MagnetOs, Vitoss, and Novabone in a Multi-endpoint Study of Posterolateral Fusion

Study Design:

This study was a multi-endpoint analysis of bone graft substitutes implanted as a standalone graft in a clinically relevant Ovine model of instrumented posterolateral spinal fusion (PLF).

Objective:

The objective of this study was to obtain high-quality evidence on the efficacy of commercial bone graft substitutes compared with autograft in instrumented PLF using a state-of-the-art model with a complete range of assessment techniques.

Summary of Background Data:

Preclinical and clinical data on the quality of spinal fusions obtained with bone graft substitutes are often limited. Calcium phosphates with submicron topography have shown promising results in PLF, as these are able to induce bone formation in tissues distant from the host bone, which facilitates bony union.

Methods:

Nine female, skeletally mature sheep (4–5 y) underwent posterior pedicle screw/rods instrumented PLF at L2–L3 and L4–L5 using the following bone graft materials as a standalone graft per spinal segment: (1) biphasic calcium phosphate with submicron topography (BCP_<µm), (2) 45S5 Bioglass (BG), and (3) collagen-β-tricalcium phosphate with a 45S5 Bioglass adjunct (TCP/BG). Autograft bone (AB) was used as a positive control treatment. Twelve weeks after implantation, the spinal segments were evaluated by fusion assessment (manual palpation, x-ray, micro-computed tomography, and histology), fusion mass volume quantification (micro-computed tomography), range of motion (ROM) testing, histologic evaluation, and histomorphometry.

Results:

Fusion assessment revealed equivalence between AB and BCP_<µm by all fusion assessment methods, whereas BG and TCP/BG led to significantly inferior results. Fusion mass volume was highest for BCP_<µm, followed by AB, BG, and TCP/BG. ROM testing determined equivalence for spinal levels treated with AB and BCP_<µm, while BG and TCP/BG exhibited higher ROM. Histologic evaluation revealed substantial bone formation in the intertransverse regions for AB and BCP_<µm, whereas BG and TCP/BG grafts contained fibrous tissue and minimal bone formation. Histologic observations were supported by the histomorphometry data.

Conclusions:

This study reveals clear differences in efficacy between commercially available bone graft substitutes, emphasizing the importance of clinically relevant animal models with multiendpoint analyses for the evaluation of bone graft materials. The results corroborate the efficacy of calcium phosphate with submicron topography, as this was the only material that showed equivalent performance to autograft in achieving spinal fusion.

Spinal fusion procedures involve the use of bone grafts to mechanically and biologically conjoin ≥2 consecutive spinal segments. Posterolateral spinal fusion (PLF) is one of the more challenging bone grafting indications performed clinically, because it requires the formation of a large, consolidated bone mass through the paraspinous soft tissues with limited host bone contact. To avoid adverse effects related to the harvesting of iliac crest–derived bone graft,1 synthetic bone graft materials are used as extenders or substitutes of autograft bone (AB). Numerous synthetic bone grafts are available on the market, of which many are based on calcium phosphate and bioactive glass.2,3 Calcium phosphate materials are suitable bone graft materials due to their similar composition and structure to mineralized inorganic bone matrix, which facilitates excellent osteoconductive and bone-bonding properties.4 Besides this, specific surface characteristics of calcium phosphates have been shown to strongly affect bone regeneration in vivo. Submicron size and morphology of calcium phosphate surface features have been linked to an ability to induce bone formation in tissues distant from host bone without the addition of stem cells or growth factors, resulting in enhanced performance in orthotopic sites.5–9 Bioactive glasses have been shown to release ionic dissolution products that can stimulate the activity of osteogenic cells in vitro,10–12 termed osteostimulation. Bioactive glasses have also been shown to elicit deposition of a crystalline calcium phosphate surface layer in simulated body fluid,13,14 which has been related to osteoconduction and strong bone-bonding in vivo.15,16 Although different types of bioactive glass have been studied in recent years, 45S5 bioactive glass (ie, Bioglass) developed by Hench and colleagues has been most well-known as a bone graft substitute material.3

The selection of the most appropriate bone graft for PLF may be challenging for surgeons, because preclinical studies on these materials have mostly been performed in nonclinically relevant models. Few studies have compared materials from different classes of synthetic bone grafts (eg, calcium phosphate, Bioglass) in spinal fusion models in vivo. However, side-by-side comparison of such materials in well-designed, clinically relevant animal models could provide valuable insights that could aid surgeons in the selection of treatment options for spinal surgery.

