Comparison of Intrauterine Device Insertion-Related Pain and Ease of Procedure at Different Times During Menstruation

Abstract

Objective

Fear of pain during the copper intrauterine device (Cu-IUD) insertion may lead patients to reject this highly effective birth control method. The aim of this study was to investigate the pain scores associated with IUD insertion and the ease of procedure at different times during menstruation.

Method

In this prospective cohort trial, eligible women received IUD at three-time segments of menstruation: Group I, at 0.5 to 0.69-time segment (n=53); Group II, at 0.7 to 0.89-time segment (n=67); and Group III, at 0.9 to 1-time segment (n=72). The time segments during menstruation were calculated for each participant by dividing the menstrual cycle day of IUD insertion to total number of menses days. The score of pain experienced at different steps of IUD insertion during and five min. after the procedure measured by Wong-Baker FACES Pain Rating Scale (WBS) and the ease of insertion were compared among groups.

Results

There were significant differences in age (p=0.011) and time since the last delivery (p=0.017). After adjusting for potential confounding factors, the mean WBS score and the ease of insertion were not statistically significant among groups, respectively (p=0.664 and p=0.149). The most painful step was observed as uterine sounding (median, 4 [interquartile range {IQR}, 2]). No significant correlation was observed between WBS scores, the ease of insertion, and main characteristics of the participants.

Conclusion

The most painful step of IUD insertion was observed as uterine sounding. IUD insertion-related pain and the ease of procedure do not appear to be different at any time in the second half of menstruation.

Introduction

Implantation of an intrauterine device (IUD) is one of the most common type of contraceptive method and used widely in the world¹. The main concerns of the method are pain experienced during procedure, increased amount of menstrual blodd loss, expulsion of the device, and complications such as perforations.

Fear of pain during IUD insertion may lead patients to reject this highly effective birth control method². Factors that increase the risk of pain during implantation are increased age, being nulliparous, increased duration between the last menstruation or pregnancy and the procedure, not breastfeeding period, having dysmenorrhea, pain anticipation, and insertion of levonorgestrel-releasing intrauterine system (LNG-IUS) rather than copper IUD³. Extensive research has been published aiming to decrease the perception of pain during IUD insertion with no consensus on an effective method^4,5.

The copper IUD may be inserted at any time during the menstrual cycle if pregnancy can be reasonably excluded⁶. IUD insertion during menses may be viewed as preferable by some providers, as it provides reassurance that the woman is not pregnant⁷. Theoretically, placing the device would be easier and less traumatic, thus generating less pain, as the cervical ostium is dilated slightly during menstrual bleeding period. In addition, insertion of the device would be more favorable during menstruation because it might decrease the bleeding duration as it is inserted during the endometrial breakdown⁸.

Objectives

There is no evidence that Cu-IUD insertion at different moments of the menstrual cycle influences pain during insertion^7,8. Therefore, we decided to investigate pain scores associated with IUD insertion and ease of procedure at different times during menstruation.

Material and Methods

Statement of Ethics

The study protocol was in accordance with the ethical guidelines and approval of Goztepe Prof Dr. Suleyman Yalcin City Hospital, Clinical Studies Ethic Committee (Protocol number 2017/0355). Informed consent was obtained from all participants in the study.

Study design and participants

The current study was a single-center, prospective cohort trial conducted from January 2019 through March 2020 at (Goztepe Prof. Dr. Suleyman Yalcin City Hospital). Women who applied to Family Planning Clinic and sought copper IUD insertion were clinically evaluated. The medical eligibility of the patients was based on WHO criteria⁹. Women whom have no contraindications for Cu-IUD insertion were invited to participate the present study. Eligible women were Caucasian, Turkish-speaking, aged 18-49 years, with previous menstrual cycle lengths of 24-34 days, and did not receive any analgesics in the 24 h prior to IUD insertion. Exclusion criteria were dysmenorrhea, dyspareunia, chronic pelvic pain, history of abnormal uterine bleeding, previous history of cervical surgery, presence of uterine abnormalities, endometrial lesions, adenomyosis, fibroids, intrauterine adhesions, patients who requested analgesia, and misplaced IUD (immediately after insertion).

Demographic and clinic characteristics, findings of the gynecological examination were recorded. In our clinic, IUD insertions are routinely performed during the second half of menses. Eligible women received IUD at three-time segments of menstruation: Group I, received IUD at 0.5 to 0.69-time segment; Group II, received IUD at 0.7 to 0.89-time segment; and Group III, received IUD at 0.9 to 1-time segment. The time segments during menstruation were calculated for each participant by dividing the menstrual cycle day of IUD insertion to the total number of menses days. The primary outcome measure was the score of pain experienced at different steps of IUD insertion and five min. after the procedure, measured by the Wong-Baker FACES Pain Rating Scale (WBS). Secondary outcome was determined as the ease of IUD insertion. The ease of insertion was scored as easy, mildly difficult, moderately difficult, and very difficult.

