Mitochondrial protection partly mitigates kidney cellular senescence in swine atherosclerotic renal artery stenosis

Abstract

Background/Aims:

Atherosclerotic renal artery stenosis (ARAS) may cause kidney injury and mitochondrial dysfunction, which is linked to cellular senescence. Elamipretide, a mitochondria-targeted peptide, improves renal function in ARAS, but whether it alleviates senescence is unknown. We hypothesized that elamipretide would reduce senescence stenotic kidney (STK) in ARAS.

Methods:

Domestic pigs were randomized to control and unilateral ARAS untreated or treated with subcutaneous elamipretide (5d/wk) for 4 weeks starting after 6 weeks of ARAS or sham (n=6 each). After completion of treatment, STK renal blood flow (RBF) and glomerular filtration rate (GFR) were assessed in-vivo using multi-detector computed-tomography. Renal fibrosis and oxidative stress were analyzed in trichrome- and dihydroehidium-stained slides, respectively. Mitochondrial markers involved in the electron-transport chain (COX4, ATP/ADP ratio), biogenesis (PGC1α, PPARα), dynamics (MFN2, DRP1), and mitophagy (parkin, p62) were measured in the kidney using ELIZA, western-blot, and immunohistochemistry. Cellular senescence (senescence-associated β-galactosidase and heterochromatic foci, phosphorylated-H2AX, and p16/21/53) and senescence-associated secretory phenotype (SASP; PAI-1, MCP-1, TGFβ, and TNFα) markers were studied by microscopey, quantitative reverse transcription-polymerase chain reaction, and western-blot.

Results:

Blood pressure was elevated whereas STK-RBF and GFR were decreased in ARAS pigs, and tissue scarring was increased. ARAS induced STK cellular senescence and accumulated dysfunctional mitochondria, which were associated with cardiolipin loss, upregulated mitochondrial biogenesis, and defective mitophagy. Elamipretide normalized STK-RBF and GFR, alleviated fibrosis and oxidative stress, and restored mitochondrial cardiolipin, biogenesis, and mitophagy in ARAS, but did not change SASP markers, and attenuated only senescence-associated β-galactosidase activity and p53 gene expression.

Conclusion:

Mitochondrial protection improved renal function and fibrosis in the ARAS STK, but only partly mitigated cellular senescence. This finding suggests that mitochondrial dysfunction may not be a major determinant of cellular senescence in the early stage of ARAS.

Introduction

Atherosclerotic renal artery stenosis (ARAS) remains the leading cause of renovascular hypertension, and increases in prevalence due to aging of the population and increasing prevalence of atherosclerosis risk factors. As the disease progresses, ARAS results in downstream renal pathological alterations with gradual functional loss [1–3]. We have recently demonstrated mitochondrial dysfunction in ARAS [3], which partly mediates ARAS-induced kidney damage secondary to prolonged kidney ischemia and dyslipidemia [3].

Cellular senescence is an irreversible proliferation arrest in response to stress [4]. Senescent cells not only have anti-apoptotic and pro-survival defenses, but frequently express the senescence-associated secretory phenotype (SASP) which consolidates senescence and adversely influences adjacent cells [5]. Cellular senescence has been shown to contribute to the pathogenesis of atherosclerosis. Atherosclerotic lesions show senescence-associated β-galactosidase (SA-β-Gal) expression [6], and obesity promotes vascular senescence, making the tissue susceptible to ischemia [7]. In the kidney, senescent cells have been detected in acute ischemic injury [8]. However, the involvement of cellular senescence in chronic renal damage remains unclear.

Mitochondrial dysfunction and cellular senescence are both important contributors to aging and age-related disease [9]. The importance of mitochondria in eliciting cellular senescence, especially the pro-inflammatory phenotype [10] is correlated with production of mitochondrial reactive oxygen species (ROS) [11], whereas senescent cells conversely accumulate dysfunctional mitochondria [12]. This bidirectional link between senescence and mitochondria might be involved in stenotic kidney (STK) injury in ARAS, yet this link in ARAS has not been demonstrated.

