Natural resistance of tomato plants to Tomato yellow leaf curl virus

Abstract

Tomato yellow leaf curl virus (TYLCV) is one of the most harmful afflictions in the world that affects tomato growth and production. Six regular antagonistic genes (Ty-1, Ty-2, Ty-3, Ty-4, ty-5, and Ty-6) have been transferred from wild germplasms to commercial cultivars as TYLCV protections. With Ty-1 serving as an appropriate source of TYLCV resistance, only Ty-1, Ty-2, and Ty-3 displayed substantial levels of opposition in a few strains. It has been possible to clone three TYLCV opposition genes (Ty-1/Ty-3, Ty-2, and ty-5) that target three antiviral safety mechanisms. However, it significantly impacts obtaining permanent resistance to TYLCV, trying to maintain opposition whenever possible, and spreading opposition globally. Utilizing novel methods, such as using resistance genes and identifying new resistance resources, protects against TYLCV in tomato production. To facilitate the breeders make an informed decision and testing methods for TYLCV blockage, this study highlights the portrayal of typical obstruction genes, common opposition sources, and subatomic indicators. The main goal is to provide a fictitious starting point for the identification and application of resistance genes as well as the maturation of tomato varieties that are TYLCV-resistant.

1 Introduction

Tomato (Solanum lycopersicum L.) is one of the ubiquitous and vital crops grown worldwide (Howladar, 2016; El-Sappah et al., 2021a; Abbas et al., 2022). The fruit’s appealingness (sizes, colors, flavors, and forms), widespread use, and synthesis of the medicinal chemicals contribute to an annual increase in consumption (Cheng et al., 2020). Tomato fruits are significant because they provide dietary fiber, antioxidants, vitamins, minerals, proteins, carbohydrates, and other nutrients needed for a healthy human diet (Liu et al., 2020; Alluqmani and Alabdallah, 2022). On the other hand, tomato plants are vulnerable to several ailments, and approximately there are 136 viral species known to be harmful (Qi et al., 2021; Islam et al., 2022).

One of the most severe viral diseases to plague tomato plants is tomato yellow leaf curl virus (TYLCV), brought by a group of phylogenetically related Begomovirusspp, and spread by the whitefly Bemisiatabac (Piedra-Aguilera et al., 2019). TYLCV symptoms in tomato plants are hindered development, chlorosis, leaf curl, and powerless natural product yield (Lapidot and Polston, 2006). In 1932, the TYLCV virus was discovered for the first time in Sudan and the Middle East (Idris and Brown, 2005; Van Brunschot et al., 2010). It has since spread throughout the world’s tropical and subtropical regions, including the Mediterranean Basin, the Far East (Asia), the Caribbean, Australia, North, South, and Central America, and many others ( Figure 1 ) (Czosnek and Laterrot, 1997; Navas-Castillo et al., 1997; Zhang et al., 2009; Péréfarres et al., 2010; Ning et al., 2015; Kil et al., 2016). Recently, it was discovered that TYLCV was seed-distributed (Kil et al., 2016; Kil et al., 2017; Kil et al., 2018). However, the vector Bemisiatabaci (Gennadius) (Hemiptera: Aleyrodidae), notably biotypes B and Q, are responsible for the majority of diseases during transportation (Pan et al., 2012) by the whitefly in its adult stage, Bemisiatabaci, possibly the most bothersome pest of vegetables and other produce (Ning et al., 2015; Pakkianathan et al., 2015).

Figure 1.

The distribution of Tomato yellow leaf curl virus (TYLCV) globally. The global distribution of TYLCV disease is updated by the EPPO Global Database (19 November 2021). The yellow marks indicate present infection, the orange marks indicate reported condition, and the green marks indicate non-reported infection.

Diverse methodologies have been utilized to hinder the spread of TYLCV, including strict quarantine guidelines, traditional rearing, and hereditary designing (Lapidot and Polston, 2006; Polston and Lapidot, 2007). Till today, cultivated tomato varieties have included the Ty-1 to Ty-6 resistance genes from their related species, which has resulted in the development of virus resistance, but it’s crucial to emphasize that this resistance has never been entirely effective (Prasad et al., 2020; Yan et al., 2021; Mori et al., 2022). Ty-1, Ty-2, Ty-3, and ty-5 have all been cloned in recent years (Ren et al., 2022). Ty-1, Ty-3, Ty-4, and Ty-6 genes were all introduced from S. chilenseaccessions and are located on chromosomes 6, 6, 3, and 10, respectively (Zamir et al., 1994; Ji et al., 2007a; Ji et al., 2009b; Kadirvel et al., 2013; Tabein et al., 2017; Gill et al., 2019). The ty-5 and Ty-2 were introgressed from S. peruvianum and S. habrochaites, respectively (Hanson et al., 2006; Hutton et al., 2012). Ty-1 is an allelic variant of Ty-3 that codes for an RNA-dependent RNA polymerase; it is the first resistance locus discovered in S. chilense (LA1969) (Verlaan et al., 2013). The Ty-1 can make geminiviruses more resistant by boosting the viral genome’s cytosine methylation (Butterbach et al., 2014). The Ty-2, a dominant resistant gene on chromosome 11, can confer resistance to some monopartite begomoviruses, including TYLCV, but not to any other monopartite or bipartite begomoviruses like Tomato yellow leaf curl Sardinia virus (TYLCSV) (Barbieri et al., 2010; Prasanna et al., 2015). Ty-4 confers resistance to TYLCV less effectively than Ty-3, which was delivered by introgression from the long arm of chromosome 3 of S. chilense (LA1969) (Ji et al., 2009b). The tomato homolog of the messenger RNA surveillance factor Pelo, implicated in the ribosome recycling phase of protein synthesis, has recently been linked to the ty-5 gene (Anbinder et al., 2009), located on chromosome 4 of S. peruvianum (Lapidot et al., 2015). The Ty-6 gene confers resistance against monopartite and bipartite begomoviruses, completing the protection provided by the known Ty-3 and ty-5 genes (Gill et al., 2019).

The resistance breakthrough fueled the TYLCV dispersion, prompting plant breeders to continually search the wild tomato gene pool for potent new sources of resistance. Immunization schedules, screening and validation of resistance sources, gene discovery and genetic mapping, field evaluation of resistance gene transfer to cultivars and inbred lines, global dissemination, TYLCV symptoms, and immunization techniques are all part of TYLCV resistance breeding programs. The presentation will focus on innate immunity to TYLCV, organized resistance genetic defense, marker-assisted resistance breeding selectable markers, and natural resistance resources. The main objective is to lay the background for future studies into the genes responsible for TYLCV disease resistance.

2 TYLCV symptoms in tomato plants

Earlier study shows that the whole tomato plants were weakened by TYLCV infection, and there was a significant decrease in the yield. After inoculation, the first TYLCV symptoms on tomato plants appear 2-4 weeks later and may take up to two months to fully manifest (Ioannou, 1985). The virus isolates, host genetic background, ambient conditions, development stage, and physiological state of the tomato plant at the time of infection influence the kind and intensity of symptoms (Mauck, 2016). The leaflets of newly emerged leaves curl downward and inward in a hook-like pattern early after infection (Salati, 2001) ( Figure 2 ). Afterward, leaves are distorted and narrower with chlorosis in the center and edges and leaflet margins curling upward (Vallad et al., 2018). The underside of leaflets may also be stained purple (Gorovits et al., 2013; Ibne-Siam-Joy, 2020).

Figure 2.

Typical symptoms of TYLCV, (A) Normal plant showed no infection, (B) Infection at a very early stage between 2 to 4 weeks post-infection, (C) tomato plant after five weeks infection, (D–F) Infection at a late stage where the plants show severe symptoms consisting of marked yellowing, puckering, and severe size reduction in the top leaves.

