Modified Z-POEM technique to allow easier closure of the tunnel entry

Introduction

Zenkerʼs diverticulum is an acquired herniation of the mucosa posteriorly through Killianʼs space. Treatment options are surgical, rigid endoscopic, or flexible endoscopic techniques. Flexible endoscopic treatment was first described in 1995 ¹ .

Cricopharyngeal mucomyotomy has a 91 % success rate, with 11 % adverse events (AEs) and 11 % risk of recurrence ² .

Zenkerʼs peroral endoscopic myotomy (Z-POEM) is a recently proposed technique using third space endoscopy to enable a complete division of the septum in order to decrease the risk of recurrence ³ . Complete closure of the tunnel is essential to avoid adverse events.

Case description

Video 1  A modified Z-POEM with a “precut” myotomy.

Download video file ^{(68.2MB, mp4)}

An 85-year-old woman presented with dysphagia due to Zenkerʼs diverticulum ( Fig. 1 ). It measured 2 cm on esophagram ( Fig. 2 ). She underwent a modified Z-POEM technique, as follows ( Video 1 ).

Fig. 1.

 Zenkerʼs diverticulum on endoscopy.

Fig. 2.

 Zenkerʼs diverticulum on esophagram.

Submucosal injection with a combination of normal saline and methylene blue was followed by mucosal incision at the edge of the septum using a Hybrid T knife.

The incision (no longer than 1.5 cm) leaned toward the diverticular side in order to allow an easier closure of the tunnel entry.

Dissection of the submucosal fibers was performed until the cricopharyngeal muscle was exposed. The submucosal fibers on both sides of the muscle were dissected (before entering the tunnel) using forced coagulation. Repeated injections were performed using the Erbe jet in order to avoid mucosal injury.

We avoided the temptation to enter the tunnel (particularly on the esophageal side) in order to avoid stretching and pushing the esophageal edge of the entry down toward the esophagus as this approach can make the tunnel closure more difficult. Instead, a “precut” was performed by starting to divide the cricopharyngeal muscle before entering the tunnel.

After partial myotomy, the endoscope entered the tunnel smoothly and the remaining cricopharyngeus fibers were divided completely ( Fig. 3 ). The tunnel entry ( Fig. 4 ) was then easily closed using clips ( Fig. 5 ).

Fig. 3.

 Endoscopic image of the tunnel after a complete myotomy.

Fig. 4.

 Endoscopic image of the tunnel entry after completed myotomy.

Fig. 5.

 Endoscopic image of the tunnel entry after closure with clips.

There were no AEs. A water-soluble esophagogram performed the next day showed no leakage ( Fig. 6 ). The patientʼs diet was advanced and she was discharged.

Fig. 6.

 Water-soluble esophagogram after Z-POEM.

At a follow-up visit a week later her dysphagia resolved.

Conclusions

While the Z-POEM technique is based on the premise that a complete cricopharyngeal muscle division decreases the risk of recurrence, a robust closure of the tunnel is essential to avoid complications.

Complete closure of the tunnel entry can be facilitated by limiting the length of the mucosal incision and leaning it toward the diverticular side. A “precut” of the cricopharyngeus muscle before entering the tunnel enables a smoother tunnel entry without stretching the edges. This might result in an easier closure of the tunnel.
