Landscape of cell heterogeneity and evolutionary trajectory in ulcerative colitis-associated colon cancer revealed by single-cell RNA sequencing

Abstract

Objective

The goal of this study was to get preliminary insight on the intra-tumor heterogeneity in colitis-associated cancer (CAC) and to reveal a potential evolutionary trajectory from ulcerative colitis (UC) to CAC at the single-cell level.

Methods

Fresh samples of tumor tissues and adjacent UC tissues from a CAC patient with pT3N1M0 stage cancer were examined by single-cell RNA sequencing (scRNA-seq). Data from The Cancer Genome Atlas (TCGA) and The Human Protein Atlas were used to confirm the different expression levels in normal and tumor tissues and to determine their relationships with patient prognosis.

Results

Ultimately, 4,777 single-cell transcriptomes (1,220 genes per cell) were examined, of which 2,250 (47%) and 2,527 (53%) originated from tumor and adjacent UC tissues, respectively. We defined the composition of cancer-associated stromal cells and identified six cell clusters, including myeloid, T and B cells, fibroblasts, endothelial and epithelial cells. Notable pathways and transcription factors involved in these cell clusters were analyzed and described. Moreover, the precise cellular composition and developmental trajectory from UC to UC-associated colon cancer were graphed, and it was predicted that CD74, CLCA1, and DPEP1 played a potential role in disease progression.

Conclusions

scRNA-seq technology revealed intra-tumor cell heterogeneity in UC-associated colon cancer, and might provide a promising direction to identify novel potential therapeutic targets in the evolution from UC to CAC.

Introduction

Colorectal cancer (CRC) is the third most common type of cancer worldwide, and approximately 147,950 new cases and 53,200 deaths were estimated in 2020 in the United States. CRC has been the second most common cause of cancer death, even including 17,930 cases and 3,640 deaths in patients under 50 years of age ( 1). In China, the incidence and mortality of CRC have been on the rise ( 2) and CRC incurs a heavy economic burden on the society and individuals ( 3). Moreover, patients with colitis-associated cancer (CAC), a particular type of CRC that develops from inflammatory bowel diseases (IBDs), have an earlier morbidity and a poorer prognosis ( 4). CAC is often thought to arise from flat dysplasia with indistinct margins, in a field of concomitant inflammation, scarring, and pseudopolyposis, rather than development from a polypoid adenoma, which is the major cause of sporadic CRC ( 5). Furthermore, at the molecular level, the sequence of events leading to CAC is distinct from that of sporadic CRC. A distinct set of genes in sporadic CRC, including TP53 ( 6), APC ( 7), and KRAS ( 8) contains more mutations than genes in CACs. However, the molecular process underlying colorectal carcinogenesis in IBDs is still poorly understood. Ulcerative colitis (UC), the most common form of IBD, has become increasingly prevalent worldwide ( 9). In a previously performed meta-analysis, quantitative estimates of CAC risk in UC patients have been reported to be 2% after 10 years, 8% after 20 years, and 18% after 30 years of disease ( 10), thereby indicating the importance of intensive studies.

In the past, research on tumor origin only targeted the genetic and epigenetic changes of tumor cells. However, over the last 20 years, the tumor micro-environment (TME) has been shown to play an equally important role in cancer development. Intra-tumoral heterogeneity among malignant and non-malignant cells, and their interactions within the TME are critical to tumor initiation, progression, metastasis, and many other diverse aspects of tumor biology ( 11). Accurate TME information not only helps to gain a better understanding of the tumor origin and development, but also contributes to the development of novel therapeutic targets.

In previous studies, genomic and transcriptomic studies have revealed driver mutations, aberrant regulatory programs, and disease subtypes for major human tumors ( 12). However, these studies relied on profiling technologies that measure tumors in bulk, and resulted in data that represent an “average” of all cells present, thereby limiting their ability to capture intra-tumoral heterogeneity. Single-cell sequencing provides an avenue to explore genetic and functional heterogeneity at cellular resolution ( 13). Single-cell RNA sequencing (scRNA-seq) combined with computational methods for functional clustering of cell types provides a less biased approach to the understanding of cellular heterogeneity. ScRNA-seq has been used in many studies involving human tumors ( 14), circulating tumor cells ( 15), and patient-derived xenografts ( 16), and has exhibited its unique predominance in studies of tumor composition, genomic evolution, cancer stem cells, tumor metastasis, and drug resistance. Here, we used scRNA-seq to generate phylogenetic trees and determined the evolutionary process of UC-associated colon cancer. To our knowledge, this is the first study depicting the cellular landscape of TME in UC-associated colon cancer at the single-cell transcriptome level.

Materials and methods

Human specimen collection

Fresh tumor tissues and non-malignant tissues (adjacent UC tissues) were taken from a 43-year-old female patient with UC-related colon adenocarcinoma who had a history of UC for eight years. The postoperative pathology was classified as pT3N1M0 (IIIB stage), which was defined as median differentiation ulcerative adenocarcinoma and microsatellite stability. Written informed consent was provided by the patient. This study was approved by the Research and Ethical Committee of Peking University People’s Hospital and complied with all relevant ethical regulations. Following surgical resection, a tumor tissue sample and a non-malignant colon tissue sample, which was at least 5 cm away from the neoplastic foci were obtained ( Supplementary Figure S1 ).

Figure S1.

A tumor tissue sample and a non-malignant colon tissue sample (>5 cm away from the neoplastic foci) were obtained following surgical resection. N, non-malignant colon tissue; T, tumor tissue.

Protocols of scRNA-seq and data quality control

Protocols for the preparation of single-cell suspensions, droplet-based scRNA-seq, and other methods related to single-cell analysis, are described in Supplementary Materials. Single cells were filtered for further analysis based upon the criteria, cells that had either fewer than 201 unique molecular identifiers (UMIs), over 6,000 or under 101 expressed genes, or over 10% UMIs derived from the mitochondrial genome were excluded. Gene expression (in UMI) was normalized for scale and transformed in log2 (UMI+1).