Temperatures exceeding 25°C can aggravate leaf symptoms (Polston and Lapidot, 2007; Anfoka et al., 2016). Infectious plants showed severe symptoms such as yellowing, curling, and a significant loss in apical leaf size (Lapidot et al., 2001). The leaves curl between the veins, and the midrib may become arched And thepetioles twisting can be seen in elder leaves (Shankar et al., 2014). The leaf surface was found to have pale yellow dots that grew larger with time (Gorovits et al., 2013) which is, however, a less prevalent symptom. Tomato plants contaminated with TYLCV were significantly stunted, with numerous branchlets and reduced internodes (Davino et al., 2006; Shankar et al., 2014). Due to increased flower shedding, young, early-affected plants are frequently infertile. Since most blooms (>90%) droop after infection, there is almost no fruit. As a result, yield reductions are more significant when plants are infected prematurely. Late-stage infections can drastically diminish the yield of new fruit. Infected plants produce fewer and smaller fruits that come off easily. Fruit ripens appropriately and is likely to bear before infection (Dam et al., 2005).

3 Methods for identifying resistance to TYLCV in tomato

In vivo and in vitro approaches are used to test the rate of TYLCV infection and understand the processes of plant resistance to TYLCV as shown in Figure 3 .

Figure 3.

Methods for Identifying Resistance to TYLCV in Tomato; (A) Inoculation types, followed by (B) PCR screening method. This figure was made using BioRender.

3.1 In vivo infection

3.1.1 Natural whitefly field infection

It is a method for the testing of TYLCV resistance and essential to recognize hotspots and favorable seasons for effective screening under natural disease conditions (Dhaliwal et al., 2020). The two types of field infection are controlled greenhouse inoculations and spontaneous field inoculations (Lapidot, 2007). Even under intense inoculation pressure, many plants resist infection, proving that spontaneous field infection is frequently ineffectual (Vidavsky et al., 1998). Only 50% of susceptible tomato plants with whiteflies and TYLCV infections became infected within the first month of germination in whitefly and TYLCV-infested areas. Only 10% of sensitive plants survived the infection 90 days after transplantation despite rising whitefly numbers and easily accessible viral inoculums (Vidavsky et al., 1998). Another study by Cohen et al. (1988) discovered that the percentage of virus-carrying whiteflies in the general whitefly populace in the field was deficient. Only 3-6 percent of whiteflies obtained in the wild can spread the virus based on the TYLCV-sensitive host from which they were taken.

It should be emphasized that a sensitive plant evading inoculations may be employed as a resistant parent in subsequent crosses if it is (inadvertently) checked for resistance. A deluge of supposedly resistant yet sensitive plants can quickly jam breeding operations. Therefore, choosing tomato plants only based on an infected field’s lack of symptoms may be deceiving (Vidavsky et al., 1998). In addition to facilitating inoculate outbreaks, spontaneous field inoculations have other drawbacks. Due to late and asynchronous infection, inoculations may result in less severe disease symptoms than controlled inoculations. (Picó et al., 1998). Compared to plants infected at a younger age, plants inoculation at a mature age may have milder symptoms. Milder symptoms could be misconstrued as signs of genetic resistance instead of just late infection. Several TYLCV-resistant cultivars respond sensitively to controlled greenhouse inoculations, whereas field inoculations result in resistance levels comparable to other, more resistant cultivars (Picó et al., 1998). The response of resistance sources to TYLCV may differ depending on the inoculation technique used, with controlled greenhouse inoculations corresponding to high inoculum concentrations and spontaneous field inoculations corresponding to low inoculum concentrations. The most sensitive genotypes might be excluded by field testing, despite the low and delayed incidence of illness following spontaneous field inoculations (Picó et al., 1998; Picó et al., 2000; Lapidot, 2007). Another issue with spontaneous field inoculations is that TYLCV-resistant plants could incorrectly be labeled sensitive after contracting unrelated viruses or other diseases. Whitefly stress, inoculation intensity, viral inoculum size, and plant age were unknown variables in field the inoculations. Also unknown is the interval between getting the whitefly and the virus’s propagation. Like all begomoviruses, TYLCV is spread via a sustained, cyclical process from its whitefly vector. Although transmission can continue for the duration of the vector’s existence, transmission efficiency degrades over time, as demonstrated in TYLCV (Cohen and Harpaz, 1964; Picó et al., 1998; Lapidot et al., 2001).

Consequently, it is unknown and impossible to replicate the effectiveness of field inoculations. Several metrics can be used to compare inoculation effectiveness in controlled greenhouse inoculations to spontaneous field inoculations. The researchers administering the inoculations during controlled greenhouse can change the whitefly age, feeding time, transfer nutrition time, number of whiteflies per infected plant, and so on. It should be remembered that when used as viral vectors, whiteflies can cause significant damage to plants as well as transmit viruses. Whiteflies devour plants by over-juicing, secreting honeydew (which encourages the formation of black mold), and creating systemic illness (Schuster et al., 1990; Byrne and Bellows, 1991). Whitefly inoculations feed on target plants, therefore, need long enough to include successful inoculations but short enough to limit direct whitefly harm. After exposing young tomato seedlings to a large number of virus-carrying whiteflies (about 30-50 whiteflies per plant, which transmit the virus to plants by feeding with almost 100% efficiency) for 48 hours (commercially acquired feeding), all sensitive controls were infected with TYLCV (Lapidot et al., 1997).

3.1.2 Whitefly inoculation in cages

For TYLCV screening, whitefly-mediated mass inoculation or individual plant inoculation is commonly used. Non-preference issues could arise even with carefully regulated greenhouse inoculations. Whiteflies prefer to feed on other tomato plants when inoculating various plants in the same spot (Legarrea et al., 2020). They are inefficient at inoculating one specific type or variety and dislike most physical obstacles in tomatoes, including waxy or thick cuticles or specific trichomes, which hinder whiteflies from colonizing and feeding on those leaves (Bellotti and Arias, 2001). When inoculating wild tomato cultivars, this issue is most apparent. Adding some wild species seems to help prevent infection when looking for new sources of resistance because they are not preferred by whiteflies (Picó et al., 1998). One inoculation of many wild tomato cultivars in cages can solve the non-preference issue. In this instance, a plant is put in a cage with virus-carrying whiteflies, forcing them to feed on the target plant because it is the only plant they will consume (thus spreading the virus). Precision work, or the lack thereof, is another issue that has emerged since the widespread administration of the whitefly vaccine. It is practically impossible to determine the proper number of whiteflies per plant and which leaves to target for inoculation when vast numbers of plants are infected on a big scale. Whiteflies can be precisely controlled using clip cages or leaf cages. Managing the number of whiteflies used per plant, their age and gender, the precise length of the acquisition access period (AAP) and the inoculation access period (IAP), and the TYLCV inoculation location are all advantages of clip cage inoculation (Lapidot, 2007). Because cages allow all test plants to employ the same whitefly-mediated inoculation circumstances, they also make it possible to compare how various plants react to TYLCV infection, for instance, when comparing plants with varying degrees of viral resistance. The clip cage is a tiny cylinder of clear plastic with both sides clipped off. One side of the cage has a thin mesh cover that may be opened to suck whiteflies into the cage. A clip may quickly fasten to the opposite side’s bottom of the preferred wing. The AAP claims that physical barriers like gills, waxy or thick cuticles, or the presence of certain trichomes that prohibit whiteflies from colonizing and feeding on such leaves are to blame for a known number of whitefly-by-whitefly epidemics (Bellotti and Arias, 2001).

3.1.3 Non-whitefly-mediated inoculation

Other non-whitefly-mediated inoculation techniques are required because whiteflies must be bred to improve a time-consuming and laborious TYLCV-controlled inoculation protocol (Kil et al., 2016; Dhaliwal et al., 2020). Mechanical TYLCV transfer has been attempted using various sources and test plants (Lapidot, 2007). When using datura (Datura stramonium) plants as parent plants, the highest mechanical TYLCV transmission rates only reached less than 17%. Only 12% of tested plants, such as the datura, were successful (Dhaliwal et al., 2020). The transmission was not achieved during mechanical inoculation utilizing tomato plants as the parent and test plants (Makkouk et al., 1979). As a result, even though TYLCV can be mechanically transmitted, the success rate is too low to support the creation of a successful inoculation regimen using this technique. To immunize against TYLCV, inlay inoculations are used. In this technique, the test plants are either grafted onto scions infected with TYLCV or laterally with the infected plants’ leaves or tips (Pereira-Carvalho et al., 2015; Koeda et al., 2020). Graft inoculation has been used to identify plants resistant to TYLCV with increasing transportation effectiveness (Pico et al., 2001; Leibman et al., 2015). The characteristic of graft inoculation is the ongoing exposure of test plants to the highest concentrations of viral inoculums. Grafting is a method that can be used to test resistance. When resistant plants were grafted with TYLCV-symptomatic leaves, the plants remained symptom-free (Friedmann et al., 1998). (Kegler, 1994; Friedmann et al., 1998). Graft inoculation is ineffective as a mass inoculation technique because it is labor-intensive and time-consuming (Sastry and Zitter, 2014).

