Beyond Breast Density: Risk Measures for Breast Cancer in Multiple Imaging Modalities

Abstract

Breast density is an independent risk factor for breast cancer. In digital mammography and digital breast tomosynthesis, breast density is assessed visually using the four-category scale developed by the American College of Radiology Breast Imaging Reporting and Data System (5th edition as of November 2022). Epidemiologically based risk models, such as the Tyrer-Cuzick model (version 8), demonstrate superior modeling performance when mammographic density is incorporated. Beyond just density, a separate mammographic measure of breast cancer risk is parenchymal textural complexity. With advancements in radiomics and deep learning, mammographic textural patterns can be assessed quantitatively and incorporated into risk models. Other supplemental screening modalities, such as breast US and MRI, offer independent risk measures complementary to those derived from mammography. Breast US allows the two components of fibroglandular tissue (stromal and glandular) to be visualized separately in a manner that is not possible with mammography. A higher glandular component at screening breast US is associated with higher risk. With MRI, a higher background parenchymal enhancement of the fibroglandular tissue has also emerged as an imaging marker for risk assessment. Imaging markers observed at mammography, US, and MRI are powerful tools in refining breast cancer risk prediction, beyond mammographic density alone.

© RSNA, 2023

Summary

Going beyond mammographic density, this article describes the range of imaging markers associated with breast cancer risk in digital mammography, digital breast tomosynthesis, whole-breast US, and MRI.

Essentials

• ■ Breast density assessed with digital mammography or digital breast tomosynthesis is an independent risk factor for developing breast cancer and is included in several risk-assessment models.

• ■ Beyond mammographic density, the spatial arrangement of fibroglandular tissue can be assessed with radiomic features and deep learning, identifying complex parenchymal patterns associated with higher risk.

• ■ While both stromal and glandular components of fibroglandular tissue appear bright or "dense" on mammograms, breast US allows the two components to be visualized separately in a manner that is not possible with mammography; a higher glandular component at screening breast US is associated with higher risk for breast cancer.

• ■ On breast MRI scans, higher background parenchymal enhancement of normal fibroglandular breast tissue is associated with a higher risk for breast cancer.

Introduction

Individuals with dense breasts are at higher risk for breast cancer, as well as cancer masking by dense breast tissue, than individuals at otherwise similar risk who have less dense breasts (1,2). Breast density refers to fibroglandular tissue, which has both “fibrous” (stromal) and glandular (lobular and ductal) components (3). Fibroglandular tissue appears dense (white) on both two-dimensional digital mammography (DM) and digital breast tomosynthesis (DBT) images; adipose tissue appears darker (4). Breast density tends to decrease with age, having children, and tamoxifen use (an estrogen blocker), but increases with lower body mass index and hormonal replacement therapy (5–9).

The prevalence of mammographically dense breasts is approximately 43% in women aged 40–74 years in the United States (10). In addition to notification of mammographic density (11), supplemental screening with whole-breast US or MRI can be considered in women with dense breasts due to the combination of masking of cancers by dense breast tissue and the increase in cancer risk with increasing breast density. These supplemental screening modalities offer higher sensitivity in women with dense breasts, but with the trade-off of increasing the number of false-positive findings (12,13).

Breast cancer most frequently arises from ductal and glandular elements of the breast. This article provides an overview of imaging markers of these structures. In DM and DBT, risk is measured through the amount and textural complexity of dense fibroglandular tissue. Breast US offers the ability to visualize the two components of fibroglandular tissue separately (stromal and glandular) and, thus, measure risk in terms of the relative proportion of glandular to stromal tissue. Breast MRI quantifies the dynamic enhancement of normal breast parenchyma, also an independent imaging marker. Similar to MRI, increased background parenchymal enhancement (BPE) levels at contrast-enhanced mammography (14,15) and background parenchymal uptake at molecular breast imaging (16) may be an indication of breast cancer risk and, thus, is important to report. However, as of November 2022, contrast-enhanced mammography and molecular breast imaging are not widely used and, hence, they are not included in the current review.