Principle component analysis (PCA) and t-distributed stochastic neighbor embedding (tSNE)

PCA was used to summarize the resulting variably expressed genes to reduce the dimensionality of this data set. tSNE was applied to recalculate the sample distance by the conditional probability of random neighbor fitting based on Student’s t-distribution in high dimensional space, which was further conducted for the above principle components dimensionality reduction via the default settings of the Run tSNE function, in order that sample presents a clearly separated cluster in a low dimensional space.

Pathway and functional annotation analysis

Kyoto Encyclopedia of Genes and Genomes (KEGG) is a database resource for understanding high-level functions and effects of the biological system ( http://www.genome.jp/kegg/), and performed via DAVID ( https://david.ncifcrf.gov/). Enriched pathways with a Q value ≤0.05 were considered significantly different, like the functional annotation through the Gene Ontology database, for which the Fisher’s exact test was used to select only significant categories including biological process, cellular components, and molecular function classifications. Q value ≤0.05 was considered significantly different.

Gene prognostic performance in The Cancer Genome Atlas (TCGA) data

To evaluate the role of cell type in a larger compendium of tumors, we assessed their expression in bulk RNA-seq data from the TCGA ( http://www.cbioportal.org/). Specifically, we downloaded preprocessed gene expression data as well as clinical data for primary solid tumors and normal solid tissues for colon and rectal adenocarcinoma using the Bioconductor TCGA biolinks package ( http://www.bioconductor.org/). A total of 598 CRC samples were included and divided into high- and low-expression groups based on median gene expression level. Z scores from the TCGA and the validation cohort were combined using the weighted Z method. For Kaplan-Meier analysis, marker gene expression categorization was optimized.

Immunohistochemical (IHC) staining in The Human Protein Atlas

To confirm the expression change in these genes along with disease progression, IHC staining was used for assessment of the different expression level of a specific gene between normal and tumor tissues from The Human Protein Atlas ( https://www.proteinatlas.org/).

Results

scRNA-seq and cell typing of non-malignant and CAC tissues

Fresh tumor and non-malignant tissues were taken from a 43-year-old Chinese female patient with colon adenocarcinoma classified as pT3N1M0, and this patient had been diagnosed with UC for 8 years. Once non-malignant and CAC tissues were obtained ( Supplementary Figure S1 ), it was rapidly digested to a single-cell suspension and analyzed using scRNA-seq involving a single-tube protocol with unique transcript counting through barcoding with UMIs ( Figure 1A ). To obtain detailed cellular genetic information on this tumor, over 1.6 billion post-normalization reads were performed for subsequent analysis, which were obtained from 4,777 cells; a median of 1,220 genes per cell were expressed. Of the sample cells, 2,250 (47%) originated from tumor tissues and 2,527 (53%) originated from non-malignant tissues ( Figure 1B ). Following gene expression normalization for read depth and mitochondrial read count, PCA was applied to genes that were variably expressed across all 4,777 cells (n=1,220 genes). Subsequently, cells were classified by cell type using graph-based clustering on the informative principle components (n=12). This approach identified cell clusters that, through marker genes, could be readily assigned to known cell lineages. In addition to cancer cells, myeloid cells, T cells, B cells, fibroblasts, endothelial cells and epithelial cells were identified ( Figure 1B , C , Supplementary Table S1 ). The transcript analysis showed that these cells differed considerably in transcriptional activity, either between different cell types or between regions of the same type. This approach also distinguished the sample origin and numbers between diverse subgroups ( Figure 1D ).

Figure 1.

scRNA-seq and cell typing of non-malignant and CAC tissues. (A) Overview of the study design; (B) tSNE of the 4,777 cells profiled here, color-coded by (left to right) cell type, sample origin (tumor or non-malignant tissue) and transcripts counts detected in that cell (log scale as defined in the inset); (C) Expression of marker genes for cell types defined above each panel. In addition to cancer cells, we identified myeloid cells, T cells, B cells, fibroblasts, endothelial cells and epithelial cells; (D) For each of the cell subclusters (left to right): fractions of original cells, and number of cells. scRNA-seq, single-cell RNA sequencing; CAC, colitis-associated cancer; tSNE, t-distributed stochastic neighbor embedding; UMI, unique molecular identifier.

Table S1. Maker genes for cell types and subclusters.

