. 2020 Jun 17;2(2):175–185. doi: 10.1089/bioe.2020.0015

Differential Cell Death and Regrowth of Dermal Fibroblasts and Keratinocytes After Application of Pulsed Electric Fields

Bodhisatwa Das 1, Anil Shrirao 1, Alexander Golberg 2, Francois Berthiaume 1, Rene Schloss 1, Martin L Yarmush 1,,3,,4,✉
PMCID: PMC8370327  PMID: 34471845

Abstract

Background: High-powered pulsed electric fields (PEF) may be used for tissue debridement and disinfection, while lower PEF intensities may stimulate beneficial cellular responses for wound healing. We investigated the dual effects of nonuniform PEF on cellular death and stimulation.

Methods: Dermal fibroblast or keratinocyte monolayers were exposed to PEF induced by two needle electrodes (2 mm apart). Voltages (100–600 V; 1 Hz; 70 micros pulse width; 90 pulses/cycle) were applied between the two electrodes. Controls consisted of similar monolayers subjected to a scratch mechanical injury.

Results: Cell growth and closure of the cell-free gap was faster in PEF-treated cell monolayers versus scratched ones. Media conditioned from cells pre-exposed to PEF, when applied to responder cells, stimulated greater proliferation than media from scratched monolayers.

Conclusions: PEF treatment causes the release of soluble factors that promote cell growth, and thus may play a role in the accelerated healing of wounds post PEF.

Keywords: skin, wound healing, pulsed electric fields

Introduction

Pulsed electric fields (PEF) have been utilized for a large number of biological applications, including food disinfection, cloning, gene silencing, and drug and other biomolecule delivery.1–4 It is thought that PEF achieves nonthermal cell death mainly through rapid alteration of the resting membrane potential of the target cells, leading to irreversible generation of nanopores (irreversible electroporation or IRE) and rupture of the cells.5 In general, PEF parameter selection for specific applications encompasses electric field strength, pulse number, duration, frequency, and polarity.6–8 Recently, health care engineering has explored this highly interesting biophysical technique for a number of therapeutic purposes.9,10

Another area where PEF have been explored is for wound healing and related therapies; for example, PEF-induced IRE can be a highly effective technique to disinfect burn injuries.11,12 It can also assist in the disinfection of antibiotic-resistant biofilm-forming bacterial colonies to restore the wound healing process.13 It is postulated that IRE can kill cells at the injury site without degrading the native exracellular matrix architecture.14 By preserving the native tissue scaffold, cells can migrate into the injuiry site and may even lead to scarless wound healing.15–17 Although it has been proposed that IRE enhances blood flow into the surrounding tissue, the molecular and cellular mechanisms behind improved healing are unclear.18

While a lethal dose of high-intensity pulses is utilized for massive cellular destruction and as an alternative to surgical debridement, PEF has also been explored for electrostimulation in wound healing; for example, it has been hypothesized that PEF may guide stem cells toward injured dermal tissue.19–22 Low-voltage electrostimulation has been found to alter regenerative gene expression in keratinocytes, and electric fields have been found23 to enhance migration and influence directionality of keratinocytes.24 PEF also have been observed to affect the prolifrtation and differentiation pattern of hematopoetic stem cells, osteoblasts, and myoblasts.25,26

In most health care applications of PEF, studies only focus on a single mode of PEF application, either stimulation or tissue ablation.11,16 Herein, we explored the combined effect of PEF on cell death and cell growth stimulation in two major skin cell types (human dermal fibroblasts and keratinocytes). The data suggest that PEF results in a dual effect of IRE-induced cell death and release of soluble factors that stimulate remaining viable cells.

Materials and Methods

All cells were cultured in Dulbecco's modified Eagle's medium (with 4.5 g/L glucose; Gibco) supplemented with 1% Penicillin–Streptomycin solution (Gibco) and 5% fetal bovine serum (Gibco) in an incubator at 37°C and in the presence of 5% CO2 and controlled humidity. Human dermal fibroblasts (passages 3–5) and keratinocytes (HaCaT cells, passages 38–42) were used for in vitro cell culture studies. For cell washing purposes, phosphate-buffered saline (PBS; Gibco) was utilized. A BTX extracellular matrix (ECM) 830 (Harvard Apparatus) was utilized for electroporation studies. High impedance electroporation buffer (from BTX) was used to prevent short circuits and sparks, and isolate a conduction path through the cell monolayer.

