A new view of macula densa cell microanatomy

Abstract

Although macula densa (MD) cells are chief regulatory cells in the nephron with unique microanatomical features, they have been difficult to study in full detail due to their inaccessibility and limitations in earlier microscopy techniques. The present study used a new mouse model with a comprehensive imaging approach to visualize so far unexplored microanatomical features of MD cells, their regulation, and functional relevance. MD-GFP mice with conditional and partial induction of green fluorescent protein (GFP) expression, which specifically and intensely illuminated only single MD cells, were used with fluorescence microscopy of fixed tissue and live MD cells in vitro and in vivo with complementary electron microscopy of the rat, rabbit, and human kidney. An elaborate network of major and minor cell processes, here named maculapodia, were found at the cell base, projecting toward other MD cells and the glomerular vascular pole. The extent of maculapodia showed upregulation by low dietary salt intake and the female sex. Time-lapse imaging of maculapodia revealed highly dynamic features including rapid outgrowth and an extensive vesicular transport system. Electron microscopy of rat, rabbit, and human kidneys and three-dimensional volume reconstruction in optically cleared whole-mount MD-GFP mouse kidneys further confirmed the presence and projections of maculapodia into the extraglomerular mesangium and afferent and efferent arterioles. The newly identified dynamic and secretory features of MD cells suggest the presence of novel functional and molecular pathways of cell-to-cell communication in the juxtaglomerular apparatus between MD cells and between MD and other target cells.

NEW & NOTEWORTHY This study illuminated a physiologically regulated dense network of basal cell major and minor processes (maculapodia) in macula densa (MD) cells. The newly identified dynamic and secretory features of these microanatomical structures suggest the presence of novel functional and molecular pathways of cell-to-cell communication in the juxtaglomerular apparatus between MD and other target cells. Detailed characterization of the function and molecular details of MD cell intercellular communications and their role in physiology and disease warrant further studies.

INTRODUCTION

The macula densa (MD) is a plaque of 20–25 highly specialized and polarized renal epithelial cells in each nephron at the distal end of the thick ascending limb, strategically localized at the glomerular vascular pole as the tubular component of the juxtaglomerular (JG) apparatus (JGA). Their basal cell surface is facing and is in direct contact with the vascular component of the JGA, including vascular smooth muscle cells of the afferent arterioles (AA) and efferent arterioles (EA), renin-producing JG cells, and extraglomerular mesangial cells. The unique MD cell microanatomy, including prominent primary cilia at the luminal membrane (1–3), apically localized cell nuclei, and various organelles involved in MD protein and autacoid synthetic machinery packed in the basal part of the cell body, has been long recognized and linked to the functional role of the MD in sensing the local tissue environment and signaling to the JGA (4–8). In fact, the special features of these organelles play important roles in the traditional functions of the MD to sense alterations in tubular salt and other factors of the local tissue environment and to translate that information to the synthesis and release of various chemical mediators through their basal membrane for paracrine cell-to-cell cross-talk with other JGA cell types (5, 7–9). On the whole cell and physiological level, via these features MD cells regulate renal and glomerular hemodynamics via tubuloglomerular feedback and the release of renin from adjacent JG cells (5, 7, 8).

MD cells are thought to communicate with their neighbor JGA cells via humoral mediators released extracellularly through their basolateral cell membrane and the very thin and fragmented basement membrane and in the absence of significant direct physical cell-to-cell contact such as gap junctions (10, 11). Tiny processes of the MD cell basal membrane protruding toward the mesangium have been described earlier based on electron microscopy of fixed kidney specimens (6, 9, 12), including a recent report on the human MD (1). However, the full extent and dynamic features of these basal processes have been unknown due to the complex three-dimensional (3-D) structure of the JGA and inherent limitations in past histology techniques. Recently, new fluorescence imaging techniques and genetic mouse models have been developed that allow cell membrane targeting of highly fluorescent marker proteins (13–15). These approaches have helped to label and visualize fine details of cell membranes including podocyte foot processes (16) and in vivo approaches (17) using optical microscopy.

The purpose of the present study was to visually characterize and analyze the morphological and dynamic features of MD cell microanatomy using novel fluorescence imaging tools, with particular emphasis on the critically important but most inaccessible basal cell processes.

MATERIALS AND METHODS

Animals and Kidney Tissues

All animal protocols were approved by the Institutional Animal Care and Use Committee of the University of Southern California. Male and female, 6- to 8-wk–old C57BL6/J mice (Jackson Laboratory, Bar Harbor, ME) were used in all experiments. Tamoxifen-inducible, conditional MD-green fluorescent protein (GFP) mice on the C57BL6/J background were generated by intercrossing neuronal nitric oxide synthase (nNOS)/CreERT2 and mTmG/fl mice as previously described (both from Jackson Laboratory) (15). The mTmG reporter mice contain a myristoylated and palmitoylated 41-amino acid NH₂-terminal myristoylated alanine-rich C-kinase substrate (MARCKS) membrane tag for efficient membrane targeting as described before (18). Tamoxifen was administered 75 mg/kg by oral gavage only once for partial induction and for a total of three times (every other day) for full induction. Some mice received a low-salt diet for 10 to 14 days (TD 90228, Harlan Teklad, Madison, WI) combined with angiotensin-converting enzyme (ACE) inhibitor treatment using enalapril (150 mg/L via drinking water, purchased from Sigma, St. Louis, MO) or a high-salt diet (4% NaCl, TD110078, Harlan Teklad). For immunohistochemical analysis, anonymized, human adult (32–87 years old) formalin-fixed paraffin-embedded renal cortical tissues were obtained from unaffected regions of tumor nephrectomy specimens (HS-15-00298 and HS-16-00378 protocols approved by the Institutional Review Board, Keck School of Medicine of the University of Southern California). Basic patient history data regarding the presence of chronic kidney disease (CKD) and comorbidities, such as hypertension and diabetes, were available. Only samples with no history of CKD and diabetes were included in this study. For serial block face scanning electron microscopy, human kidney tissue was obtained with appropriate consent and after review by United Kingdom research ethics committee (study approval 07/H0102/45) in accordance with United Kingdom legislation and the Helsinki Declaration.