Cluster/subsets	Annotated name	Cells (N)	Tumor cells [n (%)]	Maker genes	Full spelling of abbreviation
CAF, cancer associated fibroblast.
Endothelial cells-1	Vascular endothelial cells	66	50 (75.76)	ACKR1	Atypical chemokine receptor 1
				AKAP12	A-Kinase anchoring protein 12
				SELE	Selectin E
				CCL2	C-C motif chemokine ligand 2
Endothelial cells-2	Vascular endothelial cells	74	7 (9.46)	CYR61	Cellular communication network factor 1
				IGHG1	Immunoglobulin heavy constant gamma 1 (G1m Marker)
				IGHG3	Immunoglobulin heavy constant gamma 3 (G1m Marker)
				IGHG4	Immunoglobulin heavy constant gamma 4 (G1m Marker)
Endothelial cells-3	Vascular endothelial cells	63	49 (77.78)	CA4	Carbonic anhydrase 4
				CD32	Fc fragment of IgG receptor IIa (FCGR2A)
				FLT1	Fms related receptor tyrosine kinase 1
Endothelial cells-4	Lymphatic endothelial cells	25	25 (100)	LYVE1	Lymphatic vessel endothelial hyaluronan receptor 1
				CCL21	C-C motif chemokine ligand 21
				EFEMP1	EGF containing fibulin extracellular matrix protein 1
				CLU	Clusterin
				MMRN1	Multimerin 1
Fibroblast-1	CAF	132	128 (96.97)	PCOLCE	Procollagen C-endopeptidase enhancer
				MFAP5	Microfibril Associated Protein 5
				SFRP2	Secreted frizzled related protein 2
				PI16	Peptidase inhibitor 16
Fibroblast-2		298	15 (5.03)	PLAT	Plasminogen activator, tissue type
				AGT	Angiotensinogen
				CTHRC1	Collagen triple helix repeat containing 1
				CARD16	Caspase recruitment domain family member 16
Fibroblast-3		140	62 (44.29)	ARHGDIB	Rho GDP dissociation inhibitor beta
				RGS5	Regulator of G protein signaling 5
				MEF2C	Myocyte enhancer factor 2C
				CSRP2	Cysteine and glycine rich protein 2
Fibroblast-4	CAF	138	135 (97.83)	CXCL6	C-X-C motif chemokine ligand 6
				CCL13	C-C motif chemokine ligand 13
				HAPLN1	Hyaluronan and proteoglycan link protein 1
				CCL8	C-C motif chemokine ligand 8
Fibroblast-5		87	52 (59.77)	MYH11	Myosin heavy chain 11
				DES	Desmin
				CNN1	Calponin 1
				PLN	Phospholamban
Fibroblast-6		62	4 (6.45)	STMN2	Stathmin 2
				ADAM28	ADAM metallopeptidase domain 28
B cells-1	Plasma cells	513	231 (45.03)	IGHG1	Immunoglobulin heavy constant gamma 1 (G1m marker)
				IGHG2	Immunoglobulin heavy constant gamma 2 (G1m marker)
				IGHG3	Immunoglobulin heavy constant gamma 3 (G1m marker)
				IGHG4	Immunoglobulin heavy constant gamma 4 (G1m marker)
				APOE	Apolipoprotein E
B cells-2	Plasma cells	178	75 (42.13)	IGHG1	Immunoglobulin heavy constant gamma 1 (G1m marker)
				IGHG2	Immunoglobulin heavy constant gamma 2 (G1m marker)
				IGHG3	Immunoglobulin heavy constant gamma 3 (G1m marker)
				IGLL5	Immunoglobulin lambda like polypeptide 5
B cells-3	Plasma cells	184	62 (33.70)	IGHG4	Immunoglobulin heavy constant gamma 4 (G4m marker)
				IGHA	Immunoglobulin heavy constant alpha 1
B cells-4	B1 cell-like cells	88	80 (90.91)	REG3A	Regenerating family member 3 alpha
				DEFA6	Defensin alpha 6
				PRSS2	Serine protease 2
				ITLN2	Intelectin 2
				LYZ	Lysozyme
B cells-5	follicular B cells	137	123 (89.78)	MS4A1	Membrane spanning 4-domains A1
				LTB	Lymphotoxin beta
				HLA-DRB1	Major histocompatibility complex, class II, DR beta 1
				CD37	CD37 molecule
				APC	APC regulator of WNT signaling pathway
				CD52	CD52 Molecule
Myeloid cells-1	Macrophages	133	12 (9.02)	CAPG	Capping actin protein, gelsolin like
				TREM2	Triggering receptor expressed on myeloid cells 2
				GPNMB	Glycoprotein Nmb
				CAPG	Capping actin protein, gelsolin like
				CHI3L1	Chitinase 3 Like 1
Myeloid cells-2	Monocytes	95	85 (89.47)	CXCL2	C-X-C motif chemokine ligand 2
				PRDM1	PR/SET domain 1
Myeloid cells-3	Dendritic cells	84	40 (47.62)	IDO1	Indoleamine 2,3-dioxygenase 1
				CD1E	CD1e molecule
				CLEC9A	C-Type lectin domain containing 9A
Myeloid cells-4	Granulocytes	50	36 (72.00)	CCL20	C-C motif chemokine ligand 20
				S100A12	S100 calcium binding protein A12
				PTGS2	Prostaglandin-endoperoxide synthase 2
				G0S2	G0/G1 Switch 2--- G0S2
				IL1-B	Interleukin 1 beta
T cells-1	Helper cells	154	132 (85.71)	YPEL5	Yippee like 5
				TSC22D3	TSC22 domain family member 3
				GPR183	G protein-coupled receptor 183
T cells-2	Cytotoxic lymphocytes	125	55 (44.00)	GZMA	Granzyme A
				KIAA0101	PCNA clamp associated factor (PCLAF)
				TUBB	Tubulin beta class I
				STMN1	Stathmin 1
				HIST1H4C	Histone cluster 1 H4 family member C
				HMGB2	High mobility group box 2
				PKM	Pyruvate kinase M1/2
				GNLY	Granulysin
T cells-3	Natural killer cells	39	28 (71.79)	PIGR	Polymeric immunoglobulin receptor
				NTS	Neurotensin
				TPSB2	Tryptase beta 2
				TPSAB1	Tryptase alpha/beta 1
				KRT8	Keratin 8
				ELF3	E74 Like ETS transcription factor 3
				KRT13	Keratin 13
				PHGR1	Proline, histidine and glycine rich 1
				DEFA5	Defensin alpha 5
Epithelial cells-1	Cancer cells	437	433 (99.08)	ENPEP	Glutamyl aminopeptidase
				RBP2	Retinol binding protein 2
				APOC3	Apolipoprotein C3
				APOA1	Apolipoprotein A1
				CYP3A4	Cytochrome P450 family 3 subfamily a member 4
				SLC15A1	Solute carrier family 15 member 1
				MGAM	Maltase-glucoamylase
				KHK	Ketohexokinase
				ALPI	Alkaline phosphatase, intestinal
Epithelial cells-2		354	11 (3.11)	PI3	Peptidase inhibitor 3
				TIMP1	TIMP metallopeptidase inhibitor 1
				SLPI	Secretory leukocyte peptidase inhibitor
				STAT3	Signal transducer and activator of transcription 3
				OCIAD2	OCIA domain containing 2
Epithelial cells-3	Cancer cells	344	302 (87.79)	OLFM4	Olfactomedin 4
				REG1A	Regenerating family member 1 alpha
				CLCA1	Chloride channel accessory 1
				MT1G	Metallothionein 1G
Epithelial cells-4		315	3 (0.95)	MUC1	Mucin 1, cell surface associated
				ABCC3	ATP binding cassette subfamily c member 3
				STT3-B	STT3 oligosaccharyltransferase complex catalytic subunit B
				MT-CO2	Mitochondrially encoded cytochrome C oxidase II
Epithelial cells-5		258	5 (1.94)	CA4	Carbonic anhydrase 4
				TM4SF4	Transmembrane 4 L six family member 4
				EMP1	Epithelial membrane protein 1
				SAA1	Serum amyloid A1
				DUOX2	Dual oxidase 2
Epithelial cells-6		204	10 (4.90)	HMGB2	High mobility group box 2
				HIST1H4C	Histone cluster 1 H4 family member C
				TUBA1B	Tubulin alpha 1b
				HMGN2	High mobility group nucleosomal binding domain 2