Elamipretide is a novel tetrapeptide that selectively and transiently concentrates in the inner mitochondrial membrane, where it binds to and stabilizes cardiolipin, facilitating efficient electron transport and preventing apoptosis [13]. We have shown that elamipretide in ARAS blunts oxidative stress, microvascular loss, and tissue injury, and improves renal function [3]. However, whether elamipretide would alleviate renal senescence is unknown.

This study was designed to test the hypothesis that mitochondrial dysfunction in ARAS may account for STK cellular senescence, and thereby senescence-associated secretory phenotype (SASP). Furthermore, we hypothesized that due to its mitochondrial-protective properties, elamipretide would alleviate STK cellular senescence.

Materials and Methods

This study was approved by the Institutional Animal Care and Use Committee. Twenty-four domestic female pigs were studied during 16 weeks of observation. At 3 months of age, pigs were randomized to ARAS or Normal without or with elamipretide treatment (ARAS+ELAM and Normal+ELAM; n=6 each group). Normal pigs were fed with isocaloric diets of standard chow, and ARAS pigs with a high-fat diet containing 2% cholesterol (Harlan Teklad, Madison, WI) [14] starting 6 weeks prior to induction of renal artery stenosis. All animals had free access to water. Six weeks after initiation of diet, pigs were anesthetized with 0.25g of intramuscular tiletamine hydrochloride/zolazepam hydrochloride and 0.5g of xylazine, and maintained with intravenous ketamine (0.2 mg/kg/min) and xylazine (0.03 mg/kg/min). In ARAS groups, RAS was induced by placing a local irritant coil in the right main renal artery, as described [15]. The Normal groups underwent a sham procedure. Six weeks after induction of RAS, the degrees of stenosis were determined by renal angiography, and the treatment groups started with subcutaneous injections of elamipretide (MTP-131, SS-31, Stealth Biotherapeutics, Newton Centre, MA), 0.1 mg/kg in 1mL of phosphate-buffered saline once daily 5 days/week. A vehicle was injected in the control pigs [3]. Four weeks after initiation of treatment, the pigs were again anesthetized. The degree of stenosis was determined by angiography, and systemic venous blood samples collected for lipid profile and serum creatinine (DiaSorin, Stillwater, MN, USA) measurements. Renal hemodynamics and function were assessed in vivo using multi-detector computed tomography (MDCT). After completion of all in vivo studies and 30–60 min after the last dose of elamipretide, pigs were euthanized (sodium pentobarbital, 100 mg/kg). The kidneys were dissected, and sections preserved fresh frozen or in formalin for ex vitro studies.

In vivo studies

Renal hemodynamics and function

After 4 weeks of treatment, renal blood flow (RBF) and glomerular filtration rate (GFR) were assessed using MDCT (Somatom Sensation 64; Siemens Medical Solutions, Forchheim, Germany) [15, 16] by acquiring 140 consecutive scans (330ms each) after a central venous injection of iopamidol (0.5mL/kg per 2 seconds). MDCT images were reconstructed and displayed with the Analyze^® software package (Biomedical Imaging Resource, Mayo Clinic, Rochester, MN). For data analysis, time-attenuation curves were generated from regions of interest (ROIs) in the aorta, renal cortex, and medulla to obtain measures of renal function [16]. Blood pressure was measured in all animals using an arterial catheter during MDCT.

Ex vivo studies

Fibrosis and oxidative stress

Kidney tissue was embedded in paraffin and sectioned (5μm) for Masson’s trichrome staining. Glomerulrosclerosis and interstitial fibrosis was analyzed in 10–15 fields per slide (ZEN; Carl Zeiss, Oberkochen, Germany). Sclerotic glomeruli were counted, and their percentage out of 100 glomeruli calculated [17]. The in situ production of superoxide anion was studied in renal tissue using dihydroethidium (DHE) staining and fluorescence microscopy [3]. The degree of interstitial fibrosis in the renal cortex and DHE area was semi-automatically quantified using a masking algorithm based on color thresholding and edge detection in a computer-aided image-analysis program AxioVision^© (Carl Zeiss) and expressed as an average percent of total field area [17].