3.2 In vitro infection/agroinoculation

Agroinoculation inoculation is yet another TYLCV inoculation test (Czosnek et al., 1993; Kheyr-Pour et al., 1994; Lucioli et al., 2003; Mori et al., 2021). A. tumefaciens is employed for agroinoculation to introduce cloned viral DNA into host cells (Grimsley et al., 1986; Lu et al., 2003; Delbianco et al., 2013). Tandem repeats (or 1.5–1.8 -mers) of the viral genome are cloned into the T-DNA of the Ti plasmid of A. tumefaciens in the case of TYLCV and another geminivirus before being injected into plants. Replicates are widespread systemically in plants due to genome-sized viral DNA forms, which also cause disease symptoms (Stenger et al., 1991). Agroinoculation is a popular technique used to inoculate plants or leaf discs with geminiviruses. It has been suggested that agroinoculation be utilized as a test technique for TYLCV inoculation and screening of resistant plants because it has been used successfully to introduce the virus into leaf discs and entire plants (Czosnek et al., 1993; Kheyr-Pour et al., 1994). However, it has been demonstrated that cloned TYLCV DNA delivered through agroinoculation inoculation can surpass the virus’s natural resistance in wild tomato species (Abhary et al., 2006; Maliano, 2021).

The effectiveness of agricultural immunization for testing of TYLCV resistance was shown to be dubious (Kheyr-Pour et al., 1994). The usefulness of agricultural immunization as a technique to test various wild and farmed tomato genotypes for TYLCV resistance was recently examined (Pico et al., 2001). Rub agroinoculation (rubbing emery-dusted leaves with an Agrobacterium tumefaciens suspension) led to irregular, weak infections and failed to distinguish between genotypes with various levels of resistance (Pico et al., 2001; Lapidot, 2007). Although the inoculation rate of susceptible controls was 100%, the inoculation efficiency of resistant genotypes was lower. Agrobacterium inoculation of the strain (injection of A. tumefaciens suspension into the strain) was more successful (Lapidot, 2007). It was determined that agricultural immunization might be employed in breeding programs but only as an adjunct to immunization against whiteflies (Pico et al., 2001).

Plants have also been vaccinated with Bergomo virus DNA using particle bombardment (gene gun inoculation) (Garzón-Tiznado et al., 1993). Biolistic Inoculation of cloned Bergomo virus DNA per unit-length (monomer) or tandem repeats (dimer) results in high inoculation efficiency by removing time-consuming DNA manipulation and enabling the inheritance of bergomovirus analysis (Bonilla-Ramírez et al., 1997). Although biolistic inoculation of viral DNA monomers still presents in the cloned plasmid has been proven to be possible, it has only been accomplished after the viral clones removed from the plasmid increased vaccination rates (Liu, 2011; Ceniceros-Ojeda et al., 2016).

However, biolistic inoculation has only been observed in begomoviruses: only the tomato leaf roll Karnataka virus has undergone biolistic inoculation using fractional DNA dimers cloned from monopartite begomoviruses. It served as the initial evidence in 2002 (Chatchawankanphanich and Maxwell, 2002). Tomato yellow leaf curl Sardinia virus (TYLCSV) and TYLCV-[Cu] (a TYLCV strain from Cuba) were used in the first documented biolistic inoculation of TYLCV in 2003 (Ramos et al., 2003). TYLCSV clones were contagious following biolistic vaccination (for unclear reasons), but neither virus was contagious following agroinoculation vaccination (Ramos et al., 2003). Finally, plants with DNA in dimer form were cloned from the TYLCV-[Alm] (Almeria isolate), TYLCV-Mld (mild strain), and TYLCV (Morilla et al., 2005).

Examination of transgenic plants for TYLCV resistance involving in vivo vaccination methods under open climate or non-proficient nursery conditions is troublesome because of stringent guidelines on the genetically modified organisms (Ben Tamarzizt et al., 2009). Subsequently, a controlled immunization convention should be laid out to forestall the unwanted spread of the virus into the climate, mainly while testing new virus strains or recombinants. Two past reports portrayed the improvement of a virus vaccination framework reasonable for in vitro plants (Russo and Slack, 1998; Mazier et al., 2004; Al Abdallat et al., 2010). Utilizing the described system, in vitro-developed plants can be effectively inoculated utilizing mechanical procedures. The rule of the new vaccination technique is to submerge the foundation of the plant in an answer containing agrobacterium with an irresistible TYLCV clone. Al Abdallat et al. (2010) fostered a novel and proficient technique for in vitro immunization of tomato plants with TYLCV. This technique has been successfully used to uncover TYLCV opposition in wild tomatoes and permit stockpiling and spread of contaminated tomato plants under appropriately controlled conditions. Starting screening of transgenic plants with further developed protection from TYLCV utilizing the portrayed in vitro method is suggested

4 Natural resources resistant to the TYLCV in tomato

Natural TYLCV-resistant germplasm resources have been studied and characterized in numerous tomato lines, genotypes, and cultivars over the last few decades, most of which are addressed in Table 1 . S. pimpinellifolium, S. peruvianum, S. chilense, S. habrochaites, and S. cheesmaniae are wild tomato that have been the focus of plant breeders’ efforts to uncover natural sources of virus resistance (Yan et al., 2018). Ty-1’s initial source was LA1969, (Verlaan et al., 2011; Verlaan et al., 2013) and Ty-2 from S. habrochaites f. glabratum accession “B6013” (Yang et al., 2014). The self-incompatible and heterogeneous S. chilense wild tomato variety produces numerous alleles of the same gene in a single accession (Bai et al., 2004). LA1932 demonstrates that resistance allele 35 exists for Ty-1/Ty-3 and Ty-4 (Ji et al., 2009b). In LA2779, Ty-3 and Ty-6 were also discovered (Hutton and Scott, 2013). The potential that previous S. chilense-derived lines carry various resistance genes for TYLCV resistance in accordance with the selection process and heterogeneity of S. chilense (Caro et al., 2015). Finally, several tomato varieties and cultivars have recently been introduced around the world through various breeding programs, such as Yarkiy (Rumyanets), Malinovyi (Slon), and Nicola in Kazakhstan (Pozharskiy et al., 2022). Quamruzzaman et al. (2021) evaluated 75 tomato entries in Bangladesh for resistance to TYLCV infection, and 47 showed zero percent infection. Furthermore, in Egypt, two new tomato lines (TYG-1-3 and KIS-N-2-1) were resistant to TYLCV infection (Elmorsy et al., 2021). Hussain et al. (2022) screened 24 lines in Pakistan for TYLCV using disease scoring and TAS-ELISA; seven accessions, Acc-17890, AVR-261, CLN-312, AVR-321, EUR-333, CLN-352, and CLN-362, expressed resistance to TYLCV.

Table 1.

Tomato resources resistance to TYLCV.