Different angiogenesis pathways in tumor and non-malignant endothelial cells

A total of 228 endothelial cells were detected and four clusters were revealed ( Figure 2A ). We next aimed to identify marker genes for each of these clusters and assign them to known endothelial cell types ( Figure 2B , Supplementary Table S1 ). This revealed three sets of vascular endothelial cells: two were mostly tumor-derived (clusters 1 and 3; ACKR1+ and CA4+, respectively) and one was mostly non-malignant tissue-derived (cluster 2; CYR61+). Another set of 25 lymphatic endothelial cells was found in the tumor sample (cluster 4; marker genes LYVE1+ and CCL21+), however, interestingly, no distinct cluster of lymphatic endothelial cells from the non-malignant sample was identified.

Figure 2.

Different angiogenesis pathways in tumor and non-malignant endothelial cells. (A) tSNE plot of 228 endothelial cells (top to bottom), color-coded by their associated cluster, the sample type of origin, and the number of transcripts detected in each cell; (B) tSNE plot color-coded for expression (gray to red) of marker genes, (cluster 1, ACKR1+; cluster 2, CYR61+; cluster 3, CA4+ and cluster 4, LYVE1+); (C) Differences in pathway activities scored per cell by GSVA among the vascular clusters. The KRAS signaling pathway was significantly down-regulated in cluster 2, but up-regulated in clusters 1 and 3, while the Myc target pathway showed contrasting results; (D) Violin plots show the expression distribution of selected genes involved in the KRAS and Myc pathways; (E) SCENIC analysis of the involved transcription factors involved among the clusters. Many transcription factors took part in attending angiogenesis, including FOXP1 and ETS1; (F) Exhibition of the involved pathways (KRAS, Myc) and transcription factors ( FOXP1, ETS1) and their target genes, corresponding to the degree of expression. tSNE, t-distributed stochastic neighbor embedding; GSVA, gene set variation analysis; SCENIC, single-cell regulatory network inference and clustering.

Except for lymphocyte-composed cluster 4, we used hallmark pathway gene signature analysis to identify different characteristics among the other three clusters, which were all from vascular endothelial cells ( Figure 2C ). Interestingly, the KRAS signaling pathway was significantly down-regulated in cluster 2, but up-regulated in clusters 1 and 3, whereas the Myc target pathway showed contrasting results ( Figure 2D ). Detailed analysis has shown that the two pathways were angiogenesis-related, however, different tissue-derived clusters seemed to have diverse mechanisms. The role of KRAS oncogenes in promoting cellular transformation is well described, and KRAS modulates tumor-stroma interactions and supports cancer invasiveness by influencing the expression of metalloproteinases and cytokines involved in angiogenesis ( 17). In our study, the high enrichment of KRAS pathway observed in tumor tissues was in accordance with the hyper-vascular nature of tumors.

Next, single-cell regulatory network inference and clustering (SCENIC) analysis ( 18) was applied, in which differentially expressed genes were scanned for overexpressed transcription factor binding sites, the co-expression of transcription factors and their putative target genes were analyzed ( Figure 2E , F ). Many transcription factors play a role in angiogenesis, including FOXP1 and ETS1. Of note, FOXP1 can stimulate angiogenesis by repressing semaphorin 5B in endothelial cells, and regulate angiogenesis through the circ-SHKBP1/miR-544a/FOXP1 pathway ( 19). Furthermore, ETS1 enables angiogenesis in several ways ( 20).

Cancer associated fibroblasts (CAFs) play various roles in tumorigenesis

Fibroblasts have long been suggested to be a heterogeneous population, but the extent of heterogeneity has yet to be explored. Fibroblast phenotypes are considered highly context-dependent and unstable in culture. In our samples, 857 fibroblasts were detected ( Figure 3A ). Sub-clustering revealed six distinct subtypes: clusters 1 and 4 (cluster 1, PCOLCE2+ and cluster 4, CXCL6+) were strongly enriched in tumor tissues, while cluster 2 ( PLAT+) was fully enriched in non-malignant tissues. In addition, other clusters (cluster 3, ARHGDIB+; cluster 5, MYH11+; cluster 6, STMN2+), however, were derived from a mixture of tumor and non-malignant tissues, but were mostly enriched in non-malignant tissues ( Figure 3B ). Remarkably, fibroblasts ( CD34+ and KLF4+) were generally enriched in tumor tissues. The marker genes of CAFs, PCOLCE2 and CXCL6 were significantly up-regulated in tumor tissues by the bulk RNA-seq data from TCGA data ( Figure 3C ).

Figure 3.