Mitochondrial function and biogenesis

Total cardiolipin content was measured by enhanced multidimensional mass spectrometry based shotgun lipidomics, as previously described [3]. Activity of mitochondrial respiratory chain complex IV subunit COX-4 was determined by ELISA (Abcam) [18]. To evaluate mitochondrial biogenesis, renal protein expression of peroxisome proliferator-activated receptor gamma coactivator (PGC)1-α (1:1000, Abcam), peroxisome proliferator-activated receptor-γ-coactivator (PPAR)-α (1:1000, Abcam), mitofusin (MFN)-2 (1:1000 Cell Signaling), dynamin-related protein (DRP)-1 (1:1000 Cell Signaling), P62 (1:1000, Abcam), and GAPDH in 100μg of protein from each homogenized kidney tissue sample was measured by Western blot.

In addition, MITO-ISO kit (ScienCell, Carlsbad, CA) was used for mitochondrial isolation. Then protein expression of Parkin (1:200, Santa Cruz) and COX-IV (1:1000, Cell Signaling) was measured by Western blot and quantified by ImageJ software. Renal ATP and ADP content was assessed in isolated mitochondria by colorimetric methods and expressed as ratio [19]. To assess mitophagy, colocalization of Parkin with Tom-20, a mitochondrial outer membrane protein, was evaluated in renal paraffin-sections (5μm thick). Confocal microscopy demonstrated the immunostaining of Parkin (Santa Cruz, Alexa Fluoro 594, red) and Tom-20 (Santa Cruz, Alexa Fluor 488, green). The percent area of co-localized Parkin and Tom-20 was quantified semiautomatically in 10–15 random fields using AxioVision^© [20].

Senescence and SASP markers

Senescence-associated β-galactosidase (SA-β-gal) staining was done using the Senescence β-Galactosidase Staining Kit (#9860, Cell Signaling, Boston, MA), as described [21]. Sections were counterstained with eosin, dehydrated, and mounted. SA-β-Gal–positive area was determined in ten randomly chosen fields per section at ×20 magnification and assessed for development of blue color. The degree of senescence was expressed as an average of percent SA-β-Gal–positive to total field area [22]. To assess p16 protein expression, p16 colorimetric staining (Abcam) was done on formalin-fixed paraffin-embedded (FFPE) renal sections. To assess proliferation and senescence-associated heterochromatin foci (SAHF), FFPE sections were stained with Ki67 (Abcam) and histone H3K9 trimethyl (Epigentek), respectively, and mounted with DAPI (Invitrogen) [23, 24]. To evaluate senescence in endothelial cells, renal cryosections were co-stained with fluorogenic β-galactosidase detection kit (SPiDER-βGal, Dojindo) and CD31 (ABD Serotec). The % of positive cells was manually computed in ten random fields per section at x40 magnification. Protein expression of γ-phosphorylated histone-2AX (γH2AX) (1:1000 Abcam), total H2AX (1:1000 Abcam), plasminogen activator inhibitor (PAI)-1 (1:1000 Abcam), monocyte chemoattractant protein (MCP)-1 (1:10 Abcam), transforming growth factor (TGF)-β (1:1000 Abcam), and tumor necrosis factor (TNF)-α (1:100 Abcam) was measured in 100μg of protein from each homogenized kidney tissue sample by Western blot [20]. GAPDH (1:5000 Abcam) was used as loading control and band intensity quantified using ImageJ software. In addition, fluorimetric SA-β-Gal activity was assayed using a Cellular Senescence Activity Assay Kit (Enzo Life Sciences, Farmingdale, NY). Renal gene expression of p16 (Hs00923894), p21 (Hs00355782), p53 (Hs01034249), Activin-A (Hs01081598), and GAPDH (Hs02786624) was assessed on Applied Biosystems ViiA7 Real-Time PCR systems using the delta-delta CT method with validated TaqMan primers from Thermo Fisher Scientific (Waltham, MA) [25].

Statistical analysis

Statistical analysis was performed using JMP software version 13.0 (SAS Institute, Cary, NC). Results are presented as mean±SD for normally distributed variables and as median (interquartile range) for data without normal distribution. Parametric (one-way analysis of variance followed by Student’s t-test) and non-parametric (Kruskal-Wallis followed by Wilcoxon) test were used for comparisons among groups. A P value≤0.05 was considered statistically significant.