Experimental setup for PEF application

PEF application was aided by a machined template cover with guiding holes (1 mm apart) for inserting needle electrodes (600 μm diameter) at specified locations inside individual wells of a 24-well plate. (Fig. 1A, B). PEF was applied by a BTX ECM 830 square wave electroporator.

FIG. 1.

FIG. 1.

Open in a new tab

In vitro customized electrode guiding system designed to fit 24-well plates. (A) Top view of guide covered well where black holes remain open and the two white holes are the ones used here for needle insertion (needle electrode 600 μm diameter), with an edge-to-edge distance of 2 mm. (B) Side view of poly acrylic guide with electrodes inserted in two holes 2 mm apart. The bottom of the needle electrodes reaches the level of cellular monolayer through the electroporation media. (C) Representative PEF waveforms showing pulse width, duration between pulses, and number of pulses (note that pulse width is not to scale). PEF, pulsed electric fields.

Cell monolayer recovery after injury by PEF

For this study, 1 × 105 cells/well (fibroblasts or keratinocytes), were seeded in 24-well plates and allowed to grow to confluence for 72 h. Cell culture medium was removed, cells washed with PBS, and electroporation medium was added to the well. After PEF treatment, the electroporation medium was removed, the cells were washed with PBS, and fresh medium was added. Voltages ranging from 100 to 600 V were applied between the two electrodes (2 mm apart edge to edge), while the other PEF parameters (1 Hz; 70 μs pulse width; 90 pulses per cycle, 1 cycle applied for each sample) remained constant (Fig. 1C).

Wells were imaged by phase contrast (2 × magnification, EVOS cell imaging system; Thermo Scientific), before PEF application, and then at various time points extending up to 120 h post-PEF. Fibroblast controls consisted of monolayers subjected to a similar-sized mechanical scratch injury (as of post PEF application in the voltage range 500–600 V) created using a micropipette tip. Keratinocyte controls also consisted of mechanical scratch injuries but the area was made to match the injury area of PEF application (500–600 V) post 24 h, due to delayed cell death observed in this cell type after PEF. The studies were run in quadruplicate and monolayer recovery was monitored daily up to 96 h.

Images were analyzed using ImageJ software to determine average area and diameter of the cell-free zone (corresponding to the injury). These values were measured and plotted as mean ± standard deviation versus time using Origin Pro-8 software. To analyze recovery curves, straight lines were fitted to the curves taking all the regions of the curve into consideration to obtain the average slope and intercepts. Slope measurement was conducted from the linear fit of the area recovery curves. The slope values were plotted using negative Y-axis for both fibroblasts and keratinocytes as the original curves had negative slopes due to area shrinkage from high to low. The slope measurement plots represent the rate of recovery of the injuries in different voltage applications with respect to controls. We also measured the horizontal (X axis) intercepts of the linear fitted plots of the area recovery curves, which represent the predicted time of closure of the injury.

Detection of ECM deposition post-PEF/mechanical injury

To determine whether PEF-mediated cell removal left some ECM behind, we electroporated (500 V between 2 mm) monolayers of both cell types, washed the monolayers thrice with PBS, and fixed them with 4% paraformaldehyde. Hematoxylin solution (Thermo Fisher) was added onto the sample for 5 min and washed with deionized water thrice. A negative control of mechanical scratch injury was also treated the same way. Color changes were visualized after exposing the samples to 1% acid alcohol for 30 s, followed by staining using Eosin solution (Thermo Fisher) for 2 min, and a three-time wash with deionized water. The samples were dehydrated using an ethanol gradient series. The control for this experiment consisted of cell monolayers killed by exposure to pure deionized water for 1 h and stained by the protocol mentioned above. All samples were imaged using an Olympus microscope with a color camera and images were further processed using ImageJ.