CAF plays various roles in tumorigenesis. (A) tSNE plot of 857 fibroblast cells (top to bottom), color-coded by their associated cluster, the sample type of origin, and the number of transcripts detected in each cell; (B) tSNE plot color-coded for expression (gray to red) of marker genes (cluster 1, PCOLCE2+; cluster 2, PLAT+; cluster 3, ARHGDIB+; cluster 4, CXCL6+; cluster 5, MYH11+; cluster 6; STMN2+); (C) CAFs marker genes, PCOLCE2 and CXCL6 were confirmed to be significantly up-regulated in tumor tissues, as confirmed in bulk RNA-seq data from TCGA; (D) Differences in pathway activities scored per cell by GSVA among the clusters. Clusters 1 and 4 were enriched in Wnt and KRAS signaling, which have a close relationship with tumor proliferation; (E) Violin plots show the expression distribution of selected genes involved in Wnt and KRAS pathways; (F) Different fibroblast clusters expressed different kinds of collagens; (G) The involved marker genes ( FN1, HAS2, CXCL12, POSTN, PRG4), and transcription factor KLF12 and its target genes, corresponding to the degree of expression. tSNE, t-distributed stochastic neighbor embedding; CAF, cancer associated fibroblast; TCGA, The Cancer Genome Atlas; GSVA, gene set variation analysis; COAD, colon adenocarcinoma.

The prime role of CAFs is promoting the proliferation of cancer cells. Clusters 1 and 4 were enriched in Wnt and KRAS signaling, and are closely related with tumor proliferation ( 21) ( Figure 3D , E ). SCENIC analysis showed that KLF12, which promotes CRC growth, was highly expressed in cluster 1 ( 22) ( Figure 3G , Supplementary Figure S2 ). Furthermore, cluster 4 showed high expression in TGFβ and Wnt signaling, which are also related to cancer invasion and metastasis ( 23). Another remarkable characteristic of CAFs is extracellular matrix (ECM) remodeling, and collagens, important ECM components, participate in tumor progression ( 24). We found that various collagens were highly expressed in fibroblasts, and different clusters seemed to have different expression inclinations ( Figure 3F ). In addition to collagens, many other ECM components, such as fibronectin, periostin, hyaluronan, and proteoglycans (marker genes PRG4, POSTN, HAS2 and FN1, respectively) were also up-regulated by CAFs ( 25, 26). The corresponding genes were highly expressed in CAFs ( Figure 3G ). CAFs also influenced the drug resistance of tumors, and CXCR4 expression predicted patient outcome and recurrence patterns after hepatic resection for colorectal cancer with liver metastases. CXCL12 can mediate drug resistance by combining with CXCR4 that is expressed in cancer cells ( 27). In addition, FAP+ CAF can mediate immune suppression by CXCL12 ( 28).

Figure S2.

SCENIC analysis of transcription factors involved among the fibroblasts clusters, and showed that KLF12, which promotes CRC growth, was highly expressed in cluster 1. SCENIC, single-cell regulatory network inference and clustering; CRC, colorectal cancer.

CRC-related pathways are enriched in tumor-derived B cells

In our study, we detected 1,100 B lymphocyte cells. B cells are the most prevalent type of stromal cells ( Figure 4A ). Clustering revealed five clusters, including two clusters (clusters 4 and 5; REG3A+ and MS4A1+, respectively) that were mostly tumor enriched, whereas the other three clusters (cluster 1, IGHM+; cluster 2, IGLL5+ and cluster 3, IGHGP+, respectively) were composed of both tumor and non-malignant cells ( Figure 4B ). Moreover, clusters 1, 2 and 3 showed plasma properties and were not grouped into distinct clusters. Although all cells expressed immunoglobulin A, tumor-derived cells showed higher levels of IgM expression, while non-malignant-derived cells showed a higher IgA expression. Cluster 4 significantly expressed many innate immunity-related genes, such as REG3A, PRSS2, ITLN2 and LYZ, but had a negative CD5 expression. Therefore, these cells were identified as B1 cell-like cells. Cluster 5 showed a high expression of MS4A1, LTB and HLA-DRB1, which were characteristics of follicular B cells ( Figure 4C ).

Figure 4.

CRC-related pathways are enriched in tumor-derived B cells. (A) tSNE plot of 1,100 B cells (top to bottom), color-coded by their associated cluster, the sample type of origin, and the number of transcripts detected in each cell; (B) tSNE plot color-coded for expression (gray to red) of marker genes (cluster 1, IGHM+; cluster 2, IGLL5+; cluster 3, IGHGP+; cluster 4, REG3A+ and cluster 5, MS4A1+); (C) Exhibition of the marker genes ( REG3A, PRSS2, ITLN2, HLA- DRB1, MS4A1, LTB) corresponding to the degree of expression; (D) Differences in pathway activities scored per cell by GSVA among the clusters. Pathway analyses showed that peroxisome signaling was highly expressed in tumor cells. CRC, colorectal cancer; tSNE, t-distributed stochastic neighbor embedding; GSVA, gene set variation analysis.

Pathway analyses showed that peroxisome signaling was highly expressed in tumor cells ( Figure 4D ). Moreover, peroxisome signaling was closely related to CRC risk ( 29) and was positively correlated with lymph node metastasis and poor prognosis of CRC ( 30). The results also showed that the oxidative phosphorylation pathway was enriched in non-malignant-derived cells, which might be attributed to the impact of colitis. SCENIC analysis failed to identify differences between non-malignant tissue-derived and tumor-derived plasma cells ( Supplementary Figure S3 ). In addition, no differences were observed in transcript numbers in tumor-associated vs. non-malignant tissue-associated plasma cells, however, the plasma cells showed a higher transcription trend than clusters 4 and 5 ( Figure 4A ).

Figure S3.

SCENIC analysis of transcription factors involved among B cell clusters, and SCENIC analysis failed to identify differences between non-malignant tissue-derived and tumor-derived plasma cells. SCENIC, single-cell regulatory network inference and clustering.