Immunohistochemistry of Fixed Kidney Tissue

Immunofluorescence detection of proteins was performed as previously described (15). Briefly, kidneys were perfused and fixed in 4% paraformaldehyde for 2 h at room temperature, embedded in paraffin, and sectioned to 8 µm thickness. For antibody stains, slides were washed in 1× PBS. For antigen retrieval, heat-induced epitope retrieval was applied by boiling sections in sodium citrate buffer (pH 6.0) or Tris-EDTA (pH 9.0) for 10 min. To reduce non-specific binding, sections were blocked with normal goat serum (1:20). Primary and secondary antibodies were applied sequentially overnight at 4°C and 2 h at room temperature. Primary antibodies and dilutions were as follows: nNOS (Santa Cruz Biotechnology, Santa Cruz, CA, 1:100), α-tubulin and pregnancy-associated plasma protein A2 (PAPPA2; ThermoFisher Scientific, Waltham, MA, 1:100), renin (AS-54371, AnaSpec, 1:100), and GFP (ThermoFisher, 1:200). Alexa Fluor 488-, 594-, and 647-conjugated secondary antibodies and Alexa Fluor 680-phalloidin were purchased from ThermoFisher Scientific. In some experiments, the primary PAPPA2 antibody was preincubated with the immunizing (blocking) peptide per the manufacturer’s instructions (ThermoFisher Scientific). Slides were mounted by using DAPI-containing mounting media (VectaShield, Vector Laboratories, Burlingame, CA). The immunohistochemistry images for actin-associated proteins Rho guanine nucleotide exchange factor 25 (ARHGEF25) and actin-related protein 2/3 complex subunit 1 A (ARPC1A) as well as cilia and flagella-associated protein 36 (CFAP36) and intraflagellar transport (IFT)-associated protein (IFT43) were obtained from the Human Protein Atlas (http://www.proteinatlas.org) that were obtained with antibodies that have not been fully validated in the current study (19).

For structural analysis of MD cell major processes, 20-µm-thick frozen sections and endogenously expressed genetic reporter (GFP) imaging were used. Sections were washed in PBS and mounted with DAPI-containing mounting media. High spatial resolution Z-stack recordings and maximum intensity projection images (MIP) were used to measure the length of basal cell processes. Only superficial cortical nephrons were selected, and the longest process per individual MD cell was included in the blind morphometric analysis. The sections were identified by animal number only rather than by experimental groups, which were unknown to the examiner. Sections were examined with Leica TCS SP5 and SP8 DIVE (Leica Microsystems, Wetzlar, Germany) confocal/multiphoton laser scanning microscope systems as described previously (15, 20, 21). Imaris 9.2 image analysis software was used for 3-D reconstruction modeling.

Multiphoton Microscopy of Live MD Cells In Vivo and In Vitro

MD-GFP mice were anesthetized and intravital imaging of the intact living kidney was performed using a Leica SP8 DIVE multiphoton microscope (MPM; Leica Microsystems) powered by a Discovery laser system (Coherent, Santa Clara, CA) as described previously (17, 20, 21). For imaging live MD cells in vitro, MD-GFP mice were perfused through the left ventricle with ice-cold PBS, and the kidneys were harvested. Freshly isolated and in vitro microperfused JGA preparations from superficial cortical nephrons with attached glomeruli were used as described before (22). For the isolation of single live MD cells, the kidney cortex was isolated and digested using hyaluronidase and liberase enzyme combination (concentrations of 2 and 2.5 mg/mL, respectively, from Sigma). After digestion, MD and control cells were isolated based on their genetic reporter expression (GFP or tdTomato) using a FACS ARIAII cell sorter at 4°C and excitation wavelengths of 488 and 633 nm in sterile conditions. Subsequently, the freshly isolated single living MD cells were immediately transferred to a glass coverslip-bottomed chamber and bathed in culture media (DMEM mixture F-12, pH 7.4) at room temperature and no-flow conditions. High temporal and spatial resolution fluorescence imaging was performed to visualize the microanatomical features as described before (15, 22) using a Leica TCS SP5 multiphoton confocal laser scanning microscope system (Leica Microsystems). Z-stack recordings and MIP images of single MD cells were used to identify the number of minor cell processes per cell. Some coverslips with attached MD cells were subsequently processed for paraformaldehyde fixation (at room temperature for 10 min) and immunofluorescence labeling as described above.

Tissue CLARITY

3-D imaging was performed as previously described (23) by carrying out whole-mount immunofluorescence stains on slices of MD-GFP mouse kidneys. Slices were fixed in 4% formaldehyde in 1× phosphate-buffered saline (PBS) at room temperature for 45 min, washed in 1× PBS, blocked in 1× PBS with 0.1% Triton X-100 and 2% SEA Block (Thermo Fisher Scientific) for 1 h, and sequentially incubated in primary and secondary antibodies over 2 days. Primary and secondary antibodies were diluted in the blocking solution. To clear tissue slices, the slices were dehydrated in methanol via increasing concentrations 50%, 75%, and 100%, diluted in PBS (each for 1 h), and subsequently submerged in a 50:50 benzyl benzoate/benzyl alcohol (BABB)-methanol solution followed by 100% BABB. High resolution imaging of MD plaques and the adjacent glomeruli was performed on a Leica SP8 multiphoton microscope using a ×63 glycerol immersion objective (numerical aperture: 1.3). 3-D reconstruction and surface rendering was performed as described previously (24). Briefly, high temporal resolution Z-stack recording of MD plaques (×63 magnification, 0.2-µm Z-step size) was used and processed by Imaris 9 surface rendering technology. To create a 3-D surface defining the morphology of MD cells including the fine details of basal processes, membrane-targeted GFP fluorescence of MD cells was used as the source channel. Using surface rendering, fluorescence thresholding, and masking, the accurate 3-D structure of individual MD plaques and cells was obtained including the number and orientation of major and minor basal cell processes.