DM and DBT

Mammographic Density

Early works in mammography assessed breast cancer risk with categorical measures, including the four patterns defined by Wolfe (17), the Tabár classification of five categories based on histopathologic-mammographic correlations (18), and the six categories of percent density proposed by Boyd et al (19). To standardize clinical image interpretations, the American College of Radiology developed the Breast Imaging Reporting and Data System (BI-RADS) with four risk categories in DM and DBT based on breast density (Fig 1). The 4th edition (20) used percent density in assessing risk. In the 5th edition (21), percent density was removed. Instead, the impact of breast density on obscuring or “masking” underlying cancer (degree of masking) is emphasized (Table 1). The classifications are as follows: (a) almost entirely fatty; (b) scattered areas of fibroglandular density; (c) heterogeneously dense, which may obscure detection of small masses; and (d) extremely dense, which lowers the sensitivity of mammography. An example of a breast that would be classified differently by the two editions is one with a high concentration of fibroglandular tissue in a single area (Fig 2) but less than 51% percent density. This breast would be classified as “category 2: scattered densities (approximately 25%–50% glandular)” according to the 4th edition. However, this breast would be categorized as “category C: heterogeneously dense, which may obscure detection of small masses” according to the 5th edition because the dense retroareolar tissue could obscure lesions.

Figure 1:

Mediolateral oblique digital mammograms illustrating the four categories of visually assessed breast density according to the 5th edition of the Breast Imaging Reporting and Data System show (A) breast that is almost entirely fatty; (B) breast with scattered areas of fibroglandular density; (C) breast that is heterogeneously dense, which may obscure detection of small masses; and (D) breast that is extremely dense, which lowers the sensitivity of mammography. Of note, with increasing higher density, there is a higher risk of breast cancer.

Table 1:

Categories of the American College of Radiology BI-RADS Assessment of Mammographic Breast Density

Figure 2:

Mediolateral oblique screening digital mammogram in a 56-year-old woman shows dense tissue in the anterior subareolar area of the breast (arrow). If assigned a Breast Imaging Reporting and Data System (BI-RADS) breast density based on the 4th edition, the percent density in the breast would be less than 51% and, therefore, would be considered category 2 or “scattered fibroglandular densities.” However, if classified according to the 5th Edition of BI-RADS for density, the dense tissue in the anterior breast could “mask” or obscure a lesion, causing a reduction in detection sensitivity. Based on the density definitions in the 5th Edition, this breast would be considered “heterogeneously dense, which may obscure detection of small masses.”

BI-RADS risk assessment is prone to interreader variability (22). Attempts have been made to standardize BI-RADS risk assessment with deep learning (23). For example, Lehman et al (24) found that 90% of four-category classifications with DM using deep learning were accepted by the interpreting radiologist. Additionally, 94% of binary (dense vs nondense) classifications were accepted by the radiologist; among discordant classifications, 33% were downgraded from dense to nondense, whereas 67% were upgraded from nondense to dense. As noted in that work, results may have been impacted by changes in BI-RADS editions, with each edition offering a different perspective on breast cancer risk. The 4th edition emphasizes the role of percent density in breast cancer risk prediction, yet the 5th edition emphasizes the role of dense tissue in cancer masking (reducing sensitivity).

As an alternative to categorical measures of density, previous works have calculated area-based percent density (total dense area relative to breast area). The reference standard software for this calculation is Cumulus (University of Toronto), which enables manual segmentation of dense tissue. Attempts have been made to automate the calculation with deep learning (25–27), and similarity to manual segmentation of dense tissue has been demonstrated, for example, with Dice coefficients of 63% in Kallenberg et al (25) and 76% in Li et al (26). As of November 2022, there are at least nine U.S. Food and Drug Administration–approved density assessment methods for DM, DBT, and synthetic mammography (SM) using artificial intelligence (28).

One application of area-based percent density is discriminating individuals at high risk from those at low risk. For example, Maghsoudi et al (27) used multiple research and commercial density assessment methods to distinguish cases that developed cancer an average of 4.7 years after a negative or benign DM examination from controls. Areas under the receiver operating characteristic curve (AUCs) ranged from 0.557 to 0.619, similar to other works (25,29,30) analyzing area-based percent density. An AUC of 0.70 or greater is considered acceptable for predictive modeling (31).