Recently, this research team demonstrated equivalent performance between a calcium phosphate with submicron topography and the gold standard, autograft, in clinically relevant animal models of PLF.17,18 One of these studies involved a challenging Ovine model of instrumented PLF with implantation as a standalone bone graft. In the current work, this Ovine PLF model was again utilized to compare 3 commercially available bone grafts based on calcium phosphate and 45S5 Bioglass. The groups included were (1) a putty formulation of BCP (biphasic calcium phosphate) with submicron surface topography, previously shown to have equivalent performance to autograft in this model,17,18 (2) a putty formulation of 45S5 bioactive glass, (3) a collagen-β-tricalcium phosphate (βTCP) composite with a 45S5 bioactive glass adjunct. AB was included as the “gold standard” reference treatment. Twelve weeks following implantation, the treated segments were evaluated by a range of assessment methods, including fusion assessment [manual palpation, x-ray, micro-computed tomography (CT), and histology], biomechanical range of motion (ROM) testing, fusion mass volume quantification (micro-CT), histologic evaluation of tissue responses, and histomorphometry of bone tissue and residual graft material.

METHODS

Materials

Three commercially available bone grafts were examined in this study. The submicron structured biphasic calcium phosphate bone graft was provided in a putty formulation (BCP_<µm; MagnetOs Putty; Kuros Biosciences BV, The Netherlands). This formulation contained 1–2 mm calcium phosphate granules with a submicron surface topography6 and a phase composition of 65%–75% βTCP and 25%–35% hydroxyapatite, embedded in a fast-resorbing polymer carrier. The polymer carrier consisted of polyethylene glycol and L‐lactide monomer and occupied the granule pores and intergranular space. MagnetOs Putty is currently not labeled for use as standalone bone graft in spinal fusion surgery in the United States.

The bioactive glass-based bone graft was a putty formulation (BG; Novabone Putty; Novabone Products LLC) and consisted of ±70 vol/vol% bioactive glass (45S5) particles of 32–710 µm in a water-soluble carrier of polyethylene glycol and glycerin. 45S5 bioactive glass is composed of ±45% silica (SiO₂), 24.5% calcium oxide (CaO), 24.5% sodium oxide (Na₂O), and 6% phosphorous pentoxide (P₂O₅) (wt%).15

The collagen-βTCP composite with 45S5 Bioglass (TCP/BG; Vitoss BA2X Foam pack, Orthovita Inc.) was comprised of a bovine type I collagen carrier containing βTCP particles (≥95%–100% βTCP) of 1–4 mm, with a separate vial of 1.5 g 45S5 bioactive glass particles of 90–150 µm. The implant was prepared according to the instructions for use. In short, the bioactive glass particles were loaded onto the collagen-βTCP composite, after which physiological saline was added, and the composite was thoroughly mixed. The final composition of the graft was ±55% βTCP, 27% 45S5, and 18% collagen (wt%).

Animal Study

A previously described Ovine model of 2-level instrumented PLF was used in this study.18 Nine female, skeletally mature sheep (Ovis Aries, Border Leicester Merino Cross, 4–5 y, 80–90 kg) were used at the University of New South Wales, Australia, following approval from the local Animal Care and Ethics Committee (ACEC). The animals were randomly allocated treatments at levels L2–L3 and L4–L5 according to a randomization scheme, with n=6 for AB, n=6 for BCP_<µm, n=3 for BG, and n=3 for TCP/BG. After the administration of appropriate antibiotics, analgesics, and anesthetics, surgery was performed, as previously described.18 In brief, the animal was positioned in sternal recumbency and draped using sterile technique. The correct levels were identified and marked preoperatively using fluoroscopy. A skin incision was made in the dorsal midline, after which facet joints and transverse processes (TPs) for the relevant levels were exposed and decorticated. The 2 operative levels (L2–L3 and L4–L5) were instrumented bilaterally with polyaxial pedicle screws (Ø 5.5×25 mm) and solid titanium rods (Ø 5.5 mm). Thereafter, 2 single-level posterolateral arthrodeses were performed at the exposed levels. For each graft material, 10 cm³ of material was placed into both posterolateral gutters (20 cm³ total per level) at the appropriate level in direct apposition with the decorticated TPs, spanning the intertransverse process space. Corticancellous autograft was obtained from the bilateral Os Iliums using rongeurs, after removal of the cortex. Autograft was reduced to 2–5 mm bone chips that were mixed to obtain a 1:1 ratio of both donor sites. The surgical sites were closed in layers. Postoperatively, the animals were monitored and received proper postoperative care, antibiotics, and analgesics. At 12 weeks’ follow-up, animals were anesthetized and euthanized by lethal injection of Lethobarb (325 mg/2 kg intravenously). The lumbar spines were excised and harvested for endpoint analyses.