Transmission Electron Microscopy

Kidneys were fixed via total body perfusion as previously described (25). Without prior flushing, the animals were directly perfused with 2% glutaraldehyde-PBS (GA-PBS) supplemented with 0.05% citric acid (pH 7.5, 485 mOsmol/L) at a constant pressure of 100 mmHg for 3 min. Kidney slices were postfixed in 2% GA-PBS overnight and in 1% OsO₄ for 2 h and subsequently dehydrated and embedded into epon by standard procedures. Ultrathin sections of selected areas were cut on ultracut microtome (Leica Nußloch) using a diamond knife and studied with transmission electron microscopy (TEM) as previously described (25).

Serial Block Face Scanning Electron Microscopy

Human tissue blocks were prepared from unused transplant kidneys by perfusion fixation combined with additional aqueous heavy metal steps as previously described (26). Briefly, the trimmed mounted block with the region of interest was attached to the chuck and the resin-embedded glomeruli with the adjacent MD were sectioned using a Gatan 3view ultramicrotome within a FEI Quanta 250 scanning electron microscope [serial block face scanning electron microscopy (SBF-SEM)]. Once the surface was imaged, an automatic routine advanced the specimen and sectioned the block face removing a 150-nm-thick resin section. The sequence of advance was repeated until all images were acquired.

Statistical Methods

Data are expressed as averages ± SE and were analyzed using Student’s t tests (between two groups) or ANOVA (for multiple groups) with post hoc comparison by the Bonferroni test. P < 0.05 was considered significant. Statistical analyses were performed using GraphPad Prism 7.0c (GraphPad Software).

RESULTS

Histological Features of the MD-GFP Mouse Model

Using the classic MD cell-specific marker nNOS in a Cre/lox-based genetic strategy, MD-GFP mice were generated by intercrossing nNOS/CreERT2 and mTmG/fl mice as described recently (15). These mice feature MD-specific, tamoxifen-inducible membrane-targeted enhanced GFP (eGFP) expression in the renal cortex, whereas other cell types remain red by expressing the membrane-targeted red fluorescent protein tdTomato (Fig. 1A). To confirm the MD cell-specific, nNOS-driven expression of membrane-targeted eGFP (mG) in MD-GFP mice, immunofluorescence double labeling of nNOS and eGFP was performed (Fig. 1B). The overlay in Fig. 1B shows colabeling of nNOS and eGFP only in MD cells, confirming the validity and specificity of the applied genetic approach.

Figure 1.

Histological features of the macula densa (MD)-green fluorescent protein (GFP) mouse model. A: overview of a MD-GFP mouse kidney section with membrane-targeted enhanced GFP (eGFP) expression in MD cells (green, arrowheads), and membrane-targeted tdTomato expression in all other kidney cell types (red). Nuclei were labeled with DAPI (blue). Note that all green cells were localized directly adjacent to intensely red-labeled glomeruli (G). B: immunofluorescence double labeling of the MD cell marker neuronal nitric oxide synthase (nNOS) (red) and the nNOS-driven eGFP reporter (green). The overlay image shows co-localization (yellow) confirming MD-specific expression of eGFP. C and D: fluorescence images of MD-GFP mouse kidney sections showing longitudinal, horizontal, and cross-sectional views of the MD cell plaque after full (C) or partial (D) induction of eGFP expression by tamoxifen. Some images show tissue autofluorescence (C, blue) for additional morphological detail. Note the fine morphological details of single MD cells that were visible only with partial tamoxifen induction, that include major (arrowhead) and minor cell processes (arrows) at the cell base, projecting toward the glomerulus and other MD cells (D). The dashed circle represents the border of the MD plaque. IA, interlobular arteriole; AA, afferent arteriole. Bars = 20 µm.

Next, tamoxifen dosing was adjusted to alter the level of Cre induction and hence the density of GFP-labeled MD cells in the renal cortex. Fig. 1C shows labeling of the entire MD plaque after full induction (75 mg/kg of tamoxifen via oral gavage given every other day for a total of three times), whereas partial induction (75 mg/kg of tamoxifen via oral gavage only once) led to sporadic MD cell labeling, only 1 to 3 MD cells/plaque on average (Figs. 1D, 2, and 3). As a result of the membrane-targeting genetic fluorescence labeling approach, it became possible to visualize the fine morphological details of MD cell membrane structures, such as the primary cilia at the MD cells’ apical membrane (Fig. 2C). Importantly, the combination of membrane-targeted fluorescence reporter expression with the sporadic labeling of single MD cells enabled the visualization of the microanatomical details of MD cells and depicted an elaborate network of major and minor processes at the cell base, projecting toward the glomerulus and other MD cells (Fig. 1D). We named these structures maculapodia, based on their foot-like projections from the MD cell body at their basal region.

Figure 2.