Breast density can also be assessed three-dimensionally by total dense volume (sum total of fibroglandular pixel volumes) and volumetric percent density (total dense volume relative to breast volume), for example, by using Quantra (Hologic) and Volpara (Volpara Health). To illustrate differences between these measures, four breasts with variations in total dense volume yet effectively equivalent volumetric percent density (approximately 25%) are shown (Fig 3). Brandt et al (32) found that volumetric percent density at DM offered stronger association with breast cancer risk than total dense volume.

Figure 3:

Mediolateral oblique digital mammograms in four different women show effectively equivalent volumetric percent density (approximately 25%) but broad variation in the total dense volumes, which range from 62 mL to 233 mL. Volume-based density measures include the total dense volume (sum total of all fibroglandular pixel volumes) and volumetric percent density.

Augmenting Epidemiologically Based Models with Breast Density

Various works showed that augmenting epidemiologically based models with breast density improves AUC (33–35). Brentnall et al (35) augmented the Gail and Tyrer-Cuzick models with radiologist visual assessment of area-based percent density, improving the AUCs from 0.55 to 0.59 and from 0.57 to 0.61, respectively, for 10-year risk assessment.

As of November 2022, at least three risk-assessment models incorporate mammographic density (Table 2). For example, in the Tyrer-Cuzick model (version 8), mammographic density is typically measured in terms of volumetric percent density or BI-RADS density, as Brentnall et al concluded that total dense volume is a weaker predictor of risk than these two density measures (36). Adding breast density to the Tyrer-Cuzick model improved the accuracy of risk stratification for both women at high-risk (>8%, 10-year risk) and those at low-risk (<2%, 10-year risk). The percentage of patients considered high risk increased from 4.8% (without density) to 7.1% (BI-RADS density) and 6.8% (volumetric percent density).

Table 2:

Risk Models That Include Breast Density in Risk Calculations

Assessing Breast Texture with Radiomic Features

Breast parenchymal complexity quantifying the spatial arrangement of fibroglandular tissue is a separate measure of breast cancer risk. Parenchymal complexity can be assessed with high-throughput extraction of radiomic features (37), which can be visualized in DM with heat maps of the breast area; skewness (a gray-scale feature) and entropy (a co-occurrence feature) are examples (Fig 4) (38). Examples of breasts varying in terms of both density and complexity are illustrated in Figure 5 (39).

Figure 4:

(A, B) Digital mammographic heat maps show radiomic feature calculations in the breast area; for example, skewness (A) (a gray-scale feature) and entropy (B) (a co-occurrence feature). (C) To capture heterogeneities in breast texture in the breast area (dashed yellow line), radiomic features can be calculated in multiple windows whereby each window (example in red, with the length of each side defined as W) is centered on a lattice point (blue circle) and green lines define the lattice grid, with the spacing between lattice points defined as D. (Reprinted, with permission, from reference 38.)

Figure 5:

Mediolateral oblique digital mammograms with negative findings at screening in women with (A) high density and high complexity, (B) high density and low complexity, (C) low density and high complexity, and (D) low density and low complexity. Breast density is associated with higher risk for developing breast cancer. In addition, breasts with more complex parenchymal patterns are at higher risk for breast cancer. These parenchymal patterns were assessed with handcrafted radiomic features to develop an overall complexity score. (Reprinted, with permission, from reference 39.)

In some works (40,41), a single region of interest is used in radiomic feature extraction. Alternatively, multiple regions of interest capture heterogeneities in breast texture. Sun et al (42) partitioned the breast into five subregions varying from the densest region to the whole breast. In assessing near-term risk (the risk of cancer at the next DM examination), the AUC in case-control classification was higher when extracting radiomic features from different subregions as opposed to the whole breast. Zheng et al (38) created a lattice of windows for radiomic feature extraction in DM, with cases defined by the contralateral image of a cancer-positive mammogram. That work found case-control classification to be optimized with a 6.3 mm window size (the smallest considered); that is, AUCs of 0.59 (area-based percent density), 0.85 (radiomics), and 0.86 (radiomics plus area-based percent density).

Another application of radiomics is discriminating BRCA1 and BRCA2 variant carriers from controls (43–45). Clinically, this may prove important if a patient’s genetic history is unknown. For example, Li et al (45) showed that radiomic features (AUC, 0.81) performed better than area-based percent density (AUC, 0.53) for discriminating BRCA1 and BRCA2 variant carriers from controls.