Genotype/Lines/Cultivars	Material Source	Resistance Gene	Notes	References
LA1969	S. chilense	Ty-1	Source of resistance	(Zakay et al., 1991; Laterrot, 1993; Zamir et al. 1994)
LA1932, LA1938, LA1960, and LA1971	S. chilense	Ty-1/Ty-3	Resistance	(Yan et al., 2018)
LA1961	S. chilense	Ty-1or Ty-4 or Ty-6	Resistance	(Scott and Schuster, 1991)
LA 1968	S. chilense	-	Resistance	(Scott and Schuster, 1991)
TY52	S. lycopersicum	Ty-1	Resistance	(Wang et al., 2018b)
LA3473	S. chilense	Ty-1	Resistance	(Prasanna et al., 2015)
LA1932	S. chilense	Ty-1	Resistance	(Ji et al., 2007a)
CLN2513, CLN2514, and CLN2515	S. lycopersicum	Ty-1	Contain combined resistance derived from Ty-1 and Ty-2.	(Yan et al., 2018)
BL982		Ty-1	Resistance	AVRDC (2002) (Yan et al., 2018)
B6013	S. habrochaites	Ty-2	Resistance	(Hanson et al., 2000; Hanson et al., 2006)
CLN2777A	S. lycopersicum	Ty-2	Resistance	(Wang et al., 2018b)
CLN2585D	S. habrochaites	Ty-2	Resistance	(Prasanna et al., 2015)
CLN2513, CLN2514, and CLN2515		Ty-2	Resistance	(Yan et al., 2018)
CLN2116	S. lycopersicum	Ty-2	Resistance	AVRDC (2002) (Yan et al., 2018)
LN2460G, CLN2460H, CLN2460I, CLN2460J, CLN2463O, and CLN2463P	S. lycopersicum	Ty-2	Resistance	(Yan et al., 2018)
LA2779/LA1938 LA4440	S. chilense	Ty-3	Resistance	(Ji et al., 2007a)
LA1932	S. chilense	Ty-3a	Resistance	(Ji et al., 2007a)
CA4 and GC171	S. chilense	Ty-3	Resistance	(Prasanna et al., 2015)
LA1969	S. chilense	Ty-3b	Resistance	(Ji et al., 2007a)
LA1932	S. chilense	Ty-4	-less efective against TYLCV. -Increase resistance levels in combination with Ty-3	(Ji et al., 2009b; Kadirvel et al., 2013)
GC171 LA4440	S. chilense	Ty-4	Resistance	(Prasanna et al., 2015; Lee et al., 2020)
Tyking	S. lycopersicum	ty-5	Recessive resistance	(Lapidot et al., 2015)
LA1938	S. peruvianum	ty-5	Recessive resistance	(Anbinder et al., 2009; Hutton et al., 2012)
TY172	S. peruvianum	ty-5	Recessive resistance	(Friedmann et al., 1998; Anbinder et al., 2009)
AVTO1227	S. lycopersicum	ty-5	Recessive resistance	(Wang et al., 2018b)
Fla.8753, Fla. 344 and Fla.8062	S. chilense	ty-5	high level of resistance due to the presence of ty-5 and Ty-6.	(Hutton et al., 2012; Scott et al., 2015)
Fla.8624 and Fla.8638B	S. chilense	Ty-6	moderate level of resistance	(Scott et al., 2015)
LA2779	S. chilense	Ty-6	Resistance	(Scott et al., 2015)
Fla.8753, Fla.344 and Fla.8062	S. chilense	Ty-6	Introduce high level of resistance due to the presence of ty-5 and Ty-6.	(Hutton et al., 2012; Scott et al., 2015)
Fla.456	S. chilense	Ty-6	Resistant	(Bian et al., 2007; Gill et al., 2019)
UPV-16910	L. hirsutum	–	partially tolerant	(Picó et al., 2002)
PI-126944b	Lycopersicon hirsutum (L. hirsutum)	–	Resistant	(Picó et al., 1998; Roselló and Nuez, 1999)
PI-211840	S. pimpinellifolium	–	Resistant	(Scott and Schuster, 1991)
LA386	L. hirsutum	–	Resistant	(Scott and Schuster, 1991)
PI 212408, LA373, LA1582, LA1478 and Hirsute	S. pimpinellifolium	–	Resistant	(Scott and Schuster, 1991)
TY-20, LA 121and EC 104395	L. esculentum	–	Resistant	(Scott and Schuster, 1991)
LA 1401	L. cheesmanii	–	Resistant	(Scott and Schuster, 1991)

5 Natural genes resistant to TYLCV in tomato

Six distinct genes (Ty-1, Ty-2, Ty-3, Ty-4, ty-5, and Ty-6) are located on different tomato chromosomes ( Figure 4 ) and provide varying levels of resistance in wild germplasm when transfected into commercial cultivars (Anbinder et al., 2009; Hutton and Scott, 2013; Prabhandakavi et al., 2021). Except for ty-5, which has recessive inheritance, all of these genes are dominant resistance (Ren et al., 2022). Ty-1, Ty-3, Ty-4, and Ty-6 are derived from S. chilense (Hutton and Scott, 2013), whereas Ty-2 and ty-5 may be derived from S. habrochaites and S. peruvianum, respectively (Anbinder et al., 2009; Wolters et al., 2015). It is now possible to introduce resistance genes without causing cross-resistance or to pyramid numerous resistance genes in marker-assisted breeding thanks to the development of molecular biotechnology.

Figure 4.

Mapping of TYLCV resistance genes on tomato chromosomes. (A) The site of Ty-4 on chromosome 3 of S. chilense cv., (B) the site of ty-5 on chromosome 4 of S. peruvianum cv., (C) the site of Ty-1, Ty-3 and Ty-3a on chromosome 6 of S. chilense cv. (LA1969, LA2279 and LA1932 respectively), (D) the site of Ty-6 region on chromosome 10 of S. chilense (LA2279) and (E) the Ty-2 region on chromosome 11 of S. habrochaites cv.

5.1 Ty-1

Ty-1 was included in LA1969 from S. chilense (Verlaan et al., 2011; Verlaan et al., 2013). The first was identified and located on tomato chromosome 6’s short arm by Zamir et al. (1994). Ty-1 is related to the Mi-1 gene cluster at the REX-1 locus, indicating that Ty-1 is derived from the short arm of chromosome 6 (Milo, 2001). Ty-1 was discovered on the long arm of chromosome 6 and linked to the Ty-3 locus (Pérez de Castro et al., 2013). de Castro et al. (2007) found that Ty-1 is associated with the CT21 marker, which is situated below the long arm’s centromere, in a different investigation. Also, Ty-1 has recently been fine-mapped and cloned, and it has been shown to contain an allele of a gene coding for an RNA-dependent RNA polymerase (RDR) (Verlaan et al., 2011; Verlaan et al., 2013). The Ty-1 gene thus represents a distinct family of genes that increase the transcriptional silence of viral genes to confer disease resistance or tolerance. Recent research has demonstrated that in genetically modified N. benthamiana plants, the Ty-1 gene can also confer resistance to the beet curly top virus (a genus Curtovirus) (de Nazaré Almeida dos Reis et al., 2020; Voorburg et al., 2020). More research is needed to determine the effect of the Ty-1 gene on ssDNA viral and subviral diseases associated with tomatoes in the Neotropics. More viruses (14 versus 6 species) were found in tomatoes lacking the Ty-1 gene, including a gemycircularvirus (Genomoviridae), a new alpha-satellite, and two novel Begomovirus species (de Nazaré Almeida dos Reis et al., 2020; Nehra et al., 2022). A novel Begomovirus was found only in the Ty-1 pool in the de Nazaré Almeida dos Reis et al. (2020) survey, and it was the only species associated with severe symptoms in Ty-1 plants. Three ORFs were predicted to be T-y1/Ty-3, and the Ty-1 gene has been identified as genomic alleles for genes Ty-3, Ty-3a, and Ty-3b (Jensen et al., 2007; Ji et al., 2007a; Verlaan et al., 2011; Verlaan et al., 2013). Though since plants with this factor allow for a minor onset of symptoms, primarily in the apical meristem region, and then gradually recover as the plant grows/develops, phenotypic expression of the Ty-1 gene is more accurately described as a tolerance response (Cooper and Jones, 1983; de Nazaré Almeida dos Reis et al., 2020). Finally, Ty-1 is the most common resistance gene used in tomato breeding. TYLCV, on the other hand, undermines Ty-1 resistance when co-infected with a betasatellite. This suggests that the TYLCV/betasatellite complex can bypass the commonly used Ty-1 resistance gene (Ren et al., 2022).

