Cancerous Tissue Diagnosis by LIF Spectroscopy Derived From Body-Compatible Fluorophores

Abstract

Introduction: The laser-induced fluorescence (LIF) method as molecular emission spectroscopy is used to diagnose cancerous tissues. According to the previous reports, the red-shift in the fluorescence spectrum from Rhodamine 6G (Rd6G)-stained cancerous tissues compared to healthy ones impregnated with the same dye provides the feasibility for diagnosis. In this paper, we have employed the LIF emissions as a diagnostic method to distinguish between cancerous and healthy tissues infiltrated by a body-compatible fluorophore to avoid the toxicity and hazard of Rd6G dye.

Methods: Biological tissue specimens are stained with sodium fluorescein (NaFl) dye and then irradiated by the blue CW diode laser (405 nm) to examine the spectral properties that are effective in detecting cancerous tissues.

Results: The spectral shift and the intensity difference of fluorescence are keys to diagnosing in vitro cancerous breast, colon, and thyroid tissues for clinical applications. The notable tubular densities in the breast and colon tissues and the space between the papillae in the thyroid ones cause the cancerous tissues to be prominently heterogeneous, providing numerous micro-cavities and thus more room for dye molecules.

Conclusion: Here, we have assessed the spectral shift and intensity difference of fluorescence as a diagnostic method to distinguish between cancerous and healthy tissues for clinical applications.

Introduction

Cancer means the growth, proliferation, and sometimes abnormal release of body cells. All such diseases have an unbridled growth pattern and tend to detach from the source and metastasis.¹ The prevalence of breast cancer is about one-third of all cancers in women, and it is the most common cause of cancer mortality among women, which significant efforts have been done to diagnose and treat it in a timely manner. Standard methods for diagnosing or preventing breast cancer include x-ray mammography, ultrasonography, magnetic resonance imaging, and positron emission tomography.² Biopsies are usually performed routinely after diagnosing a lesion by various clinical breast examinations. Then the biopsied tissue is fixed in the histology laboratory and stained with special dyes for pathological studies.³ Besides, rapid, quantitative, and non-invasive diagnostic methods based on fluorescence spectroscopy, as a link of morphological and biochemical properties of tissues, can be an essential step in the diagnosis and treatment of cancer.⁴ The development of malignancies, in addition to metabolic and structural changes in cell and subcellular levels, can also affect the optical properties of tissue, such as dispersion, absorption, and fluorescence. Therefore, optical spectroscopy contains useful information for the diagnosis of cancerous tumors and is also a promising method for in vitro and in vivo studies of tissues as well as blood. The laser is used as non-ionized coherent radiation to detect the optical properties of soft tissues.^5,6

In laser-induced fluorescence (LIF) spectroscopy, visible or ultraviolet light is used to stimulate the molecules of the sample. Photons are absorbed in molecular transitions due to Stokes shift (the difference between the maximum absorption line and the fluorescence radiation ) re-emission at longer wavelengths.⁵ Palmer et al⁷ have evaluated auto-fluorescence spectra derived from healthy and cancerous breast cells and have shown significant differences in their fluorescence properties. According to this report, the cancerous cells gain several receptors as a distinguishable characteristic, unlike healthy cells. Also, and Elshemey⁸ used a 266 nm diode laser to stimulate healthy, benign, and malignant tissues and produce auto-fluorescence radiation. It presents differences such as the parameters of the sub-peak range of the fluorescence spectrum and its moderate intensity to distinguish between tissues. Ghasemi et al⁹ used LIF spectroscopy to measure the spectral displacement from stained breast tissue with Rhodamine 6G (Rd6G) to distinguish between healthy and cancerous tissues. They have shown that the fluorescence spectrum derived from cancerous tissues compared to healthy ones move to the longer wavelengths.

In previous reports, tissue samples have been examined by LIF, either by auto-fluorescence or by chemical and toxic Rd6G fluorophores. Braginskaja et al¹⁰ have also used LIF spectroscopy by injection sodium fluorescein (NaFl) dye into rats to diagnose gastric cancer. They showed that in all cases, due to penetration and the selective accumulation of NaFl in the tumor, the fluorescence intensity in the tumor stomach tissues was higher than that in the adjacent normal one. In this paper, the spectral shift and the intensity difference of fluorescence were assessed as a diagnostic criterion to detect in vitro cancerous breast, colon, and thyroid tissues for clinical applications. In vitro diagnosis of healthy and malignant tissues using the body-compatible dye through LIF spectroscopy was the purpose of this study.