Results

Characteristics and renal function

The degree of stenosis was comparable in untreated and treated ARAS groups (P=0.63) (Table 1). ARAS increased blood pressure (P=0.03 vs. Normal) and lipid levels. ARAS also lowered STK GFR (P=0.04 vs. Normal) and elevated serum creatinine (Figure 1A, P=0.008 vs. Normal). Elamipretide improved STK-GFR and RBF (P=0.002 and 0.04 vs. ARAS, respectively) without affecting lipid profile in ARAS pigs. ELAM did not change blood pressure, renal function, or RBF in Normal pigs.

Table 1.

Characteristics of normal and atherosclerotic renal artery stenosis (ARAS) pigs untreated or treated with elamipretide (ELAM) for 4 weeks (n=6 each).

	Normal	Normal+ELAM	ARAS	ARAS+ELAM
Degree of stenosis (%)	-	-	95(67.5–99.5)	85(62.5–87.5)
Total cholesterol (mg/dl)	87(77–113.5)	87(77.5–91)	519(453–545)*	484.5(450.5–613.7)*
Low density lipoprotein cholesterol (mg/dl)	50.8(36.6–57)	34.6(29.1–40.5)	324.6(245–375)*	285.7(231.3–435.6)*
Mean arterial pressure (mmHg)	96.5(89.2–103.9)	91.7(84–101.3)	139.7(99.3–170.3)*	117.3(91.7–137.3)

^*p<0.05 vs. Normal. Data are expressed as median (interquartile range).

Figure 1. Elamipretide improves stenotic kidney (STK) function and blunts fibrosis.

A. Atherosclerotic renal artery stenosis (ARAS) pigs showed a decrease in both STK and overall kidney function. Elamipretide improved serum creatinine, STK glomerular filtration rate (GFR), and renal blood flow (RBF). B. ARAS developed STK fibrosis (trichrome, blue) and glomerulosclerosis, which elamipretide alleviated. N, Normal; N+E, Normal+elamipretide; A, ARAS; A+E, ARAS+elamipretide. *P<0.05 vs. Normal, †P<0.05 vs. ARAS.

Glomerulosclerosis, tubulointerstitial fibrosis, and oxidative stress:

ARAS developed STK fibrosis and glomerulosclerosis (P=0.001 and P<0.0001 vs. Normal, respectively), but elamipretide abolished fibrosis (P=0.02 vs. ARAS) and alleviated, albeit not normalized, glomerulosclerosis (P<0.0001 vs. ARAS) (Figure 1B). Renal production of superoxide anion was increased in ARAS (P=0.005 vs. Normal) and attenuated after elamipretide treatment (P=0.005 vs. ARAS) (Figure 2A).

Figure 2. Elamipretide alleviates oxidative stress and restores renal mitochondrial function.

A. Renal production of superoxide anion (DHE: pink, DAPI: blue) was increased in atherosclerotic renal artery stenosis (ARAS) and attenuated by elamipretide. B. Elamipretide increased total cardiolipin content and complex-IV activity in the ARAS kidney, while mitochondrial ATP/ADP ratios were not different among the groups. Renal expressions of PGC-1α and PPAR-α increased in ARAS, and elamipretide reversed them. Renal expressions of MFN-2 and DRP-1 were elevated in both ARAS and ARAS+elamipretide kidneys. N, Normal; N+E, Normal+elamipretide; A, ARAS; A+E, ARAS+elamipretide. *P<0.05 vs. Normal, †P<0.05 vs. ARAS.