Procedure

Participants were informed that data would be collected using a WBS. Pain medication was not given to the patients to reduce IUD placement-related pain. The study provides IUDs or visits free of charge. Copper IUD (SMB® Copper T 380A, SMB Corporation of India, Mumbai) was inserted to all patients conforming to a standardized protocol. All insertions were applied while women were menstruating in the outpatient setting by two certified and experienced midwives (A.N. and A.I.). After pelvic examination, speculum was inserted into the vagina, and the cervix was cleansed with Povidone-iodine. The tenaculum was placed to the anterior lip of the cervix to stabilize the uterus and provide traction for straightening the cervical canal. Uterine sound was inserted for measurement of the uterine length. Then, the IUD was placed through the cervix using the cannula based on the measured cavity length. The cannula was released leaving IUD inside the uterine cavity and the threads were cut slightly short. Confirmation was done after placement by transvaginal ultrasound that the top of the IUD was at no smaller distance than 20 mm from the uterine fundus¹⁰.

A WBS was used in the evaluation of pain. This scale provides a score ranging from 0, indicating “no pain,” to 10, indicating “maximum pain.”¹¹. Study staff were not blinded because a research assistant held on a sheet of paper showing the WBS in front of the patient asked her to rate the intensity of pain at seven steps during the IUD insertion: 1) Baseline (after placement in the dorsal supine position but before lithotomy positioning), 2) speculum placement, 3) tenaculum placement, 4) uterine sounding, 5) IUD insertion, 6) after speculum removal, 7) 5 min after speculum removal. Following IUD placement, the ease of insertion was recorded by two midwives who were applied all insertions (A.N. and A.I.).

Follow-up

Follow-up visit was scheduled one month after IUD insertion. As a part of the study protocol transvaginal ultrasound was performed to determine the position of IUD, at one month after placement by the same sonographer.

Power calculation and statistical analyses

A power analysis was performed for WBS pain scores during seven steps of IUD insertion by using the Univariate General Linear Model. The statistical power of this study was calculated as 0.979 (97.9%).

Categorical variables were described through absolute frequencies, and continuous variables through median and interquartile range (IQR). Continuous variables were tested with the parametric test Shapiro-Wilk. The Kruskal-Wallis test and chi-square test were used to compare the demographic and clinic characteristics of the study subjects among the groups. The association between WBS pain scores during and five min after insertion and the timing of IUD insertion was assessed using the Kruskal-Wallis test. Potential confounding variables, including age and time since last delivery were controlled by using repeated measures ANOVA. Then, the association between WBS pain scores at procedural steps and timing of IUD insertion was evaluated. Moreover, multinomial logistic regression was used to assess the relationship between ease of procedure and timing of IUD insertion. In this analysis, potential confounding variables, including age and time since the last delivery were controlled. Pearson correlation and Mann Whitney-U test were used to investigate the relationship between WBS pain scores during and after insertion and some demographic and clinic characteristics of the participants.

Results

A total of 192 women were included in the present study, 53 in Group I, 67 in group II, and 72 in Group III (Figure 1). All patients had successful IUD insertion and completed follow-up. There was no adverse event during the study period. After one month, during the transvaginal ultrasound, it was shown that all IUDs were correctly positioned in the uterine cavity. Moreover, there were significant differences in age (p=0.011) and time since the last delivery (p=0.017) between groups (Table 1).

Figure 1.

Flowchart of study subjects undergoing intrauterine device (IUD) insertion.

Table 1.

Comparison of demographic and clinical characteristics between groups.

Characteristics	Group I 0.5 to 0.69-time segment (n=53)		Group II 0.7 to 0.89-time segment (n=67)		Group III 0.9 to 1.0-time segment (n=72)
Quantitative§	median (IQR)	min; max	median (IQR)	min; max	median (IQR)	min; max	p
Age, years	33 (11)	18-47	34 (10)	22-47	36.50 (11)	23-49	0.011*
Body mass index, kg/m2	25.67 (7.50)	16.89-42.97	25.96 (4.64)	17.30-34.89	25.87 (5.80)	17.78-39.45	0.884
Time since last delivery, months	24 (113)	2-288	48 (144)	2-276	108 (149)	2-324	0.017*
Qualitative ‡	Frequency	%	Frequency	%	Frequency	%	p-value
Number of vaginal deliveries							0.338
1	7	38.9	5	33.3	5	27.8
2	15	28.3	21	39.6	17	32.1
>2	13	25.0	14	26.9	25	48.1
Prior abortion							0.278
No	36	30.8	42	35.9	39	33.3
Yes	17	22.7	25	33.3	33	44.0
Prior curettage							0.113
No	47	30.9	52	34.2	53	34.9
Yes	6	15.0	15	37.5	19	47.5
Previous IUD insertion							0.065
No	23	37.1	22	35.5	17	27.4
Yes	30	23.1	45	34.6	55	42.3
Type of delivery							0.829
VD	35	28.5	41	33.3	47	38.2
CS	18	26.1	26	37.7	25	36.2

Abbreviations: Min, minimum; Max, maximum; IQR, interquartile range; IUD, intrauterine device; VD, vaginal delivery; CS, cesarean delivery

The time segments during menstruation were calculated for each participant by dividing the menstrual cycle day of IUD insertion to total number of menses days.