Representative images and morphological analysis of macula densa (MD) cell major processes. A–E: native fluorescence images of MD plaques from MD-green fluorescent protein (GFP) kidney frozen sections with single, enhanced GFP (eGFP)-labeled MD cells and the adjacent glomerulus (G). Note the increased length of major cell processes (arrowheads) compared to control (A) in conditions of low-salt diet with angiotensin-converting enzyme inhibition (ACEi) (B), but the much shorter length of these structures in high-salt diet (C). Occasionally, the primary cilium of MD cells was visible at the apical membrane (C, arrow). Compared to kidney tissue from male mice (A–C), MD cell major processes were more elaborate in female mice (D–F). F: high magnification maximum projection image of a Z-stack series of optical sections showing a maculapodia network consisting of major (arrowhead) and minor processes (arrows) in a single MD cell (same area magnified as shown in panel E). G: statistical summary showing the alterations in the length of MD cell major processes based on sex and in response to various dietary salt intake conditions (33-100 total data points in each group, n = 4 in all groups, except n = 5 in female low-salt diet with ACEi inhibition). **P < 0.01; ns = not significant compared to control in the same sex group. Comparisons (****P < 0.0001) between male and female sexes of the same salt diet-fed groups are shown by bars. CTRL, control; LS+ACEi, low-salt diet with ACEi; HS, high-salt diet. H: representative image of eGFP-labeled MD cells from a deep juxtamedullary (JM) nephron. Note the presence of major cell processes (arrowheads) similarly to MD cells from superficial cortical nephrons (A–F). Bars = 20 µm.

Morphological Analysis of MD Cell Major Processes

To characterize the size of the cell processes network at the MD cell basal region, morphological analysis was performed first on fixed kidney sections to measure the length of major processes. Major processes were defined as a few primary (projecting directly from the cell body, 1–3 on average) and thick (>0.5–1.0 µm) cytoplasmic protrusions from the MD cell basal region. Histological analysis confirmed that most MD cells under all conditions had visible major cell protrusions at their base running in parallel with the tubular side of the basement membrane or crossing through the fragmented basement membrane toward other MD cells, the extraglomerular mesangium (EGM), the AA, and the EA. In control, the length of major processes was 4.63 ± 0.21 µm on average (n = 8 mice) but was occasionally seen to extend up to 14 µm (Fig. 2, A–G). Interestingly, we found that female mice had significantly longer major processes (5.68 ± 0.32 µm) compared to male littermates (3.76 ± 0.22 µm, P = 0.001, n = 4 each), as shown in Fig. 2, A, D, and G, and Supplemental Video S1 (Supplemental Video S1; all Supplemental Material is available at https://doi.org/10.6084/m9.figshare.11983791.v1). Although only superficial cortical nephrons were included in all morphometric analysis, MD cells in inner cortical (juxtamedullary) nephrons appeared to have similar features (Fig. 2H).

Since tubular salt sensing and paracrine signaling to the JGA are well-known traditional functions of MD cells, we next applied various dietary salt intake manipulations to address the physiological regulation of MD cell microanatomy at the basal region. As shown in representative images and morphological analysis in Fig. 2, A–G, the stimulation of MD cell salt sensing activity by combined low-salt diet and ACE inhibition resulted in the development of a more elaborate maculapodia network in male mice, with a significant increase in the length of major processes (5.01 ± 0.34 µm, P = 0.002; n = 4) (Fig. 2, B and G). In contrast, high dietary sodium intake led to a significant decrease in the length of these structures in both male and female mice (1.94 ± 0.22 µm in male mice and 3.88 ± 0.36 µm in female mice, P = 0.01; n = 4–5) (Fig. 2, C and G). Furthermore, we found that the sex difference in the length of major processes was preserved in the condition of high dietary salt intake, whereas the sex difference disappeared under combined low-salt diet and ACE inhibition conditions due to significant changes in male but not female mice (Fig. 2G).

Intravital Imaging of Maculapodia

To confirm the presence of MD cell major and minor processes in the intact living kidney tissue, low-salt diet and ACE inhibitor-treated MD-GFP mice were used due to the presence of a more elaborate maculapodia network in this condition. We first performed MPM of intact MD-GFP kidneys in vivo. Although motion artifacts due to vital functions made the visualization of minor processes difficult, several major MD cell processes were clearly observed projecting from the MD base into the EGM and toward glomerular arterioles (Fig. 3A). In another approach of imaging intact living tissue, we next used the freshly dissected and in vitro microperfused JGA preparation from MD-GFP mice after partial tamoxifen induction. In contrast to the in vivo model, this was a perfectly steady preparation. Accordingly, both major (0.5–1.0 µm thick and up to 34 µm long) and much thinner, hair-like minor MD cell basal processes were clearly observed forming a dense maculapodia network between individual MD cells and between MD and other JGA cells (Fig. 3B and Supplemental Video 1, see https://doi.org/10.6084/m9.figshare.11983791.v1). Minor processes were seen originating from either the cell body or major processes (Fig. 3B).

Figure 3.

Multiphoton microscope (MPM) imaging of maculapodia in intact living kidney tissues. A and B: representative MPM Z-stack (Supplemental Video S1; see https://doi.org/10.6084/m9.figshare.11983791.v1) projection images of a low-salt diet and angiotensin-converting enzyme inhibitor treated macula densa (MD)-green fluorescent protein (GFP) mouse kidney in vivo (A) and in the freshly isolated and in vitro microperfused juxtaglomerular apparatus preparation (B). Note the MD cell-specific enhanced GFP (eGFP) expression (green) and tdTomato expression in all other kidney cell types (red). Plasma was labeled by albumin-Alexa Fluor 680 (gray) in A. Nuclei were labeled with DAPI (blue) in B. The MD areas were magnified in both panels as indicated with labeling of MD cell major (arrowheads) and minor processes (arrows). Dashed circle represents the border of MD plaque. G, glomerulus; cTAL, cortical thick ascending limb; EA, efferent arteriole; AA, afferent arteriole. Bars = 20 µm.