For the fluorescence diagnosis of human malignancy, NaFl is permitted and recommended for its high specificity to the tumor.¹¹

Materials and Methods

Preparation of Samples and Solutions

Healthy and cancerous in vitro formalin breast, colon, and thyroid tissue samples were investigated in the laboratory. Normal and cancerous tissues were examined from 30 patients affected by three types of cancer—breast, colon, and thyroid. More than 10 healthy and 10 cancerous samples of each kind of tissue were fixed after surgery or biopsy and then cut into pieces (5 ×3 ×2 mm³).

Before the LIF spectroscopy examination, the samples were immersed in an optimum concentration (1 mM) of a NaFl solution in ethanol solvent for 3 hours and then exposed to a laser beam. NaFl is a non-toxic and body-compatible dye in low doses, with a high quantum yield (0.88) and C₂₀H₁₀Na₂O₅ chemical formula. Unlike healthy breast tissue, which has a high percentage of fat and a yellow appearance, cancerous tissues are stiff and white. The samples are cut into slices with micron size, using a microtome, and then placed on a slide. An optical microscope is also employed to image the paraffin-embedded tissues.

Experimental Array

A blue CW diode laser at a 405 nm wavelength and 150 mW power (MLPH-Ⅲ model/Noor Sanate Pars company) is utilized as an irradiation source to excite the NaFl fluorophores. The LIF emission from the sample was collected by a fiber bundle UV 600 (core)/660 (cladding) type with an SMA-905 fiber connector having NA 0.22 and 1 m lengths. The fiber output was coupled to the entrance site of a Phystec miniature spectrometer (UVS 2500; Pooyesh Tadbir Karaneh company) over the wavelength range of 200-800 nm with 0.1 nm resolution. Figure 1 illustrates the arrangement for LIF experiments.

Figure 1.

The Schematic of LIF Set-up for the NaFl-Stained Tissues.

Results

First, NaFl solution was prepared in ethanol solvent at various concentrations and exposed to 405 nm diode laser radiation to obtain the optimal fluorescence conditions.Figure 2 shows the LIF spectrum of NaFl solutions at different concentrations of 0.1-10 mM to find the optimum conditions.

Figure 2.

The LIF Emission Spectrum of NaFl Dye at Various Concentrations of 0.1 up to 10 mM of Solvent.

The fluorescence signal is intensified due to the larger population of molecular transitions. In contrast, the decrease in amplitude arises from static/dynamic quenching, including self-quenching, collisional effects, and the aggregation of monomers to dimers.¹² So, as shown in Figure 2, the signal magnitude lucidly rises versus the solution concentration (up to 1 mM), and after that, it decreases with increasing the solution concentration due to the increasing collision effects and Forster resonance energy transfer (K_t) as well as the increase of self-quenching.^13-15 Therefore, the optimum dose of 1 mM of solution concentrations is considered for staining biological tissues.

Moreover, a significant red-shift took place in the emission by increasing the NaFl concentration, due to the more re-absorption and re-emission of photons in the specimen. Figure 3 illustrates the variation of intensity and the spectral red-shift (∆) of emission relative to the absorption versus the NaFl solution concentration.

Figure 3.

The Intensity (Left Axis) and the Spectral Shift (Right Axis) Between the Absorption and the Emission Spectra at Various Concentrations of NaFl Dye.

According to the results, the cut samples of healthy and cancerous breast tissues (Invasive Ductal Carcinoma) were placed in a 1mM concentration of dye solution for three hours. After that, the NaFl infiltrated tissues were irradiated by a laser to record the LIF emission. Figure 4 represents the typical emission spectra from normal and abnormal tissues taken from a patient. It shows that the cancerous tissues exhibit the spectral shift of 8.55 nm and increased intensity relative to the healthy samples.

Figure 4.