*p<0.05 indicates statistical significance.

^§ Kruskal-Wallis test.

^‡ Chi-square test.

For the primary outcome, the median WBS pain scores at the different stages of IUD insertion and five min after insertion are presented in Table 2. The median WBS score was not significantly different between the groups (p>0.05). Distributions of WBS score differences according to timing of IUD insertion was obtained by using repeated measures ANOVA. After adjustment for potential confounding variables, including age and time since last delivery, the mean WBS score was not statistically significant among the groups (p=0.664) (Figure 2). For the secondary outcome, after adjustment for age and time since last delivery, the ease of IUD insertion was not significantly different among the groups (p=0.149) (Table 2).

Table 2.

Main outcomes of the study.

Primary outcome§: within-group variations in the median pain scores during and 5-minutes after IUD insertion measured using a Wong-Baker FACES Pain Rating Scale
	Group I 0.5 to 0.69-time segment of menstruation (n=53)		Group II 0.7 to 0.89-time segment of menstruation (n=67)		Group III 0.9 to 1.0-time segment of menstruation (n=72)
Procedural Step	median (IQR)	min; max	median (IQR)	min; max	median (IQR)	min; max	p-value
Before IUD insertion	0(0)	0; 2	0(0)	0; 2	0(0)	0; 2	0.736
Speculum placement	2(2)	0; 4	2(2)	0; 4	2(0)	0; 4	0.620
Tenaculum placement	4(2)	2; 6	2(2)	0; 6	4(2)	2; 8	0.445
Uterine sounding	4(2)	2; 8	4(2)	2; 8	4(2)	2; 8	0.895
IUD insertion	4(2)	0; 8	4(2)	2; 10	4(2)	0; 6	0.505
Speculum removal	0(2)	0; 4	0(2)	0; 6	0(2)	0; 4	0.911
5-minute after speculum removal	0(0)	0; 2	0(0)	0; 2	0(0)	0; 8	0.248
Secondary outcome ‡: ease of IUD insertion scores
Difficulty of IUD insertion	19 (50%)		21 (51.2%)		17 (42.5%)		0.149
Easy	14 (36.8%)		12 (29.3%)		16 (40%)
Mildly difficult	4 (10.5%)		7 (17.1%)		5 (12.5%)
Moderately difficult	1 (2.6%)		1 (2.4%)		2 (5%)
Difficult

Abbreviations: Min, minimum; Max. maximum; IQR. interquartile range; IUD. intrauterine device

The time segments during menstruation were calculated for each participant by dividing the menstrual cycle day of IUD insertion to total number of menses days.

*p<0.05 indicates statistical significance.

^§ Kruskal-Wallis test.

^‡ Multinomial logistic regression.

Figure 2.

Distributions of Wong-Baker FACES Pain Rating Scale (WBS) (0= no pain to 10= maximum pain) differences of the participants according to timing of IUD insertion. After adjustment for confounding variables, including age and time since last delivery, repeated measures ANOVA showed that the mean WBS score was not statistically significant among groups (p=0.664).

Figure 3 illustrates the differences in median WBS score at each procedural step differences between the participants. As a result, statistically significant difference was found in median WBS score among the study subjects (p<0.001). While the most painful step was observed as uterine sounding (median, 4 [IQR, 2]), the least pain score was found immediately before the insertion (median, 0 [IQR, 0]).

Figure 3.

Differences in median Wong-Baker FACES Pain Rating Scale (WBS) (0= no pain to 10= maximum pain) at each procedural step by using repeated measures ANOVA. Statistically significant difference was found in median WBS score among the study subjects (p<0.001). While the most painful step was observed as uterine sounding (median, 4 [interquartile range {IQR}, 2]), the least pain score was found immediately before the insertion (median, 0 [IQR, 0]).

The validity was tested using Pearson’s correlation coefficients between all median WBS pain scores and the demographic and clinical variables (age, time since last delivery, gravidity, parity, duration of menstrual period, and body mass index). As a result, no significant correlation was observed between WBS pain scores and above-mentioned characteristics of the participants (p>0.05). Similarly, the chi-square test was used to evaluate correlations between ease of IUD insertion and the characteristics of the study subjects included mode of delivery and prior curettage. Finally, no significant correlation was found (p>0.05).