Effect of conditioned media on cells

To collect conditioned media, fibroblasts and keratinocyte monolayers were exposed to PEF as before using 500 V between 2 mm. After PEF and washing of PEF buffer with PBS three times, fresh and warm complete medium was added to the cultures. After 24 h, the conditioned media were collected and applied onto mechanically scratched monolayers of the same cell type. Control media samples from cells that were mechanically scratched over a similar area using a 200 μL micropipette tip (MS) were collected and applied. Additional controls consisted of spent media samples collected from untreated (UT) cell monolayers. Thus, the conditioned media study consisted of six different groups: PEF-fibroblasts to UT fibroblasts, MS-fibroblasts to UT fibroblasts, UT fibroblasts to UT fibroblasts, PEF-keratinocytes to UT keratinocytes, MS-keratinocytes to UT keratinocytes and UT keratinocytes to UT keratinocytes. The monolayer recovery was monitored at 24, 48, and 72 h.

Statistical analysis and curve fitting

All the results are reported as mean ± standard deviation with sample size n = 3, unless indicated otherwise. Student's t-test and analysis of variance were used to evaluate the significance of differences. At least p ≤ 0.05 was considered statistically significant.

Results

Cell monolayer recovery after injury by PEF

The effect of simultaneous cellular ablation and stimulation by a nonuniform electric field was studied by applying voltages ranging from 100 to 600 V (between 2 mm) DC in electric pulses of 70 μs duration with a frequency of 1 Hz at a very short distance above monolayers of fibroblasts or keratinocytes. The effect of PEF on the monolayer morphology was assessed over the course of 96 h.

To determine if this post-PEF behavior resulted from the application of a simulated mechanical wound to the monolayer, a scratch wound of approximately equal size was created. Recoveries of individual monolayers of fibroblasts and keratinocytes to both injury types were compared. In the case of fibroblasts (Fig. 2), the PEF treated cells (600 V applied 2 mm apart) appeared to repopulate the PEF-induced dead zone area (Fig. 2A–D) faster than the mechanically injured cellular monolayer (Fig. 2E–H).

FIG. 2.

FIG. 2.

Open in a new tab

Injury recovery of human fibroblast (HFB) monolayers after treatment with 600 V PEF between 2 mm, or after mechanical scratching (injury control). (A–D) Representative images for PEF-treated monolayers after 0–72 h. (E–H) Representative images for mechanically injured monolayers after 0–72 h. The initial scratch area was purposely made to be similar to that due to PEF. Scale bar: 2 mm. Cell monolayer boundaries of the injuries are outlined manually on the individual images.

Next, we carried out a voltage dose–response between 100 and 600 V (Fig. 3A). When using fibroblast monolayers, increasing voltage generally led to increased initial injury area, which then decreased in size as a function of time. The rate of decrease was fastest initially and then slowed down as the wound area approached zero at 72–96 h. Controls consisting of monolayers with initial mechanical scratch areas similar to that observed with 600 V PEF exhibited a constant rate of decrease until the wound was nearly closed at 96 h (Fig. 3B).

FIG. 3.

FIG. 3.

Open in a new tab

Monolayer scratch injury area recovery as a function of time for fibroblasts (HFB). (A) Recovery plots after applying voltages ranging from 100 to 600 V, 2 mm apart. (B) Recovery plots for two scratch injuries in fibroblast monolayers compared with the initial injury area post-500–600 V PEF. (C) Comparison of slopes (representing average rate of healing) obtained from the recovery kinetics of fibroblasts shown in (A, B). (D) Comparison of horizontal intercepts obtained from recovery kinetics of fibroblasts shown in (A, B). Data are represented as mean ± standard deviation, n = 3. *p ≤ 0.05 and **p ≤ 0.001 with respect to control.

The slope analysis represents the rate of monolayer recovery at different PEF intensities compared with scratch injury controls. In the case of fibroblasts (Fig. 3C), for 500 and 600 V, where the initial injury area is comparable to the initial area of mechanical injury controls, the recovery rate was significantly higher than controls. However, at lower PEF intensities (100–400 V) the recovery rate was lower compared with mechanical injury. The horizontal intercept value provides an estimate of the time of wound closure (Fig. 3D). The wound closure time between different PEF voltages did not change significantly, but was much lower than mechanical injury controls (72–80 vs. >100 h).