Different derived myeloid cells show diverse expressing properties

The 362 myeloid cells clustered into four subsets, which were not completely separated ( Figure 5A ). One cluster corresponded to macrophages (cluster 1, CAPG+), another cluster to monocytes (cluster 2, CXCL2+). There was also a dendritic cell cluster (cluster 3, IDO1+) and a granulocyte cluster (cluster 4, CCL20+) ( Figure 5B ). Dendritic cells and granulocytes were typically more abundant in tumors than in non-malignant tissues. In contrast, macrophages were more abundant in non-malignant tissues. In both tissues, monocytes were detected at similar numbers.

Figure 5.

Different derived myeloid cells showed diverse expression properties. (A) tSNE plot of 362 myeloid cells (top to bottom), color-coded by their associated cluster, the sample type of origin, and the number of transcripts detected in each cell; (B) tSNE plot color-coded for expression (gray to red) of marker genes (cluster 1, CAPG+; cluster 2, CXCL2+; cluster 3, IDO1+ and cluster 4, CCL20+); (C) Differences in pathway activities scored per cell by GSVA among the clusters. Tumor-associated cells increased in tumorigenesis, cell proliferation and low-oxygen metabolism pathway (that is, pathways associated with TNFα signaling, KRAS signaling and hypoxia), while the non-malignant tissue-derived cells preferred the oxidative phosphorylation and biomass production pathways (pathways associated with phosphorylation and protein secretion). tSNE, t-distributed stochastic neighbor embedding; GSVA, gene set variation analysis; TNF, tumor necrosis factor.

The cell numbers of macrophages and monocytes displayed extensive heterogeneity in tumors compared with those in non-malignant tissues, however, SCENIC analysis did not show significance among different derived cells ( Supplementary Figure S4 ). Furthermore, the pathways of the differently derived cells were analyzed and revealed a tumor-associated increase in tumorigenesis, cell proliferation, and low-oxygen metabolism pathways (that is, pathways associated with tumor necrosis factor α signaling, KRAS signaling and hypoxia). Non-malignant tissue-derived preferred oxidative phosphorylation and biomass production pathways (pathways associated with phosphorylation and protein secretion) ( Figure 5C ).

Figure S4.

SCENIC analysis of transcription factors involved among myeloid cell clusters. The cell numbers of macrophages and monocytes displayed extensive heterogeneity in tumors compared with those in non-malignant tissues, but SCENIC analysis showed no significance among different derived cells. SCENIC, single-cell regulatory network inference and clustering.

Several typical species of T cells identified in multiple analysis

With 318 cells detected, T cells were mainly divided into three clusters, and were designated as naive T cells (cluster 1, YPEL5+), cytotoxic T cells (cluster 2, GZMA+), and natural killer T cells (cluster 3, PIGR+) ( Figure 6A , B ). In cluster 1, the significantly expressed genes, including YPEL5 and GPR18, were closely related to proliferation and cell differentiation ( 31). Pathway analysis showed that many proliferation- and differentiation-related pathways, such as Myc targets, G2M checkpoints and E2F targets, were highly expressed in cluster 1 ( Figure 6C ). SCENIC analysis also showed that T cell-specific differentiation-related transform factor ELF-1 was significantly up-regulated ( Figure 6D , E ). In cluster 2, we found that cytotoxic T cell-specific genes, such as GZMA and GNLY, were highly expressed. Additionally, the glycolysis pathway was most highly expressed in cluster 2 among the three clusters, and a related gene, PKM, was also highly expressed ( 32). Furthermore, in cluster 2, a small number of populations of cells were detected expressing higher levels of the immune checkpoint molecule HAVCR, which acts in the tolerance and exhaustion of T cells ( 33) and is currently targeted in clinical trials of immunotherapy for cancers ( 34). At the meantime, this subtype of cells showed high expression of MKI67, which encoded proliferation-related proteins ( 35), and the notable transcription numbers also reflected their high proliferative activity ( Figure 6A , B ).

Figure 6.

Several typical species of T cells are identified in multiple analysis. (A) tSNE plot of 318 T cells (top to bottom), color-coded by their associated cluster, the sample type of origin, and the number of transcripts detected in each cell; (B) tSNE plot color-coded for expression (gray to red) of marker genes, naive T cells (cluster 1, YPEL5+), cytotoxic T cells (cluster 2, GZMA+) and natural killer and natural killer T cells (cluster 3, PIGR+); (C) Differences in pathway activities scored per cell by GSVA among the clusters. Pathway analysis showed that many proliferation- and differentiation-related pathways, such as Myc targets, G2M checkpoints and E2F targets, were highly expressed in cluster 1; (D,E) SCENIC analysis of transcription factors involved among the clusters, and SCENIC analysis showed that the T cell-specific differentiation-related transform factor ELF-1 was significantly up-regulated. tSNE, t-distributed stochastic neighbor embedding.

Heterogeneity of epithelial cells was demonstrated

In total, 1,912 epithelial cells were characterized and divided into six clusters; two tumor-derived clusters (cluster 1, ENPEP+; cluster 3, OLFM4+, respectively), and four clusters were almost exclusively from non-malignant tissues (cluster 2, PI3+; cluster 4, MUC1+; cluster 5 CA4+; cluster 6, HMGB2+, respectively) ( Figure 7A , B ). Pathway analysis showed significant differences between tumor- and non-malignant-derived tissues ( Figure 7C ). In particularly, cluster 1 typically exhibited malignant properties. High proliferation- and embryonic developmental process-related pathways were highly expressed (Wnt signaling, Myc targets and EMT signaling) ( 36), and lesions repair-associated pathways, including the DNA repair pathway, were down-regulated ( 37) ( Figure 7D ).

Figure 7.