Manual Palpation

Directly after harvesting of the spines and removal of the pedicle rods, 2 trained observers assessed fusion rigidity of the treated spinal levels in a blinded manner by manual palpation, as previously described.19 All levels were graded as fused (rigid, low mobility) or not fused (not rigid, high mobility) in lateral bending (LB) and flexion-extension (FE), with an untreated level used as a relative comparison.

Radiography

Faxitron

Harvested spines were radiographed in the posteroanterior plane using a Faxitron (Faxitron Bioptics LLC, Tucson, AZ) and digital plates (Agfa CR MD 4.0 cassette; Agfa, Germany). An Agfa Digital Developer and workstation was used to process the digital images (Agfa CR 75.0 Digitizer Musica; Agfa). The radiographic status of the spinal arthrodesis was evaluated by 2 experienced observers in a blinded manner on anteroposterior radiographs using the Lenke 4-point grading scale20 (Table 1).

TABLE 1.

Fusion Grading Scale for X-Ray and Micro-Computed Tomography Assessment Based on the Lenke Classification20

Micro-CT

Micro-CT was performed on the spines using an Inveon Scanner (Siemens Medical Solutions USA Inc., Knoxville, TN). Scans were made with a slice thickness of 53 µm and were stored in DICOM format. Three-dimensional reconstructions were generated from the scans. Status of the spinal arthrodesis was evaluated by 2 experienced observers in a blinded manner in 3 orthogonal planes (ie, axial, sagittal, coronal) and anterior and posterior 3-dimensional reconstructions. As for the radiographs, the Lenke 4-point grading scale was used to grade fusion status.

Quantification of Fusion Mass Volume

Fusion mass volume quantification was performed on TIFF stacks generated from the DICOM scans of the treated spinal levels using dedicated image computing software (3D Slicer 4.1021). This was achieved by performing manual, intensity-based selection of the separate left and right fusion masses on interspersed axial slices (53 µm) throughout the micro-CT files, taking care to exclude the host vertebrae and TPs. Subsequently, interpolation of boundaries between adjacent scan layers was performed using a contour interpolation algorithm,22 resulting in segmentations of the fusion mass. The total volume of each fusion mass in cm³ was derived from the number of voxels in each segmentation, including both (new) mineralized bone and residual graft material.

Biomechanical Analysis

Nondestructive biomechanical ROM testing was performed to obtain a multidirectional flexibility profile of the treated spinal levels. After removal of the pedicle rods, each of the spinal levels was mounted onto a 6-axis simVITRO robotic musculoskeletal simulator (Simulation Solutions Ltd, Stockport, UK and Cleveland Clinic Biorobotics Lab, Cleveland, OH). A ±7.5 Nm pure moment was applied to the spinal levels in LB, FE, and axial rotation (AR). Each loading profile was repeated 3 times, and a mean value for LB, FE, and AR was recorded in the ROM degrees.

Histology and Histomorphometry

Following mechanical testing, spines were fixed at room temperature in 10% formalin in 0.145 M phosphate-buffered saline under gentle rotation for at least 96 hours. Subsequently, specimens were processed for polymethylmethacrylate embedding. A Leica SP1600 saw microtome was used to cut sections in the sagittal plane from the region between TPs lateral of the spine at both sides. From each side, a minimum of 3 sections separated by 300 µm was obtained. A histologic staining of methylene blue (Sigma; 1% in 0.1 M borax buffer, pH 8.5) and basic fuchsin (Sigma; 0.3% in demi water) was performed to visualize bone tissue (bone matrix: pink, fibrous tissues: blue). Sections were examined under a Leica microscope (Eclipse 50i; Nikon) and were scanned with a slide scanner (DiMage scan 5400 Elite II; Konica Minolta, Tokyo, Japan) to obtain low-magnification overviews.

Histologic Evaluation and Fusion Assessment

Histologic evaluation included qualitative assessment of the tissue response, including evidence of inflammation, evidence of graft resorption, new bone formation, and bone marrow space development. Low-magnification overviews of each section were used for fusion assessment and histomorphometry. Fusion assessment by histology was performed by 2 trained observers in a blinded manner on 3 sections from each lateral side of the treated spinal level, resulting in 2 scores per level. Each section was scored as histologically fused if a continuous bridge of bone tissue was observed between the TPs of L2–L3 or L4–L5, thus connecting the adjacent spinal levels. When at least 1 of the 3 sections was scored as fused, the sample was considered “fused” on that side of the spine. If no fusion was determined in any of the 3 slides, the sections were digitally stacked and reevaluated for fusion.