Mitochondrial markers

Total cardiolipin content was decreased in ARAS compared to Normal (P=0.03) and restored after elamipretide treatment (P=0.008 vs. ARAS) (Figure 2B). COX-4 activity was unchanged in the ARAS STK compared to Normal, but higher in ARAS+ELAM vs. ARAS (P=0.02). Mitochondrial ATP/ADP ratios were not different among the groups (P=0.18). Renal expression of the mitochondrial biogenesis markers, PGC-1α and PPAR-α, was increased in ARAS compared with Normal (P=0.04 and 0.004, respectively), and elamipretide tended to normalize them (P=0.05 and 0.07 vs. ARAS, respectively). ARAS increased STK expression of the fusion marker MFN-2 (P=0.002 vs. Normal), which elamipretide did not affect in ARAS (P=0.5), but elevated in Normal kidneys (P=0.01 vs. Normal). Renal expression of DRP-1 in ARAS was higher than in Normal (P=0.0002) and further elevated in ARAS+ELAM (P=0.02). In immunofluorescent staining, the percent area of Parkin-TOM20 co-localization, indicating mitophagy, was lower in ARAS than in Normal (P=0.01) and restored in ARAS+ELAM (P=0.005 vs. ARAS) (Figure 3A). Parkin expression in isolated mitochondria tended to decrease in ARAS vs. Normal (P=0.08), and increased in ARAS+ELAM compared with ARAS (P=0.02) (Figure 3B). P62 expression was higher in Normal+ELAM, ARAS, and ARAS+ELAM than in Normal kidneys (P=0.008, P<0.0001, and P<0.0001, respectively), but was lower in ARAS+ELAM than in ARAS (P=0.02), suggesting that decreased mitophagy in ARAS was improved in ARAS+ELAM. In terms of morphology, ARAS mitochondria were fewer and more round than normal groups, and dispersed in the cytoplasm, showing mitochondrial damage (Figure 3C). Despite a significant increase in mitochondrial density, some ARAS+ELAM mitochondria remained fragmented and located in perinuclear area, possibly due to the increase in mitochondrial fission and mitophagy.

Figure 3. Elamipretide restores mitophagy in atherosclerotic renal artery stenosis (ARAS) kidneys.

A. The area of TOM20 (green) and Parkin (red) co-staining in renal tubules (arrow), reflecting mitophagy, was decreased in ARAS and restored in ARAS+elamipretide. Blue, DAPI. B. Elamipretide increased Parkin in mitochondria and decreased P62 expression in the ARAS stenotic kidneys. C. Representative confocal images of TOM20 (green) at 100× magnification. In ARAS, mitochondria were more round and fewer than normal groups, and dispersed in the cytoplasm. Despite a significant increase in mitochondrial density, some ARAS+elamipretide mitochondria remained fragmented and located in perinuclear area. N, Normal; N+E, Normal+elamipretide; A, ARAS; A+E, ARAS+elamipretide. *P<0.05 vs. Normal, †P<0.05 vs. ARAS.

Renal senescence

Positive SA-β-Gal staining was markedly increased in both the ARAS STK medulla and cortex compared with Normal (P=0.03 and P=0.006, respectively), and decreased after elamipretide (both P=0.02), yet was not fully normalized (Figure 4A). The number of p16+ cells increased or tended to increase in both ARAS and ARAS+ELAM (P=0.01 and 0.06 vs. normal, respectively) (Figure 4B). Identified by location and morphology, renal tubular, interstitial, and endothelial cells were p16+ in ARAS. Furthermore, some endothelial cells in ARAS co-expressed SA-β-gal and CD31, underscoring endothelial cell senescence, which tended to decrease in ARAS+ELAM (P=0.06 vs. ARAS) (Figure 6). In ARAS, the number of Ki67-positive cells was not different from normal despite renal injury (P=0.31), whereas their number was increased in ARAS+ELAM compared to normal pigs (Figure 4C, P=0.05). The numbers of SAHF-positive cells per field were increased both in ARAS and ARAS+ELAM compared to normal (Figure 4D, P=0.04 and 0.02, respectively). Renal SA-β-Gal activity was higher in ARAS and ARAS+ELAM than in Normal (both P=0.01), and elamipretide tended to decrease it, but this did not reach statistical significance (Figure 5A, P=0.06 vs. ARAS). H2AX activation (phosphorylated-to-total H2AX protein ratio) was elevated in the ARAS kidney (P=0.008 vs. Normal), but unaffected by elamipretide (P=0.8 vs. ARAS) (Figure 5B). While renal p16 and p21 gene expression did not differ among the groups (P=0.14 and 0.72, respectively), p53 gene expression was increased in ARAS (P=0.03 vs. Normal), decreased after elamipretide treatment (Figure 5C, P=0.05 vs. ARAS), and directly correlated with SA-β-Gal positivity in the ARAS STK cortex.

