessary for mammalian cell growth and development. Loss of normal cell-cycle control is a hallmark of human cancer.17 Although a role for CDK1 in controlling the development and patient outcomes for several cancer types has been confirmed, further bioinformatics analysis of LC is still needed. In the current study, we determined mRNA expression and prognostic value (OS, FP, and PPS) of CDK1 in LC. These results support efforts to improve LC diagnosis, prognostic analysis, and treatment.
The cell cycle is an essential and tightly controlled process regulating the proliferation and development of cells.18 The loss of typical cell-cycle regulation indicates malignancy.19 Many therapeutic approaches have been developed to regulate the cell cycle in cancers.20 CDK1 is a catalytic subunit of a protein kinase complex, which induces cell entry into mitosis. This gene is responsible for controlling the transition from G1 to S phase and from G2 to M phase of the cell cycle.8 Dysregulated activity of CDK1 has been observed frequently in cancers. CDK1 is reported to be an adverse prognostic biomarker of LUAD, and increased expression of CDK1 is associated with a higher risk of cancer recurrence and poor survival compared with normal expression of CDK1 in patients with LUAD.21 Another study demonstrated that using dinaciclib to inhibit the expression of CDK1 induced anaphase catastrophe in lung cancer.22 These findings were similar to those of other studies, in which increased expression and activity of CDK1 were found in colorectal, prostate, and epithelial ovarian cancer.23–25 In our study, findings from the Oncomine and GEPIA databases indicated that CDK1 upregulation was linked to clinical characteristics of patients with LC. Kaplan–Meier plots indicated that CDK1 levels were linked to poorer OS, FP, and PPS, in line with an oncogenic role for CDK1. These previously reported findings, together with those of our study, confirm that regulation of CDK1 is vital in governing the cell cycle and cell differentiation and that upregulation of CDK1 appears to contribute to lung cancer development and poorer differentiation. However, there are several limitations in our study. First, the data used in the current study were provided from various public databases, not generated by us. Second, the results were web-based and not verified by biological experiments. Thus, further mechanistic studies based on our findings are needed.
In conclusion, our study provides a comprehensive bioinformatics analysis of CDK1, which may be involved in the progression and development of lung cancer. Our results may improve our understanding of the heterogeneity and complexity of LC. The increased expression of CDK1 in LC tissues may be important in LC oncogenesis, and CDK1 could become a prognostic marker. However, the mechanisms of CDK1 in LC and its value as a prognostic and therapeutic target need to be further studied.
Availability of data and materials
The datasets used or analyzed during the current study are available from the corresponding author on reasonable request.
Authors’ contributions
Mingyao Li and Fenyi He conceived and designed the study strategy, acquired the data, performed the statistical analysis, and interpreted the data. Zhanchun Zhang collected references and managed the data. Mingyao Li and Fenyi He drafted and revised the manuscript, Zhenfei Xiang wrote the manuscript, Danfei Hu prepared the figures, and all authors reviewed the manuscript.
Declaration of conflicting interest
The authors declare that there is no conflict of interest.
Funding
This research received no specific grant from any funding agency in the public, commercial, or not-for-profit sectors.
ORCID iD
References
- 1.Sun CC, Li SJ, Li Get al. Long intergenic noncoding RNA 00511 acts as an oncogene in non-small-cell lung cancer by binding to EZH2 and suppressing p57. Mol Ther Nucleic Acids 2016; 5: e385. DOI: 10.1038/mtna.2016.94. [DOI] [PMC free article] [PubMed] [Google Scholar]
- 2.Sun C, Li S, Zhang Fet al. Long non-coding RNA NEAT1 promotes non-small cell lung cancer progression through regulation of miR-377-3p-E2F3 pathway. Oncotarget 2016; 7: 51784–51814. DOI: 10.18632/oncotarget.10108. [DOI] [PMC free article] [PubMed] [Google Scholar]
- 3.Fang J, Sun CC, Gong C. Long noncoding RNA XIST acts as an oncogene in non-small cell lung cancer by epigenetically repressing KLF2 expression. Biochem Biophys Res Commun 2016; 478: 811–817. DOI: 10.1016/j.bbrc.2016.08.030. [DOI] [PubMed] [Google Scholar]
- 4.Liu G, Pei F, Yang Fet al. Role of autophagy and apoptosis in non-small-cell lung cancer. Int J Mol Sci 2017; 18: pii: E367. DOI: 10.3390/ijms18020367. [DOI] [PMC free article] [PubMed] [Google Scholar]
- 5.Nair CK, Mathew AP, George PS. Lung cancer: presentation and pattern of care in a cancer center in South India. Indian J Cancer 2017; 54: 164–168. DOI: 10.4103/ijc.IJC_56_17. [DOI] [PubMed] [Google Scholar]