The Typical LIF Spectra Recorded From Normal and Abnormal Breast Samples at a 1mM Concentration of NaFl.

Similar experiments for different breast tissue specimens were carried out to examine the repeatability of spectral displacement and increasing the fluorescence intensity of cancerous tissues relative to the healthy ones. Figure 5 illustrates the obtained results to emphasize the red-shift as well as the increased intensity of fluorescence emission of malignant samples.

Figure 5.

The Wavelength of Fluorescence Peak (a) and the Emission Intensity (b) Taken From Four Cancerous Breast Samples Compared to Their Healthy Ones, at 1mM Dye Concentration.

The biological tissues are highly scattering (opaque) environments.¹⁶ Then, the multiple scattering of emitted photons by entering a tissue dispersal environment results in the increasing re-absorption and subsequently red-shift in the irregular and disturbed tumor tissues. Moreover, with abnormal cell proliferation, numerous micro-cavities have formed, resulting from structural changes in tubular architecture.¹⁷ As Figure 6 illustrates, tubular structures are present in the breast tissues, which increases the density and irregularities of the tubules with the increasing tissue malignancy, which means the presence of porosity in tissue.^9,12

Figure 6.

Histological Images of (a) Dye-Stained Normal and (b) Dye-Stained Malignant (Invasive Ductal Carcinoma) Breast Tissues.

The fluorescence radiation spectrum depends on the external factors (such as NaFl) and tissue structure, as a scaffold for fluorophores particles as well as the dye concentration. Therefore, we have also investigated the effect of solution concentration on the spectral red-shift. The healthy and cancerous breast tissue samples were placed in a solution of NaFl in ethanol solvent at concentrations of 0.1, 1, 3, and 10 mM for 3 hours and then exposed to radiation. The spectral red-shift increases with increasing the dye concentration for healthy and cancerous tissues, as shown in Figure 7. There is a maximum spectral displacement of ~10.6 nm in malignant breast tissues compared to healthy ones, at ten mM. In general, the spectral red-shift in malignant tissues results from a high rate of re-absorption.

Figure 7.

The Spectral Displacement of Stained Healthy and Cancerous Breast Tissues With Different Concentrations (0.1, 1, 3, and 10 mM) of NaFl Solutions.

As noted, cancerous breast tissues have a higher density of tubular structures than healthy tissues, which leads to the capture of dye molecules. The tendency of the dye molecule accumulation in the cancerous tissues is mainly due to the high permeability of the damaged cell membranes with respect to the healthy ones.⁵ Therefore, LIF spectra represent a significant red-shift, and the relative shift of cancerous tumors with respect to healthy ones enhances dye concentration. The spectral shift accounts for the high re-absorption rates in a hybrid medium due to the fact that the higher natural abundance of scatterers in the cancerous tissue medium results in the long random walk of scattered photons. Moreover, a large Forster constant (K_t) and the type of chemical bond formed between tissue and the dye molecules, leading to high re-absorption and eventually the sensible spectral shift.^5,12,14

It is worth noting that by repeating the LIF experiments on several samples of colon and thyroid tissues, similar results were obtained to emphasize the LIF as a method to diagnose cancerous tissues. Figure 8 depicts the typical fluorescence emission recorded from normal and abnormal colon and thyroid samples at 1mM concentration of NaFl solution. The specimens of each tissue were taken from one patient. Thus, the pathological (type of malignancy) and even the physical (color) features of healthy and cancerous specimens for each tissue were completely identical. Both LIF signals are more intense and move to the longer wavelengths, which is a marker of the distinction between normal and abnormal tissues and the detection of cancer.

Figure 8.

The Typical LIF Spectra Recorded From Normal and Abnormal: (a) Colon and (b) Thyroid Samples at a 1mM Concentration of NaFl.

Therefore, as shown in Figure 8, a notable red-shift of 9.1 and 10.2 nm took place in the malignant colon and thyroid tissues compared to the healthy tissues.

The colon tissues were Adenocarcinoma type with the tubular structure.^18,19 Therefore, similar to breast tissue samples, it can be stated that the density and irregularity of tubules have increased in cancerous colon tissues compared to healthy specimens (Figure 9).