Figure 4. Elamipretide decreases senescence-associated β-galactosidase (SA-β-gal) activity in the stenotic kidneys (STKs).

A. SA-β-Gal positive area (blue) increased both in the medulla and cortex of atherosclerotic renal artery stenosis (ARAS) STK, and decreased after elamipretide. B. P16-positive cells were increased in ARAS and tended to remain elevated in ARAS+elamipretide compared to normal pigs. Renal tubular (yellow arrowhead), interstitial (red arrowhead), and endothelial (red arrow) cells were p16-postivie in ARAS. C. In ARAS, the number of Ki67-positive cells (pink) per field was not different from normal, but increased in ARAS+elamipretide compared to in normal pigs. D. The numbers of senescence-associated heterochromatin-foci (SAHF)-positive cells (red) per field increased in ARAS and persisted in ARAS+elamipretide compared to normal. N, Normal; N+E, Normal+elamipretide; A, ARAS; A+E, ARAS+elamipretide. *P<0.05 vs. Normal, †P<0.05 vs. ARAS.

Figure 6. Elamipretide slightly improves endothelial cell senescence.

A few population of cells expressed both SPiDER-βGal (green) and CD31 (red) in atherosclerotic renal artery stenosis (ARAS), suggesting endothelial cell senescence, which tended to decrease in ARAS+elamipretide. N, Normal; N+E, Normal+elamipretide; A, ARAS; A+E, ARAS+elamipretide.

Figure 5. Elamipretide decreases p53 gene expression in stenotic kidneys (STKs), whereas expression of γ-phosphorylated histone-2AX (γH2AX), PAI-1, MCP-1, and TGFβ remained unaltered.

A. Renal SA-β-Gal enzyme activity was elevated in atherosclerotic renal artery stenosis (ARAS) and ARAS+elamipretide, and only slightly decreased by elamipretide. B. γH2AX activation in ARAS remained unchanged in the ARAS+elamipretide kidney. C. Renal p16 and p21 gene expression did not differ among the groups, whereas p53 gene expression was increased in ARAS and decreased after elamipretide treatment. D. PAI-1, MCP-1 and TGFβ expression was upregulated in both ARAS and ARAS+elamipretide kidneys, while TNFα expression levels were not different among the groups. E. The expression of PAI-1 and MCP-1 levels was directly correlated with renal γH2AX expressions and SA-β-Gal activity. N, Normal; N+E, Normal+elamipretide; A, ARAS; A+E, ARAS+elamipretide. *P<0.05 vs. Normal, †P<0.05 vs. ARAS.

Expression of the SASP components PAI-1 and MCP-1 was increased in both the ARAS (P=0.001 and P=0.001 vs. Normal, respectively) and ARAS+ELAM (P<0.0001 and P=0.0002 vs. Normal, respectively) STK (Figure 5D), and TGFβ expression showed a similar pattern (p=0.002 and p=0.0002 vs. Normal, respectively). TNFα expression was unchanged among the groups (P=0.72). The expression levels of PAI-1 and MCP-1 were directly correlated with renal γH2AX expressions and SA-β-Gal activity (Figure 5E).

Discussion

The current study shows that ARAS is associated with cellular senescence and accumulation of dysfunctional mitochondria in the STK. The mitochondrial-targeted peptide elamipretide restores mitophagy and biogenesis as well as mitochondrial cardiolipin, and improves renal function and redox status in the ARAS STK. However, elamipretide only partly alleviates cellular senescence. This finding argues against a strong causal relationship between mitochondrial dysfunction and cellular senescence in the early stage of ARAS.