Keratinocytes are another predominant skin cell type involved in wound healing. Therefore, we analyzed keratinocyte responses to PEF, where comparably sized injuries were created through PEF (600 V), which were also compared with mechanically scratched monolayers (Fig. 4). PEF-treated keratinocyte monolayers increased wound size between 0 and 24 h post-PEF, after which wound size decreased until disappearance. In contrast, mechanical scratch injuries monotonically decreased in size as a function of time. Thus, while PEF-treated keratinocyte monolayers underwent further wound opening in the first 24 h, subsequent recovery was more rapid than mechanically injured controls. When the PEF and mechanical injury wound area recovery was compared, the complete recovery time was observed to be within 72 h for PEF and >96 h for mechanical injury (Fig. 5A, B).

FIG. 4.

FIG. 4.

Open in a new tab

Injury recovery of keratinocyte monolayers after treatment with 600 V PEF 2 mm apart, or after mechanical scratching (injury control). (A–D) Representative images for PEF-treated monolayers after 0–72 h. (E–H) Representative images for mechanically injured monolayers after 0–72 h. The initial scratch area was purposely made to be similar to the injury area post 24 h after application of PEF of 500–600 V voltage range. Scale bar: 2 mm. Cell monolayer boundaries of the injuries are outlined manually on the individual images.

FIG. 5.

FIG. 5.

Open in a new tab

Monolayer scratch area recovery as a function of time for keratinocytes. (A) Recovery plots after applying different voltages ranging from 100 to 600 V, 2 mm apart. (B) Recovery plots for two scratch injuries in keratinocyte monolayers having areas comparable to the injury area 24 h post-PEF (500–600 V). (C) Comparison of slopes (representing average rate of healing) obtained from the recovery kinetics of fibroblasts at different PEF intensities and two mechanical scratch controls shown in (A, B). (D) Comparison of horizontal intercepts obtained from recovery kinetics of fibroblasts at different PEF intensities and two mechanical scratch controls shown in (A, B). Data are represented as mean ± standard deviation, n = 3. *p ≤ 0.05 and **p ≤ 0.001 with respect to the control.

Next, we quantified the postinjury recovery for voltages ranging from 100 to 600 V. Except for the lowest intensities (100 and 200 V), a biphasic response was seen where wound area initially increased, followed by a decrease at 24 h post-PEF and beyond (Fig. 5A). The quickest injury recovery was observed when 500 V was applied (Fig. 5B).

To further compare and clarify the effect of PEF versus mechanical injury, both the slope and horizontal intercept for different PEF voltages and mechanical scratch injuries were calculated after fitting straight lines to the curves obtained above (Fig. 5C, D).

Similar trends for slope and intercept were also observed for keratinocytes. However, the rate of recovery around 500–600 V was much higher compared with the other PEF intensities and mechanical scratch controls (Fig. 5C). The estimated wound closure times among different PEF voltages did not vary significantly (Fig. 5D), but were collectively much lower than mechanical injury controls (70–90 vs. >140 h). Given these results, 500 V PEF applied 2 mm apart appears to be optimal for both cell types (recovery rate/slope = 11,200 μm2/h in fibroblasts and 7000 μm2/h in keratinocytes).

Mechanism analysis for enhanced cell growth after PEF

We hypothesized that enhanced cell growth post-PEF application may be attributed to either remaining ECM as guiding adherent cues or soluble molecular cues, which may signal neighboring cell infiltration.27 Thus, PEF-treated monolayers were stained for ECM deposition, and the post-PEF-conditioned media were evaluated for its ability to promote cellular proliferation.

First, we assessed ECM deposition post-PEF or mechanical injury. For both keratinocytes and fibroblasts, no significant remaining protein was observed (Fig. 6B, E), which was also the case with mechanical injury (Fig. 6C, F). These results suggest that nominal to negligible ECM remains post-PEF indicating that deposited ECM is not likely a major factor in the recovery of monolayers after PEF treatment. In contrast, protein deposits were clearly visible after hypotonic lysis (Fig. 6A, D).

FIG. 6.

FIG. 6.