5.2 Ty-2

Hanson et al. (2000) were the first to report the presence of a resistance introgression (Ty-2) derived from S. habrochaites accession B6013 in the tomato-resistant line H24, which was developed from S. habrochiates f. glabratum accession ‘B6013’ (Kalloo and Banerjee, 1990) and contains an introgression spanning at least 19 cM from TG36 (map position 84 cM) to TG393 (103 cM) (Ji et al., 2009a). According to Ji et al., the Ty-2 gene was restricted in a 500kb introgressed region between markers C2 At2g28250 (physical location 51.307Mb) and T0302 (51.878 Mb) (2009). Later, Yang et al. (2014) reduced the Ty-2 region to a 300 kb distance between markers UP8 (51.344 Mb) and M1 (51.645 Mb) at the end of chromosome 11’s long arm (Barbieri et al., 2010). Ty-2 is one of the essential TYLCV resistance genes used in tomato breeding, but it is ineffective against many TYLCV strains worldwide (Shen et al., 2020). Numerous tomato breeding projects have attempted to identify recombinants containing Ty-2 and I-2, but have so far been unsuccessful. Ty-2 is intimately associated with susceptibility to Fusarium wilt race 2, and efforts to date have been ineffective (Ji et al., 2007a). There have been numerous attempts to define the gene structure and produce a perfect map of the Ty-2 locus. However, there is no concrete proof that a particular gene is responsible for Ty-2-mediated resistance (Yamaguchi et al., 2018).

5.3 Ty-3

Ty-3 was identified in S. chilense accessions such as LA1932, LA1938, and LA2779, and it was first located on the long arm of chromosome 6 in these accessions (Ji et al., 2007a). Resistance to the TYLCV and begomovirus tomato mottle virus (ToMoV) is possible (Ji et al., 2007a). Ty-3 and Ty-1 areas overlap, indicating the potential for alleles (Verlaan et al., 2013). Ty-1 and Ty-3 have been focused breeding efforts that have been joined to create trade hybrids around the globe. The Ty-1/Ty-3 gene from chilense (LA1969) encodes an RNA-dependent RNA polymerase that participates in antiviral RNA silencing and was the first and only TYLCV dominant resistance gene to be cloned. Ty-1 and Ty-3 are RDR type homologs of A. thaliana RDR3, RDR4, and RDR5 genes, which have yet to be assigned functions (Verlaan et al., 2013).

Increased amounts of TYLCV-specific siRNA targeting the V1 promoter area were seen in plants with Ty-1/Ty-3, along with cytosine methylation in the region’s promoter, which suggested an increased transcriptional gene silencing (TGS) resistance mechanism (Butterbach et al., 2014). In Solanum species, the catalytic region of the Ty-1/Ty-3 gene is conserved S. chilense, and six other wild species of Solanum have a 12-base pair introduction in Ty-1/Ty-3, albeit it is not entirely linked to TYLCV resistance. SNPs targeting resistant Ty-1/Ty-3 alleles can improve allele-specific markers (Caro et al., 2015). However, the co-dominant SCAR marker P6-25 was utilized to identify the Ty-3, Ty-3a, and Ty3b alleles in three Chinese accessions, LA2779, LA1932, and LA1969, at a distance of 25 cM. Tomato with begamovirus resistance (Ji et al., 2007a; Ji et al., 2007b).

5.4 Ty-4

Ty-4 originated from S. chilense accession LA1932; it has been located on the third chromosome’s long arm (Ji et al., 2009b; Dhaliwal et al., 2020). Only 15.7% of the entire variation was accounted for by Ty-4, which had no impact on TYLCV resistance; in contrast, 59.6% of the variation was accounted for by Ty-3, which originated from S. chilense (Ji et al., 2009b). Although we did not test for bipartite begomovirus, Ty-4 is efficient against TYLCV. However, in Guatemala, inbred lines carrying both Ty-3 and Ty-4 were more resistant than lines carrying just Ty-3 (D.P. Maxwell, unpublished data), showing that Ty-4 is resistant to a number of (up to 7) bipartite begomoviruses that are active, and these viruses are likely prevalent there (Nakhla et al., 2005). Compared to other Ty genes, Ty-4 is less efficient against TYLCV (Kadirvel et al., 2013).

5.5 ty-5

The ty-5 has been identified in the tomato reproducing line TY172, which is descended from four different elevations of S. peruvianum (PI126926, PI126930, PI390681, and LA0441) (Friedmann et al., 1998; Hutton et al., 2012; Lapidot et al., 2015). The genetic analysis has shown that ty-5-mediated blockage on chromosome 4 is constrained by a substantial quantitative trait loci (QTL) (Anbinder et al., 2009). The ty-5 co-isolates with the marker SlNAC1 and is acquired latently (Anbinder et al., 2009; Hutton et al., 2012). It should be merged into the two guardians of a crossover, according to ty-5 features. However, the ability to apply related markers will consider a skillful fusion of this allele into cutting-edge material by marker-assisted selection. The ty-5 confers broad-spectrum resistance to geminiviruses and was effective against two representative begomoviruses in China, TYLCCNV/TYLCCNB and TbLCYnV. ty-5 also provided partial resistance to BCTV, a virus in the Curtovirus genus. Subsequently, ty-5 was resistant to TYLCV co-infected with a betasatellite (Ren et al., 2022).According to Levin et al. (2013) cloning study, the ty-5 gene codes for a pelota homolog related to protein translation. TYLCV opposition is linked to a T-to-G transversion in the pelota allele’s coding region. The ty-5 gene demonstrates that the Pelota gene is a TYLCV host susceptibility factor by addressing the functionality of the Pelota gene’s allele (Lapidot et al., 2015). Loss-of-work mutations have demonstrated resistance to various Gemini viruses at the Pelo homologous locus (Yan et al., 2021).

5.6 Ty-6

The Ty-6 is generated from S. chilense accession LA2779 and is a newly discovered TYLCV resistance locus (Hutton and Scott, 2014; Scott et al., 2015; Gill et al., 2019). According to preliminary mapping data, it is located in a region of about 3 Mb on the long arm of chromosome 10 (Gill et al., 2019). A notable discovery was the identification of Ty-6, which expands breeders’ toolkit of Ty genes and confers resistance to bipartite and begomoviruses monopartite (Prasad et al., 2020; Gupta et al., 2021). Contrary to popular belief, Ty-6 is primarily responsible for ToMoV resistance in lines such as Fla. 8680, not Ty-3 (Scott et al., 2015; Gill et al., 2019).

Similarly, even though ty-5 and Ty-6 work together to cause TYLCV in lines like Fla. 8638B and Fla. 8472, Gill et al. (2019) discovered that ty-5 is ineffective against ToMoV and that the existence of Ty-6 in such lines is what causes the bipartite resistance. Given that S. chilense is in the pedigree of all Ty-6-containing UF/IFAS lines evaluated thus far, Scott et al. (2015)‘s claim that this species was the source of Ty-6 in Fla. 8624 and Fla. 8638B is probably accurate. Ty-6 will probably be very helpful for many tomato breeding efforts worldwide due to its wide efficacy against mono- and bipartite begomoviruses and the complementing resistance it provides when combined with other genes (Gill et al., 2019). Despite discovering numerous SNPs associated with Ty-6 that can be used for breeding, none were consistently polymorphic between Ty-6 and Ty-6 breeding lines (Gill et al., 2019).

6 Molecular markers for resistance to TYLCV in tomato

Indirect selection of desirable plant phenotypes employing linked molecular DNA markers as a binding mechanism is known as marker-assisted selection (MAS) (El-Sappah et al., 2019; El-Sappah and Rather, 2022). According to the MAS theory, a gene of interest is present when a closely connected marker is found (Jiang, 2013). The development of novel resistant crops has numerous advantages. The two main benefits of molecular breeding are that it takes less time (Xu and Crouch, 2008) and is less expensive than field screening (Morris et al., 2003). Additionally, it is less damaging to the environment than pesticides (Afify et al., 2022). The tomato is one of the most remarkable plants for commercial breeding with molecular markers (Hanson et al., 2016). Molecular markers for MAS in CAPS and SCAR markers have been used to develop the Ty-1/Ty-3 resistance gene (Ji et al., 2009a; Nevame et al., 2018; Kim et al., 2020). Although, concerns have been voiced over their physical proximity to the resistance genes in the genome, posing the possibility of false-positive or false-negative outcomes in breeding programs (Antignus, 2007; Yang et al., 2014; Nevame et al., 2018). Gene-specific marker technology was developed to create gene-specific molecular markers to get around the issues mentioned earlier (Ramkumar et al., 2010; Ramkumar et al., 2011). As a result, functional markers, resistance gene-based markers (RGM), gene-targeted markers, and RNA-based markers have all been developed (Sorri et al., 1999; Kasai et al., 2000; Valkonen et al., 2008). Functional markers are polymorphic DNA sequences that play a role in phenotypic trait variation, according to Andersen and Lübberstedt (2003), whereas gene-targeted markers are gene-specific and can mark untranslated regions (Arnholdt-Schmitt, 2005; Varshney et al., 2007). RGM can make it possible to detect resistance genes in fresh germplasm and isolate populations to support plant gene pyramids (Poczai et al., 2013). The DNA markers for these TYLCV resistance genes are presented in Table 2 . Since Ty-1 and Ty-3 were discovered separately from various tomato germplasms, various DNA markers closely related to Ty-1 or Ty-3 have been applied in tomato breeding projects. However, new research has revealed that these two are allelic-related at a single locus (Verlaan et al., 2013; Caro et al., 2015). Research is being done on the resistance levels and spectra that Ty-1 and Ty-3 bestow. Ty-2 resistance was successfully selected using the SCAR marker T0302 on chromosome 11, but it has recently been reported in a 300 kb region, and efforts are being made to identify its genes in order to create gene-based markers (Wolters et al., 2015). Based on the information provided by Lapidot et al. (2015), a gene-based dCAPS marker for ty-5 was developed.