Quantitative Visualization of Structural and Dynamic Features of MD Cell Minor Processes

Minor processes were defined as long, very thin (<0.5 µm) hair-like cell processes projecting from either the cell body or major processes. To further elucidate their specificity, scale, and dynamic features, living MD cells were freshly isolated from kidney tissue of MD-GFP mice on control and a low-salt diets using FACS and visualized by using high temporal and spatial resolution MPM imaging. As observed in fresh living tissues and histology sections (Figs. 1, 2, and 3), high resolution MPM imaging of single living MD cells depicted a dense network of long, thin, hair-like minor processes (Fig. 4A). No major processes were seen in freshly isolated MD cells. The minor processes were preserved at the cells’ basal region and specific for MD cells based on the absence of such processes in control cells that were adjacent to the MD (Fig. 4B and Supplemental Video S2, see https://doi.org/10.6084/m9.figshare.11983791.v1). In control conditions, MD cells from female mice had a higher number of minor processes (10.3 ± 1.4 per single MD cell) as compared to male littermates (4.8 ± 1.4 per single MD cell, P < 0.05; n = 8–15 MD cells from n = 3 mice in each group) as shown in Fig. 4A, further strengthening the case that female mice have a more detailed maculapodia network. Physiological stimulation of MD cell salt sensing by combined low-salt diet with ACE inhibition resulted in a significantly increased number of MD cell minor processes (14.5 ± 1.3 per single MD cell, n = 47 MD cells from n = 7 mice) as compared to control (8.4 ± 1.1 per single MD cell, n = 23 MD cells from n = 6 mice) (Fig. 4A). This increase was more pronounced in males (12.8 ± 1.5 per single MD cell, n = 29 MD cells from n = 4 mice) as compared to females (17.2 ± 2.1 per single MD cell, n = 18 MD cells from n = 3 mice).

Figure 4.

Representative images of the regulation (A) and structural and dynamic features (B–D) of macula densa (MD) cell minor processes. A: representative images and statistical summary of the long, thin, hair-like minor cell processes of living, enhanced green fluorescent protein (eGFP)-labeled MD cells freshly isolated from male and female animals in control conditions (n = 3 male and female each) or after a combined low-salt diet LS with angiotensin-converting enzyme inhibition (ACEi) (n = 4 male and n = 3 female) as labeled (A). Note the high density of very long MD cell processes in female LS+ACEi image (arrow)(also in Supplemental Video S2; see https://doi.org/10.6084/m9.figshare.11983791.v1). Variability in cell body appearance (presence/absence of dark nuclear region) is due to different Z-planes of optical sections. B: comparison of MD cell (eGFP, green) and control cell (tdTomato, red) membrane structures in freshly isolated single cells or cell groups. Note the presence of numerous long, minor processes in MD cells (green) in a group of 3 cells that remained attached to each other, but not in control (red) cells. Minor processes (arrows) were seen only at basal cell regions, identified based on anatomical considerations and the typical apical location of MD cell nuclei. C: immunofluorescence labeling of α-tubulin (green) and F-actin (red) in freshly isolated and attached MD cells [note the presence of F-actin but not tubulin in minor processes (arrows)] and immunoperoxidase labeling of actin-associated proteins Rho guanine nucleotide exchange factor 25 (ARHGEF25) and actin-related protein 2/3 complex subunit 1 A (ARPC1A), cilia flagella-associated protein 36 (CFAP36), and intraflagellar transport protein 43 (IFT43) showing high level and MD cell-specific expression in human kidney tissue. Magnified insets show labeling at the MD apical (arrowheads) and basal membranes (arrows). Immunoperoxidase images are from the Human Protein Atlas and available for ARHGEF25 (https://images.proteinatlas.org/52016/120419_A_8_5.jpg), ARPC1A (https://images.proteinatlas.org/4334/13143_A_8_5.jpg), CFAP36 (https://images.proteinatlas.org/8994/24077_A_7_5.jpg), and IFT43 (https://images.proteinatlas.org/3438/10487_A_8_5.jpg). D, left: structural and dynamic features of MD cell minor processes including multiple vesicles visible within the processes (arrows, high GFP intensity) in a freshly isolated eGFP-expressing single MD cell (also in Supplemental Video S4; see https://doi.org/10.6084/m9.figshare.11983791.v1). D, middle left: immunofluorescence image of pregnancy-associated plasma protein A2 (PAPPA2) expression in the human kidney showing high level of labeling in MD cells (red) in a vesicular pattern including at basal cell regions (red arrows) (autofluorescence is shown in green, cell nuclei were labeled blue with DAPI) with the inset demonstrating the lack of PAPPA2 immunolabeling after blocking with the immunizing peptide. D, middle right: PAPPA2 immunofluorescence labeling (red) in fixed freshly isolated attached MD cells showing vesicular pattern within cell processes (magnified inset, arrows). D, right: time-lapse imaging of a freshly isolated eGFP-expressing single MD cell showing rapid outgrowth of minor processes (arrow) within 2 min (also in Supplemental Video S3; see https://doi.org/10.6084/m9.figshare.11983791.v1). G: glomerulus; CTRL, control condition. Bars = 10 µm.