Histomorphometry

Histomorphometry of the fusion mass was performed on 3 sections from each side of the treated spinal level. Pixels representing bone (B) and remaining implant material (M) in a region of interest (ROI) were pseudocolored using image editing software (Adobe Photoshop 5.0). Next, the number of pixels for B, M, and ROI was recorded, and the area percentage of bone in the available space was calculated by the following formula: B/(ROI−M)×100%. In addition, the area percentage of remaining implant material was calculated by the following formula: M/ROI×100%.

Statistical Analysis

Statistical analysis of data was performed using dedicated software tools (GraphPad Prism, San Diego, CA; SPSS Inc., Chicago, IL). Fusion grading data from manual palpation, x-ray, micro-CT, and histology were analyzed by the Fisher-Freeman-Halton exact test. Data from micro-CT volume quantification, biomechanical ROM testing, and histomorphometry were analyzed by analysis of variance followed by Tukey honest significant difference test for post hoc analysis. Normal distribution of data was assessed by the Shapiro-Wilk normality test. For all statistical tests, a significance level of P-value <0.05 was utilized.

RESULTS

Surgery

All surgeries and study procedures proceeded as planned. All graft materials handled well, as they were moldable and easy to implant into the posterolateral gutters. No adverse events occurred in any animal during surgery and the 12-week follow-up period.

Manual Palpation

Results of fusion assessment by manual palpation are presented in Table 2. Successful arthrodesis was confirmed in all levels treated with AB, with 100% of specimens graded as rigid in both LB and FE. Results varied between treatment groups. Although BCP_<µm showed a similar fusion rate to AB with all specimens scored as rigid, both bone grafts (BG and TCP/BG) containing bioactive glass were graded as rigid in only 1 of 3 treated levels. All fusion grades by manual palpation were coherent between reviewers and between the different modes LB and FE. The difference between groups was confirmed by statistical analysis.

TABLE 2.

Outcomes of Fusion Assessment Per Evaluation Method

Radiographic Evaluation and Fusion Assessment

Faxitron radiographs (Fig. 1) were evaluated for evidence of bone formation and residual graft material in the posterolateral regions in between TPs of L2–L3 and L4–L5. In the AB group (Fig. 1A), a consolidated mass of mineralized bone was observed in the bilateral intertransverse process regions. Individual autogenous bone particles could not be discriminated. In the BCP_<µm group (Fig. 1B), a large, radiopaque fusion mass was evident in the region between the bilateral TPs. Although individual BCP_<µm particles could still be discriminated, the grafts had consolidated into a dense, continuous fusion mass between the TPs. At levels treated with BG (Fig. 1C), thin masses of radiopaque material, which were of variable intensity and continuity, were observed between TPs. In the TCP/BG group (Fig. 1D), there was a significant lack of radiopaque substance in the intertransverse regions of all treated levels. The TCP/BG grafts had a low radiopacity with a granular appearance and did not form a consolidated mass at the treated levels.

FIGURE 1.

Representative examples of faxitron radiographs of the spinal levels treated with AB (A), BCP_<µm (B), BG (C), and TCP/BG (D), after removal of instrumentation. AB indicates autograft bone; BCP_<µm, biphasic calcium phosphate with submicron topography; BG, Bioglass; TCP, tricalcium phosphate.

On micro-CT reconstructions (Fig. 2), a bony fusion mass forming a bridge between L2–L3 or L4–L5, was commonly observed in the AB group (Fig. 2A). In many cases, the fusion masses were well-developed, showing a smooth, continuous bone mass with a de novo cortex. Occasionally, fusion masses were not yet completely consolidated and matured, as an outer cortex had not yet developed, and autograft chips could be distinguished in the developing bone mass. The BCP_<µm grafts (Fig. 2B) formed uniform, solid, and continuous fusion bridges between the TPs. The center of the BCP_<µm grafts was compact, and individual BCP particles could be hardly distinguished on axial, sagittal, and transversal slices, indicating bone formation between the granules. New bone growth into the calcium phosphate grafts could be observed in the regions near the host bone.

FIGURE 2.

Representative examples of 3-dimensional micro-computed tomography reconstructions (A–D) of spinal levels treated, AB (A), BCP_<µm (B), BG (C), and TCP/BG (D). The host spinal bone (off-white) and fusion mass (gray) including (new) bone and residual implant material are shown as individual segmentations. For each treatment group, unilateral fusion mass volume (bone+graft material) was determined by performing voxel-based quantification (E). Data shown as mean and SD. •, significantly different from AB, BG, and TCP/BG (P<0.001). ★, significantly different from BCP_<µm, BG, and TCP/BG (P<0.001). AB indicates autograft bone; BCP_<µm, biphasic calcium phosphate with submicron topography; BG, Bioglass; TCP, tricalcium phosphate.

