Bladder and urethral duplication and a bladder exstrophy plate with omphalocele in a female child

Abstract

The Exstrophy – Epispadias Complex (EEC) is a spectrum of rare congenital malformations involving the urinary, genital and musculoskeletal systems. We present an atypical or variant case of EEC in which a bladder plate is found involving a small omphalocele, separated pubic bones and bladder and urethral duplication. The treatment had a favorable outcome, with bladder control and the child voiding normally. Perhaps the best accepted embryonic theory to explain exstrophy and its variants should be reviewed as it fails to satisfactorily explain the alterations we found.

Introduction

The Exstrophy – Epispadias Complex (EEC) is a spectrum of rare congenital malformations involving the urinary, genital and musculoskeletal systems. Exstrophy variants or “split symphysis variants” are even rarer, observed in approximately 1 in every 400.000 live newborns or in 1 in every 500.000 ones, most commonly found among girls as compared to boys, unlike what is perceived in regular exstrophy cases.^1,2 The etiology of EEC is quite unknown yet and different theories have been suggested to explain the abnormal development of the cloacal membrane.³ We report on the case of a female child who was born with a bladder exstrophy variant and an omphalocele in the middle of the plate, besides a bladder and urethral duplication.

Case report

A seven-day-old girl was referred to our department diagnosed with omphalocele and ambiguous genitalia. She was born after a normal pregnancy, Cesarean section, diabetic and hypertensive mother, in week thirty-seven of pregnancy. Nothing abnormal appeared in the ultrasounds performed during pregnancy. After birth she underwent an abdominal ultrasonography that revealed nothing unusual, a transfontanelar ultrasound equally normal and an echocardiogram that detected an interatrial communication and an interventricular communication with no hemodynamic repercussions. When she was first examined an omphalocele involved by a bladder plate was found, apparently with no ureteral ostia. She had bifid clitoris and clearly female genitals (Fig. 1). An abdominal radiography showed that her pubic bones were separated, as usually occurs in cases of exstrophy-epispadias complex. On day eight she underwent posterior osteotomy of the iliac bones and a median laparotomy. Besides the bladder plate involving the omphalocele, two well characterized bladders were noticed, each one with its ureteral ostium and respective urethra (Fig. 2a). Both bladders were opened and united with Vycril 4-0 stitches (Fig. 2b). Two urethral catheters were left in place for 48 hours. The abdominal wall was sutured with Vycril 2-0 separated stitches and the pubic bones were quite easily approximated by three Vycril 1 stitches (Fig. 3). The child remained with her lower limbs immobilized for three weeks. She had an uneventful postoperative and was released with no complication. She is currently six months old and voids normally.

Fig. 1.

Vesical plate and omphalocele on the day of birth.

Fig. 2.

a: Two bladders and two urethras with catheters inside.:b The two bladder are unified.

Fig. 3.

Final aspect.

Comment

According to Turner et al. exstrophy variants are found in 8% of all patients with exstrophy.⁴ Such variants were classified into 5 sub-groups^1,5:

• 1.Superior vesical fissure: A musculoskeletal defect is present, however with minimal bladder eventration and limited to the apex.
• 2.Pseudo-exstrophy: There are characteristic musculoskeletal defects with no major defect except for subcutaneous location of the bladder.
• 3.Duplicate exstrophy: Only a patch of the bladder exstrophy mucosa in the infraumbilical region is present but the urinary tract is intact.
• 4.Superior vesical fistula: A tiny communication between the bladder and the exterior is present in addition to the musculoskeletal defect.
• 5.Covered exstrophy: there is a visceral sequestration where, in addition to the musculoskeletal defect, an isolated bowel segment is present on the anterior abdominal wall close to the genital area.

In our case urethral and bladder duplication was found, with normal ureters and kidneys, besides the presence of a bladder exstrophy plate with an omphalocele in the middle, i.e., a combination of duplicate exstrophy and pseudo-exstrophy (Fig. 1).

In the embryonic phase, a misleading fact in the development of an exstrophy and its variants is that at no stage in the human or animal embryonic development anything similar to an exstrophy occurs. So, most likely, exstrophy is not caused by a discontinuity in the development process. The most accepted theory for the development of an exstrophy and its variants was described by Marshall et Muecke who suggest and abnormal development of the cloacal membrane, in which there is no development of the mesenchyme between the ectoderm and the endoderm of the infraumbilical region, leading to a perforation that can be either early, leading to a cloacal exstrophy, or late, leading to an bladder exstrophy, or even later which in turn leads to the development of epispadias.⁵

Exstrophy variants have been suggested as being a manifestation of a circumscribed perforation of the cloacal membrane, predominantly in its cranial or more caudal position. Our patient, in addition to presenting an exstrophy plate with an omphalocele in the middle had bladder and urethral duplication, which may suggest that Marshall et Muecke's theory should be reconsidered for further evaluation.

Conclusion

The bladder-exstrophy complex is a spectrum of challenging congenital malformations ranging from classical or typical forms to variant or atypical ones. Perhaps the best accepted embryonic theory to explain all cases should be reviewed when considering variant or atypical forms.