Since actin and actin-associated proteins are common molecular building blocks of such cell processes, immunofluorescence labeling of freshly isolated, attached, and fixed MD cells was performed that identified the presence of F-actin but not tubulin within the minor processes (Fig. 4C). In addition, immunoperoxidase labeling of human kidney sections (based on data obtained from the Human Protein Atlas) identified the high level and MD cell-specific basolateral expression of ARHGEF25 and ARPC1A as well as well-known CFAP36 and IFT-associated proteins (e.g., IFT43). Besides the high level of expression of these actin-associated and microtubule proteins at the apical region that correlates with the previously characterized prominent primary cilia in MD cells (1–3, 27) and therefore serves as a positive control, a distinct basolateral expression was also detected, suggesting their role in the structure and vesicular transport system of the MD cell basal processes network (Fig. 4C).

The expression of membrane-targeted eGFP in MD-GFP mice and the MPM imaging approach enabled the high temporal and spatial resolution imaging of both plasma and intracellular membranes. Time-lapse imaging of single MD cells and their minor processes revealed the highly dynamic features of these long cell processes (Fig. 4D), such as their outgrowth or shortening in a few seconds (Fig. 4D and Supplemental Video S3, see https://doi.org/10.6084/m9.figshare.11983791.v1). In addition, multiple cytoplasmic vesicles were visible within minor processes and appeared rapidly moving in both directions between the cell body and their tip, suggesting their role in MD cell endocytosis and secretory functions (Fig. 4D and Supplemental Video S4, see https://doi.org/10.6084/m9.figshare.11983791.v1). To identify the potential cargo of such vesicles, immunostaining of PAPPA2, a known secreted protease that has been used recently as a specific MD-distal tubule marker (28, 29), was performed on human kidney sections and freshly isolated, attached, and fixed MD cells from MD-GFP mice. Fig. 4D shows the high level of expression of PAPPA2 in MD cells in a vesicular pattern within the cell body as well as at basal cell regions in the human kidney and within the cell processes of mouse MD cells (Fig. 4D). To confirm antibody specificity, the PAPPA2 immunolabeling was lost after the primary antibody was preincubated with the immunizing (blocking) peptide (Fig. 4D).

Ultrastructural Analysis of the MD Cell Basal Region by TEM in Multiple Species

TEM was performed to re-evaluate the ultrastructure of the MD basal anatomic region in the rabbit, rat, and human kidney. Besides the well-known unique features of MD cells, such as apically localized nuclei and organelles involved in protein synthetic machinery packed in the basal part of the cell body, these experiments visualized and further confirmed that MD cells have prominent basal cell major and minor processes extending into the EGM. The basal cell protrusions displayed fine ramifications, which seemed to interdigitate (Fig. 5, A–D). Adjacent MD cells were seen interconnected by minor processes both at the basal and lateral membranes (Fig. 5C). The interface between the MD and the EGM in all species studied consisted of areas with many major and minor processes originating from MD cells that were intertwined with each other, partially separated by the fragmented and thin basement membrane material, and seemed to protrude into the EGM (Fig. 5, A–E). SBF-SEM of human MD plaque and the adjacent glomerulus (Fig. 5E) confirmed the presence of a dense network of MD cell processes projecting into the EGM in close proximity to the efferent arteriole (Fig. 5E).

Figure 5.

Transmission electron microscopy (A−D) and serial block-face scanning electron microscopy (E) images of the macula densa (MD) cell basal region ultrastructure in the rabbit (A and B), rat (C and D), and human kidney (E). A: overview of a rabbit MD plaque. The profile of eight MD cells can be distinguished based on the presence of apical tight junctions (5 of these cells have visible cell nuclei). The lateral intercellular spaces are expanded. The interface to the extraglomerular mesangium (EGM) displays processes from MD cells that appear to protrude into the area. One of the MD cells with a prominent basal major process is highlighted in yellow. Other basal major and minor processes that seem to interdigitate with each other and cannot be clearly assigned to a certain cell are marked by red arrows. B: the cell with its prominent major process shown in A (yellow) is enlarged showing that from the trunk of the major process many fine ramifications (minor processes) emerge. Such processes may contain dark staining vesicles (red arrow). C: slightly tangential section through the MD and the EGM of a rat kidney. The lateral intercellular spaces are expanded. MD cells are interconnected by minor processes (arrows, magnified in inset). The interface between the MD and EGM consists of an area with many cell processes of MD cells that are intertwined with each other (partially separated by basement membrane material) and seem to protrude into the EGM. D: cross-section of a MD plaque in a rat kidney shows the extensive MD basal cell major and minor processes network. The MD basal processes are crossing the fragmented basement membrane (black arrows) and protruding into the EGM. The magnified inset shows the tangential and cross sections of minor processes that contain several vesicles of variable density (red arrows). E: overview of a MD and adjacent EGM region in a human kidney. Several MD cells can be distinguished. The lateral intercellular spaces are expanded. MD cells appear to have a high density of basal cell processes (arrows) running toward the EGM as well as to the branching EA. EA, efferent arteriole. Bars = 10 µm.

3-D Reconstruction of the MD Cell Basal Processes (Maculapodia) Network

To visualize the 3-D structural features of mouse MD cells’s basal region, MPM optical slicing was performed on immunofluorescence labeled whole kidney tissues of MD-GFP mice that were optically cleared using BABB CLARITY. Specifically, our focus was the features of the basal cell region and orientation, relative to the adjacent glomerulus, EGM, AA, and EA. High-resolution optical slices clearly depicted the intercellular network of MD cell basal major and minor processes as shown in Fig. 6, A–C. The reconstruction of MD cell basal cell membrane features in 3-D confirmed the presence of cell-to-cell contacts between individual MD cells via major and minor processes within the same MD plaque (Fig. 6, A and C). In addition, MD cell major and minor processes were detected projecting into the EGM at the glomerular vascular pole and closely wrapping around individual cells of the AA and EA (Fig. 6, A and C, and Supplemental Video S5, see https://doi.org/10.6084/m9.figshare.11983791.v1). To study the 3-D spatial relationship of MD cell processes and renin cells in the JGA, double labeling of MD cells and JG renin cells was performed on thick frozen sections of MD-GFP mouse kidney tissue. High spatial resolution Z-stack projection images were generated by using 3-D surface rendering model. The results shown in Fig. 6C further confirmed the presence of a dense network of MD cell minor processes extending up to 30 µm long (Fig. 6C) toward the individual cells of the AA, EA, and surrounding EGM. Target cells that MD cells were making contact with via the major and minor processes included, but were not limited to, JG renin cells of the AA and EA (Fig. 6C and Supplemental Video S6, see https://doi.org/10.6084/m9.figshare.11983791.v1).