The spinal levels treated with BG (Fig. 2C) presented thin, underdeveloped fusion masses versus AB and BCP_<µm, as observed by micro-CT. The radiopaque mass, in the region between TPs (if present), had a fine, granular appearance with localized, dense regions in the center or in apposition with TPs. A continuous mass between TPs was lacking, and Bioglass granules were few and dispersed. None of the treated levels presented a consolidated fusion mass between TPs with TCP/BG (Fig. 2D). A small amount of dispersed, granular material was occasionally observed in the intertransverse regions. In some cases, regions of minor osteoconductive bone growth were observed near the host bone.

Results of fusion grading on radiographs and micro-CT according to the Lenke scale are presented in Table 2. Both AB and BCP_<µm obtained high fusion scores, with either unilateral or bilateral robust bone bridging in all treated levels. Radiographic fusion scores were lower in the other groups, while the BG group obtained more favorable grades than TCP/BG. The differences in radiographic fusion grades reached statistical significance, although no between-group comparisons were analyzed.

Fusion Mass Volume

Micro-CT quantification (Fig. 2E) revealed that the levels treated with AB had an average unilateral, mineralized fusion mass volume of 5.70±1.59 cm³. The volume in the BCP_<µm group was significantly higher at 9.60±0.45 cm³. Volumes were significantly lower in BG and TCP/BG, at ∼3 cm³. Statistical significance was reached for all group comparisons, except for BG versus TCP/BG.

Biomechanical Testing

Functional treatment efficacy was quantified by use of biomechanical ROM testing (Fig. 3). The BCP_<µm group revealed an equivalent ROM to AB in all modes, while ROM for levels treated with BG and TCP/BG was evidently higher in LB and FE. Statistical analysis revealed equivalence between AB and BCP_<µm in all modes, while ROM in these groups was significantly lower in LB and FE compared with BG and significantly lower in FE compared with TCP/BG. No significant difference in AR ROM was determined between all treatments.

FIGURE 3.

Diagrams of nondestructive biomechanical range of motion testing results, as performed in lateral bending (A), flexion-extension (B), and axial rotation (C). Data are presented as range of motion degrees in mean and SD. ★, significantly different from AB and BCP_<µm (P<0.005). •, significantly different from AB and BCP_<µm (P<0.05). ▪, significantly different from AB and BCP_<µm (P<0.005). AB indicates autograft bone; BCP_<µm, biphasic calcium phosphate with submicron topography; BG, Bioglass; TCP, tricalcium phosphate.

Histologic Evaluation and Fusion Assessment

Histology of the spinal levels treated with AB (Fig. 4A) revealed the presence of abundant new and remodeling bone tissue in the intertransverse process space. The implanted AB particles had been remodeled into uniform bone mass in the intertransverse process space.

FIGURE 4.

Representative, low-magnification micrographs of sagittal histologic sections (methylene blue/basic fuchsin) taken from the intertransverse process regions of spinal levels treated with AB (A), BCP_<µm (B), BG (C), and TCP/BG (D). Bone matrix is shown in pink, soft tissues in blue, residual calcium phosphate material in black, and Bioglass particles are translucent. The low-magnification micrographs were graded for fusion, evident from a continuous bone bridge between adjacent transverse processes. AB indicates autograft bone; BCP_<µm, biphasic calcium phosphate with submicron topography; BG, Bioglass; TCP, tricalcium phosphate.

In BCP_<µm specimens (Figs. 4B, 5A–D), a large area consisting of calcium phosphate granules integrated in trabecular bone was observed throughout the implant sites (Fig. 4B). Bone was of mature, lamellar morphology including new bone marrow spaces (Figs. 5A–C) and evidence of a pseudocortex in some specimens (Fig. 5D). The bone matrix was in direct apposition with the BCP_<µm material. Typical bone cells, including osteoblasts lining regions of new bone formation, osteoclasts, and osteocytes were observed throughout the specimens (Fig. 5C) Multinucleated cells were observed resorbing the calcium phosphate material on granule surfaces not covered by bone (Fig. 5C).

FIGURE 5.