Table 2.

Genetic markers assisted breeding to TYLCV resistance.

Marker	Gene	Marker Type (restriction Enzyme)	Forward/Reverse of Marker sequences	Product Size (bp)	References
SCAR1	Ty-1	SCAR	5'-CAATTTATAGGTGTTTTTGGGACATC-3' 5'-GTTCAACACTTGGCCAATGCTTACG-3'	R:350 S:610	(Nevame et al., 2018)
JB1	Ty-1	SCAR	5'-AACCATTATCCGGTTCACTC-3' 5'-TTTCCATTCCTTGTTTCTCTG-3'	R: 450 S: 400	(de Castro et al., 2007)
TG178	Ty-1	SCAR	5'-GAGTCCCTAACGAATGGTCCTACT-3' 5'-GCAGACAAATGCTCAAAGGTCACACC-3'	Multiple bands	(Barbieri et al., 2010)
Ty1-TaqI	Ty-1	CAPS (TaqI)	5'-ATGAAGACAAAAACTGCTTC-3' 5'-TCAGGGTTTCACTTCTATGAAT-3'		(Jung et al., 2015)
Ty1-SspIHJ	Ty-1	SNP	5'-GGTTGGTCTCCTTGATAGTCATGT-3' 5'-TCCACTTGAAGCTTAATAGTCTTTGA-3'	R:118	(Jung et al., 2015)
Ty1-3	Ty-1,Ty-3	InDel	5'-GGGTGATCCGTTGATTGAAG-3' 5'-TCTTCTTGATAGGACGACGTGA-3'		(Hu et al., 2014)
14IY218	Ty-1/3	CAPS (SspI)	5'-ATGAAGACAAAAACT GCT TC-3' 5'-TCAGGG TTTCACTTCTATGAA T-3'	R: 383, 226 S: 609	(Jung et al., 2015)
M2	Ty-1/3	SCAR	5'-GATCCGTTGATTGAAGAAAT-3' 5'-AGGAAGAGGAGAGACAATCC-3'	R: 264 S: 252	(Jung et al., 2015)
TY-1/3_K	Ty-1/3	SCAR	5'-ACAGGAAAAATGGGTGATCC-3' 5'-CCTGCTCCTTGCAGATTCTA-3'	R: 114 S: 102	(Chen et al., 2015)
Ty1-SspI	Ty1/3	CAPS (SspI)	5'-ATGAAGACAAAAACTGCTTC-3' 5' -TCAGGGTTTCACTTCTATGAAT-3'	R: 608	(Jung et al., 2015)
Ty1-BglII	Ty1/3	CAPS (BglII)	5' -ATGAAGACAAAAACTGCTTC-3' 5' -TCAGGGTTTCACTTCTATGAAT-3'		(Jung et al., 2015)
ACY	Ty-1,Ty-3, Ty-3a	Indel	5' -GAAGCACAGATTGAAGAAAACC-3' 5' -CCTTATGATGTCTCGTGAAAGG-3'	R: 132 S:123	(Nevame et al., 2018)
P1-16	Ty-2	SCAR	5' -CACACATATCCTCTATCCTATTAGCTG-3' 5'-CGGAGCTGAATTGTATAAACACG-3'		(Yang et al., 2014)
SCAR2 (T0302)	Ty-2	SCAR	5'-TGGCTCATCCTGAAGCTGATAGCGC-3' 5'-AGTGTACATCCTTGCCATTGACT-3'	R:900 S:800 or 791	(Garcia et al., 2007; Nevame et al., 2018)
20IY10	Ty-2	InDel	5'-GTTCTATCACAAGACTTGCCA-3' 5'-TGCATTCACCATTGATGTATAAGA-3'	R: 738 S: 600	(Lee et al., 2020)
TES0344	Ty-2	SSR	5'-GCCTTTTCCCACTTATATTCCTCTC-3' 5'-ACACATACGACGTTCCGTCA-3'	R: 190 S: 205	(Yang et al., 2012)
Ty2-UpInDe	Ty-2	InDel	5'-ACCCCAAAAACATTTCTGAAATCCT-3' 5'-TGGCTATTTTGTGAAAATTCTCACT-3'	R:120 S:213	(Kim et al., 2020)
Ty3-InDel4	Ty-3	CAPS (BstZ17I)	5'-CCTATCCTCAGTGTTTCGGTCA-3' 5'-GGCGAAAGACTTTGTGTACACA-3'	R: 353/325 (678) S: 669 (669)	(Kim et al., 2020)
Ty3- SNP9	Ty-3	CAPS (MfeI)	5'-CCTATCCTCAGTGTTTCGGTCA-3' 5'-GGCGAAAGACTTTGTGTACACA-3'	R:678 (678) S: 555/114 (669)	(Kim et al., 2020)
Ty3-SNP17	Ty-3	CAPS (RsaI)	5'-TCTCAGGTGATGCTGAGCAC-3' 5'-AGAGAACGAAAACGAAATTTCAAACA-3'	R:497/148/65/52/51 (813) S:562/148/52/51 (813)	(Kim et al., 2020)
P6-25	Ty-3 Ty-3a Ty-3b	SCAR	5'-GGTAGTGGAAATGATGCTGCTC-3' 5'-GCTCTGCCTATTGTCCCATATATAACC-3'	R: 623bp for Ty-3a 453bp for Ty-3 and 660 bp for Ty-3b S: 320bp for ty-3	(Ji et al., 2007a; Salus et al., 2007; Nevame et al., 2018)
Cauty4	Ty-4	InDel	5'-GGGCAACTCAATGGTGAAAC-3' 5'-TCTGAATGTAGGGCCAAAGG-3'		(Hu et al., 2014)
18IY23	Ty-4	dCAPS (StuI)	5'-AGAAGAAATCCAAGAAAAGCAATA AGA ATGAGG CC-3 ' 5'-CTT GTAATCACG TCCACAACG-3'	R: 304 S: 269, 35	(Lee et al., 2020)
18IY13	Ty-4	InDel	5'-CTTCTGTTCTATGCAGGTGTG-3' 5'-GGATACAACTGTCAACGCAC-3'	R: 228 S: 200	(Lee et al., 2020)
ty-5	ty-5	SSR	5'-GACTGCATTGGATTTGGCTT-3' 5'-CAATCGATGCACAAAACACC-3'		Yang et al. (2016)
14IY5	ty-5	dCAPS (RsaI)	5'-TTCAAGTCCTTCTTCAACATAGATTTA AACAACAATTATAGA-3' 5'-GATAAAAAAGTTACCTGT-3'	R: 300 S: 260, 40	(Lee et al., 2020)
AVRDC-TM719	ty-5	SSR	5'-TCGATTTGGAATGAGTTTTC-3' 5'-TGAAATAGATTTGTCAGGTGTT-3'	S: 237	(Chen et al., 2015)
SLM4-34	ty-5	SSR	5'-GACCATTAACCTCGATCA-3' 5'-GAAAGTCATGTGAATAGCAG-3'	Multiple bands	(Kadirvel et al., 2013)
SINAC1 (TAQ I)	ty-5	SSR	5'-TGCCTGGTTTCTGCTGTCA-3' 5'-TAAAGCTGAAGAAGGACTTACCCT-3'	Multiple bands	(Anbinder et al., 2009)
AVRDC-TM273	ty-5	SSR	5'-GGTGCTCATGGATAGCTTAC-3' 5'-CTATATAGGCGATAGCACCAC-3'	R: ~180 S: 173	(Chen et al., 2015)
AVRDC-TM81	ty-5	SSR	5'-GTATGGAGAGTCGAGTCCTG-3' 5'-CCATGATAAGTAGCGAGAGG-3'	S: 153	(Chen et al., 2015)
AVRDC-TM70	ty-5	SSR	5'-TTTCTTTGTTTCCTTTCAGTG-3' 5'-GCCTTGGACAAGGTACAATA-3'	Multiple bands	(Chen et al., 2015)
AVRDC-TM947	ty-5	SSR	5'-TGCGTCTAGTTTTCTTTGTTT-3' 5'-CAAGCTGAAAGGAATTCAAC-3'	Multiple bands	(Chen et al., 2015)

R and S at product size mean Resistance and Susceptible, respectively.