Heterogeneity of epithelial cells was demonstrated. (A) tSNE plot of 1,912 epithelial cells (top to bottom), color-coded by their associated cluster, the sample type of origin, a+nd the number of transcripts detected in each cell; (B) tSNE plot color-coded for expression (gray to red) of marker genes (cluster 1, ENPEP+; cluster 2, PI3+; cluster 3, OLFM4+; cluster 4, MUC1+; cluster 5, CA4+; cluster 6, HMGB2+); (C) Differences in pathway activities scored per cell by GSVA among the clusters. Pathway analysis showed significant differences between the tumor- and non-malignant-derived tissues. In particularly, cluster 1 and 3 existed typically exhibited malignant properties; (D) Violin plots show the expression distribution of selected genes involved in the Wnt and DNA repair pathways. In cluster 1 and 3, high proliferation- and embryonic developmental process-related pathways were highly expressed (Wnt signaling, Myc targets and EMT signaling), and lesions repair-associated pathways, such as the DNA repair pathway, were down-regulated; (E) Exhibition of the involved transcription factors ( CDX2, STAT3) and their target genes, corresponding to the degree of expression. tSNE, t-distributed stochastic neighbor embedding; EMT, epithelial-mesenchymal transition.

Through SCENIC analysis, we demonstrated that the transcription factors CDX2 and STAT3 were significantly up-regulated in cluster 1, and showed almost no expression in other clusters except for cluster 3 ( Supplementary Figure S5 ). CDX2 inhibits aggressive phenotypes of colon cancer cells both in vitro and in vivo ( 38) and might be a prognostic marker related to the benefit of adjuvant chemotherapy ( 39). STAT3 is essential for the transduction of tumor-promoting signals of the IL-6/STAT3 pathway, which is highly activated in CAC ( 40). Collectively, different clusters exhibited obviously diverse properties even in the same tissues ( Figure 7E ).

Figure S5.

SCENIC analysis of transcription factors involved among the epithelial clusters. The transcription factors CDX2 and STAT3 were significantly up-regulated in cluster 1, but showed almost no expression in other clusters besides cluster 3. SCENIC, single-cell regulatory network inference and clustering.

Evolutionary trajectory of disease development and internal variation in crucial genes

Complete transcriptome data for many epithelial cells allowed us to gain insights into the functional states of and relationship among these cells. Carcinogenesis follows the principles of Darwinian evolution, whereby somatic cells acquire genomic alterations that provide them with a survival and/or growth advantage ( 41). Therefore, the dynamic information of gene expressions could be used to track the progress of the disease. Transcriptional similarity-based pseudotime analysis was applied ( 42) to order epithelial cells and indicated their developmental trajectories ( Figure 8A ). All cells from each cluster aggregated into nine states based on expression similarities, and different states formed a trajectory by pseudotime analysis that began with states 4, 7 and 8 (non-malignant-derived cells), followed by states 2, 3 and 5 (mixed derived cells), and ended with states 1, 6 and 9 (tumor-derived cells) ( Figure 8A , B ). Following this trajectory, the differentially expressed genes were identified, and these genes might play crucial roles in the evolution from colitis to cancer. Therefore, in the subsequent analysis, we focused on the top three differentially expressed genes, CD74, CLCA1 and DPEP1 ( Figure 8C ). Different degrees of IHC staining between normal and tumor tissues for CD74, CLCA1 and DPEP1 from the public data website of The Human Protein Atlas confirmed the change in expression in these genes along with disease progression ( Figure 8D ).

Figure 8.

Evolutionary trajectory of disease development and internal variation in crucial genes. (A) Transcriptional similarity-based pseudotime analysis was used to order epithelial cells and indicated their developmental trajectories. All the cells from each cluster aggregated into nine states based on pseudotime analysis; (B) Distribution of the cells originally from the tumor and non-malignant tissues into six clusters (left to right); (C) Following this trajectory, the differentially expressed genes were identified, and these genes might play crucial roles in the evolution from colitis to cancer. Top 3 differential expressed genes ( CD74, CLCA1 and DPEP1) were showed along with evolutionary trajectory; (D) Different degrees of immunohistochemical staining between normal and tumor tissues for CD74, CLCA1 and DPEP1 from the public data website of The Human Protein Atlas; (E) Different expression of genes ( CD74, CLCA1 and DPEP1) in tumor and normal tissues from TCGA. TCGA data showed that the expression of CD74 was significantly high in normal tissues (P<0.05), the expression of DPEP1 was significantly high in tumor tissues (P<0.05), but there was no significance for the expression of CLCA1 between tumor and normal tissues (P=0.07); (F) Relationships between gene expression levels and survival time. Patients with high CD74 expression had better survival (P<0.01), but there were no relevance between CLCA1 or DPEP1 expression and the prognosis of patients ( CLCA1, P=0.11; DPEP1, P=0.09).

CD74, cluster of differentiation 74, also known as HLA-DR antigen-associated invariant chain and encoded by the CD74 gene, is a polypeptide that is involved in the formation and transport of MHC class II protein, which is found in several types of cancer cells ( 43, 44). In CRC, stimulation of CD74 by MIF induces a signaling cascade, leading to up-regulation of Bcl-2, thereby resulting in a significantly increased survival of patients with colon cancer. The MIF/CD74 axis is a target for novel therapies ( 45). Taken together, our data demonstrated that CD74 was down-regulated as tumorigenesis progressed, which was consistent with the findings presented in previous reports. TCGA data showed that CD74 expression was significantly high in normal tissues (P<0.05) ( Figure 8D , E ), and patients with high CD74 expression had a better survival (P<0.01) ( Figure 8F ).

CLCA1, calcium-activated chloride channel regulator 1, is a protein that is encoded by the CLCA1 gene in humans and plays many roles, including the regulation of mucus production and secretion in goblet cells ( 46). CLCA1 regulates tissue inflammation in the innate immune response ( 47) and tumor suppression in CRC ( 48), and can suppress CRC aggressiveness via inhibition of the Wnt/β-catenin signaling pathway. Low expression of CLCA1 predicts a poor prognosis in CRC ( 49). Thus, our data demonstrated that CLCA1 was first up-regulated, then down-regulated during the late period of the pseudotime analysis. TCGA data indicated no significance for the expression of CLCA1 between tumor and normal tissues (P=0.07) ( Figure 8D , E ), and no relevance between CLCA1 expression and patient prognosis (P=0.11) ( Figure 8F ).