Representative micrographs from histologic sections of the spinal levels treated with BCP_<µm (A–D), BG (E–K), and TCP/BG (L–P). Micrographs were obtained from regions near the host transverse process (A, E–G, L, M) and the intertransverse central region (B, C, H–K, N–P). A pseudocortex on the outside of the fusion mass was observed in specimens treated with BCP_<µm (D—blue arrows). High-magnification images show cellular processes observed near the graft materials, including osteoblasts (C, F, M—black arrows) depositing osteoid and cell-mediated resorption of materials by multinucleated cells (C, O, P—yellow arrows). Inflammatory foreign body reaction was observed in BG and TCP/BG specimens, as evidenced by encapsulation of material (I), high numbers of lymphocytes (I, P) and foreign body giant cells (I–K, P—yellow arrows). BCP_<µm indicates biphasic calcium phosphate with submicron topography; BG, Bioglass; BM, bone marrow; FT, fibrous tissue; HB, host bone; NB, new bone; O, osteoid; TCP, tricalcium phosphate.

Histology of the BG specimens (Figs. 4C, 5H–K) presented as fibrous tissue with dispersed Bioglass particles and absence of bone tissue throughout the implant site (Fig. 4C). Residual Bioglass particles were contained in fibrous tissue and commonly contained cracks, sometimes having a hollow center, or were fragmented (Fig. 5H). Occasional osteoconductive bone formation was observed in the vicinity of host TPs (Fig. 5E). However, sometimes, no osteoconductive bone formation was observed even when Bioglass was in direct apposition with the host bone (Fig. 5G). In 5 of 6 specimens, a foreign body reaction was observed around Bioglass particles throughout the implant sites, characterized by encapsulation by granulatomous inflammatory tissue with presence of lymphocytes and foreign body giant cells (Figs. 5I–K). Moreover, 3 of 6 specimens contained dense regions of Bioglass of variable dimensions, which upon further inspection revealed to be areas of severely fragmented material and evidence of foreign body reaction (Fig. 5J).

For TCP/BG (Figs. 4D, 5L–P), most sections had to be obtained from regions very medial to the spinal body, as graft material or bone in the regions between TPs was largely absent (Fig. 4D). The implantation sites contained fibrous tissue with sparse calcium phosphate particles, which were commonly in the process of disintegration due to cell-mediated resorption (Figs. 5N–O). The Bioglass particles were very small and could only be observed by high magnification, with a similar appearance to those observed in the BG group (Figs. 5L–P). An inflammatory reaction around the Bioglass particles was generally not observed. Newly formed bone tissue was absent in the central region of the implants, although some specimens exhibited new bone formation in the vicinity of TPs. Calcium phosphate and Bioglass particles were occasionally observed being integrated in the bone matrix (Figs. 5L–M). One specimen presented a region with graft material enclosed by granulatomous tissue that contained high numbers of lymphocytes and resorbing multinucleated giant cells, indicating a foreign body granuloma (Fig. 5P).

Results of fusion assessment by histology are presented in Table 2. Histologic fusion scores in the AB and BCP_<µm groups were significantly higher than in the BG and TCP/BG groups. For levels treated with AB, the positive control, fusion was reported in 9 of 12 samples, corresponding to a fusion rate of 75%. In the BCP_<µm group, 10 of 12 samples were scored as fused, which translates to a fusion rate of 83%. For the BG and TCP/BG groups, a bony fusion between TPs was not reported in any of the specimens, thus corresponding to a fusion rate of 0%. Statistical analysis revealed that the differences in histologic fusion rate were statistically significant (P<0.05).

Histomorphometry

As determined by histomorphometry (Fig. 6), the fusion masses of levels treated with AB and BCP_<µm contained a substantially higher percentage of bone, as compared with the BG and TCP/BG groups (Fig. 6A). Bone proportions were similar for AB and BCP_<µm, with over >40% of bone in the available space in both groups. This percentage was significantly lower for the other groups, the lowest being BG, followed by TCP/BG. Statistical analysis confirmed equivalence for AB versus BCP_<µm and BG versus TCP/BG, while all other comparisons were significantly different. Area percentage of remaining graft material (Fig. 6B) was highest for BCP_<µm implants, followed by BG, with the TCP/BG graft having the lowest percentage. Statistical significance was reached for all group comparisons in material percentage.

FIGURE 6.

Histomorphometry diagrams of bone (A) and residual material (B) performed on low-magnification micrographs of histologic sections. Data are presented as area%, in mean and SD. ★, significantly different from BG and TCP/BG (P<0.001). •, significantly different from BG (P<0.005) and TCP/BG (P<0.001). ▪, significantly different from BCP_<µm (P<0.005) and TCP/BG (P<0.001). AB indicates autograft bone; BCP_<µm, biphasic calcium phosphate with submicron topography; BG, Bioglass; TCP, tricalcium phosphate.