Deep Learning in Breast Cancer Risk Assessment

Recent advances in deep learning have allowed the computer to “learn” the features associated with breast cancer risk (23). Although handcrafted radiomic features could potentially be more interpretable, the advantage of deep learning is that features predictive of risk do not need to be known a priori.

Various works (46–48) have shown that deep learning models are more predictive of risk than mammographic density alone; for example, Arefan et al (46) analyzed cancer cases and controls using negative or benign DM images from at least 1 year prior. In that study, the deep learning model with the highest AUC (0.73) performed better than area-based percent density (AUC, 0.54). Ha et al (48) used a convolutional neural network–based pixel-wise risk model to identify women at high-risk by analyzing negative mammograms from at least 2 years prior to cancer (with controls having at least a 2-year follow-up with negative findings). In pixel-wise heat maps, areas in red have features that overlap with patients who developed cancer, as opposed to normal areas in blue (Fig 6). Heat maps with substantially more red areas allow the patient at higher risk to be identified among two heterogeneously dense breasts (Fig 6A, 6B), as well as among breasts with scattered areas of fibroglandular density (Fig 6C, 6D), illustrating how risk is predicted in a manner separate from mammographic density.

Figure 6:

(A, B) Mammograms (left) of heterogeneously dense breasts are analyzed in terms of a convolutional neural network–based pixel-wise risk model (right), which identifies the breast at higher risk for cancer (A) by having more substantial areas in red, corresponding to features that overlap with patients who developed breast cancer, as opposed to normal (blue) areas. (C, D) Similarly, among two breasts with scattered areas of fibroglandular density at mammography (left), the breast at higher risk for cancer (C) is identified by having more substantial red areas (right). (Reprinted, with permission, from reference 48.)

Previous works have investigated deep learning to refine risk models in clinical use. For example, for 5-year risk assessment, Yala et al (49) evaluated the AUCs of a risk factor–based logistic regression model using traditional risk factors (AUC, 0.67), an image-only deep learning model for DM (AUC, 0.68), and a hybrid deep learning model combining traditional risk factors and DM images (AUC, 0.70). The hybrid deep learning model achieved a statistically significant gain in AUC over the Tyrer-Cuzick version 8 model (AUC, 0.62). Additionally, AUCs obtained with the Tyrer-Cuzick version 8 model differed by race and ethnicity (eg, 0.45 and 0.62 for African American and White women, respectively), yet AUCs obtained with the hybrid deep learning model were insensitive to race and ethnicity (0.71).

In a subsequent study, Yala et al (50) developed Mirai, a mammography-based deep learning model, to assess 1- to 5-year risk at DM. In a test set consisting of patients who developed cancer within 5 years, 41.5% of patients were successfully identified as high risk with Mirai as opposed to 36.1% with the hybrid deep learning model and 22.9% with the Tyrer-Cuzick version 8 model, illustrating how deep learning improves risk stratification over the Tyrer-Cuzick version 8 model.

Digital Breast Tomosynthesis

As of November 2022, DBT has become widespread for mammography screening (51,52). DBT uses a reconstruction in combination with a two-dimensional image, obtained either with DM or SM (53,54). Previous works compared DM, DBT, and SM in terms of density assessments. Tice et al (55) found no difference in BI-RADS density classifications at DM and DBT in data from 2010 to 2017 (under the 4th and 5th editions of BI-RADS), and no difference in the strength of the association between mammographic density and invasive breast cancer. Haider et al (56) found that SM did not significantly change binary (dense vs nondense) classifications compared with DM. Other works, however, found that use of DBT with SM downgraded BI-RADS density classifications (57–59); Aujero et al (58) and Zuckerman et al (59) suggested that this may be related to perceptual adaptation to SM.

Lotter et al (60) applied deep learning to detect cancers in DBT based on the use of a maximum suspicion projection. Risk modeling in DBT is still an open area of research. Given that deep learning is already computationally intensive in DM, future applications in DBT are expected to be even more computationally demanding. At a typical DBT examination, 300 images may be produced while only four images are produced at DM. Deep learning in DBT is also challenging due to the anisotropic voxels (differing sizes in three directions) and variations in the compressed breast thickness. Early studies suggested improved performance in DBT risk prediction compared with DM data alone (60,61). Eriksson et al (61,62) showed that combining deep learning features (density, calcifications, masses) with familial, demographic, lifestyle, and polygenic risk scores achieved a higher AUC for a 2-year risk model (DM = 0.73, DBT = 0.83) than the Tyrer-Cuzick version 8 model (AUC, 0.62).