Figure 9.

Histological Images of (a) Normal Dye-Stained and (b) Malignant Dye-Stained Colon Tissues (Adenocarcinoma).

As shown in Figure 10, this difference in the tubular structure of Adenocarcinoma tissues compared to healthy ones increased the intensity and red-shift for their spectra.

Figure 10.

The Wavelength (a) and the Intensity (b) of Fluorescence Peak Taken From Four Cancerous Colon Samples Compared to Their Healthy Ones, at 1mM Dye Concentration.

Also, as the type of thyroid cancer tissues in this paper was papillary thyroid carcinoma, therefore, according to Figure 11, the space between the papillae in the cancerous tissues increased compared to the normal ones. Given that the density of the space between the papillae is different from that of the cell regions, colloidal matter is located in this space, which contains thyroid hormones. Given that the space between the papillae is completely different from the cellular areas in terms of density and it contains the colloidal material, which contains thyroid hormones and also lacks cells.

Figure 11.

Histological Images of (a) Dye-Stained Normal and (b) Malignant (Papillary Thyroid Carcinoma) Tissues.

The space between the papillae in thyroid samples plays a similar role in tubular structures in breast and colon tissues. Therefore, increasing this space in papillary thyroid carcinoma tissues compared to healthy specimens can cause the red-shift and increase the intensity of the fluorescence spectrum for these cancerous tissues, as shown in Figure 12.

Figure 12.

The Wavelength (a) and the Intensity (b) of Fluorescence Peak Taken From Four Cancerous Thyroid Tissues Compared to Their Healthy Ones, at 1mM Dye Concentration.

Discussion

The LIF spectrum taken from stained-NaFl tissues contains valuable information to distinguish between normal and abnormal samples based on the accumulation and behavior of a body-compatible non-toxicity fluorophore.

The micro-partitioning structure of the cancerous tissues decelerates the rate of aggregation processes such that the micro-cavities do trap further fluorophore molecules. This indicates the notable reduction of the self-quenching events. Therefore, by capturing fluorophore molecules, they cause increasing the distance between them and ultimately reduce aggregation and suppression. It leads to an increased fluorescence radiation intensity in cancerous tissues compared with the healthy ones.^9,12,14 These results agree with previous reports^5,9 about increasing the emission intensity and spectral displacement of stained-Rd6G cancerous tumor samples relative to healthy tissues.

Also, it is worth mentioning that the used samples in this work are epithelial tissues whose basement membrane is under the epithelial cells. The fluorophore particles penetrate the basal-lateral tissue membrane due to the specific types of connections between the epithelial cells. Here, the entry and accumulation of dye into space between cells, tubules in the colon, and breast tissues, as well as the space between the papillae in the thyroid tissue, were relevant.

The velocity of the dye particles and their penetration into biological structures are different depending on the size and polarity of a permeable fluorophore.²¹ The penetration rate of smaller molecules such as Rhd-6G is higher for mono-cationic chromophores with smaller species sizes, such as Rd6G, and the penetration time within the tissue is, on average, 30-45 minutes.^9,22 However, for the larger dicationic compounds, such as NaFl, the penetration rate is lower, and consequently, it has a longer penetration time (approximately 3 hours). This expression reflects the differences between the interaction of rhodamine and fluorescein with the cells.

Conclusion

Here, we have assessed the spectral shift and intensity difference of fluorescence as a diagnostic method to distinguish between cancerous and healthy tissues for clinical applications. The least invasive LIF method can be developed with the optimal dose of NaFl solution without the need for surgery or biopsy for an in-vivo detection of tumor samples. What distinguishes this research is the use of NaFl as a body-compatible dye at the optimal dosages, rather than toxic ones such as Rhd6G.

Ethical Considerations

Written informed consent was obtained from the patients before the experiments.

Conflict of Interests

The authors declare no conflict of interest.

Please cite this article as follows: Asghari Moghaddam A, Sajad B, Mehrad Nia F, Madani SH. Cancerous tissue diagnosis by lif spectroscopy derived from body-compatible fluorophores. J Lasers Med Sci. 2021;12:e10. doi:10.34172/jlms.2021.10