7 Mechanism of natural resistance to the TYLCV in tomato

The tomato plant’s molecular and cellular responses to TYLCV infection are depicted in Figure 5 . Six partially overlapping open reading frames are present in the single-stranded, circular, bidirectionally structured DNA genome of TYLCV (Gronenborn, 2007). Due to their restricted coding capability, like most viruses, they depend on the host cell’s machinery and their proteins for the infection cycle (Hanley-Bowdoin et al., 2004). Viral ssDNA exits the capsid and moves into the cytoplasm and nucleus of infected cells, where it engages in a rolling cycle and recombination-dependent replication (Gutierrez, 1999). The freshly replicated viral ssDNA can be transformed into dsDNA, which can be used as a template for further replication or transcription. It can also be encapsulated by viral activity proteins for transport via plasmodesmata from infected cells to nearby cells or packaged in a contagious kind to allow for long-distance viral transmission (Gutierrez, 1999; Hanley-Bowdoin et al., 2013). In addition, geminiviruses rely extensively on host proteins to complete their infection cycle because they have little capacity for coding. To control cell division and the cell cycle, coordinate with multiple cellular mechanisms, and affect host components at various cellular levels, their replication, and transcriptional processes depend on host enzymes (Hanley-Bowdoin et al., 2013). Additionally, they produce short RNAs and block numerous TGS and post-transcriptional gene silencing (PTGS) components by encoding a variety of proteins that disrupt PTGS pathways (Raja et al., 2010; Hanley-Bowdoin et al., 2013; Gnanasekaran et al., 2019). In order to reduce symptoms in different crops and viruses, these proteins also utilize viral suppressors of the RNA silencing mechanism (VSRs) (Ceniceros-Ojeda et al., 2016; Basu et al., 2018). Geminivirus VSRs are versatile proteins that support the viral life cycle and weaken host defense (Teixeira et al., 2021). They can abolish PTGS and TGS in any of the three stages of the operation, and they can also directly or indirectly impact DNA methylation through events that happen after TGS (Loriato et al., 2020). Mechanically, RNA silencing machinery components are either actively inhibited or prevented from accumulating (expression) by geminivirus VSRs. Representatives of the viral repertoire known as C4/AC4 interact with and sequester dsRNA precursors from DCL cleavage and siRNAs from RISC loading in order to prevent antiviral RNA silencing. AC1 (bipartite geminiviruses) and C1 (monopartite geminiviruses) have been shown to function as powerful VSRs in both PTGS and TGS (Amin et al., 2011; Sunitha et al., 2013). Additionally, during the amplification phase, a subsequent event of TGS, AV2 and V2 impair host methylation activity and block antiviral RNA silencing (Luna et al., 2017; Wang et al., 2018a; Luna et al., 2020). Through a number of methods, the C1 protein encoded by the -satellite genome functions as an effective VSRs, preventing the methylation of viral genomes in plants and PTGS that have been infected (Yang et al., 2011; Saeed et al., 2015). To identify and trigger defense reactions against pathogens, the plant immune system has created a multi-layered receptor system. The initial line of defense, according to the traditional zig-zag model of plant immunity, is the recognition of pathogen-associated molecular patterns (PAMPs) by host pattern recognition receptors (PRRs), which activate PAMP-triggered immunity (PTI) (Jones and Dangl, 2006). Successful pathogens release effectors in response, suppressing the PTI response and causing effector-induced susceptibility (ETS). Receptor-like kinases (RLKs) and receptor-like proteins, two transmembrane receptors, are responsible for the appearance of PRRs. These PRRs realize damage-associated molecular patterns (DAMPs), which are exclusively expressed by endogenous danger signals supplied by pathogens or host plants during infection (Macho and Zipfel, 2015). To create an active immunological complex, RLKs and RLPs typically need a co-receptor (Ma et al., 2016). PAMPs and DAMPs function as bonds to enhance the dimerization and oligomerization of PRRs, one-way transmembrane receptors interacting with RLK co-receptors to initiate signaling and activate immune complexes (Macho and Zipfel, 2015). Following PTI activation, the MAP kinase cascade is activated, PTI-related defense genes are induced, ethylene and salicylic acid are synthesized, and callose is deposited (Teixeira et al., 2021; Raza et al., 2022). PTIs appear to be a component of the host’s arsenal of defense against geminivirus infection, despite the fact that geminivirus PAMPs and their associated PRRs have not been described. The TYLCCNB-C1 protein interacts with and is phosphorylated by tomato sucrose non-fermentation 1-associated kinase (SlSnRK1), which may cause proteasomal destruction (Shen et al., 2011). It has been demonstrated that the TYLCCNB-C1 protein inhibits methylation-mediated RNA silencing and its function in lowering PTI in tomato plants. Another line of defense is available. Where plants produce cytoplasmic R proteins, also known as NB-LRRs (nucleotide-binding leucine-rich repeat proteins), which can detect the presence or absence of specific viral impacts, such as avirulent (AVR) activity and result in effector-induced immunity (ETI) (Jones and Dangl, 2006). According to their N-terminal structures, plant NLRs are divided into two groups: CC-NLRs (CNLs) and Toll/Interleukin-1 (TIR)-NLRs (TNLs) (Selth et al., 2004). Ty-2 is a CC-NBS-LRR (CNL) type gene member of the CNL genes with an I-2-like subclass (Shen et al., 2020). When Ty-2 is co-expressed and activated with the TYLCV Rep/C1 protein, a hypersensitive responses (HR) response is produced.

Figure 5.

Molecular response of tomato during TYLCV infection; (A) the whitefly carries the virus and transfer it to the tomato during its feeding, (B) the tomato’s first line of defense is recognition of pathogen-associated molecular patterns (PAMP) by host pattern recognition receptors (PRRs), resulting in activation of PAMP triggered immunity (PTI), (C) the tomato second line of defense, plants have evolved cytoplasmic R proteins (nucleotide binding–leucine-rich repeat proteins, NB-LRR) (NLRs) i.e., Ty-2 gene that recognizes the presence or activity of specific virus effectors like avirulence AVR, resulting in effector triggered immunity (ETI), (D) Once the viral ssDNA is released from the capsid, it enters the cytoplasm of the infected cell and subsequently enters the cell nucleus, where it undergoes rolling-circle and recombination dependent replication and plant immunity begin by inducing both TGS and PTGS, with the help of Ty-1/Ty-3 genes, (E) Tomato autophagy, where Rep protein of TLCYnV, CLCuMuB βC1 protein interacts with autophagy related protein NbATG8 through its ATG8 interacting motif (LVSTKSPSLIK) and directs it for degradation. This figure was made using BioRender.

ETIs frequently cause HR and systemic acquired resistance (SAR) (Saile et al., 2020). Recent research suggests that there may not be a very distinct difference between PAMPs and effectors or between PAMP receptors and resistance-causing proteins (Thomma et al., 2011). As a result, PTI and ETI are not always different defensive reactions; instead, both defensive reactions can be strong or weak depending on the contact circumstances. Thus, detecting danger signals, whether they come directly from microorganisms (PAMPs and effectors) or through damage to or change of eukaryotic host structures, can recapitulate the activation of innate plant defense. The geminivirus AC2/C2 protein, a viral effector required for productive infection and can occasionally cause HR, seems to fit these criteria (Roy, 2016).