DISCUSSION

The posterolateral spine environment is a challenging biological and biomechanical environment, as it provides limited host bone contact and significant exposure to soft tissues. Even with use of the “gold standard” of autograft, surgeons commonly deal with revision surgery rates of ±10%–20%.23–26 Considering this, it is important that the selection of graft materials is based on preclinical evidence obtained in studies of high methodological quality, using clinically relevant animal models and multiple evaluation techniques. A large number of bone grafts are commercially available for clinical use, which makes selection of the most appropriate challenging for the surgeon community. Most reports on commercial graft materials in the literature are of preclinical studies performed in rabbits, and they involve the repair of small, cancellous bone defects with a high ratio of bone surface to defect volume.27–33 Although critically sized, that is, they will not completely spontaneously heal without the use of a graft, such defects are less challenging than, and do not properly model, the posterolateral spine environment. This limits the extrapolation of results from these models to PLF indications. Moreover, many studies have been of poor methodological design, for example, no use of critical-sized defects, lack of proper positive and/or negative controls, and use of limited endpoints and assessment methods with low sensitivity.27–29,34 Clinical reports for the use of synthetic bone grafts are limited in number and often of low methodological strength (ie, observational studies). Furthermore, outcomes can only be determined using techniques with low sensitivity and/or specificity, such as radiographic evaluation and patient-reported outcomes.

Of the available animal models of PLF, the instrumented Ovine PLF35 model is among the most translational, as bone remodeling properties and spine biomechanics of sheep are similar to those of humans, and the model allows the use of relevant graft volumes and pedicle instrumentation.36–39 For comparison, the Boden rabbit PLF model,19 which is used to obtain market approval for bone graft materials in the United States, is noninstrumented and differs in anatomy, biomechanics, and bone turnover rate from the clinical reality in humans.40 Note, the current study used aged sheep (4–5 y old), which challenges the model due to age.41

With regard to assessment techniques used for fusion evaluation, it is important that a range of different methods is applied, as they may individually give limited information and vary in sensitivity. Classically, fusion assessment in preclinical models was performed by the less sensitive techniques of manual palpation and plain film radiography.19 Recently, more sensitive techniques have been added, including micro-CT, histology, and biomechanical testing. For synthetic bone grafts, fusion evaluation by radiography (eg, x-ray, CT) may lead to an overestimation of fusion, as bone mineral and radiopaque implant materials cannot easily be distinguished by these methods. Histology provides a unique insight and accurate representation of a fusion mass at the tissue and cell level, allowing investigators to differentiate between bone and graft material and to evaluate tissue and cellular responses. Last, biomechanical testing is an important quantitative method performed in conjunction with the other techniques to determine whether fusion outcomes also have a functional significance, that is, reduction of mobility between spinal segments. Here, a robotic musculoskeletal simulator was used to apply controlled loading regimens to the spinal segments.

Using this validated, multi-endpoint, clinically relevant, Ovine model of instrumented PLF, 3 commercially available bone grafts implanted as a standalone graft were compared against AB, the current gold standard for bone grafting. Of the evaluated synthetic bone grafts, BCP_<µm was the only material that presented substantial, solid fusion masses between TPs that contained mature bone, resulting in similar fusion scores to AB by all assessment methods and equivalent biomechanical ROM. These outcomes were corroborated by all assessment techniques and were in line with previous results.17,18 In contrast to BCP_<µm, spinal levels treated with BG and TCP/BG significantly underperformed to the positive control by all evaluation methods. Although by biomechanical testing no significant differences between treatments were determined in AR, it is recognized that flexibility testing in AR has a lower sensitivity than the other modes.42,43

These results confirm the limitations of fusion evaluation by radiographic techniques when synthetic bone graft materials are used in PLF. Although spinal levels treated with BG obtained a moderate fusion grade B of the Lenke scale in 2 of 3 specimens by both x-ray and micro-CT, histology revealed that all apparent fusion bridges did not contain any bone tissue. These results show that the option to use histology is a significant advantage of preclinical models over clinical investigation. Histology also allows the evaluation of local tissue reactions, as the materials resorb and participate in the bone repair and remodeling process, which is not possible by other techniques.