Figure 6.

Visualization of macula densa (MD) cell basal major and minor processes in 3-D in the MD-green fluorescent protein (GFP) mouse kidney. Reconstruction of a MD plaque and the adjacent glomerulus, afferent arterioles (AA), and efferent arterioles (EA) in 3-D from a female MD-GFP mouse receiving a low-salt diet and angiotensin-converting enzyme inhibition. A: whole-mount immunofluorescence labeling of optically cleared mouse kidney tissue using CLARITY. MD cells were identified with GFP labeling (green), and the basement membrane was labeled with collagen type IV immunostaining (magenta). Cell nuclei were labeled with DAPI (blue). 3-D surface rendering revealed the network of MD cell basal major and minor processes running toward the extraglomerular mesangium (EGM), AA, and EA (arrows). B and C: immunofluorescence labeling and optical sectioning of 20-µm-thick frozen sections of a MD-GFP mouse kidney. Three MD cells (MD1-3) were labeled by the endogenous, membrane-targeted eGFP (green), and juxtaglomerular renin cells were visualized by renin immunolabeling (magenta). Z-stack maximum intensity projection image of the vascular pole of a glomerulus including the AA and EA and between the MD (B). C: 3-D reconstruction with surface rendering analysis of the same xyz image as shown in B. The smooth enhanced GFP-positive areas are the 3 MD cells’ apical surfaces (arrows). A surface rendering model enabled the visualization of the fine details of the dense MD cell basal processes network and the anatomical orientation of the basal cell major and minor processes of MD cells (arrowheads) relative to the EGM, AA and EA. Note the dense network of MD cell minor processes and their long extensions (up to 30 µm) projecting toward renin-labeled (magenta) individual cells of the AA and EA as well as toward renin-negative cells of the EGM. Bar = 10 µm for all images.

DISCUSSION

The present study provided an unprecedented detailed view and comprehensive morphological analysis of the microanatomical features of the unique specialized renal epithelium of the MD, by taking advantage of recent developments in imaging, transgenic mice, tissue processing, and clearing technologies. Genetic labeling of single MD cells in MD-GFP mouse kidneys, and their high resolution MPM imaging in vivo, in vitro, in fixed thick sections, and after the fresh isolation of living MD cells uniformly found an elaborate network of major and minor processes at the cell base, projecting toward the glomerulus and other MD cells. Here we named these structures maculapodia, based on their foot-like appearance and projections from the base of the MD cell body. The extent of these basal cell processes showed regulation by dietary salt intake and sex specificity. Time-lapse imaging of MD minor processes revealed their highly dynamic features including rapid outgrowth and an extensive, including secretory vesicular transport system within these processes. Electron microscopy analysis in multiple species (rat, rabbit, human) and 3-D image reconstruction of the JGA volume in optically cleared whole mount MD-GFP mouse kidneys further confirmed the presence of MD cell major and minor basal processes projecting into the EGM at the glomerular vascular pole and the AA and EA. The highly elaborate network and physiological regulation of maculapodia, which contain various vesicles with secretory cargo (including PAPPA2), are all novel findings in this study, which uncovered new anatomic and functional pathways of JGA intercellular communication.

Our results confirmed the well-known microanatomical details of MD cells that have been shown before with TEM and conventional histology approaches. Previous studies revealed the polarized nature of MD epithelium with specific features including the presence of long, apical primary cilium (Fig. 2C) (1–3, 27), dilated intercellular spaces (Fig. 5) (25, 30), and unique basal protrusions containing vesicles (Figs. 1, 2, 3, 4, and 5)(1, 4, 25, 31). Although the presence of MD cell basal processes has been described in these earlier reports, in light of the present findings it appears that the highly extensive nature of these structures has been previously unrecognized or understated. This was likely due to the lack of techniques to study living MD cells and the inherent technical limitations of TEM to accurately identify the cellular origin and complex 3-D structure of these long, interdigitating major and minor processes within the densely packed tissue of the JGA. Of note, it is well established that MD cells do not form gap junctions with other cells of the JGA (11, 22), although the importance of intercellular communications in this region is well known. Therefore, the dense network of MD cell processes and vesicle-containing long (up to 30–50 µm, Figs. 3B, 4, A–D, and 6C) maculapodia that the present study visualized projecting toward other MD cells and the glomerular vascular pole in close contact with cells of the mesangium, AA, and EA (Fig. 6, A–C) may be key ultrastructural elements of MD-to-JGA cell communications.