Open in a new tab

Comparative morphology of cell monolayers after PEF-induced injury (500 V, 2 mm apart) or mechanical injury. Monolayers were fixed and stained with Hematoxylin and Eosin. (A) Keratinocyte control monolayer after exposure to deionized water to lyse cells while keeping ECM on the surface. (B) Keratinocyte monolayer after PEF. (C) Keratinocyte monolayer after mechanical injury. (D) Fibroblast control monolayer after exposure to deionized water. (E) Fibroblast monolayer after PEF. (F) Fibroblast monolayer after mechanical injury. Scale bar 50 μm. Inset higher magnification images provided: scale 20 μm. ECM, extracellular matrix.

Next, we tested the potential of soluble factors secreted in conditioned media obtained from cellular monolayers post-PEF treatment to promote the healing of standard mechanically scratched responder cells (both fibroblasts and keratinocytes). Three different groups were used to generate conditioned media: (1) intact UT monolayers, (2) mechanically injured monolayers (injury control), and (3) 500 V PEF injured monolayers. Conditioned media were collected after 24 h incubation and applied onto responded cells of the same type. In the case of fibroblasts (Fig. 7), it was evident that recovery of the scratch injury was fastest in PEF-conditioned media (within 48 h) followed by mechanical injury-conditioned and UT monolayer-conditioned media.

FIG. 7.

FIG. 7.

Open in a new tab

Effect of conditioned media (collected 24 h post PEF application) on recovery of scratch wounds in fibroblast monolayers. (A–D) Samples exposed to conditioned media from untreated cells. (E–H) Samples exposed to conditioned media from mechanically scratched cells. (I–L) Samples exposed to conditioned media from containing PEF-treated cells.

We quantifed this response by comparing the area of recovery versus time for fibroblasts (Fig. 8A), and confirmed that PEF-conditioned media caused the responder cells to heal much faster (90% closure within the first 48 h). Furthermore, the slope (Fig. 8B), which reflects the rate of recovery, was significantly steeper (∼3900 μm2/h) compared to that for mechanical injury (∼2000 μm2/h) and UT monolayers (∼2600 μm2/h). The horizontal intercept (Fig. 8C), used to estimate the wound closure time, was also the lowest for the PEF-conditioned media group.

FIG. 8.

FIG. 8.

Open in a new tab

Effect of conditioned media from PEF-treated or mechanically scratched cells on scratched responder monolayers. (A) Wound area recovery as a function of time in the presence of different conditioned media in fibroblasts. (B) Comparison of slopes (rate) of the recovery plot under influence of different conditioned media (fibroblasts). (C) Comparison of horizontal intercepts (probable complete recovery time) of the recovery plot under influence of different conditioned media (fibroblasts) (*p ≤ 0.05 with respect to control [untreated 24 h spent media] and #p ≤ 0.05 with respect to mechanical injury).

When a similar experiment was conducted with keratinocytes (Fig. 9), PEF-conditioned media were also found to promote the fastest wound healing response in the responder cells (Fig. 10B) (PEF: 6000 μm2/h, mechanical injury: 2900 μm2/h and UT monolayer 3500 μm2/h). The estimated wound closure time was also the shortest with PEF-conditioned media (Fig. 10C).

FIG. 9.

FIG. 9.

Open in a new tab

Effect of conditioned media (collected 24 h post PEF application) on recovery of scratch wounds in keratinocyte monolayers. (A–D) Samples exposed to conditioned media from untreated cells. (E–H) Samples exposed to conditioned media from mechanically scratched cells. (I–L) Samples exposed to conditioned media from containing PEF-treated cells.

FIG. 10.

FIG. 10.

Open in a new tab

Quantification of the effect of conditioned media (24 h post PEF application) on recovery of scratch wounds in keratinocyte monolayers. (A) Wound area decreases as a function of time in the presence of different conditioned media. (B) Comparison of slopes (rate of wound closure) for the different conditioned media. (C) Comparison of X intercepts (estimated wound closure time) for the different conditioned media. *p ≤ 0.05 and **p ≤ 0.001 with respect to conditioned media from untreated monolayers, and #p ≤ 0.05 with respect to conditioned media from mechanical injury.