Fusion mass volume quantification is a more novel method for evaluation of PLF outcomes that assists in further differentiation of radiographic endpoints. It should be noted that the use of micro-CT, which is not available clinically, provides a level of detail beyond traditional radiographs or clinical CT. The technique can provide meaningful information on graft volume stability, as too fast or too severe resorption of a graft may potentially result in atrophic pseudarthrosis.44 Here, clear differences in fusion mass volumes were determined between groups. Although the same starting volume of 10 cc was implanted in each posterolateral gutter for all groups, the mineralized volume after 12 weeks was around 3 cm³ for BG and TCP/BG grafts, whereas for BCP_<µm, it was just under 10 cm³. Although the initial radiopaque volume of the grafts was not determined and the data represent the volume of both new bone and residual graft material, we may still assume that BG and TCP/BG have undergone substantial resorption after implantation. This notion was supported by histologic observations and histomorphometry results. The finding that spinal levels treated with AB had lower fusion mass volumes compared with BCP_<µm may be potentially related to a lower initial radiopaque volume, but could also suggest resorption. Indeed, AB has been reported to undergo resorption and remodeling after implantation in the posterolateral spine, leading to a volume loss of up to ±35% during the first year.45–47

The above findings demonstrate a clear difference in the performance of commercially available synthetic bone grafts in instrumented PLF in sheep. Correlation of performance outcomes to specific bone graft factors is challenging due to the many physicochemical differences between the grafts that could affect bone regeneration potential, for example, composition, surface properties, carrier materials, particle size, and graft to carrier ratio. However, the submicron surface topography of BCP_<µm seems to play a leading role in bone graft performance48 and may explain its enhanced efficacy in this PLF model.

In recent years, research has consistently demonstrated that calcium phosphates with a submicron topography show enhanced performance to conventional calcium phosphates, following from their ability to induce bone formation in regions far from host bone or with minimal bone contact.7–9,48 This property is particularly desirable for use in PLF, in which bone formation should occur in the paraspinous soft tissues with limited host bone surface contact. A suggested mechanism underlying the enhanced efficacy of calcium phosphates with submicron topography is the upregulation of anti-inflammatory M2 macrophages at the material surface, which have been associated with bone regeneration (R. Duan, Y. Zhang, L.A. van Dijk, D. Barbieri, J.J.J.P van den Beucken, H. Yuan, J.D. de Bruijn, 2019, unpublished data).49–51

Bone induction by the TCP component of the TCP/BG group has been evaluated in 2 previous studies.48,52 Both studies demonstrated the absence of submicron topography correlated with the lack of ectopic bone induction, even in the presence of Bioglass.52 Furthermore, the TCP component in TCP/BG reportedly consists of 100% phase pure βTCP and has a porosity of 78%.52 A calcium phosphate with these properties is expected to have a high resorption rate, with potentially detrimental effects on bone healing.53 This notion is in agreement with the findings of the current study and other works.32,33,52,53

The presence of 45S5 Bioglass in BG and TCP/BG grafts, resulting in enhanced osteoblast activity and osteogenic differentiation of stem cells in vitro,10–12,54–56 did not promote spinal fusion in this l PLF model. To our knowledge, there is no literature on the use of Bioglass as a standalone graft in PLF models, and beneficial effects of osteostimulation have not been demonstrated in other in vivo models. We may, therefore, conclude that osteostimulative Bioglass, whether used alone or as an adjunct to calcium phosphate, has little biological relevance to use of bone graft materials in spinal fusion. Moreover, the inflammatory foreign body reaction observed around Bioglass particles, which has also been reported in other studies,57–59 is presumably not beneficial for bone formation. However, foreign body reaction against Bioglass particles was not observed in TCP/BG, which contained a lower content of Bioglass than BG (25% vs. 100%), suggesting that only larger proportions of Bioglass may induce such reactions.

CONCLUSIONS

Using a challenging, clinically relevant, Ovine model of instrumented PLF, this study reveals clear differences in performance between commercially available bone graft materials implanted as a standalone graft, after evaluation by a full range of assessment techniques. The results demonstrated favorable outcomes with a putty formulation of BCP_<µm, which has a submicron topography, versus 2 other bone graft materials, being a putty formulation of 45S5 Bioglass and a collagen-βTCP with a 45S5 Bioglass adjunct. Through all outcomes, the BCP_<µm reached equivalence to the positive control, autograft, in achieving functional spinal fusion, while the other 2 materials significantly underperformed, showing an inability to form a solid, bony fusion between the spinal segments during the 12-week follow-up period. These results corroborate previous findings on the efficacy of BCP_<µm with submicron topography in spinal PLF models, following from its ability to promote bone formation in soft tissues distant from host bone. These findings emphasize the importance of side-by-side comparison of commercial bone graft materials in clinically relevant, multi-endpoint animal models in determining spinal fusion efficacy.