The exceptional detailed view of the MD microanatomic structure shown in the present study was made possible by the use of a recently established MD-GFP-inducible fluorescent reporter mouse model (15) in which MD cells were specifically labeled by a high level of membrane-targeted GFP expression. Partial tamoxifen induction in MD-GFP mice enabled the visualization of single MD cells within the multi-cell MD plaque, revealing the fine details of MD cell basolateral features, especially the major and minor cell processes running between individual MD cells (Figs. 1, 2, 3, and 4). This detailed view is lost when all MD cells within the MD plaque are highly fluorescent (Fig. 1, C and D), which necessitated the presently used single cell labeling approach similarly to that in a recent podocyte study (16). Additional technical novelties in the present study were the high spatial and temporal resolution MPM imaging of intact living MD-GFP mouse kidney tissues in vivo and in vitro (Fig. 3, A and B), in freshly isolated live single MD cells (Fig. 4), and the use of 3-D reconstruction models (Fig. 6). These approaches confirmed that all MD cells under all conditions have major and minor processes; however, these structures were not always clearly visible in thin tissue sections due to their intertwined, complex 3-D morphology (Fig. 6A). Therefore, due to this inherent limitation of conventional thin tissue sections, the length rather than the number (density) of the longest major processes were clearly visualized and analyzed (Fig. 2G).

Since most MD cell minor processes are tightly packed in the tiny extracellular space at the base of MD cells (Fig. 5D), they were best viewed in isolated single cells (Fig. 4). The membrane labeling in MD cells by targeted GFP expression enabled the visualization of both the plasma (cell processes) and intracellular membranes (vesicles). An additional benefit of this approach combined with live cell imaging was to gain new knowledge of the dynamics of MD processes, such as rapid outgrowth and profound vesicular transport, suggesting their role in MD cell secretory functions in JGA cell-to-cell communications (Fig. 4D and Supplemental Videos S3 and S4, see https://doi.org/10.6084/m9.figshare.11983791.v1). Despite these advantages of using freshly isolated MD cells, it should be noted that the observed features of MD cell minor processes may not be representative of the in vivo behavior of MD cells and may, at least in part, result from the cells’ adaptation to in vitro culture conditions. In contrast to MD cells in the intact tissue (Fig. 1), no major processes were seen in freshly isolated MD cells (Fig. 4) likely due to remodeling of the actin cytoskeleton. In addition, whereas MD cell major processes showed no further expansion by dietary salt in female mice (Fig. 2, D–G), the number of MD cell minor processes from female mice increased in response to low salt conditions (Fig. 4A). Nevertheless, the presence of minor processes was confirmed in intact living MD cells (Figs. 2 and 3) suggesting that these structures are not artifacts due to in vitro culturing. If their ability of rapid outgrowth as demonstrated here (Fig. 4D and Supplemental Video S3; see https://doi.org/10.6084/m9.figshare.11983791.v1) is preserved in situ (which needs to be confirmed in future work), this would suggest that MD cells can quickly form new connections with other JGA cells.

As suggested in a recent report (1) and present TEM results (Fig. 5, B and D), the dense-core vesicles described in the MD basal processes are likely secretory in nature and may contain a diverse cargo. To identify at least one element of the cargo, we performed immunolabeling for PAPPA2, a known secreted protein and local regulator of insulin-like growth factor (IGF) bioavailability that was localized to the cortical thick ascending limb-distal tubule region in recent reports (28, 29). The expression of PAPPA2 in MD cells including within cell processes in a vesicular pattern (Fig. 4D) is further strengthening the secretory role of MD cells in cell-to-cell communication. The role and target JGA cell type of PAPPA2 needs further investigation. Similarly, the molecular building blocks of maculapodia, including the presence of actin (Fig. 4C) and actin-associated and microtubule proteins, beyond ARHGEF25, ARPC1A, CFAP36, and ITF43 that were localized to MD cells based on data from the Human Protein Atlas (not validated in the current work) (Fig. 4C) need to be identified in future studies.

Since the maculapodia network is very likely involved in MD-to-JGA effector cell communication, the presently observed upregulation of the length and density of these structures by low dietary salt intake (Figs. 2 and 4) may be a structural component of the well-known physiological adaptations in the classic function of MD, namely higher sensitivity of tubuloglomerular feedback control of renal and glomerular hemodynamics, and increased renin secretion under low-salt diet conditions (7, 32–34). Interestingly, the female sex was another stimulatory factor of both major and minor MD cell processes (Figs. 2G and 4A). Although the density of minor processes was up regulated by both female sex and low-salt diet and ACE inhibitor treatment (additive effect, Fig. 4A), the length of major processes in control female mice increased to the level of low salt-stimulated conditions and did not further increase with low-salt diet and ACE inhibition (Fig. 2G). These results may suggest that the low salt and female regulatory mechanisms likely utilize similar signaling pathways for the control of major but not minor processes. The sex difference in the length of major processes was preserved in the condition of high dietary salt intake, which had a significant negative effect in both males and females (Fig. 2G). Sex differences identified in these experiments further support the notion that in addition to several other kidney functions and mechanisms (35), JGA function is regulated by male and female sex hormones as suggested by previous reports (36, 37). Considering the strategically central localization of MD cells at the glomerular entrance and the key role these cells play in sensing alterations in the tubular environment and transducing signals to regulate glomerular filtration rate and the activity of the renin-angiotensin system in both health and disease, it is intriguing to speculate that the presently described MD microanatomical features may play a role in sex disparities in kidney disease prevalence and progression (35). The functional relevance of maculapodia in controlling glomerular hemodynamics and vasoactivity, including the functions of PAPPA2 and other secreted MD factors on AA and EA renin- producing cells and other, yet to be identified renin-negative JGA target cells (Fig. 6C), needs further study.

In summary, the present study illuminated a physiologically regulated dense network of basal cell major and minor processes (maculapodia) in MD cells that were understated in previous work. The newly identified dynamic and secretory features of these microanatomical structures suggest the presence of novel functional and molecular pathways of cell-to-cell communication in the JGA between the MD and other target cells that need to be further explored in future studies. Detailed characterization of the function and further molecular details of MD cell intercellular communications and their role in physiology and disease warrant further studies.