One of the interesting observations in our study was that ARAS induced STK cellular senescence. We found that SA-β-Gal activity, p16, SAHF, and γH2AX expression, representing accumulation of senescent cells [26], and levels of the SASP markers PAI-1 and MCP-1, and TGFβ expression [27], were all elevated in the ARAS STK. Furthermore, cellular proliferation failed to rise in the ARAS STK, despite ischemic renal injury. This observation may account for our previous finding of blunted apoptosis in stenotic ARAS kidneys [28], a characteristic of senescent cells [5].

The factors promoting senescence in the ARAS kidney may include factors like hypercholesterolemia, atherosclerosis, increased blood pressure, and renal ischemia. High-fat diet leads to vascular endothelial senescence, associated with prominent inflammation and endothelial dysfunction [29]. In more advanced atherosclerosis, complex mechanisms including telomere attrition, accumulated DNA damage, increased oxidative stress, and epigenetic modifications result in cellular senescence [30]. Notably, senescent cells exacerbate atherosclerosis at all stages, and clearing them leads to lesion regression [6]. In addition, high blood pressure and renin-angiotensin-aldosterone system activation induce senescence in renal tubular, glomerular, and interstitial cells, indicated by increased p16^INK4a expression through p38-MAPK activation [31]. Cycle arrest may also be mediated by hypoxia-inducible factors induced by renal ischemia, which promote cellular senescence [32], and by aldosterone in tubular cells via a p53/21-dependent pathway [33]. Hence, both atherosclerosis and renal ischemia in our model can induce cellular senescence in various cell types, including renal tubular, interstitial, and endothelial cells.

Moreover, increased oxidative stress and mitochondrial dysfunction might be related to cellular senescence. ROS induce DNA damage by adversely affecting nuclear DNA and proteins, and mitochondria are leading targets for ROS damage as well as a major source of ROS [34]. Oxidative stress activates p53-signalling, which mediates the antiproliferative cellular responses including senescence [35]. Indeed, p53 gene expression was upregulated in the ARAS STK and, further, directly correlated with SA-β-Gal activity. Tumor suppressor pathways like p16 are pivotal in engagement of senescence, but cytokine-signaling pathways can also initiate senescence [36]. We detected no significant changes in p16 mRNA expression, but observed upregulation of p16 protein expression in ARAS STK. This discrepancy between gene and protein expressions might be secondary to differences in protein translation and degradation rates [37]. In addition, at the early stage of ARAS senescence might involve primarily activation of p53 and cytokine signaling, whereas the p16 pathway plays a lesser role. Moreover, in many cell lines p21 activation is temporary, and the level of this protein decreases after cell cycle arrest [38].

The pro-senescence and inflammatory milieu associated with autocrine and paracrine SASP is in turn implicated in tissue injury [39]. SASP cytokines involved in inflammation, monocyte chemotaxis, and proteolysis, which atherosclerosis contribute to pro-atherogenic process including extracellular matrix degradation and weakening of the vessel wall [6]. In our study, the role of PAI-1 and MCP-1 as SASP markers is underscored by the observation that their levels directly correlated with SA-β-Gal activity and γH2AX expression. We have previously shown that upregulated expression of MCP-1 in the STK contributes to functional and structural impairment by inflammatory cell infiltration, and its inhibition confers renoprotective effects [40]. We also found increased PAI-1 level in ARAS, suggesting that its biologic role including fibrinolytic inhibition might contribute to progression of atherosclerosis in ARAS [41]. A recent study has shown that TGFβ, which was upregulated in ARAS kidneys, also contributes cellular senescence of neighboring cells [42], as well as its pro-fibrotic effect. Thus, SASP may be responsible at least in part for kidney injury of ARAS.