Discussion

Findings and interpretation

In this prospective cohort trial, after adjustment for confounding variables, including age and time since the last delivery, we found no significant difference in median WBS pain scores and the ease of insertion among groups. While the most painful step was observed as uterine sounding, the least pain score was found immediately before the insertion. Moreover, no significant correlation was observed between WBS pain scores, the ease of insertion and the main characteristics of the participants.

Similarities and differences in relation to other studies

Although IUDs are the highest ranked contraceptive methods in terms of efficacy, a substantial amount of women and medical doctors are known not to prefer using the device due to its painful insertion procedure¹². Various adjunctive measures for reduction of IUD insertion-related pain were studied¹³. A recent systematic review and network meta-analysis that synthesized the evidence about the pharmacologic treatment for pain management of IUD insertion showed that the most powerful pain reliever was lidocaine-prilocaine cream¹². Furthermore, non-pharmacological pain management strategies include psychological preparation and counselling before insertion and verbal anesthesia and distraction during the insertion might reduce pain levels¹⁴. In the review, many authors suggested that further studies focusing on non-pharmacological interventions needed to be conducted and reported in the literature¹³. In this context, we aimed to investigate pain related to IUD insertion and the ease of insertion at different times during menstruation without analgesic use. Our data showed no significant difference in median WBS pain scores and the ease of IUD insertion between groups. Therefore, it may be assumed that Cu-IUD might be inserted at any time segment in the second half of the menstruation regarding perceived pain, as well as ease of insertion.

No published studies has yet demonstrated that Cu-IUD insertion at different time segments of the menses influences pain related to IUD insertion. However, reviewing the literature, we found relatively few studies that have focused on pain-related to IUD insertion within menses or outside menses without pain medication. Kokonya et al. determined the insertion problems including pain related to an IUD insertion during or outside menses. This study comprised 1667 women and showed that pain at the time of Cu-IUD insertion was more common among those who had a Cu-IUD inserted outside menses than during menses. However, they did not report direct statistical comparisons regarding the pain measurement¹⁵. Another study by van der Heijden et al. performed a randomized controlled trial to compare pain perception for the insertion of the levonorgestrel-releasing intrauterine system (LNG-IUS) during menstruation and outside menstruation. They did not find a difference in patient-perceived pain between the groups, stratified for nulliparous and multiparous women⁸. In the other hand, a prospective study in 84 nulliparous women evaluated the expected, immediate, and three-minute pain response following IUD insertion undergoing a first IUD insertion. The authors suggested that immediate pain following IUD insertion was independent of day of cycle¹⁶.

Notably, we found that the most painful step was uterine sounding. In consistent with our results, in a prospective, randomized, controlled, and triple blinded study assessing the effect of eutectic mixture of local anesthetics on IUD insertion pain, the authors suggested that insertion hysterometry was found as the most painful IUD insertion ¹⁷. However, the insertion instructions recommend performing uterine sounding prior to IUD insertion to guarantee proper determination of uterine size and position^18,19. In this context, Ali et al.¹⁹ suggested that Cu-IUD can be inserted successfully without using uterine sound provided using TV/ US prior to insertion in a randomized clinical trial. They concluded that this method related to less pain and greater women satisfaction during insertion with shorter duration.

Strength and weaknesses

The present investigation had the following strengths. Our study has an adequate sample size. All participants used the same type of IUD. We used a standard WBS to measure pain, as it is the most reliable pain measurement tool, and a standardized insertion that involved all steps of IUD insertion. All placements were performed electively. Furthermore, all IUDs were inserted by two specialized midwives, limiting variability in skill among providers. However, this study has a limitation too. It was monocentric.

Open questions and future research

The need for further studies examining adequate and reliable pain relief with IUD insertion is evident²⁰. However, non-pharmacological pain management strategies include timing of IUD insertion might ease to reduce pain levels. IUD insertion during menses may be viewed as preferable by some providers⁷. Currently, many clinicians prefer to do the IUD insertion during or toward the end of a woman’s menstrual period to minimize the complaints of bleeding which usually accompany insertion. Therefore, our study was designed to explore whether anticipated pain during IUD placement can be affected by different times at the second half of the menstruation. We suggest further studies to confirm and extend our findings. Furthermore, it would be great interest to explore the effects of inserting IUDs at different times during menstruation on contraceptive continuation, effectiveness, and safety.

Conclusion

To the best of our knowledge, this is the first study to assess the pain scores during and after IUD insertion and the ease of procedure at different times during menstruation. Our findings revealed that the ease of insertion and the level of pain perceived at any time in the second half of menstruation did not appear to be different. Moreover, the most painful step of IUD insertion was observed as uterine sounding. We suggest further studies to confirm and extend our findings.