In general, plant defense responses triggered by direct or indirect effector sensing by NLR genes involve a variety of downstream signaling pathways, including phytohormones involved in defense, MAPK signaling cascades, and a set of defense-related genes (e.g., WRKY transcription factors) (Elmore et al., 2011; de Ronde et al., 2014; Boualem et al., 2016; Rasheed et al., 2022). After TYLCV inoculation, the SlMAPK1, SlMAPK2, and SlMAPK3 were differently upregulated and activated (Li et al., 2017; Guo et al., 2021). Rapid reactive oxygen species (ROS) burst and activation of MPK3/MPK6 are two distinct early signaling events in the plant immune system (Xu et al., 2014; Edris et al., 2021; Elebeedy et al., 2022; Sattar et al., 2022). The SA synthesis can result from H₂O₂ buildup (León et al., 1995); however, TYLCV also promotes SA accumulation early in infection (Morinaka et al., 2006). High SA and H₂O₂ can activate the PR genes expression locally (Peleg-Grossman et al., 2010).

In order to silence the expression of viral genes, geminiviruses must contend with plants on two major defenses. PTGS damages viral mRNA, while methylation-mediated TGS targets viral minichromosomes (Gupta et al., 2021). Geminivirus DNA enters the nucleus after combining with coat proteins and then attaching to the host’s histone proteins; ssDNA is replicated in the nucleus in double-stranded form and exists as minichromosomes (Abouzid et al., 1988; Gupta et al., 2021). The RNA-directed DNA methylation device (RdDM) employs transcriptional gene silencing to silence viral gene expression and reduce viral minichromosomes by taking advantage of the plant’s response to the invasion (TGS) (Vanitharani et al., 2005; Zarreen and Chakraborty, 2020).Virus-produced Plant cytoplasmic siRNA-mediated silencing pathways specifically target RNA transcripts (Gupta et al., 2021). The PTGS pathway is essential for host genes’ expression, development, and defense (Chen et al., 2004).

RDR2 participates in tomatoes’ TGS pathway and antiviral defense (Mourrain et al., 2000; Xie et al., 2001; Qi et al., 2009). Element members of the Ty-3/Gypsy-like superfamily of retrotransposons, which are transcriptionally repressed through the RdDM pathway, are upregulated due to the loss of RDR2 function (Jia et al., 2009). The TYLCV virus has two wild-type tomato resistance alleles, Ty-1 and Ty-3. These alleles are members of the RDR lineage and encode the DFDGD motif (Verlaan et al., 2013; Caro et al., 2015). Other research has demonstrated that Ty-1 increases antiviral RNAi responses, which is implied by elevated vsiRNA levels and elevated cytosine methylation in the viral DNA genome in tomatoes treated with Ty-1 (Butterbach et al., 2014). The viral genome’s cytosine methylation and RNA silencing are hypothesized to be regulated by several Ty genes (Verlaan et al., 2013; Butterbach et al., 2014; Caro et al., 2015).

Finally, autophagy, a conserved evolutionary process that recycles damaged or unneeded cellular components within cells, is another method of plant defense against TYLCV (Haxim et al., 2017; Yang et al., 2019a). According to studies on plant DNA and RNA viruses, autophagy has a potential antiviral role in host innate and adaptive immunity (Hafrén et al., 2017; Haxim et al., 2017; Gupta et al., 2021). The TLCYnV Rep protein CLCuMuB C1 interacts with the autophagy-related protein NbATG8 and regulates its degradation via the ATG8 interaction motif (LVSTKSPSLIK) (Gupta et al., 2021). More research, particularly in tomatoes, is needed to understand how autophagy is regulated during viral infection and determine whether blocking the proviral autophagy pathway could prevent diseases.

8 Challenge and prospects

The TYLCV may have originated from seeds because viral particles can stay in the seed after infection and pass on to the following generation (Albrechtsen, 2006; Baldodiya et al., 2020). Strict quarantine laws, integrated pest management, and traditional breeding are only a few methods to stop the spread of TYLCV (Prasad et al., 2020). TYLCV transmission is one of several recent transgenic strategies and traditional methods used to combat virus transmission (Pramanik et al., 2021; Asseri et al., 2022). Tomato plants that express TYLCV gene segments, such as replication-associated protein (Rep) (Antignus et al., 2004) or capsid protein (CP) provide resistance to the virus (Yang et al., 2004). Another study found that the model plant N. benthamiana overexpressed recombinant antibodies directed against the Rep protein and displayed decreased TYLCV symptoms (Safarnejad et al., 2009; Reyes et al., 2013). Immunization against TYLCV was successfully developed using viral gene silencing via RNAi-mediated techniques (Ammara et al., 2015; Leibman et al., 2015; Fuentes et al., 2016); for example, viral resistance was demonstrated by silencing the tomato SlPelo gene (Lapidot et al., 2015). Meanwhile, the overexpression of plant immunity-related genes immunity is a reasonable strategy for increasing pathogen tolerance in plants. For instance, SlMAPK3 or SlLNR overexpression reduces TYLCV pathogenicity in tomato plants (Li et al., 2017; Yang et al., 2019b). Furthermore, SlGRXC6 overexpression promoted plant growth, inhibited viral infection, and delayed TYLCV symptom development (Zhao et al., 2021).

Traditional breeding and transgenic approaches to TYLCV infection control are generally promising, but they have several drawbacks. Besides, they have been around for a long time and faces the risk of losing essential characteristics due to traditional breeding domestication (Jansson et al., 2017; Migicovsky and Myles, 2017). The main disadvantage of transgenic techniques is that the transgene must be expressed steadily to achieve a pathogen-tolerant phenotype. Thus the organisms must be classified as genetically modified (GMOs) (Shelake et al., 2019). Plant viruses have also been reported to develop a protection system by developing RNA-silencing viral suppressors (Incarbone and Dunoyer, 2013), even though RNAi does not result in complete gene silencing and requires the components of RNAi to be expressed consistently (Shuey et al., 2002; Rehman et al., 2022). As a result, novel approaches to developing TYLCV-resistant tomato crop varieties are incredibly crucial. CRISPR/Cas technology has proven to be a promising tool for creating designer crop varieties, including pathogen-resistant crops (Shelake et al., 2019; El-Sappah et al., 2021b; Pramanik et al., 2021). The two main components of CRISPR/Cas-based genome editing tools are single guide RNA (sgRNA) and Cas9 endonuclease (Binyameen et al., 2021). The sgRNA-Cas9 complex searches the genome for its target site and uses an adjacent protospacer motif to generate efficient DNA double-strand breaks. During the error-prone DNA repair process, mutations can occur (Pramanik et al., 2021). CRISPR/Cas has recently been used to target either the pathogen genome or the genes of the host plant to achieve a disease-resistant phenotype. By targeting the viral genome, CRISPR/Cas technology is effective in providing TYLCV resistance in N. benthamiana (Ali et al., 2015; Zaidi et al., 2016; Tashkandi et al., 2018). Similarly, sgRNAs targeting the CP or Rep gene decreased TYLCV accumulation in tomato plants (Tashkandi et al., 2018). According to a study published by Pramanik et al. (2021) the commercial tomato BN-86 line was CRISPR/Cas9-interceded to produce TYLCV-resistant tomato plants. Finally, in order to gain viral immunity, targeting the viral genome necessitates the stable expression of the CRISPR/Cas system, and is thus classified as GMO.

9 Conclusions

The most destructive viral disease that affects tomatoes is likely TYLCV disease. Traditional strategies, such as reproduction and transgenic techniques, have had limited success in controlling the disease. The QTL for TYLCV resistance, including Ty-1, Ty-2, Ty-3, Ty-4, ty-5, and Ty-6 in wild tomato varieties, were only recently discovered. Several methods, including stringent quarantine laws, genetic engineering, conventional breeding, and integrated pest management, have been used to stop the spread of TYLCV. Typically, tomato uses a few defense mechanisms, such as PTI, ETI, Gene silencing, and autophagy, to reduce the dangerous effects of TYLCV infections. This study compiles the characteristics of specific opposition genes, typical opposition resources, subatomic markers for aided choice, and methods for determining TYLCV protection. The main objective is to set the theoretical groundwork for identifying, utilizing, and developing tomato varieties resistant to TYLCV.