We have also detected altered expression of proteins responsible for regulating mitochondria in the ARAS-STK. Our group has previously shown that increased mitochondrial ROS production is associated with peroxidation and loss of cardiolipin in ARAS [3]. Peroxidation of mitochondrial membrane phospholipids and thereby mitochondrial dysfunction are considered as contributors to age-related disease [43]. This study shows that the levels of the mitochondrial biogenesis regulators PGC-1α and PPAR-α increased in ARAS, possibly to compensate for mitochondrial dysfunction, as were regulators of both fusion and fission. Previous studies suggest an overall shift toward fusion in senescent cells, allowing mitochondria to maintain ATP production and escape autophagy [44, 45]. Pertinently, energy production levels in the ARAS STK appeared to be relatively preserved. The downregulated mitophagy markers in the ARAS STK, including increased P62 and decreased Parkin, may lead to accumulation of dysfunctional mitochondria that produce more ROS. Indeed, mitophagy activity is reduced in senescent cells [46, 47], as a result of lipofuscin accumulation and lysosomal dysfunction [48]. Taken together, the ARAS STK showed cardiolipin loss, altered mitochondrial dynamics, and defective mitophagy, yet sustained COX-4 activity and upregulated biogenesis regulators, which might be an adaptive compensatory response potentially associated with senescence in the early stage of ARAS.

Our group has previously demonstrated that mitoprotection achieved by restoring cardiolipin attenuated oxidative stress and injury of the kidney or heart in metabolic syndrome and ARAS [3, 19, 20]. Elamipretide prevents cardiolipin peroxidation through the inhibition of cytochrome-c peroxidase, improves electron carrier function, enhances ATP and decreases ROS production [49]. In this study, cardiolipin content was normalized, and oxidative stress ameliorated in the ARAS STK after elamipretide. Furthermore, elamipretide reinstated abnormally increased biogenesis and may have facilitated removal of dysfunctional mitochondria through activation of mitophagy in ARAS. Although both MFN-2 and DRP-1 were increased in ARAS+ELAM, only DRP-1 expression was significantly higher than in ARAS, consistent with the suggestion that fission is a prerequisite for mitophagy [50, 51].

Overall, Elamipretide normalized STK-RBF and GFR, and alleviated fibrosis in ARAS, as previously shown [3]. In our previous study, elamipretide improved renal microvascular remodeling and vascular endothelial function in ARAS [3]. In the current study we found that ARAS endothelial cells underwent senescence, which elamipretide slightly blunted, implying that senescence in endothelial cells might be linked to dysfunction of their mitochondria.

Interestingly, elamipretide decreased SA-β-Gal activity in ARAS, but not γH2AX activation. The lysosomal enzyme β-Gal is markedly increased in senescent cells, and when detectable at pH 6.0 with the artificial substrate X-gal, is defined as SA-β-Gal [52]. While a commonly used senescence marker, in inflammatory conditions activated phagocytes can also increase β-Gal activity [52]. γH2AX is a sensitive marker for DNA double-strand breaks, although it has limited specificity for the phenotype in vivo [53]. A recent study has shown that mitochondrial dysfunction-associated senescence is not caused by accumulation of nuclear DNA damage, but by activation of 5’AMP-activated protein kinase and in turn p53 [54]. Indeed, p53 expression in this study was decreased after elamipretide treatment. Taken together, mitoprotection by elamipretide does not be seen to arrest DNA damage in the STK, but may partly blunt senescence by other pathways, including p53. While elamipretide improves glomerular senescence and architecture in the kidney of aged mice, STK ischemic damage may be more pronounced and involve a multitude of mechanisms [55].

This study is limited by the small group sizes. Our swine ARAS model involves a short duration and early disease stage, yet incurs comparable renal alterations to those in human ARAS kidneys [15]. The relatively young age of the animals in the current study excludes effects of aging on senescence. Mitochondrial studies were performed in renal tissue, not specifically in renal senescent cells, which are difficult to isolate, limiting the ability to directly link mitochondrial changes and senescence. Hence, a firm cause-effect relationship between senescence and mitochondrial dysfunction in ARAS remains to be established. Further studies are needed to determine the precise cell type undergoing senescence. Lastly, whether elamipretide would impact long-term renal senescence warrants further investigation.

Conclusion

In summary, mitochondrial protection improved renal function and alleviated tissue fibrosis, but only partly mitigated ARAS-induced cellular senescence. Mitochondrial dysfunction may not be the chief inducer of cellular senescence in early ARAS, possibly because of the multiple injurious pathways activated. Nevertheless, the impact of cellular senescence in ARAS on long-term renal functional and structural outcomes, and in turn application of senolytic strategies, remains to be considered.