Discussion

Our objective was to combine the lethal and stimulatory effects of PEF upon two major skin cells, dermal fibroblasts, and keratinocytes. We observed that both fibroblasts and keratinocytes are affected by strong nonuniform PEF. High-intensity PEF killed almost all of the cells at the center of the electrodes leaving an open injury. While rapid cell death was expected to take place in the center, in the area where the PEF intensity was below the lethal dose, the cells were observed to infiltrate into the open area more rapidly compared with a mechanical scratch injury of similar size (Figs. 2 and 4).28 This demonstrates that nonuniform PEF can create a dual effect of cell death and cell stimulation.26

PEF induces nanopores by altering the cell membrane potential, which can activate multiple biological pathways.29 PEF is also known to generate reactive oxygen species, which also work as secondary messengers and can contribute to a delayed cell death mechanism.30,31 Our current study indicates that there is delayed cell death in keratinocyte monolayers, which is followed by rapid recovery post PEF application. This phenomenon was completely absent in mechanical injuries. Therefore, application of PEF can affect both death and growth patterns of fibroblasts and keratinocytes, which is critical for wound healing.

Prior studies used high-intensity short-duration PEF as a means to ablate or kill cells or tissues,18,32,33 or low-intensity long-duration PEF for tissue stimulation to heal injuries.34,35 Herein, we bridge the gap between these two phenomena. Thus, nonuniform PEF can potentially be used for injured tissue removal (PEF-mediated debridement) as well as to signal nearby healthy cells to infiltrate. We determined an optimal applied voltage (500 V applied 2 mm apart), which increased the wound closure rate for both cell types we characterized (fibroblasts and keratinocytes) compared with mechanical scratch injuries (Fig. 5). However, we observed very different cell death and regrowth responses between the two cell types. After PEF, fibroblasts followed a monotonous pattern of healing with generally linear kinetics of wound closure. The major impact on fibroblasts of PEF compared with scratch injury was the shorter healing time (Fig. 3). In contrast, immediately after PEF administration to keratinocytes, an injury area developed, which increased in size over the first 24 h, in a form of delayed cell death (Figs. 4 and 5). After this phase, the growth rate of keratinocytes was enhanced drastically. Cell growth eventually slowed when approaching wound closure.

PEF induces nanopores by altering the cell membrane potential, which can activate multiple biological pathways.29 PEF is also known to generate reactive oxygen species, which also work as secondary messengers and can contribute to a delayed cell death mechanism.30,31 These pathways may explain the differences between PEF and mechanical injuries in keratinocytes.36 It is, however, unclear why fibroblasts did not exhibit delayed injury after PEF, an observation which may warrant further study.

Recently, it has been observed that PEF treatment could help skin and liver regeneration with little scar tissue formation.15,16,37 Application of PEF (500 V/mm) and higher number of pulses (1000 pulses) have also been observed to promote scarless healing and preserve secondary organs of skin like hair follicles in rodent models.17 While it has been postulated that PEF kills only cells keeping the tissue ECM architecture intact leading to less scar formation, the exact mechanism that controls these processes is not yet well understood. This in vitro study suggests that leftover ECM is not the major driving force for rapid recovery post PEF. We observed little to no sparing of the ECM on the surface after PEF, as well as mechanical scratch injury (Fig. 6). However, we observed that soluble factors released into the media may be more important contributors to the unusual stimulatory effect of PEF on woud healing in vitro. Furthermore, if we compare the slopes (rate) for PEF-treated fibroblasts and keratinocytes, we observed a faster recovery rate in keratinocytes (fibroblasts: 3900 μm2/h and keratinocytes 6000 μm2/h). Thus, soluble factors present in conditioned media due to PEF treatment might have a bigger impact on keratinocytes than fibroblasts. This may explain the faster recovery of PEF-treated keratinocytes compared with fibroblasts in our studies.

Conclusion

In summary, we observed that nonuniform electric fields can be useful for cell destruction and cell growth simultaneously. Interestingly, the application of PEF may favor keratinocytes over fibroblasts. Fibroblasts were more prone to PEF-induced cell death relative to keratinocytes. The recovery rates of PEF-induced keratinocytes were also observed to be faster with respect to fibroblasts both in direct PEF application as well as secondarily, through application of conditioned media. Further exploration of the application of PEF to different in vitro models would enable us to better understand the underlying mechanisms of previously reported improved in vivo wound healing after PEF in skin and other tissues.16,38