Breast US

Tissue Composition at Breast US: BI-RADS Classification

Tissue composition at breast US is classified as homogeneous background echotexture (fat), homogeneous background echotexture (fibroglandular), and heterogeneous background echotexture according to the BI-RADS, 5th edition (63). These three categories correspond loosely to the four density descriptors of mammography (Fig 7). Dense breasts on mammograms usually fall within the homogeneous background echotexture (fibroglandular category), defined as a thick layer of fibroglandular tissue beneath the subcutaneous fat layer, irrespective of the internal echogenicity patterns within the fibroglandular tissue.

Figure 7:

Top: Classification of tissue composition at breast US according to the Breast Imaging Reporting and Data System, 5th edition. Representative US images show (A) homogeneous background echotexture (fat), (B) homogeneous background echotexture (fibroglandular), and (C) heterogeneous background echotexture. Bottom: Corresponding craniocaudal mammograms show (A) almost entirely fat, (B) extremely dense, and (C) heterogeneously dense or scattered fibroglandular tissue at mammography.

In several studies on US assessments of mammographic parenchymal patterns or breast density, a significant correlation between mammographic and US assessments was found (64–66). In a prospective study by Kim et al (67), assessments of breast density using real-time US was in exact agreement with 86% of mammograms when BI-RADS density categories were dichotomized into fatty (almost entirely fatty and scattered areas of fibroglandular density) and dense (heterogeneously dense and extremely dense).

Internal Echogenicity Patterns of Fibroglandular Tissue

The sonographic appearance of fibroglandular tissue may vary between individuals and over time in the same individual (68). Several studies have proposed methods for classifying internal echogenicity patterns within the fibroglandular tissue. Hou et al (69) classified sonographic parenchymal patterns into four types (heterogeneous, ductal, mixed, and fibrous) based on the different compositions of ducts, fibroglandular tissue, and fat lobules. Lee et al (70) evaluated the proportions of isoechoic or hypoechoic areas representing glandular tissue relative to hyperechoic areas representing fibrous stroma in the fibroglandular tissue. The authors classified the amount of glandular tissue component in the fibroglandular tissue as minimal, mild, moderate, or marked (Fig 8). The glandular tissue component was visually estimated after scanning the entire breast. Sonographic glandular tissue component classification can be estimated more easily in the large field of views of automated breast US (71,72). The differences in the evaluation of the glandular tissue component and BI-RADS tissue composition are summarized in Table 3.

Figure 8:

(A) Handheld breast US and (B) automated breast US images show qualitative four-category classification of the glandular tissue component in women with dense breasts. When distribution of the glandular tissue component in the breast is not uniform, the dominant pattern seen in at least two quadrants, or in the area of densest fibroglandular tissue, is subjectively determined to be the glandular tissue component.

Table 3:

Comparison of Tissue Composition and Glandular Tissue Component at Breast US

Internal Echogenicity Patterns and Breast Cancer Risk

The association of internal echogenicity patterns of fibroglandular tissue with breast cancer risk is explained by the fact that breast US can be used to distinguish between glandular and stromal tissues in the fibroglandular tissue on the basis of their echogenicity in a manner that is not possible with mammography. Breasts that appear similarly dense at mammography may show a wide spectrum of patterns at breast US and histologic assessment, with predominantly hyperechoic fibrous tissue at one extreme and abundant isoechoic or hypoechoic glandular tissue at the other (Fig 9). The breast lobule or terminal duct lobular unit is known to be the primary anatomic source of breast cancer, and the progressive degrees of lobular involution are associated with a reduced risk of developing breast cancer (73). Women with dense breasts on mammograms have varying degrees of lobular involution (74) and, therefore, may have different breast cancer risk, which could be stratified by sonographic glandular tissue component assessment. A previous study in 233 women showed that a higher glandular tissue component at breast US is associated with less degree of lobular involution (70).