DPEP1, dipeptidase 1, encoded by the DPEP1 gene, hydrolyzes a wide range of dipeptides and plays a role in many biological processes, including the metabolism of glutathione and β-lactam hydrolysis in the kidney ( 50). In CRC, the expression of DPEP1 has been shown to affect cancer cell invasiveness in early stage cases, and can act as a candidate tumor-specific molecular marker for the detection of rare disseminated colorectal tumor cells in peripheral venous blood and intraperitoneal saline lavage samples ( 51). Our data demonstrated that DPEP1 was up-regulated as tumorigenesis progressed, which was consistent with the data presented in previous reports. TCGA data showed that the expression of DPEP1 was significantly higher in tumor tissues (P<0.05) ( Figure 8D , E ), however, no relevance was observed between DPEP1 expression and patient prognosis (P=0.09) ( Figure 8F ).

Discussion

In previous studies, cell identity was defined by various methods, such as morphological appearance, tissue context, and marker gene expression. As mRNA encodes cellular function and phenotype, single-cell transcriptomics could precisely refine the cellular identity based on comprehensive and quantitative readout of mRNA ( 52). Thus, scRNA-seq technology has attracted significant attention since its inception, and a large number of applied study results have been published recently ( 53). In the context of human cancer, scRNA-seq was used to reveal the intra-tumor heterogeneity and transcriptional trajectories of malignant transformation ( 54).

In this study, 4,777 single-cell transcriptomes of human colon tumorous tissues and non-malignant tissues from UC-associated colon cancer were analyzed. Furthermore, the composition of cancer-associated stromal cells was defined, the different subgroups of tumor cells were analyzed, and the notable pathways and transcription factors involved in the disease were described. Many of the tumor-derived cell types identified by a scRNA-seq approach, including B cells, T cells, endothelial cells, myeloid cells, fibroblasts, and epithelial cells (summarized in Figure 9 ), presented an altered gene expression profile with pro-tumoral properties compared with non-malignant cells. Of note, the evolutionary trajectory of tumor development was graphed, and pseudotime analysis revealed the cellular composition of CAC and its developmental trajectory. The TME might play a crucial role in the evolutionary process from a UC to a CAC. Moreover, we identified the top three differentially expressed genes that played a role in disease progression, CD74, CLCA1 and DPEP1. These results may represent a promising strategy that identifies novel potential therapeutic targets in the evolution from UC to CAC and may prevent the development of CRC.

Figure 9.

Intra-tumor landscape and statement of TME of UC-associated colon cancer. (Red words mean the cluster of tumor cells, while blue words represent the cluster of non-malignant tissues and others belong to the mixed both tumorous- and non-malignant tissue cells). TME, tumor micro-environment; UC, ulcerative colitis.

Changes in gene expression in the tumorigenesis trajectory suggest directions for the design of therapies ( 55). For instance, CD74 is abundant in non-malignant cells, but is down-regulated in tumor endothelial cells. In addition, tumor-derived epithelial cells up-regulate Wnt signaling, but down-regulate DNA repair pathways. Likewise, SCENIC analysis in fibroblasts predicts transcription factors responsible for the transformation toward CAFs, and patients might acquire therapeutic benefits when these conversion processes are blocked. Distinctive features of tumor cells may represent vulnerabilities and provide potential entry points for the design of novel therapies.

To our knowledge, a study which focused on the spatiotemporal evolution from UC to CAC was published ( 56). In this study, the authors dissected the evolutionary history of CAC using multi-region exome sequencing, but did not perform scRNA-seq and the landscape of cell heterogeneity and evolutionary trajectory in UC-associated CRC revealed by scRNA-seq was absent. It is acknowledged that this is the first study depicting the cell landscape of UC-associated colon cancer at the single-cell transcriptome level, which describes the intra-tumoral heterogeneity mainly from three different viewpoints: gene expression, pathway enrichment, and transcription factor analysis. This provides a more accurate perspective for analyzing the evolutionary progress of UC-associated colon cancer when compared to an average calculation ( 57).

However, there are also some limitations. Firstly, the results of the study have been determined based on the evolutionary process from UC to CAC in a single patient, which obviously lacks more patients with CAC to compare the obtained results. Secondly, the methods used to classify the cell types are based on distinct and highly-expressed genes, coupled with previous reports. Therefore, an authorized or unified standard should be established. Thirdly, the patient was diagnosed with UC-associated colon cancer and samples from an UC-associated tumor and adjacent inflamed tissues were collected to show the intra-tumor landscape via scRNA-seq. However, the cohort of the TCGA database has sporadic CRC patients, which might cause bias for UC-associated colon cancer. Lastly, three genes ( CD74, CLCA1 and DPEP1) were found to be a potential role in colon cancer disease progression. However, it is obviously limited and biased since there is only one case and no experiments were done to demonstrate their function in the evolutionary process. To show reliable gene panels, the results should be further validated in larger cohorts in the future, which will be helpful to yield more accurate and convincing results.

Conclusions

This study primarily elucidates the composition of TME and developmental trajectory of UC-associated colon cancer. Furthermore, these results may represent a promising strategy that identifies novel potential therapeutic targets in the evolution from UC to CAC. In the future, the researchers should confirm whether the transcriptome of CAC is associated with consensus molecular subtypes of CRC, and determine whether the transcriptome of the tumor cells could be a signature related to UC among more patients.

Acknowledgements

This study was supported by National Key Research and Development Program of China (No. 2017YFC1308800) and Industry-University-Research Innovation Fund in Ministry of Education of the People’s Republic of China (No. 2018A01013).

Footnote

Conflicts of Interest: The authors have no conflicts of interest to declare.