- 6.Kruglyak KM, Lin E, Ong FS. Next-generation sequencing and applications to the diagnosis and treatment of lung cancer. Adv Exp Med Biol 2016; 890: 123–136. DOI: 10.1007/978-3-319-24932-2_7. [DOI] [PubMed] [Google Scholar]
- 7.Santamaria D, Barriere C, Cerqueira Aet al. Cdk1 is sufficient to drive the mammalian cell cycle. Nature 2007; 448: 811–815. DOI: 10.1038/nature06046. [DOI] [PubMed] [Google Scholar]
- 8.Malumbres M, Barbacid M. Cell cycle, CDKs and cancer: a changing paradigm. Nat Rev Cancer 2009; 9: 153–166. DOI: 10.1038/nrc2602. [DOI] [PubMed] [Google Scholar]
- 9.Enserink JM, Kolodner RD. An overview of Cdk1-controlled targets and processes. Cell Div 2010; 5: 11. DOI: 10.1186/1747-1028-5-11. [DOI] [PMC free article] [PubMed] [Google Scholar]
- 10.Ravindran Menon D, Luo Y, Arcaroli JJet al. CDK1 interacts with Sox2 and promotes tumor initiation in human melanoma. Cancer Res 2018; 78: 6561–6574. DOI: 10.1158/0008-5472.CAN-18-0330. [DOI] [PMC free article] [PubMed] [Google Scholar]
- 11.Tang Z, Li C, Kang Bet al. GEPIA: a web server for cancer and normal gene expression profiling and interactive analyses. Nucleic Acids Res 2017; 45: W98–W102. DOI: 10.1093/nar/gkx247. [DOI] [PMC free article] [PubMed] [Google Scholar]
- 12.Asplund A, Edqvist PH, Schwenk JMet al. Antibodies for profiling the human proteome-The Human Protein Atlas as a resource for cancer research. Proteomics 2012; 12: 2067–2077. DOI: 10.1002/pmic.201100504. [DOI] [PubMed] [Google Scholar]
- 13.Gyorffy B, Surowiak P, Budczies Jet al. Online survival analysis software to assess the prognostic value of biomarkers using transcriptomic data in non-small-cell lung cancer. PLoS One 2013; 8: e82241. DOI: 10.1371/journal.pone.0082241. [DOI] [PMC free article] [PubMed] [Google Scholar]
- 14.Ashburner M, Ball CA, Blake JAet al. Gene ontology: tool for the unification of biology. The Gene Ontology Consortium. Nat Genet 2000; 25: 25–29. DOI: 10.1038/75556. [DOI] [PMC free article] [PubMed] [Google Scholar]
- 15.Kanehisa M, Furumichi M, Tanabe Met al. KEGG: new perspectives on genomes, pathways, diseases and drugs. Nucleic Acids Res 2017; 45: D353–D361. DOI: 10.1093/nar/gkw1092. [DOI] [PMC free article] [PubMed] [Google Scholar]
- 16.Cancer Genome Atlas N. Comprehensive molecular portraits of human breast tumours. Nature 2012; 490: 61–70. DOI: 10.1038/nature11412. [DOI] [PMC free article] [PubMed] [Google Scholar]
- 17.Coban EA, Tecimel D, Sahin Fet al. Targeting cancer metabolism and cell cycle by plant-derived compounds. Adv Exp Med Biol 2019. DOI: 10.1007/5584_2019_449. [DOI] [PubMed] [Google Scholar]
- 18.Matera R, Saif MW. New therapeutic directions for advanced pancreatic cancer: cell cycle inhibitors, stromal modifiers and conjugated therapies. Expert Opin Emerg Drugs 2017; 22: 223–233. DOI: 10.1080/14728214.2017.1362388. [DOI] [PubMed] [Google Scholar]
- 19.Dominguez-Brauer C, Thu KL, Mason JMet al. Targeting mitosis in cancer: emerging strategies. Mol Cell 2015; 60: 524–536. DOI: 10.1016/j.molcel.2015.11.006. [DOI] [PubMed] [Google Scholar]
- 20.He YC, He L, Khoshaba Ret al. Curcumin nicotinate selectively induces cancer cell apoptosis and cycle arrest through a P53-mediated mechanism. Molecules 2019; 24: pii: E4179. DOI: 10.3390/molecules24224179. [DOI] [PMC free article] [PubMed] [Google Scholar]
- 21.Shi YX, Zhu T, Zou Tet al. Prognostic and predictive values of CDK1 and MAD2L1 in lung adenocarcinoma. Oncotarget 2016; 7: 85235–85243. DOI: 10.18632/oncotarget.13252. [DOI] [PMC free article] [PubMed] [Google Scholar]
- 22.Danilov AV, Hu S, Orr Bet al. Dinaciclib induces anaphase catastrophe in lung cancer cells via inhibition of cyclin-dependent kinases 1 and 2. Mol Cancer Ther 2016; 15: 2758–2766. DOI: 10.1158/1535-7163.MCT-16-0127. [DOI] [PMC free article] [PubMed] [Google Scholar]
- 23.Zhang P, Kawakami H, Liu Wet al. Targeting CDK1 and MEK/ERK overcomes apoptotic resistance in BRAF-mutant human colorectal cancer. Mol Cancer Res 2018; 16: 378–389. DOI: 10.1158/1541-7786.MCR-17-0404. [DOI] [PubMed] [Google Scholar]
- 24.Liu X, Gao Y, Ye Het al. Positive feedback loop mediated by protein phosphatase 1alpha mobilization of P-TEFb and basal CDK1 drives androgen receptor in prostate cancer. Nucleic Acids Res 2017; 45: 3738–3751. DOI: 10.1093/nar/gkw1291. [DOI] [PMC free article] [PubMed] [Google Scholar]
- 25.Yang W, Cho H, Shin HYet al. Accumulation of cytoplasmic Cdk1 is associated with cancer growth and survival rate in epithelial ovarian cancer. Oncotarget 2016; 7: 49481–49497. DOI: 10.18632/oncotarget.10373. [DOI] [PMC free article] [PubMed] [Google Scholar]
Associated Data
This section collects any data citations, data availability statements, or supplementary materials included in this article.
Data Availability Statement
The datasets used or analyzed during the current study are available from the corresponding author on reasonable request.