Figure 9:

Spectrum of sonographic and histologic appearance of dense breasts at mammography. (A) Craniocaudal mammograms show extremely dense fibroglandular tissue in both cases. (B) Breast US images show predominately hyperechoic fibrous tissue at one end (left) and abundant isoechoic or hypoechoic glandular tissue at the other end (right) of the spectrum. (C) Histologic images (hematoxylin-eosin [H&E] stain; original magnification, x200) show the breast lobules are involuted and replaced by fibrous stroma in the former case (left), whereas the lobular involution is minimal and the size and number of acini per lobule is large in the latter case (right). GTC = glandular tissue component. (Reprinted, with permission, from reference 70.)

A recent retrospective study that included 541 women with cytopathologic confirmation of cancer and 849 age-matched women without cytopathologic confirmation of breast cancer evaluated four types of sonographic parenchymal patterns (75). The authors showed that the heterogeneous type (odds ratio, 3.97; P < .001) and fibrous type (odds ratio, 2.70; P < .001) were associated with breast cancer. Another recent retrospective cohort study evaluated the association between the glandular tissue component on breast US images and future breast cancer risk (70). Among the 8483 women with mammographically determined dense breasts who underwent supplemental US screening, 137 (1.6%) developed breast cancer during a median follow-up time of 5.3 years. The incidence of breast cancer in women with a high glandular component was significantly higher than in women with a low glandular component (P = .01). In multivariable analysis, the baseline glandular tissue component was the only factor associated with breast cancer risk (hazard ratio, 1.5; P = .03) after adjusting for other risk factors, including age, menopausal status, history of benign breast biopsy, family history of breast cancer, and breast density.

Future Directions for Breast Cancer Risk Assessment Using Breast US

Internal echogenicity patterns of the fibroglandular tissue at breast US have the potential for breast cancer risk assessment. However, standardization of evaluation methods for this new imaging marker is important prior to clinical implementation. Further studies on quantification and deep learning models will enhance robust and reproducible assessment. In addition, prospective multicenter studies are needed to validate the association between the glandular tissue component and breast cancer risk. A prospective multinational cohort study to validate the association of sonographic glandular tissue component and breast cancer risk has been published (ClinicalTrials.gov registration no. NCT05460975).

Breast MRI

MRI Overview

Breast MRI is the most sensitive imaging modality for detection of breast cancer, including ductal carcinoma in situ and invasive cancers (76). Breast MRI can also be used to evaluate features of normal breast tissue that can inform breast cancer risk assessment. The amount of fibroglandular tissue assessed at MRI follows the same four categories as the BI-RADS 5th edition for mammographic density: almost entirely fat, scattered fibroglandular tissue, heterogeneous fibroglandular tissue, and extreme fibroglandular tissue (77). Normal fibroglandular tissue enhances after the administration of gadolinium-based contrast material and is known as BPE. BPE levels are qualitatively assessed as minimal, mild, moderate, or marked using the BI-RADS lexicon (Fig 10) or may be quantitively assessed using software. BPE is an independent risk factor for the development of breast cancer, separate from mammographic density (78).

Figure 10:

Qualitative background parenchymal enhancement (BPE) assessment according to the Breast Imaging Reporting and Data System lexicon. Axial, subtracted, postcontrast, maximum intensity projection breast MRI scans show (A) minimal, (B) mild, (C) moderate, and (D) marked BPE in four patients.

Biologic Underpinnings

The biologic underpinnings of BPE have not been fully elucidated. Evidence suggests that BPE is related to endogenous and exogenous hormone levels; BPE varies with the phase of the menstrual cycle (79,80) and menopausal status (81), and BPE is reduced in women taking aromatase inhibitors and selective estrogen receptor modulators (82,83). Therefore, BPE likely partially reflects the effect of hormonal stimulation on the glandular components of the breast, which itself is associated with a higher risk of breast cancer. It is theorized that a second additional component of BPE is likely to be proliferative tissue changes, such as atypia, which are also associated with a higher cancer risk (84). Whether the cause of BPE is hormonal or due to proliferative change could be determined on the basis of whether BPE decreases after the cessation of hormonal stimulation, such as after menopause or after risk-reducing salpingo-oophorectomy. In BRCA1 and BRCA2 variant carriers who underwent risk-reducing salpingo-oophorectomy (85,86), a lack of BPE suppression would suggest that the underlying cause of BPE is proliferative change, including atypia, rather than hormonal stimulation. However, as discussed hereafter, studies show conflicting results as to whether these patients remain at higher risk for breast cancer. Additionally, several studies have found similar odds ratios for BPE and risk in premenopausal and postmenopausal groups (87,88), suggesting that endogenous estrogen does not affect the levels of BPE that reflect risk. It is possible that BPE is due to different processes in premenopausal and postmenopausal women, and in those with high and average risk. The biologic underpinnings of BPE and the relationship of BPE-associated risk to menopausal status for women at both average and high risk for breast cancer requires additional study.

BPE and Breast Cancer Risk

The amount of fibroglandular tissue is reflected in mammographic density and is associated with breast cancer risk. BPE is independent of mammographic density and instead is associated with higher tissue microvascular density, expression of vascular endothelial growth factor (89), and higher metabolic activity (79,87), representing an independent measure of tissue at risk. Women with dense breasts but minimal BPE do not have elevated breast cancer risk (87), suggesting that BPE may be a more accurate predictor of risk than density alone.

The association between BPE and breast cancer risk was first described in a case-control study of women at high risk, finding that women with moderate or marked BPE had a 6.7 times higher odds ratio of developing cancer than women with minimal or mild BPE (78). Additional single-institution, case-control, retrospective cohort, and cross-sectional studies that used BPE in breast MRI for risk assessment have yielded similar findings with odds ratios ranging from 1.45 to 14.5 depending on the patient population and BPE threshold (Table 4).

Table 4:

Overview of Studies Using BPE in Breast MRI for Risk Assessment

Since these early studies, meta-analyses (90,91) have corroborated the findings regardless of study design, timing of BPE measurement, and method of BPE assessment. Thompson et al (90) evaluated 18 studies for a total of 1910 women with breast cancer and 2541 control participants. In women at high risk, they found that at least mild BPE was associated with breast cancer with a 2.1 odds ratio. This odds ratio was reproduced across multiple studies when those with unmatched controls were excluded.

This has been further supported by a recent study notable due to its large number of patients across multiple institutions and for its retrospective cohort design. Arasu et al (87) demonstrated a higher cancer risk with each higher level of BPE (hazard ratios: 1.8 for mild BPE, 2.42 for moderate BPE, and 3.41 for marked BPE). Additionally, they found BPE strongly predicted a future diagnosis of invasive breast cancer rather than ductal carcinoma in situ, supporting the use of BPE as a relevant imaging marker for breast cancer.

BPE in Women with Elevated Risk

Most of the studies yielding an association of BPE with breast cancer risk have been performed in a cross section of women at high risk as this is the population for whom screening MRI is indicated (79) (Fig 11). Studies of women with a personal history of breast cancer showed that in this group of women at high risk, BPE is associated with a higher risk of developing a second breast cancer or interval breast cancer (92,93). The significance of BPE as a risk factor in women with genetic alterations may be different than for other women at high risk. Studies have shown that BRCA1 and BRCA2 variant carriers have lower BPE and less fibroglandular tissue than age-matched controls (94). BPE has been shown to be reduced in BRCA1 and BRCA2 variant carriers after risk-reducing salpingo-oophorectomy, suggesting that the decreased BPE reflects the hormonal changes from risk-reducing salpingo-oophorectomy, which in turn decreases breast cancer risk (95). A higher BPE level prior to risk-reducing salpingo-oophorectomy has been associated with future breast cancer (85,96). However, the literature shows mixed results regarding a change in BPE after risk-reducing salpingo-oophorectomy. DeLeo et al (85) found that BRCA1 and BRCA2 variant carriers who did not have a reduction in BPE after risk-reducing salpingo-oophorectomy had a higher risk of subsequent breast cancer, while Bermot et al (96) conversely found that a greater reduction in BPE after risk-reducing salpingo-oophorectomy was associated with a higher risk of breast cancer. Findings of both groups suggest that BPE is a phenotypic imaging marker to identify BRCA1 and BRCA2 variant carriers who may be at risk for developing breast cancer despite risk-reducing salpingo-oophorectomy (85,96). However, whether the initial high BPE level or the change in BPE after risk-reducing salpingo-oophorectomy is the more contributory BPE measure predicting a higher risk of breast cancer remains to be confirmed.

Figure 11:

Images in a 46-year-old woman at high risk for breast cancer due to strong family history (calculated lifetime risk of 33%). Screening MRI demonstrated extreme fibroglandular tissue. (A) Axial, subtracted, postcontrast maximum intensity projection MRI scan shows moderate background parenchymal enhancement (BPE) and a mass in the left axillary tail (circle). (B) Postcontrast, T1-weighted subtracted axial MRI scan with the section centered at the level of the left breast mass shows the enhancing irregular mass (arrow) that was subsequently biopsied yielding moderately differentiated carcinoma with mixed ductal and lobular features.A higher BPE level has been associated with risk of breast cancer in women at high risk.

BPE in Women with Average Risk

The few studies evaluating women at average risk show mixed results. The meta-analysis by Thompson et al (90) showed no significant association between BPE and breast cancer in the population at average risk (Fig 12). A single-institution study of 540 women at average risk who received breast MRI for suspicious or equivocal findings at conventional imaging or clinical suspicion of cancer also showed no association between BPE and breast cancer risk (97). However, the multi-institution study by Arasu et al (87) showed that women at average lifetime risk (estimated by a 5-year Breast Cancer Surveillance Consortium risk score of <1.67%) with at least mild BPE had an elevated breast cancer risk (a 2.9 times hazard ratio) than those with minimal BPE. Paradoxically, this same study found that although higher BPE was associated with a higher risk of breast cancer in women with a history of a first-degree relative with breast cancer, this association did not hold in women without a family history. Thompson et al (90) have suggested that BPE may indicate a healthy breast tissue phenomenon in women at average risk, while breast tissue in high-risk patients is biologically different than normal breast tissue. Given the growing acceptance of abbreviated MRI to expand MRI screening for women at average and intermediate risk, the significance of BPE in these groups requires additional study.

Figure 12:

Images in a 34-year-old woman without family history of breast cancer with newly diagnosed left breast cancer manifesting as a palpable lump. MRI performed for extent of disease demonstrates heterogeneous fibroglandular tissue. (A) Axial, subtracted, postcontrast maximum intensity projection MRI scan shows minimal background parenchymal enhancement (BPE) and a mass in the left lateral breast (arrow). (B) Postcontrast, T1-weighted subtracted axial MRI scan with the section centered at the level of the left breast mass shows the enhancing irregular mass (arrow) that was subsequently biopsied yielding poorly differentiated invasive ductal carcinoma. Studies show mixed results regarding the association between BPE and breast cancer in patients at average risk (ie, without family history of breast cancer or known deleterious genetic alteration).

Future Directions in MRI

There is wide variability in the MRI sequences and quantitative methods used for BPE assessment (98). In addition, there is significant interest in providing supplemental screening to women at otherwise average risk but who have dense breasts by using abbreviated, or “fast,” breast MRI where only limited postcontrast imaging is performed to improve cost-effectiveness and maintain sensitivity of cancer detection (99–102). In the future, risk prediction models will likely incorporate BPE as a quantitative imaging marker to provide more refined individualized results (103). The change in BPE after risk-reducing interventions, such as bilateral salpingo-oophorectomy or tamoxifen use, may also be incorporated into models quantifying the degree of risk reduction to personalize a patient’s preventive strategy.

Development of generalizable risk prediction models will first require standardization of quantitative BPE. Deep learning models will likely become valuable tools in providing automated, accurate, and reproducible BPE assessments (104,105). Deep learning models may also be trained on contrast-enhanced MRI scans and incorporate all the information present in the image, beyond BPE information alone, to refine risk prediction (106).

BPE is also being studied as a prognostic and predictive imaging marker in women diagnosed with breast cancer because BPE has been associated with tumor type (107), response to neoadjuvant therapy (108), and recurrence-free survival (109).

Future Directions and Clinical Implementation

Beyond the use of mammographic density alone to identify women at high risk for breast cancer, the goal of the imaging markers described in this article is to develop personalized screening strategies for breast imaging. As of November 2022, there continue to be hurdles to widespread implementation of these imaging markers, such as image-based deep learning (49,50), despite promising results over traditional risk models. These hurdles include the need for validation and prospective trials across diverse populations and sites (110,111), as well as the need for standardization of risk assessment and reporting.

Conclusion

Herein, we describe a range of imaging markers associated with breast cancer risk, with the ultimate goal of enabling personalized screening strategies.
